CANFDNET-400U
High-performance Four-channel CANFD Bus to Ethernet Converter User Manual
©2021 Guangzhou ZLG Electronics Co., Ltd.
2
User Manual
Revision History
Version
Date
Reason
V1.00
May 13, 2020
Created

CANFDNET-400U
High-performance Four-channel CANFD Bus to Ethernet Converter User Manual
©2021 Guangzhou ZLG Electronics Co., Ltd.
1
User Manual
Contents
1. Product Introduction.....................................................................................................................1
1.1 Product Overview.........................................................................................................................................1
1.2 Product Features..........................................................................................................................................1
1.2.1 Powerful Hardware............................................................................................................................1
1.2.2 Perfect Functions...............................................................................................................................1
1.2.3 Typical Applications............................................................................................................................2
2. Product Specifications .................................................................................................................3
2.1 Electrical Specifications ...............................................................................................................................3
2.2 Operating Temperature................................................................................................................................3
2.3 Protection Level............................................................................................................................................3
3. Mechanical Dimensions...............................................................................................................4
4. Hardware Interfaces.....................................................................................................................6
4.1 Panel layout..................................................................................................................................................6
4.2 Indicators......................................................................................................................................................6
4.3 Button...........................................................................................................................................................7
4.4 Power Interface............................................................................................................................................7
4.5 CANFD-bus Interfaces.................................................................................................................................8
4.6 Ethernet Interface.........................................................................................................................................9
4.7 Vehicle Ethernet Interface............................................................................................................................9
5. Quick Guide............................................................................................................................... 11
5.1 Device Connection.....................................................................................................................................11
5.2 Software Installation...................................................................................................................................11
5.3 Running the Device Configuration Tool .....................................................................................................11
5.4 Device Search............................................................................................................................................12
5.5 Basic Device Configurations......................................................................................................................13
5.5.1 Configuring Network Parameters ....................................................................................................13
5.5.2 Configuring CAN (FD) Channel Parameters...................................................................................14
5.5.3 Configuring CAN(FD)-to-Ethernet Parameters................................................................................14
5.5.4 Downloading Configurations............................................................................................................15
5.6 Connecting ZCANPRO ..............................................................................................................................16
6. Disclaimer..................................................................................................................................18

CANFDNET-400U
High-performance Four-channel CANFD Bus to Ethernet Converter User Manual
©2021 Guangzhou ZLG Electronics Co., Ltd.
1
User Manual
1. Product Introduction
1.1 Product Overview
CANFDNET-400U is a high-performance industrial Ethernet and CAN(FD)-bus data conversion device
developed by Guangzhou ZLG Electronics Co., Ltd. It integrates four CAN(FD)-bus interfaces, one Ethernet
interface, one vehicle dual-wire Ethernet interface, and provides a stable TCP/IP protocol stack. It allows users to
easily interconnect the CAN(FD)-bus network and Ethernet and further expand the scope of CAN(FD)-bus
network.
CANFDNET-400U is an industrial-grade product working in the temperature range of -40°C to 85°C. It has
one 100M/1000M adaptive Ethernet interface, one 10M/100M on-board dual-wire Ethernet interface, and four
CAN (FD) ports with a maximum baud rate of 5 Mbps. It has TCP Server, TCP Client, UDP and other work modes.
Users can flexibly set configuration parameters by using the configuration software.
1.2 Product Features
1.2.1 Powerful Hardware
⚫High-speed dual-core A9+FPGA processor;
⚫100M/1000M self-applicable Ethernet interface, 2 kV electromagnetic isolation;
⚫Car dual-wire Ethernet, meeting 100Base-T1 specification
⚫Four CAN (FD) ports, 2.5 kVDC withstand voltage isolation;
⚫Rated power supply voltage range 9V-48V DC;
⚫Operating temperature: -40°C to +85°C;
⚫Humidity: 5%-95% RH, no condensation;
⚫Rugged metal housing, SECC metal (1.1 mm);
⚫Designed specifically for industrial environments.
1.2.2 Perfect Functions
⚫CAN(FD) interface functions supported:
◼Support baud rate 40K-5Mbps, baud rate can be set arbitrarily;
◼Support various controller types: CAN, CANFD ISO or CANFD Non-ISO;
◼Support the software terminal resistance switch;
◼Support message filtering;
◼Support millisecond-level message timing sending;
◼Support bus utilization reporting;
◼The message sending buffer can be set, and the user can choose the most suitable balance
between real-time and large-capacity buffering;
⚫Multiple work modes supported:
◼Work modes: TCP Server, TCP Client, UDP;
◼Supports a maximum of four TCP servers, each of each supports a maximum of 16 connections; or
supports a maximum of 16 TCP Client or UDP connections;

