Zhermack dune 2 User guide

Maintenance and use manual
XM0620000
Rev. 12/07
SANDBLASTING MACHINE
DUNE
Mod. DUNE 2Cod. C305613
Mod. DUNE 3Cod. C305614

UK Pag. 5

5 of 36
MAINTENANCE AND USE MANUAL
DUNE
GENERAL INDEX
CH. 1
INTRODUCTION
Pag. 7 1.1 How to read and use the manual
Pag. 8 1.2 Terminology and symbols
CH. 2
GENERAL INFORMATIONS
Pag. 9 2.1 Responsibility
Pag. 9 2.2 Warranty: general instruction
Pag. 10 2.3 Authorized personnel
Pag. 10 2.4 General safety regulations
CH. 3
DESCRIPTION OF THE EQUIPMENT
Pag. 12 3.1 General description of the equipment
Pag. 12 3.2 Table of the components
Pag. 13 3.2.1 Description of the components
Pag. 14 3.3 Identification data
CH. 4
TECHNICAL CHARACTERISTICS
Pag. 15 4.1 Technical characteristics and operating start
Pag. 15 4.2 Technical Data
Pag. 15 4.2.1 Standard accessories and accessories available on request
CH. 5
TRANSPORT AND MOUNTING
Pag. 16 5.1 Warnings
Pag. 16 5.2 Packing and unpacking
Pag. 17 5.3 Transport and mounting
Pag. 17 5.4 Elimination / Dismantling
CH. 6
INSTALLATION AND FIRST-TIME USE
Pag. 18 6.1 Warnings and precautions
Pag. 18 6.2 Permitted ambient conditions
Pag. 18 6.3 Required work space
Pag. 19 6.3.1 Worktops
Pag. 19 6.4 Connecting up to the power supply
Pag. 20 6.5 Starting up
Pag. 20 6.6 Purpose of the equipment / Improper and forbidden use

6 of 36
MAINTENANCE AND USE MANUAL
DUNE
CH. 9
TROUBLESHOOTING
Pag. 28 9.1 Warnings
Pag. 28 9.2 Problems, causes and remedies
APPENDICES
Pag. 30 A.1 EC declaration of conformity
Pag. 31 A.2 Warranty certificate and identification form
Pag. 32 A.3 Maintenance and repair worksheet
Pag. 33 A.4 Notes
The data given in this manual may be modified without prior notice.
CH. 8
MAINTENANCE
Pag. 25 8.1 Cleaning
Pag. 25 8.1.1 Cleaning the inside of the sandblasting equipment
Pag. 26 8.2 Changing the light bulb and/or reactor
Pag. 26 8.3 Routine maintenance
Pag. 27 8.4 Unscheduled maintenance
Pag. 27 8.5 Restarting after a long period of inactivity
Pag. 27 8.6 Requesting technical assistance
CH. 7
USING THE EQUIPMENT
Pag. 21 7.1 Warnings
Pag. 21 7.2 Safety system
Pag. 21 7.3 Using the DUNE
Pag. 23 7.3.1 Vent valve
Pag. 24 7.4 Residual risk

