Z8 Encore! XP®F08xA Series
Development Kit
User Manual
UM018603-1005
Z8F08A28100KIT

Z8 Encore! XP®F08xA Series Development Kit
User Manual
UM018603-1005
This publication is subject to replacement by a later edition. To determine whether a later
edition exists, or to request copies of publications, contact:
ZiLOG Worldwide Headquarters
532 Race Street
San Jose, CA 95126
Telephone: [phone]
Fax: [phone]
www.ZiLOG.com
Document Disclaimer
ZiLOG is a registered trademark of ZiLOG Inc. in the United States and in other countries. All other products
and/or service names mentioned herein may be trademarks of the companies with which they are associated.
©2005 by ZiLOG, Inc. All rights reserved. Information in this publication concerning the devices,
applications, or technology described is intended to suggest possible uses and may be superseded. ZiLOG,
INC. DOES NOT ASSUME LIABILITY FOR OR PROVIDE A REPRESENTATION OF ACCURACY OF
THE INFORMATION, DEVICES, OR TECHNOLOGY DESCRIBED IN THIS DOCUMENT. ZiLOG
ALSO DOES NOT ASSUME LIABILITY FOR INTELLECTUAL PROPERTY INFRINGEMENT
RELATED IN ANY MANNER TO USE OF INFORMATION, DEVICES, OR TECHNOLOGY
DESCRIBED HEREIN OR OTHERWISE. Devices sold by ZiLOG, Inc. are covered by warranty and
limitation of liability provisions appearing in the ZiLOG, Inc. Terms and Conditions of Sale. ZiLOG, Inc.
makes no warranty of merchantability or fitness for any purpose Except with the express written approval of
ZiLOG, use of information, devices, or technology as critical components of life support systems is not
authorized. No licenses are conveyed, implicitly or otherwise, by this document under any intellectual
property rights.

Z8 Encore! XP®F08xA Series Development Kit
User Manual
UM018603-1005 Revision History
iii
Revision History
Each instance in Table 1 reflects a change to this document from its previ-
ous revision. To see more detail, click the appropriate link in the table.
Table 1. Revision History of this Document
Date Revision Level Section Description Page #
Feb.
2005 2 Introduction Corrected typo in development kit name. 1
October
2005 3 F08xA Series Development
Boar
Corrected typo in the MCU features list;
updated schematic for board rev C. 8, 13

Z8 Encore! XP®F08xA Series Development Kit
User Manual
Safeguards PRELIMINARY UM018603-1005
iv
Safeguards
The following precautions must be observed when working with the
devices described in this document.
Always use a grounding strap to prevent damage resulting from
electrostatic discharge (ESD).
Caution:

Z8 Encore! XP®F08xA Series Development Kit
User Manual
UM018603-1005 Table of Contents
v
Table of Contents
Revision History. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
Safeguards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .v
List of Figures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .v
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Kit Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Software (on CD-ROM) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
System/Software Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Supported Host System Configuration . . . . . . . . . . . . . . . . . . . . . . . . . .3
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
F08xA Series
Development Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
MCU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
UART with IrDA Endec . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Power and Communication Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
External Interface Headers JP1 and JP2 . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Schematic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Z8 Encore! XP®F08xA Series Development Kit
User Manual
Table of Contents UM018603-1005
vi

Z8 Encore! XP®F08xA Series Development Kit
User Manual
UM018603-1005 List of Figures
v
List of Figures
Figure 1. Z8 Encore! XP® F08xA Series Development Kit Contents .2
Figure 2. Z8 Encore! XP® F08xA Series Development Board . . . . .7

Z8 Encore! XP®F08xA Series Development Kit
User Manual
List of Figures UM018603-1005
vi

Z8 Encore! XP®F08xA Series Development Kit
User Manual
UM018603-1005 Introduction
1
Introduction
The Z8 Encore! XP®F08xA Series MCU is part of the line of ZiLOG
microcontroller products.
The Z8 Encore! XP®F08xA Series MCU Development Kit
(Z8F08A28100KIT) enables users to become familiar with the hardware
and software tools available with this product. This kit consists of the
8KB version of the Z8 Encore! Development board that supports and pre-
sents the features of the Z8 Encore! XP F08xA Series. This kit allows
users to begin writing application software and contains all supporting
documents.
This manual acquaints users with the Z8 Encore! XP F08xA Series MCU
Development Kit, and gives instructions on setting up and using the tools
to start building designs and applications.
Kit Contents
The Z8 Encore! XP F08xA Series MCU Development Kit contains the
following:
Hardware
• Z8 Encore! XP F08xA Series Development board
• Serial Smart Cable for PC to Z8 Encore! XP F08xA Series Develop-
ment board (DB9 to six-pin male)
• 5VDC power supply

Z8 Encore! XP®F08xA Series Development Kit
User Manual
Introduction UM018603-1005
2
Figure 1. Z8 Encore! XP®F08xA Series Development Kit Contents
Software (on CD-ROM)
• ZDS II- Z8 Encore!®IDE with ANSI C-Compiler
• Sample code
• Document browser
• Acrobat Reader install program
Documentation
• Quick Start Guide
• Registration card
• Z8 Encore! XP F08xA Series technical documentation (on CD-ROM)
Development
Board
Packaging
CD-ROM Containing
Documentation
Power
Supply
Serial Smart Cable