CANFDNET-400U
High-performance Four-channel CANFD Bus to Ethernet Converter User Manual
©2021 Guangzhou ZLG Electronics Co., Ltd.
2
User Manual
◼In each mode, you can choose to upload the CAN (FD) channel message and error message, which
can be flexibly used in various scenarios;
◼The TCP Server/Client mode connection has a built-in TCP keep-alive mechanism to ensure
reliable TCP connections;
◼In TCP Client mode, the network will automatically reconnect after disconnection, and the TCP
connection will be established reliably;
◼In UDP mode, support multicast, IP segment and other operations to support multiple users to
control multiple CAN (FD) channels at the same time;
◼Supported TCP/IP protocols include IP,ARP, ICMP, UDP, DHCP, DNS, TCP;
◼Flexible CAN (FD) packet settings meet various packet requirements of users;
◼The communication protocol is open, and the secondary development interface function library is
provided (Windows and Linux platforms supported);
⚫You can configure the working parameters by using the configuration tool, and provide the secondary
development interface function library (Windows, Linux platforms supported);
⚫Support TCP/UDP data conversion between vehicle Ethernet and Ethernet;
⚫Support local system firmware upgrade.
1.2.3 Typical Applications
⚫High-speed train operation fault detection and troubleshooting
⚫Subway train operation fault detection and troubleshooting
⚫Train control system operation fault detection and troubleshooting
⚫Wind turbine CANFD communication fault detection
⚫Multi-channel CANFD communication records and fault analysis for traditional vehicles and new energy
vehicles
⚫Ship CANFD communication fault detection and troubleshooting
⚫Coal mine CANFD communication fault analysis
⚫Elevator operation fault detection and troubleshooting
⚫Construction machinery operation fault detection and troubleshooting
⚫Aerospace vehicles and ancillary equipment operation detection and troubleshooting

CANFDNET-400U
High-performance Four-channel CANFD Bus to Ethernet Converter User Manual
©2021 Guangzhou ZLG Electronics Co., Ltd.
3
User Manual
2. Product Specifications
2.1 Electrical Specifications
Table 2.1 Electrical specifications
Parameter Name
Conditions
Rating
Unit
Minimum
Typical Value
Maximum
Operating voltage
DC
9
12
48
V
Power consumption
4.2
5.1
8.6
W
2.2 Operating Temperature
Table 2.2 Working temperature
Parameter Name
Rating
Unit
Minimum
Typical Value
Maximum
Operating temperature
-40
-
85
℃
Storage Temperature
-40
-
85
℃
2.3 Protection Level
Table 2.3 Protection level-electrostatic discharge immunity test (IEC61000-4-2)
Interface
Test Level
Test Voltage (kV)
Test Result
Remarks
Power supply
Level 4
6
Class A
Contact discharge
CANFD bus
Level 4
6
Class A
Contact discharge
Ethernet
Level 4
6
Class A
Contact discharge
Buttons, Indicators
Level 4
15
Class A
Air discharge
Table 2.4 Protection level-electrical fast transient pulse group immunity test (IEC61000-4-4)
Interface
Test Level
Test Voltage (kV)
Test Result
Remarks
Power supply
Level 3
2
Class A
Capacitive coupling
CANFD bus
Level 3
1
Class B
Capacitive coupling
Ethernet
Level 3
2
Class A
Capacitive coupling
Table 2.5 Protection level-surge (impact) test (IEC61000-4-5)
Interface
Test Level
Test voltage (kV)
Test Result
Remarks
Power supply
Level 3
1
Class A
Line-line
Level 3
2
Class A
Line-ground
CANFD bus
Level 3
1
Class B
Line-line
Level 3
2
Class B
Line-ground
Ethernet
Level 3
1
Class A
Line-line
Level 3
2
Class A
Line-ground

CANFDNET-400U
High-performance Four-channel CANFD Bus to Ethernet Converter User Manual
©2021 Guangzhou ZLG Electronics Co., Ltd.
4
User Manual
3. Mechanical Dimensions
The mechanical dimensions are shown in the following figure (unit: mm)
Figure 3.1 Host dimensions diagram 1
Figure 3.2 Host dimensions diagram 2

CANFDNET-400U
High-performance Four-channel CANFD Bus to Ethernet Converter User Manual
©2021 Guangzhou ZLG Electronics Co., Ltd.
5
User Manual
Figure 3.3 Installation method