7 of 36
MAINTENANCE AND USE MANUAL
DUNE
CHAPTER 1: INTRODUCTION
This Use and Maintenance Manual provides information on the utilisation, installation and
maintenance of the DUNE sandblasting equipments, manufactured by Zhermack S.p.A.
• The sandblasting equipment must be used in accordance with the instructions in this manual:
it is therefore recommended that you read it carefully prior to installation and start-up. Make
sure that you read the entire manual and pay particular attention to messages written in bold
type or items highlighted by boxes and/or symbols: the symbols are designed to highlight
situations involving danger or requiring caution (see paragraph 1.2).
• Observance of standards and regulations shown in this manual will ensure that the equipment
is used properly and that maintenance work is carried out safely.
• This Use and Maintenance Manual is an integral part of the equipment: it should therefore be
kept together with the cleaner so that it can be consulted as and when necessary (keep the
booklet in a secure dry place away from sunlight, atmospheric agents, etc.). It must be available
for consultation throughout the working life of the equipment even when the equipment is sold
or finally dismantled.
• It is recommended that you keep this manual constantly updated by integrating any
amendments, additions or modifications made by the Manufacturer. Any notes or comments
should be made on the blank pages at the rear of the booklet (see Appendices: Notes).
• Use the manual properly so that it is not damaged in any way.
• Do not remove, tear or write on any part of the pages.
• If the manual is lost or damaged and its contents become illegible you can request a
replacement copy from the manufacturer.
The purpose of this Use and Maintenance Manual is to provide users with information on how
to operate the equipment properly. The manual contains all the information needed to use the
device as intended: in particular the manual includes instructions and information on the
following:
• correct installation of the DUNE;
• Detailed description of how the equipment works and its components;
• Initial start-up;
• Scheduled maintenance;
• Basic Safety and Accident Prevention info.
This manual contains nine chapters each of which covers a specific argument.
The appendices at the rear of the manual are a useful complement to these chapters.
1.1
HOW TO READ AND USE THE MANUAL

8 of 36
MAINTENANCE AND USE MANUAL
DUNE
1.2 TERMINOLOGY AND SYMBOLS
It is important that you understand the following symbols and their significance as they
highlight important information such as critical situations, practical advice, or straightforward
information.
If you have any doubts as to the significance of a symbol always consult this page.
• Critical situations concerning dangerous areas or tasks in which failure to observe the
instructions may render the warranty null and void, or cause damage to equipment, connected
components or the surrounding area, are highlighted by the symbol:
DANGER!
This symbol refers to safety standards which must be observed at all times in order to
protect both workers and equipment.
WARNING!
This symbol refers to safety standards which must be observed carefully in order to
guarantee your safety, other people's safety and prevent damage to the equipment.
• Tasks for which failure to observe instructions or tampering with equipment parts may put
personnel in serious danger are highlighted by the symbol:
• Any work that fails to comply with instructions in this manual, or any tampering which might
automatically render the warranty null and void, is highlighted by the following symbol:
FORBIDDEN!
This symbol refers to actions which must never be carried out (i.e. forbidden
actions).
• Any general information and/or advice which may be useful at any time is highlighted by the
following symbol:
NOTE!
This symbol highlights information and/or useful advice.

9 of 36
MAINTENANCE AND USE MANUAL
DUNE
2.1
RESPONSABILITY
CHAPTER 2: GENERAL INFORMATIONS
Failure to observe the instructions in this Use and Maintenance Manual exonerates the
Manufacturer from any liability whatsoever.
For any matters not covered by this manual or about which you have any doubts please contact
the Manufacturer directly:
Zhermack S.p.A.
Via Bovazecchino, 100
45021 Badia Polesine • RO • Italy
Tel. [phone] • Fax [phone]
http://www.zhermack.com e-mail: [email protected]
If equipment maintenance work fails to comply with instructions or is done in such a way as to
compromise equipment integrity or modify its characteristics Zhermack S.p.A. cannot in any
way be held liable for any liability as regards worker safety and/or equipment performance.
2.2
WARRANTY: GENERAL INSTRUCTION
Included in the Appendices to this Use and Maintenance Manual you will find the Warranty
certificate and the ID Form which must be filled out in full.
In general the Warranty is rendered null and void by the following:
• Improper equipment use.
• Incorrect installation.
• Serious negligence of maintenance schedules.
• Modifications to or work on the equipment which has not been authorised by the Manufacturer
(especially on safety devices).
• Use of non-original spare parts.
Zhermack S.p.A. cannot, as of this moment, be held liable if the equipment is
modified or tampered with without prior written consent from the Manufacturer.
Consequently, any repairs made by unauthorised personnel, use of non- original
spare parts or failure to comply with the installation standards specified in this
manual shall immediately render the Warranty null and void.