Z8 Encore! XP®F08xA Series Development Kit
User Manual
UM018603-1005 Introduction
3
– Development Kit User Manual
– ZDS II - IDE User Manual
– eZ8 CPU User Manual
– Application notes
The sample code is installed with ZDS II and resides in the <installa-
tion directory>\samples in the user's disk drive.
The documentation can be installed by the user with the DemoShield
interface or can be viewed on the CD-ROM using the DemoShield menus
and a PDF reader. A copy of the Acrobat installer is provided on the CD-
ROM and can be installed from the DemoShield install screen. After
installing the documentation on the user’s system Windows Explorer can
be used to select any document to be viewed with your favorite PDF file
viewer.
System/Software Requirements
IBM PC (or compatible computer) with the following minimum configu-
rations:
Supported Host System Configuration
• Win98 Second Edition, WinNT 4.0 Service Pack 6, Win2000 Service
Pack 3, WinXP Professional Service Pack 1
• PentiumII/233MHz processor or higher up to Pentium IV, 2.8 GHz
• 96 MB RAM or more
• 25 MB hard disk space or more
• Super VGA video adapter
• CD-ROM
• One or more RS-232 communication ports

Z8 Encore! XP®F08xA Series Development Kit
User Manual
Introduction UM018603-1005
4

Z8 Encore! XP®F08xA Series Development Kit
User Manual
UM018603-1005 Installation
5
Installation
Follow the directions in the Quick Start Guide for software installation
and setup of the Z8 Encore! XP®F08xA Series Development kit.

Z8 Encore! XP®F08xA Series Development Kit
User Manual
Installation UM018603-1005
6

Z8 Encore! XP®F08xA Series Development Kit
User Manual
UM018603-1005 F08xA Series Development Board
7
F08xA Series
Development Board
Introduction
The Z8 Encore! XP®F08xA Series Development board is a development
and prototyping board for the Z8 Encore! XP F08xA Series MCU. The
board provides customers with a tool to evaluate features of Z8 Encore!
XP F08xA Series MCU, and to start developing an application before
building the hardware.
Figure 1. Z8 Encore! XP®F08xA Series Development Board

Z8 Encore! XP®F08xA Series Development Kit
User Manual
F08xA Series Development Board UM018603-1005
8
Features
• Z8 Encore!®MCU (28-pin SOIC)
• 3 LEDs
• RS-232 interface
• IrDA transceiver
• Two pushbuttons, RESET and TEST
• 5 VDC power connector
• On-Chip Debugger interface
• 20 MHz Ceramic Oscillator (Y1)
• Header for ADC input
• Prototyping area
• External interface connectors JP1 and JP2
• 2.7–3.6 V operating voltage with 5V-tolerant inputs
MCU
The Z8 Encore! XP F08xA Series MCU is member of a family of ZiLOG
microcontroller products based upon the 8-bit eZ8 core CPU. The Flash
in-circuit programming capability allows for faster development time and
program changes in the field. The eZ8 core CPU is upward compatible
with existing Z8®instructions. The rich peripheral set of the Z8 Encore!
XP F08xA Series makes it suitable for a variety of applications including
motor control, security systems, home appliances, personal electronic
devices, and sensors.
The Development board contains circuitry to support and present all the
features of the Z8 Encore! XP F08xA Series. The main features of the Z8
Encore! XP F08xA Series are:

Z8 Encore! XP®F08xA Series Development Kit
User Manual
UM018603-1005 F08xA Series Development Board
9
• eZ8 core CPU
• 8KB Flash memory with in-circuit programming capability
• 1KB register RAM
• 8-channel, 10-bit analog-to-digital converter (ADC)
• Full-duplex UART
• Infrared Data Association (IrDA)-compliant infrared encoder/decoder
• Two 16-bit timers with capture, compare, and PWM capability
• Watch-Dog Timer (WDT) with internal RC oscillator
• Eleven (20-pin package) or nineteen (28-pin package) I/O pins
• Programmable priority interrupts
• On-Chip Debugger
• Voltage Brown-out Protection (VBO)
• Power-On Reset (POR)
• 2.7–3.6 V operating voltage with 5V-tolerant inputs
• Operating temperatures: 20° ±10° C
For further information on the Z8 Encore!® family of devices, consult the
product specification, P/N PS0247, available for download from
www.zilog.com.
UART with IrDA Endec
The Z8 Encore! XP F08xA Series (component U5) contains a fully-func-
tional, high-performance UART with Infrared Encoder/Decoder
(ENDEC). The Infrared Endec is integrated with an on-chip UART allow-
ing easy communication between the Z8 Encore!®XP F08xA Series and
IrDA transceivers. Infrared communication provides secure, reliable, low-

Z8 Encore! XP®F08xA Series Development Kit
User Manual
F08xA Series Development Board UM018603-1005
10
cost, point-to-point communication between PCs, PDAs, cell phones,
printers and other infrared enabled devices.
Power and Communication Interfaces
Table 1 provides jumper information concerning the shunt status, func-
tions, devices and defaults affected of jumpers JP3 and JP4.
External Interface Headers JP1 and JP2
External interface headers JP1 and JP2 are shown in the schematic on
page 13.
Table 1. Jumpers JP3 and JP4
Jumper Status Device Affected Status Default
JP3* OUT RS-232
interface Enabled X
JP3 IN RS-232
interface Disabled
JP4* OUT IrDA interface Enabled
JP4 IN IrDA interface Disabled X
JP5 OUT U5 RESET/
PD0 PD0 (GPIO) X
JP5 IN U5 RESET/
PD0 RESET when SW1 pressed
Note: * These jumpers must not be OUT at the same time

Z8 Encore! XP®F08xA Series Development Kit
User Manual
UM018603-0805 PRELIMINARY Schematic
11
Schematic
This section includes schematics for the Z8 Encore! XP®F08xA Series
Development Board.

Z8 Encore! XP®F08xA Series Development Kit
User Manual
Schematic PRELIMINARY UM018603-0805
12