CANFDNET-400U
High-performance Four-channel CANFD Bus to Ethernet Converter User Manual
©2021 Guangzhou ZLG Electronics Co., Ltd.
6
User Manual
4. Hardware Interfaces
This section describes the hardware interfaces of CANFDDTU-400 series devices.
4.1 Panel layout
Figure 4.1 shows the device panel layout.
Figure 4.1 Panel layout
4.2 Indicators
Table 4.1 LED indicators
Identification
Function
Status
Status Description
Flash description
PWR
Power indicator
Light off
The device is not powered on
-
Red
The device is powered on properly
-
SYS
System indicator
Green flashing light
System running
100 ms cycle, after ON
twice, wait for 500 ms
Always red
Device reset and restart
-
LAN0
Ethernet indicator
Light off
Ethernet no connected
-
Green normally on
Ethernet connected
-
Green flashing
The application has data
transmission and reception
Flash at an interval of
200 ms
Flash in red
Received data parsing error
Flash at an interval of
200 ms
LAN1
Vehicle Ethernet
Light off
Ethernet no connected
-

CANFDNET-400U
High-performance Four-channel CANFD Bus to Ethernet Converter User Manual
©2021 Guangzhou ZLG Electronics Co., Ltd.
7
User Manual
Indicator
Green normally on
Ethernet connected
-
Green flashing
The app has data transfer
200 ms periodic blink -
CAN0~ CAN3
CAN channel
indicator
Light off
Channel not open
-
Green normally on
Channel open
-
Green flashing
The CAN channel sends and
receives data properly
Flash at an interval of
200 ms
Flash in red
CAN bus error
Flash at an interval of
200 ms
4.3 Button
The device provides a button as RST to reset the device and restore factory settings.
Table 4.2 Reset button function
Identification
Function
RST/DEF
Resets the device (press)
Restore factory settings (5s)
4.4 Power Interface
The rated voltage of the power input of the equipment is DC 9-48 V, and the shell is marked as "DC 9-48V".
The physical form of the interface is a 5.08 terminal. Table 4.3, Table 4.4 and Table 4.5 list the interface diagram,
signal definition, and interface specifications.
Table 4 Power interface
Type
Schematic Diagram
5.08 terminal
Table 4.4 5.08 terminal signal definition
Function
interface
Signal definition
Signal description
Interface Type
5.08 interface
Power supply
V+
Positive electrode of power
√
V-
Negative electrode of power
√
Table 4.5 Power interface specifications
Parameter Name
Conditions
Rating
Unit
Minimum
Typical Value
Maximum
Operating voltage
DC
9
12
48
V
Power consumption
5.1
W

CANFDNET-400U
High-performance Four-channel CANFD Bus to Ethernet Converter User Manual
©2021 Guangzhou ZLG Electronics Co., Ltd.
8
User Manual
4.5 CANFD-bus Interfaces
The device provides four isolated CANFD-Bus interfaces. The shell identification is "CAN0", "CAN1", "CAN2",
and "CAN3". The physical form of the interface is a DB9 terminal. Table 4.6, Table 4.7 and Table 4.8 list the
interface diagram, signal definition, and interface specifications.
Table 4.6 Pin definitions
Type
Schematic Diagram
Pin definitions
Table 4.7 Signal definition
Function Interface
Signal Definition
Signal Description
Pin Number
CANFD0~CANFD3
CANFD_L
CANFD data transceiver differential inverted signal
2
CANFD_GND
CANFD isolation ground
3, 6
CANFD_H
CANFD data transceiver differential positive phase signal
7
CANFD_FG
Shielding ground
5
NC
Not connected
1, 4, 8, 9
Table 4.8 CANFD-Bus interface specifications
Parameter
Minimum
Typical Value
Maximum
Unit
Communication baud rate
5k
1M
bps
Number of nodes
110
pcs
Dominant level (logic 0)
CANFDH
2.75
3.5
4.5
V
CANFDL
0.5
1.5
2
Recessive level (logic 1)
CANFDH
2
2.5
3
CANFDL
2
2.5
3
Differential level
Dominant (logic 0)
1.2
2
3.1
Recessive (logic 1)
-0.5
0
0.05
Maximum withstand voltage of the bus pin
-18
18
Instantaneous voltage of the bus
-100
+100
Isolation voltage (DC)
3500
V
Figure 4.2 Typical high-speed CANFD network connection