10 of 36
MAINTENANCE AND USE MANUAL
DUNE
Before using this equipment or carrying out any work on it, the operator must
read the entire contents of this manual. This manual has been drawn up to
provide the user with essential information on rational, safe utilisation of the
equipment. The user must comply with the information given at all times.
Furthermore, the user must use the work sheets enclosed with this manual so
as to keep a record of maintenance/component replacement work as well as
make notes on any equipment malfunctions.
The operator-user must only use the equipment when it is fully assembled and
the safety devices are working properly as described in this manual.
2.4 GENERAL SAFETY REGULATIONS
The operator must read the advice and warnings given below and comply with such regulations
at all times: doing so will ensure safe, long-lasting equipment performance:
• Do not allow untrained personnel to use this equipment.
• Ensure that the work area is properly prepared: it must be free from obstacles, clean and
properly illuminated.
• Take measures to ensure that you are not distracted when using the equipment.
• In the event of a malfunction follow the advice given in this manual: if you have any doubts
shut down the equipment and contact your Authorised Service Centre immediately.
• Never use a malfunctioning equipment and always inform the Maintenance Manager of any
faults.
• Do not open compartments containing electrical parts.
• Do not replace the power lead or tamper with the supplied plug.
• To replace a damaged or worn foot control unit lead and/or the pedal switch itself contact an
Authorised Servicing Centre only.
• It is forbidden to use the equipment on items other than those for which it has been specifically
designed.
• Before doing any cleaning, routine and/or unscheduled maintenance work make sure that the
equipment has been unplugged from the mains socket.
• Make sure that there are no foreign objects inside the work area as these could damage the
equipment and/or injure personnel.
• Do not use petrol or flammable solvents as detergents; use only non-flammable, non-corrosive,
and non-toxic substances (see paragraph 8.1).
• Do not used compressed air to clean small pieces; if you do so you should protect your eyes
with goggles that provide lateral protection and limit air pressure to a maximum of 2 bar.
2.3 AUTHORIZED PERSONNEL

11 of 36
MAINTENANCE AND USE MANUAL
DUNE
This equipment has electrical parts: therefore, in the event of a fire, no matter
how small, use only powder-type extinguishers. Never attempt to put out an
electrical fire with water.
Zhermack S.p.A. cannot be held liable for any damage to persons or objects
caused by incorrect maintenance carried out by unqualified personnel or main-
tenance work that does not comply with the instructions in this manual.
Zhermack S.p.A. is, as of this moment, exonerated from any liability concerning
injury to persons or damage to objects that may result from using this equipment
in a way other than that described in this manual.

12 of 36
MAINTENANCE AND USE MANUAL
DUNE
3.1 GENERAL DESCRIPTION OF THE EQUIPMENT
The equipment described in this manual is the DUNE sandblasting equipment designed to
sandblast odontotechny products.
CHAPTER 3: DESCRIPTION OF THE EQUIPMENT
3.2 TABLE OF THE COMPONENTS - DUNE Mod.3
24
23
25
27
22
30
29
20
21
31
26
35
34
32
33
36
39
37
40
38
28
2
4
6
8
10
7
15
17
14
13
12
16
19
18
3
1
5
9
11

