Zipato ZIPABOX User manual

we make every home smart www.zipato.com we make every home smart www.zipato.com
TRADEMARKS
Zipato and the Zipato logo are registered Trademarks. All
other product names mentioned herein may be trademarks or
registered trademarks of their respective companies.
NOTICE
Although Zipato has attempted to ensure the accuracy of the
content of this manual, it is possible that this document may
contain technical inaccuracies, typographical, or other errors.
Zipato assumes no liability for any error in this publication, and for
damages, whether direct, indirect, incidental, and consequential
or otherwise, that may result from such error, including, but not
limited to loss of data or profits. Zipato provides this publication
“as is” without warranty of any kind, either express or implied,
including, but not limited to implied warranties of merchantability
or fitness for a particular purpose. The published information in
the manual is subject to change without notice. Zipato reserves
the right to make changes in the product design, layout, and driver
revisions without notification to its users. This version of the
Installation guide supersedes all previous versions.
ELECTROMAGNETIC COMPATIBILITY
In proper state and when operated properly, the product complies
with all the requirements in respect of interference radiation
according to EN 301 489-17, EN 301 489-1 and EN 300 328. The
connections conducting HF signals must neither be manipulated
nor damaged.
TAKE CARE OF YOUR SAFETY
Display extreme caution when using ladders or steps, please
follow manufacturer’s instructions. Be careful when using hand
and power tools and follow the manufacturer’s guidelines when
using them. Take care that the correct tools are used. Wear
goggles or protective clothing where required.
DANGER
RISK OF ELECTROCUTION
All work on the device should only be carried out by trained and
skilled electricians. Observe the country-specific regulations.
CAUTION
The connected devices and the flush-mounted receiver can
become damaged if devices are operated that do not correspond
to the technical specifications (see technical data).
DANGER
RISK OF FATAL INJURY FROM ELECTRIC CURRENT.
The device has no basic insulation and must therefore be installed
in a way that protects against accidental contact.
DANGER
RISK OF FATAL INJURY FROM ELECTRIC CURRENT.
When installing a wall plate, the distance between the cover’s fixing
brackets or screws and the connections of the flush - mounted MM
Switch Single must be at least 4 mm once installed. If the distance is
less than 4 mm, a deeper installation box must be used. The fixing
brackets or screws of the cover must not press against the housing.
Only insulated tools may be used for operation on the device, e.g. an
insulated phase tester.
TECHNICAL MANUALS
TECHNICAL DETAILS
POWER SUPPLY Fom Zipabox
OPERATING TEMPERATURE -10° ~ +40° C
OPERATING HUMIDITY 5 ~ 95% RH
DIMENSIONS 29 x 87 x 46 mm (without antenna)
WEIGHT 62g (with antenna)
COMMUNICATION FREQUENCY 433 MHz
COMMUNICATION PROTOCOL ZigBee
COMMUNICATION RANGE Up to 30m indoor or
70m outdoor
UNPACKING
Zipabox 433MHz Module consists of:
1x Expansion Module 1x 433 MHz antenna
PLEASE NOTE: Connect antenna by screwing it clockwise to the
connector on the module
CONNECTING DEVICE
1 | Disconnect Zipabox from power
INTRODUCTION
COMPATIBILITY
This Expansion Module is designed to work only with Zipabox.
HANDLING
Do not drop, knock or shake the module. Rough handling can break
internal circuit boards and connectors.
ENVIRONMENT
Do not expose the module to excessive heat or cold, as it can damage
or shorten the life of electronic circuit boards.
If possible, dispose this module at a recycling center.
Do not dispose of this module with the household waste.
2 | Align connector of Zipabox 433 Expansion Module to expansion
Slot 2 of Zipabox (or to module connected into Slot 2)
3 | Join module and Zipabox together until gap between them is
completely closed.
INSTALLATION/MOUNTING
Mount together with Zipabox.
INTERFERENCE
All wireless devices are subject to interference, which could affect
device performance.
REPARING
Do not attempt to repair this product.
There are no user-serviceable parts inside.
WATER-RESISTANCE
This product is not water-resistant. Keep it dry.
Moisture will corrode the inner electronics.
CLEANING
Use a dry cloth to clean this product. Do not use harsh chemicals,
cleaning solvents or strong detergents.
ZIPABOX 433MHz
MODULE
QUICK INSTALLATION GUIDE
v1.0
Top right
angle
Right side
view
Left side
view
Top
view
Bottom
view
Bottom left
angle
Front
view
2
1