CANFDNET-400U
High-performance Four-channel CANFD Bus to Ethernet Converter User Manual
©2021 Guangzhou ZLG Electronics Co., Ltd.
9
User Manual
Balanced transmission is adopted for the CANFD bus .According to ISO11898-2: In the high-speed CANFD,
a 120 ohm terminal resistor needs to be connected to the network terminal node to eliminate signal reflection on
the bus and avoid signal distortion. Figure 4.2 shows the high-speed CANFD network topology.
The device has a built-in 120 ohm terminal resistance, which can be connected or disconnected through the
network configuration tool in ZCANPRO. For operation details, see chapter 5.5.2.
Note: The bus communication distance and communication rate are related to the field application and can
be designed according to the actual application and related standards. CANFD-Bus cable can be ordinary twisted
pair, shielded twisted pair or standard bus communication cable. In long-distance communication, the terminal
resistance value needs to be selected according to the communication distance, cable impedance and number of
nodes.
4.6 Ethernet Interface
The device provides one Ethernet interface. The physical form of the interface is RJ45 or M12 terminal
(parallel connection, PHY is one channel), which realizes the communication between the device and the PC.
The interface is 100/1000M specification. Table 4.9 lists the interface diagram and signal definition.
Table 4.9 Ethernet interface
Type
Schematic Diagram
RJ45 terminal
M12 terminal
4.7 Vehicle Ethernet Interface
The device provides one vehicle Ethernet interface, which meets the OPEN Alliance BroadR-Reach
specification. The physical form of the interface is the OPEN terminal, which realizes vehicle Ethernet
communication. This interface meets the 10/100M specification. Table 4.10, Table 4.11, and Figure 4.3 show the
interface diagram and signal definition.
Table 4.10 Vehicle Ethernet interface
Type
Schematic Diagram

CANFDNET-400U
High-performance Four-channel CANFD Bus to Ethernet Converter User Manual
©2021 Guangzhou ZLG Electronics Co., Ltd.
10
User Manual
5.08 terminal
Table 4.11 Signal definition
Function Interface
Signal Definition
Signal Description
Pin Number
LAN1
P
LAN1 data transceiver differential positive phase signal
1
N
LAN1 data transceiver differential inverted signal
2
Figure 4.3 Typical network connection of vehicle Ethernet

CANFDNET-400U
High-performance Four-channel CANFD Bus to Ethernet Converter User Manual
©2021 Guangzhou ZLG Electronics Co., Ltd.
11
User Manual
5. Quick Guide
5.1 Device Connection
Connect the hardware by referring to the interface instructions in the "Product Hardware Interface
Instructions" chapter, and power on the device.
5.2 Software Installation
Double-click the "ZCANPRO_Setup_Vxx.xx.xx.exe" ZCANPRO installation package. Follow the installation
instructions to install the software.After the installation is complete, run the "ZCANPRO" software.
5.3 Running the Device Configuration Tool
After starting ZACNPRO, the "Device Management" interface appears, as shown in Figure 5.1. Click the
Close button ("x") in the upper right corner to close "Device Management".
Figure 5.1 Device management interface
Click the "Tools" option in the toolbar in the upper part of ZCANPRO. Click "Network Device Configuration
Tool" in the pop-up list, as shown in Figure 5.2. "Network Device Configuration Tool" is displayed, as shown in
Figure 5.3.

CANFDNET-400U
High-performance Four-channel CANFD Bus to Ethernet Converter User Manual
©2021 Guangzhou ZLG Electronics Co., Ltd.
12
User Manual
Figure 5.2 Running the network device configuration tool
Figure 5.3 Network device configuration tool
5.4 Device Search
Click the "Search Device" option in the upper left corner of the "Network Device Configuration" tool to search
for CANFDNET devices in the network. After the search is over, the devices connected to the network are
displayed in the device list. Click a device to view or modify its configurations on the right side of the configuration
tool.

CANFDNET-400U
High-performance Four-channel CANFD Bus to Ethernet Converter User Manual
©2021 Guangzhou ZLG Electronics Co., Ltd.
13
User Manual
Figure 5.4 Network device configuration tool interface
5.5 Basic Device Configurations
When the device is used for the first time, configure the channel parameters, network parameters and
CAN(FD)-to-Ethernet parameters as required.
5.5.1 Configuring Network Parameters
When the CANFDNET device uses the "forwarding Ethernet" function, the device and the PC must be on the
same network segment, which ensures normal TCP/UDP connections. Modify the "Universal Ethernet"
configuration items as needed.
Figure 5.5 "Universal Ethernet" configuration item
1. DHCP enabling: Determine whether to enable DHCP to automatically obtain an IP address as required.
After enabling DHCP to obtain an IP address automatically, only a DHCP server device on the network
can successfully obtain an IP address and other related information.
2. IP: Configure the IP address of the device.
3. Subnet mask: Specify the subnet for the device IP address.
4. Gateway: gateway address of the device.