13 of 36
MAINTENANCE AND USE MANUAL
DUNE
1. Central cylinder lid (2)
2. Left cylinder vent valve (1)
3. Left cylinder lid (1)
4. Left cylinder (1)
5. Pressure reducer (1)
6. Pressure gauge (1)
7. Lamp unit rotation left-hand knob
8. Left aspirator connection tube
9. Fuse
10. Frame
11. Plug
12. Pressure reducer (2) - optional for DUNE Mod. 2
13. Pressure gauge (2) - optional for DUNE Mod. 2
14. Glass seal
15. Glass door
16. Handpiece body
17. Tungsten carbide nozzle
18. Right hand-passage ring
19. Right hand-passage
20. Right cylinder vent valve (3)
21. Right cylinder lid (3)
22. Right cylinder (3)
23. Pressure reducer (3)
24. Main switch
25. Pressure gauge (3)
26. Lamp unit
27. Handpiece holder support
28. Switch (4-way)
29. Left hand-passage ring
30. Left hand-passage
31. Foot control
32. Central cylinder vent valve (2)
33. Central cylinder (2) - optional for DUNE Mod. 2
34. Lamp unit rotation right-hand knob
35. Modular filter
36. Aspirator connection tube (right)
37. Embedded socket
38. Air inlet pipe (supplied)
39. Right grating
40. Left grating
3.2.1
Description of the components

14 of 36
MAINTENANCE AND USE MANUAL
DUNE
The equipment described in this manual has an ID platelet giving information about both the
equipment and the manufacturer:
C305613 - DUNE 2
Matr. 20000000
230 Vac 50/60 Hz 50W
A
B
C
D
Zhermack S.p.A.
BADIA POLESINE - ITALY
The equipments are built in compliance with the EC directives listed in the enclosed "EC
declaration of conformity". When requesting spare parts, information or assistance from the
Zhermack S.p.A. or your Authorised Servicing Centre always quote the data on the ID plate.
Should the ID plate deteriorate and become illegible, even partially, order a replacement plate
from the manufacturer Zhermack S.p.A.: remember to quote the relevant data.
A. Name and address of manufacturer
B. Equipment code and model
C. Serial number
D. Power supply information
Do not remove and/or damage the plate as you must be able to read the data
at all times.
3.3 IDENTIFICATION DATA

15 of 36
MAINTENANCE AND USE MANUAL
DUNE
The DUNE has been designed to sandblast items used in the odontotechnics field. The DUNE
unit is available as the DUNE Mod.2 (two nozzles) and the DUNE Mod.3 (three nozzles). The
constant-pressure tungsten carbide nozzles are available in various sizes so that the
technician/operator can set up a sandblaster that meets his requirements perfectly.
The following items are supplied as standard:
• n.2 nozzles ø 0.8 mm fitted on handpieces for DUNE Mod. 2
• n.3 nozzles ø 0.8 mm fitted on handpieces for DUNE Mod. 3.
The tank cylinders feature an efficient constant vibration system, specially designed to keep the
sand on the move at all times; this prevents the formation of lumps which might obstruct the
nozzles. Furthermore, a new air pumping system inside the cylinders themselves ensures that
all the sand exits the cylinders, thus eliminating the problem of continuous top-ups and breaking
up any lumps of sand that have been caused by damp.
Because there is a not just one cylinder but a set of them the equipment features a switch for
fast sandblasting change-overs: This makes work easier when different types of sand need to
be used.
DUNE Mod. 2 is built so that an optional third cylinder unit with pressure reducer, gauge and
handpiece body can be added if desired.
CHAPTER 4: TECHNICAL CHARACTERISTICS
4.1
TECHNICAL CHARACTERISTICS AND OPERATING START
4.2
TECHNICAL DATA
In addition to this Use and Maintenance Manual the DUNE comes complete with:
4.2.1
Standard accessories and accessories available on request
Technical data concerning the DUNE:
• Power supply V. 250/50-60 Hz single-phase
• Absorbed power 50 Watt max
• Sands from 25 µm to 250 µm
• Standard nozzle size 0,8 mm
• Internal neon light consumption 9 Watt
• Working pressure from 0,5 bar to 6 bar
• Dimensions (H x L x P) 41 cm x 48 cm x 62 cm
• Weight 35 Kg for Mod.2 / 44kg for Mod.3
• Tank capacity 500 cc
Nozzle ø 0,8 mm for sands from 60 µm to 110 µm (standard) XH9900110
Nozzle ø 1,3 mm for sands from 110 µm to 250 µm (accessory) XH9900120
Nozzle ø 0,5 mm for sands from 25 µm to 60 µm (accessory) XH9900100
Neon light XE1100040
Supplied kit XB0060670
Complete cylinder unit** XB0060650
Co m p o n e n t s or d e r Co d e *
* Please quote the order code when ordering a spare part. You may order parts from your local Authorised Servicing Centre.
** Complete unit with tank, lid, pressure reducer, gauge and handpiece unit.

