ZIGBEE BEKER User manual

ZigBee Wireless Dimmer Switch
09.ZGK2D.04837
55.57 mm
71.20 mm
11 mm
Function introduction
Important: Read All Instructions Prior to Installation
Front side
Back side
Battery: CR2430
Before the first use, please remove the protective film
Product Data
55.57 mm
71.20 mm
The remote control can be fixed on
the wall with 3M glue or screw.
Press and hold down both keys together to search and pair
to ZigBee network or factory reset the dimmer switch.
Click to turn on the paired
lighting devices, press
and hold down to increase
light intensity
Note: This switch
supports 48 binding
tables and 2 groups for
binding lighting devices.
Click to turn off the paired
lighting devices, Press
and hold down to
decrease light intensity
Protocol
Operation Voltage
Transmission Frequency
Transmission Range (free field)
Protection Type
Dimming Range
Dimensions
ZigBee 3.0
3VDC (CR2430)
2.4GHz
30m
IP20
0.1%-100%
71.2x71.2x13.6mm
• This device contains a button lithium battery that shall be stored and disposed properly.
• DO NOT expose the device to moisture.
Safety & Warnings
Operation
1.This ZigBee dimmer switch is a wireless transmitter that communicates with a variety of ZigBee
compatible systems. This transmitter sends wireless radio signals that are used to remotely control a
compatible system.
2.This ZigBee dimmer switch supports 1 group for binding lighting devices and enables to control
single color ZigBee lighting devices.
3.Pair to ZigBee Lighting Device Via TouchLink without Coordinator (Hub or Controller)
1)Initiate TouchLink Commissioning of ZigBee lighting device, please consult its manual to learn how.
2)Bring the switch within 10cm of the ZigBee lighting device.
3)Press and hold down both and keys until the LED indicator on the switch turns on.
4)Click button twice continuously to start TouchLink commissioning procedure of the switch.
5)The LED indicator will first flash 6 times fast to indicate linking successfully and 4s later it will flash 4 times
slowly to indicate successful binding to the device.
Note: Each lighting device can only pair to one switch via touchlink, and can not pair to different
switches simultaneously. If TouchLink fails, please factory reset the lighting device and initiate
TouchLink Commissioning again.
4.ZigBee Network Pairing Via ZigBee Coordinator (Hub or Controller Interface)
1)Please make sure the switch does not belong to any ZigBee network before pairing, click any key if the
•
•
•
•
•
•
•
•
•
ZigBee dimmer switch based on ZigBee 3.0
Enables to pair ZigBee lighting devices via touchlink commissioning without coordinator
Supports find and bind mode to pair with ZigBee lighting devices in the same network
Supports 1 group for binding lighting devices
2.4 GHz global operation
Long battery life mesh technology
Transmission range up to 30m
Compatible with universal ZigBee Gateway products
Compatible with universal single color ZigBee lighting devices

Mounting
The key part of this controller is an universal one, especially rotary standard switch element that can be
integrated in numerous frames by different manufactures as below list:
BEKER S1, B1, B3, B7 glass
GIRA Standard55, E2, Event, Esprit
JUNG A500, Aplus
MERTEN M-smart, M-Arc, M-Plan
indicator turns on, which means the switch has already paired to a network. Please remove it from the network
first, otherwise the pairing will fail.
2)Press and hold down both and keys until the LED status indicator turns on, then immediately click
button to enable the switch to search nearby network, LED indicator will flash every 1 second. 20 seconds
timeout if there is no network, the indicator will turn off, repeat the operation.
3)From your ZigBee Controller or hub interface, choose to add device and enter Locating/Pairing mode as
instructed by the controller.
4)Network Pairing Begins Automatically: LED indicator on the switch blinks 6 times quickly as it scans for a
compatible network controller to pair with.
5)After the remote is located and paired to the ZigBee network, the indicator will stop blinking and turn off, then
the remote will appear in your controller's menu.
6)The switch is now paired to the ZigBee network.
5.Battery Power Monitor Function, the switch will report battery power value to the coordinator under
following situations:
When powered on.
When user clicks both and keys simultaneously.
When user operates the switch to send data packets (over 4 hours since last operation).
When added to the network by a coordinator.
6.Pair with A ZigBee Lighting Device Via Find and Bind Mode without Coordinator
1)Start find and bind mode on the ZigBee lighting device (initiator node) and enable it to find and bind target,
please consult its manual to learn how.
2)Press and hold down both and keys on the switch until the LED indicator turns on.
3)Click button to enable the switch (target node) to find and bind initiator.
4)The binding will be successful within 4 seconds, and LED indicator on the switch will flash 4 times. If binding
fails, LED indicator will flash twice.
7.Unpair with A ZigBee Lighting Device Via Find and Bind Mode without Coordinator
1) Start find and bind mode on the ZigBee lighting device (initiator node) and enable it to find and unbind
target, please consult its manual to learn how.
2)Press and hold down both and keys on the switch until the LED indicator turns on.
3)Click button twice continuously to enable the switch (target node) to find and unbind initiator.
4)The unbinding will be successful within 4 seconds, and LED indicator on the switch will flash 4 times. If
unbinding fails, LED indicator will flash twice.
8.Unpair with All ZigBee Lighting Devices Bind with The Switch without Coordinator
1)Press and hold down both and keys on the switch until the LED indicator turns on.
2)Click button five times continuously to clear all bind lighting devices with this remote.
3)LED indicator on the switch will flash 4 times to indicate successful unbinding of all devices.
9.Binding Between the Switch and ZigBee Lighting Devices Via Coordinator (Hub or Controller
Interface)
1)Once the switch and compatible ZigBee lighting devices are paired to the same network, click any button to
activate the switch, then from your ZigBee controller or hub interface, choose to bind devices to the remote as
instructed by the controller. Then the devices can be controlled by the remote.
2)Once the binding operation is done between the remote and ZigBee lighting devices, the remote can still
control the devices in the event of gateway/coordinator loss.
Note: This switch supports 48 binding tables and 1 group for binding lighting devices.
10.Unbinding Between the Remote and ZigBee Lighting Devices
To unbind the remote and ZigBee lighting devices, first click any button to activate the switch, then from your
ZigBee controller or hub interface, choose to unbind the device from a remote as instructed by the controller.
•
•
•
•
11.Factory Reset the Switch (Remove From ZigBee Network)
From the ZigBee Controller or Hub Interface
1)From your ZigBee controller or hub interface, choose to remove or reset the remote as instructed. The LED
indicator on the remote will turn on and flash 3 times quickly to indicate successful reset to factory default
setting.
Manual
2)Press and hold down both and keys until the LED indicator on the switch turns on -> immediately click
button 5 times continuously -> LED indicator flashes 3 times quickly to indicate successful removal from the
network and reset to factory default.
Note: All configuration parameters will be reset after the remote is removed from the network.
12.ZigBee Clusters Supported by This Remote Are As Follows:
Input clusters:
Basic
Power Configuration
Identify
Diagnostics
Output clusters:
Identify
On/off
Level control
Ota
