Zline RFM-W Series User manual

BUILT-IN REFRIGERATORS
www.zlinekitchen.com
User Manual

ZLINE Kitchen and Bath provides Attainable Luxury, where the kitchen and bath of your dreams
is never out of reach. Through our unique designs and unparalleled quality, we’re dedicated to
providing you an elevated experience in the heart of your home. With an endless selection of
features and finishes, our inspiration is your reality.

WARNING: This product can expose you to chemicals including nickel, which is known to the
State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
ZLINE is fueled by a passion for innovation; A relentless pursuit of bringing the highest end luxury
designs and professional features into everyone’s homes. Because we continually strive to improve
our products, we may change specifications and designs without prior notice.

INSTALLATION SAFETY INSTRUCTIONS 1
OPERATION 9
• Product Specifications
• Keys and Controls
• Modes and Features
• Food Storage
• Shelves and Drawers
• Hinge Adjustment
MAINTENANCE AND CLEANING 23
TROUBLESHOOTING 25
WARRANTY 31
TABLE OF CONTENTS

1
General Safety
IMPORTANT SAFETY INSTRUCTIONS
WARNING
If the information in this manual is not followed exactly, a fire or explosion
may result causing property damage, personal injury, or death.
GENERAL SAFETY
• Before installation and operation, please read and follow these important instructions for
the safety of your home and the people living in it.
• This appliance is not intended for use by children unless they have been adequately
supervised by a responsible person to ensure they can use the appliance safely.
• Young children should be supervised to ensure that they never play with the appliance.
• Cleaning and care should not be performed by children unless they are supervised by an
adult or responsible person.
• Immediately unplug the product if you encounter a failure during use.
• If the product malfunctions, it must not be operated until repaired by an authorized service
provider.
• It is recommended that installation and service be performed by a qualified installer.
The appliance should not be adjusted or repaired by anyone except properly qualified
service personnel.
• The manufacturer will not be responsible for any damage to property or to persons
caused by incorrect installation, improper use of the appliance, or failure to heed the
warnings listed; the warranty will be voided.
• The manufacturer reserves the right to make changes to its products when considered
necessary and useful, without affecting the essential safety and operating characteristics.
• Do not eat ice cubes, ice cream, or other frozen foods immediately after you take them
out of the freezer compartment. This may cause frostbite in your mouth.
• Do not touch frozen food with wet hands. They may stick to your hand.
• Do not put bottled or canned liquid beverages in the freezer compartment. They may
burst.

• Please observe all local, state, and national codes and ordinances. Please ensure the
appliance is properly grounded. The plug should always be accessible.
• Never wash the appliance by spreading or pouring water onto it, as you run the risk of
electric shock.
• Never touch the plug with wet hands.
• To disconnect the appliance from power, firmly grip the plug and pull it from the electrical
outlet. Never pull by the cord.
• Do not plug in the refrigerator if the wall outlet is loose.
• Never connect your refrigerator to energy-saving devices; such systems are harmful to
your product.
• Unplug the product during installation, care, cleaning, and repairing procedures.
2
General Safety
IMPORTANT SAFETY INSTRUCTIONS
Improper use of the grounded plug can result in the risk of electrical
shock. If the power cord is damaged, have it replaced by a qualified
electrician or an authorized service provider.
WARNING

• Never use steam or steam cleaners to clean or defrost the refrigerator. Steam may
infiltrate your unit's electrical system, increasing risk of a short circuit or electric shock.
• Do not use mechanical devices or other means to accelerate the defrosting process other
than those recommended by the manufacturer.
• Never use the parts in your refrigerator, such as the door, shelves, or drawers, as a means
of support or step. This may damage the unit and/or cause it to tip over.
• Do not damage or attempt to fix/adjust the unit's sealed system where the refrigerant
circulates with drilling or cutting tools.
• If pipe extensions, surface coatings, or gas channels of the evaporator located inside
the sealed system are punctured, the refrigerant may escape, potentially causing skin
irritations and eye injuries.
• Do not cover or block the ventilation holes in your refrigerator with any object.
• Ensure beverages in round containers are tightly closed and placed vertically in the
refrigerator to avoid damage to the interior or injury when opening doors.
• Do not use gaseous sprays near the product since there is the risk or fire or explosion.
• Flammable items, products that contain flammable gases (e.g. spray), and explosive
materials should never be kept in the appliance.
• Do not place containers filled with liquid on top of the refrigerator. Splashing liquids on
any electrical parts increases the risk of fire or electric shock.
• Do not store items that need precise temperature adjustment (vaccines, heat-sensitive
medication, science materials, etc.) in the refrigerator.
• If you are not going to use the appliance for an extended period of time, unplug it and
remove any contents.
• Exposing the product to rain, snow, sun, or wind is dangerous and may increase risk of
electrical shock or failure.
• If the refrigerator's sealed mechanical system needs to be serviced or replaced by a
professional service provider, wait at least 5 minutes after installation to reconnect the unit
to electrical power.
3
General Safety
IMPORTANT SAFETY INSTRUCTIONS