16 of 36
MAINTENANCE AND USE MANUAL
DUNE
It is recommended that you keep the original packaging so that, if necessa-
ry, it can be re-utilised; doing so ensures that you do not use unsuitable
packaging materials during transport and mounting which might lead to
accidental damage (see section 5.3).
5.1 WARNINGS
5.2 PACKING AND UNPACKING
All the material is thoroughly checked by the Manufacturer prior to shipment. When you
receive the goods make sure they have not been damaged during transit and that no-one has
tampered with the packaging and removed any of the parts contained therein.
Should there be any damage or missing parts you must inform the Zhermack S.p.A. Equipment
Assistance Service or the Dealer where the equipment was purchased immediately. The Carrier
must also be informed. Photographic evidence of such damage/missing parts must be provided.
The packaging, consisting of a cardboard box with internal expanded plastic padding, contains:
• the sandblasting equipment;
• the accessories (see section 4.2.1);
• this Use and Maintenance Manual.
CHAPTER 5: TRANSPORT AND MOUNTING
To prevent any injury to persons or damage to things always proceed with the
utmost care and attention when mounting the equipment. Observe all the
precautions and instructions contained in the following paragraphs.

17 of 36
MAINTENANCE AND USE MANUAL
DUNE
Should it be necessary to move the sandblasting equipment proceed as follows:
1. Disconnect the equipment from the electrical power supply.
2. After cleaning the sandblaster thoroughly (see Chap. 8), disconnect the compressed air
tube; then disconnect the aspirator coupling.
3. Gather all its accessories together.
4. Hold the bottom of the equipment, making sure that it is always kept vertical.
Proceed cautiously, bearing in mind the size and weight of the unit (see section 4.2), so as to
prevent any accidents that might be caused by failure to evaluate such factors.
5. Pack the equipment in its original box or, if this is not possible, take all the necessary
precautions to protect the equipment against knocks or drops, in that the goods are transported
at the owner's risk.
5.3
TRANSPORT AND MOUNTING
Failure to observe the above exonerates the Manufacturer from any liability
concerning equipment malfunction and consequently renders the Warranty
null and void.
When shipping/delivering the equipment to your Authorised Servicing
Centre always enclose a copy of the purchase document and a copy of the
properly compiled ID form.
If the unit is to be transported by courier, the postal service or rail it is
recommended such shipments be insured.
5.4
ELIMINATION / DISMANTLING
When disposing of the packaging materials the user must comply with the standards in force
in his/her country regarding the following materials:
• Wood/paper: non-polluting materials, but must be recycled properly.
• Polystyrene/plastic: pollutants which must not be burnt (toxic fumes) nor dispersed into the
environment, but disposed of in compliance with the standards in force in the country of use.
If the equipment is to be dismantled the user must, in compliance with EC directives and the
laws in force in the country of use, effect elimination and recycling of the following materials:
• Plastic and glass parts, insulated electrical wiring, rubber parts.
• There are no toxic or corrosive parts.
This product must not be disposed of as household waste but rather, when
no longer used, must be collected separately according to EC Directive
2002/96.