CANFDNET-400U
High-performance Four-channel CANFD Bus to Ethernet Converter User Manual
©2021 Guangzhou ZLG Electronics Co., Ltd.
14
User Manual
5.5.2 Configuring CAN (FD) Channel Parameters
The CANFDNET device has four CAN (FD) channels, each of which needs to be configured independently.
Modify the "CANx Configuration" configuration item as needed.
Figure 5.6 CAN channel configuration interface
1. Select the controller type: protocol standard for the channel device channel to access the bus.
2. Select work mode: normal mode and listen-only mode; when the channel is working in listen-only mode,
the controller will not send data (including the answer bit) to the bus.
3. Select the baud rate: when the channel works in CAN mode, you only need to configure the "arbitration
domain baud rate", and select the baud rate as needed; when the channel works in CANFD mode, the
"data domain baud rate" needs to be configured separately; when none of the options in the baud rate
list meets the requirements, you can use a custom baud rate. After calculating the baud rate parameters
in the baud rate calculator, copy the result to the "custom baud rate" configuration item.
4. Select terminal resistance enable: Determine whether to enable terminal resistance based on the
impedance matching on the bus.After the terminal resistance is enabled, a 120 ohm resistor will be
connected in parallel on the bus; after the terminal resistance is connected, the impedance on the bus
will be changed. If you do not know whether access is required, you are advised not to enable it.
5.5.3 Configuring CAN(FD)-to-Ethernet Parameters
The CANFDNET device supports 16-channel Ethernet forwarding configuration. Click the "CAN(FD) to
Ethernet" option. The "CAN(FD) to Ethernet" configuration interface appears.
Figure 5.7 "CAN(FD)-to-Ethernet" option

CANFDNET-400U
High-performance Four-channel CANFD Bus to Ethernet Converter User Manual
©2021 Guangzhou ZLG Electronics Co., Ltd.
15
User Manual
Figure 5.8 "CAN(FD)-to-Ethernet" configuration interface
1. Work mode: Set the work mode of the device, "TCP server", "TCP client", or "UDP".
2. Local port: Set the local port of the device. When it is set to 0, it will be assigned by the system by
default.
3. Destination address: In TCP server mode, you do not need to configure the destination address; in other
modes, the destination address is the address of the remote TCP server or UDP.
4. Destination port: In TCP server mode, you do not need to configure the destination port; in other modes,
the destination address is the port number of the remote TCP server or UDP monitoring.
5. Enable forwarding configuration: After configuring the parameters, select the leftmost check box of the
current configuration item.
5.5.4 Downloading Configurations
After modifying the configuration parameters, enter the password (default: 88888) in the "Current Password"
option box of the configuration item "Password Operation", as shown in Figure 5.9. Click the "Submit Changes"
button at the top of the configuration parameter interface to download the configuration to the device.After the
configuration is modified successfully, the "Modified successfully" message appears, as shown in Figure 5.10.

CANFDNET-400U
High-performance Four-channel CANFD Bus to Ethernet Converter User Manual
©2021 Guangzhou ZLG Electronics Co., Ltd.
16
User Manual
Figure 5 Entering the device password
Figure 5.10 Successful modification
5.6 Connecting ZCANPRO
After exiting the "Network Device Configuration Tool", return to the ZCANPRO software. Click "Device
Management" in the upper option bar to display the "Device Management" interface, and select
"CANFDNET-400U-XXX" in the "Type" drop-down list. The specific device needs to match the work mode
configured in 5.5.3 Configuring CAN(FD) to Ethernet Parameters. Click "Start Device".
Figure 5.11 Starting the device in ZCANPRO
After starting the device, click "Start". On the startup interface, configure the parameters by referring to
Section 5.5.3 Configuring CAN(FD) to Ethernet Parameters, and click "OK". The CAN(FD) data can be sent and
received by using the usage method of ZCANPRO.

CANFDNET-400U
High-performance Four-channel CANFD Bus to Ethernet Converter User Manual
©2021 Guangzhou ZLG Electronics Co., Ltd.
17
User Manual
Figure 5.12 Starting the device
