ZIGBEE PSR05 User manual

Zigbee Remote PSR05
The Remote PSR05 is a simple control can controls 8 groups scene,
based on Zigbee technology.
It is the Zigbee product, it support the security, OT ... Those newest
features of the Zigbee technology. Zigbee is a wireless communication
protocol designed for home automation, specifically to remotely control
applications in residential and light commercial environments. The
technology uses a low-power RF radio embedded or retrofitted into
home electronics devices and systems, such as lighting, home access
control, entertainment systems and household appliances.
CAUTION
– replacement of a battery with an incorrect type that can defeat a
safeguard (for example, in the case of some lithium battery types);
– disposal of a battery into fire or a hot oven, or mechanically crushing
or cutting of a battery, that can result in an explosion;
– leaving a battery in an extremely high temperature surrounding
environment that can result in an explosion or the leakage of flammable
liquid or gas;
– a battery subjected to extremely low air pressure that may result in an
explosion or the leakage of flammable liquid or gas
he marking information is located at the bottom of the apparatus.
Specification
Rated DC3.7V Lithium rechargeable
battery
Charger Voltage 5Vdc from Micro USB
RF distance Min. 40M indoor,
100M outdoor line of sight,
Frequency Range 2405MHz~2480MHz
RF Maximum Power +5dBm
Location Indoor use only
Operation temperature -10 to 45° C
Humidity 95% RH max
Dimension 110(L) x 110(W) x 19(H) mm
Specifications are subject to change an
improvement without notice.

Troubleshooting
Symptom Cause of Failure Recommendation
The device can not
join to Zigbee
network
The device may in a
Zigbee network.
Reset the device
then include again.
For Instruction to http:// www.philio-tech.com
Overview

A ing to Z-WaveTM Network
There are two tamper keys in the device, one is in the back side,
another is in the front side. They have the same function. Both of them
can joining network, reset from Zigbee network.
In the first time, add the device into the Zigbee network. First, make
sure the primary controller is in the inclusion mode. nd then power on
the device, just take out the insulation Mylar in the back side of the
device. The device will auto start the try joining network mode. nd it
should be included in 120 seconds. You will see the LED light ON one
second.
* Joining network:
1. Have Zigbee Controller entered inclusion mode.
2. Hold down the central key, then press the top-right key three
times within 1.5 seconds to enter the add mode.
* Reset to efault:
1. Hold down the central key, then press the top-right key four
times within 1.5 seconds and do not release the top-right key in
the 4th pressed, and the LED will light ON.
2. fter 3 seconds the LED will turn OFF, after that within 2
seconds, release the keys. If successful, the LED will light ON one
second. Otherwise, the LED will flash once.
3. IDs are remove and all settings will reset to factory default.
Zigbee IAS-ZONE
While the device is associated with a Zigbee network:
•The PSR05 will try to find the CIE and ZCL L RM client.
•When press the button the device will send scene function
number. PSR05 will snd “ZCL larm command” to larm and CIE
client.
Function Control
PSR05 has five keys on the device. The central one has group-button
switching and special function, the others are control keys.
There are two group-buttons that can be switched by pressing central
key. When the device is switched to group-button 1, LED will light on
with red color for 3 seconds. When the device is switched to group-
button 2, LED will light on with green color.
* Scene Control
The device is in group-button 1, When press the button the LED will
light the red color. The device is in group-button 2, When press the
button the LED will light the green color.
Scene Control
Group-Button 1
Key: Top-left
Command: 0x01
Key: Top-right
Command: 0x02
Key: Bottom-left
Command: 0x03
Key: Bottom-right
Command: 0x04
Group-Button 2

Key: Top-left
Command: 0x05
Key: Top-right
Command: 0x06
Key: Bottom-left
Command: 0x07
Key: Bottom-right
Command: 0x08
Zigbee Message Report
* Low Battery Report:
When the battery level is too low, than press the button, the device will
report the trigger event and also report the battery status.
larm (Cluster ID : 0x0009)
larmCluster : 0x0001
larmCode : 0x01
Activate the power
The device can not work normally in the first time. Please activate the
battery through micro USB before the first use. fter the device is
activated by connecting to micro USB, the device will start charging and
LED will light on with red color. If the battery is full charged, LED will
light on with green color.
When device is charging, it will send Wake Up Notification to controller
minutely.
* Battery Power Check
When any keys around the central key is pressed, the device will check
the battery power. If the power level is too low, the red LED will flash
once after pressing. Please charge the device through micro USB
immediately.
* Network State Check
When the power on, the device will check the network state. If the
device join network , the LED will steady off. If doesn't, The LED will
flash in every second and continue 30 seconds.
* Try joining network
When the power on, the device will check is it already adding to the
network? If doesn't, it will auto start the joining network mode. Until
timeout or the device joined network.
Over The Air (OTA) Firmware Up ate
The device support the Zigbee firmware update via OT .
Before starting the procedure, please remove the front cover of the
device. Otherwise the hardware check will be failed.
The Device will find the OT server in the network. The OT server will
provide the necessary information to device. The device will decide if
the OT is necessary.

Disposal
This marking indicates that this product should not be
disposed with other household wastes throughout the EU.
To prevent possible harm to the environment or human
health from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of material
resources. To return your used device, please use the
return and collection systems or contact the retailer where
the product was purchased. They can take this product for
environmental safe recycling.
Company of License Holder：Philio Technology Corporation
ddress of License Holder：8F., No.653-2, Zhongzheng Rd., Xinzhuang
Dist., New Taipei City 24257, Taiwan(R.O.C)
www.philio-tech.com
FCC Interference Statement
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one of
the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for
help.
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
FCC Caution: ny changes or modifications not expressly approved by
the party responsible for compliance could void the user's authority to
operate this equipment.
This transmitter must not be co-located or operating in conjunction
with any other antenna or transmitter.
Warning
Do not dispose of electrical appliances as unsorted municipal waste,
use separate collection facilities. Contact your local government for
information regarding the collection systems available. If electrical
appliances are disposed of in landfills or dumps, hazardous substances
can leak into the groundwater and get into the food chain, damaging
your health and well-being.
When replacing old appliances with new once, the retailer is legally
obligated to take back your old appliance for disposal at least for free
of charge.
警語:

「取得審驗證明之低功率射頻器材，非經核准，公司、商號或使 者均不得擅自變更頻
率、加大功率或變更原設計之特性及功能。
低功率射頻器材之使 不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立
即停 ，並改善至無干擾時方得繼續使 。
前述合法通信，指依電信管理法規定作業之無線電通信。低功率射頻器材須忍受合法通
信或工業、科學及醫療 電波輻射性電機設備之干擾。」