18 of 36
MAINTENANCE AND USE MANUAL
DUNE
6.1 WARNINGS AND PRECAUTIONS
CHAPTER 6: INSTALLATION AND FIRST-TIME USE
So as to provide greater clarity the numbers given in the diagrams in this
chapter correspond exactly to the numbering in the Components Table
(Ch. 3).
Work area lighting is an important factor in both personnel safety and the
ultimate quality of the work being done. In Italy lighting must comply with a
Ministerial Decree Law that clearly defines minimum lighting requirements.
In other countries lighting requirements form part of the accident prevention
and workplace hygiene standards.
Before proceeding with installation make sure that all relevant safety conditions prevail and
follow the instructions below carefully.
6.3 REQUIRED WORK SPACE
Choosing a good workplace with an appropriate amount of space available for equipment
installation is an essential factor in personnel safety, the quality of the work and proper
maintenance. This zone must not only be spacious enough to allow for optimum equipment
operation but must also be well illuminated, aired, not dusty and not exposed to direct sun-
light.
6.2 PERMITTED AMBIENT CONDITIONS
Unless stated otherwise at the time of order the equipment will be configured to operate properly
under the following ambient conditions:
Ambient conditions other than those listed above may cause malfunctions or sudden
breakdowns. Lighting in the installation area must be sufficient to provide good visibility at every
single point on the equipment.
More specifically, luminosity must not be less than 200 lux, lighting must be as uniform as
possible and there must be no reflected light as this could dazzle the operator.
Min ambient temperature 0°C
Max ambient temperature 40°C
Max humidity 90%
The equipment must not be used in workplaces having an atmosphere which is
explosive and/or at risk of fire as it has not been designed for use in such areas.
Nevertheless, should a fire accidentally break out follow the procedure described
in paragraph 2.4.

19 of 36
MAINTENANCE AND USE MANUAL
DUNE
6.3.1
Worktops
The sandblasting DUNE equipment
has been designed for use on a rigid worktop
parallel to the floor.
Suitable worktops include service furniture
(where the operator is standing) or modelling
tables (where work is done sitting down).
All worktops must be checked for stability.
6.4
CONNECTING UP TO THE POWER SUPPLY
The user must provide a power connection with relative socket near the equipment installation
point. The user must also install an adequate electrical circuit breaker upstream from the socket
as well as efficacious overload/indirect contact safety devices.
Connection is effected via the safety plug (16A, in compliance with European standards) at the
end of the power lead: this must be inserted in the mains socket.
When connecting check:
• that mains voltage and frequency are as indicated on the identification plate (incorrect power
supply voltage may damage the equipment).
• that the mains supply has a proper, efficient earth connection.
It is forbidden to tamper with the power lead and its plug. When replacing them
owing to damage and/or wear please contact an Authorised Service Centre.
A proper earth connection is compulsory. Should it temporarily be
necessary to use an extension lead the latter must comply with the
standards in force in the country of use.

20 of 36
MAINTENANCE AND USE MANUAL
DUNE
6.5 STARTING UP
Figure 1
Fig. 1 : Set the equipment down on the flat surface
of a work bench.
Now follow the instructions given in section 6.3.1.
35
38
Figure 2
Fig. 2 : Connect up the air connection pipe (38) to
the compressed air line and connect it with the air
intake fitting on the modular filter block (35) on the
left-hand side of the equipment.
Failure to observe any of the above equipment installation instructions may lead
to malfunctions and render the warranty null and void.
6.6 PURPOSE OF THE EQUIPMENT / IMPROPER USE AND FORBIDDEN USE
The DUNE units have been designed and built for the sandblasting of odontotechny pro-
ducts.
The main reasons for which the Warranty may be rendered null and void are given in section
2.2 and in the "Warranty Certificate" enclosed with this Manual.
Using the equipment for any purpose other than that described in this Manual
shall be considered improper and thus forbidden.
Improper use renders the Warranty null and void and the Zhermack S.p.A. shall
not be liable for any damages to objects, workers or third parties.
Connect the lead (11) to the mains
power socket: follow the instructions in
section 6.4 carefully.
11