• Do not overload the refrigerator. Objects in the refrigerator may fall down when the door
is opened, causing injury or damage. Similar problems may arise if any object is placed
on top of the unit.
• If the product has a door handle, do not pull on the handle when re-locating the product.
The handle may become loose and become damaged and/or cause injury.
• Be careful not to jam your hand or any other body part in the moving parts of the
refrigerator.
• Do not put your hand or any other foreign materials into the ice machine while it is
operating.
INTENDED USE
• This product has been designed for domestic use. It is not suitable for commercial use and
it must not be used outside of its intended use. It must be used only for storing food and
beverages.
• The manufacturer does not take any responsibility for damages resulting from improper
use or transport.
CHILDREN'S SAFETY
• If there is a lock on the door of the product, the key should be kept out of the reach of
children.
• Do not let children play with the product.
WARNING
Before disposing of your old refrigerator or freezer:
• Ensure that children are not inside.
• Leave the shelves inside the unit to prevent children from
getting inside the product easily.
• Remove the doors.
4
General Safety
IMPORTANT SAFETY INSTRUCTIONS

COMPLIANCE WITH THE ROHS DIRECTIVE
This appliance conforms to the EU RoHS Directive (2011/65/AB). It does not contain harmful
or prohibited materials specified in the directive.
PACKAGING INFORMATION
• While some packaging materials for this product may have been manufactured from
recyclable materials, others, such as Polystyrene (Styrofoam), are not recyclable.
• Dispose of this unit's non-recyclable packaging with normal domestic waste, and consult
your local recycling programs or regulations for which materials may be recycled.
HYDROCARBON (HC) WARNING
• This product's sealed cooling system contains R600a refrigerant. This gas is flammable.
Therefore, pay attention not to damage the cooling system or piping during use and
transportation.
• If damaged, keep the product away from potential fire sources that may cause it to catch
fire and ventilate the room where the product is placed.
• Never use an appliance with a damaged cooling system. If the system is damaged upon
delivery, contact ZLINE at 1-614-777-5004.
WARNING
DANGER:
Risk of Fire or Explosion:
• This product uses flammable refrigerant.
• Do not use mechanical devices to defrost the refrigerator.
• Do not use chemicals for cleaning.
• Do not pierce the refrigerant pipe.
• If the refrigerant pipe is pierced, it must be repaired only by
licensed service personnel.
• Please consult the repair/user manual before cleaning the
product.
• All safety instructions must be followed.
• Dispose the product according to federal or local regulations.
5
General Safety
IMPORTANT SAFETY INSTRUCTIONS

ATTENTION
If the product is damaged and if you see gas leak, please keep
away from the gas. It may cause frostbite when it gets into contact
with the skin (including R600a).
ATTENTION
The type of gas used in the product is stated on the unit's label, which
is located on the left wall inside the refrigerator.
WARNING
Never throw the product into fire for disposal.
WATER PRESSURE PRECAUTIONS
• The operating pressure for the cold water inlet must be between 25 and 80 psi. If the
water pressure exceeds 80 psi (5.5 bars), install a pressure-limiting device or water
pressure protector to the inlet valve.
• Never install or operate the appliance if it's possible for the water pressure to exceed 120
psi.
• If the water pressure is lower than 14.5 psi, you can use an auxiliary pump to
compensate.
• Make sure there is no water leakage when making the water connections. Otherwise,
there will be water on the floor and the cabinets may get damaged.
• Do not install the unit on the hot water inlet.
• If you do not know how to check the water pressure, please consult a professional
plumber.
6
Water Pressure
IMPORTANT SAFETY INSTRUCTIONS

ENERGY SAVING TIPS
WARNING
Connecting your refrigerator to systems that save energy is
dangerous and may cause damage on the product.
• Do not leave the doors of your refrigerator open for a long time.
• Do not put hot food or liquids in your refrigerator.
• Do not overload the refrigerator. Cooling capacity will decrease when the air circulation
in the refrigerator is hindered.
• Do not place the refrigerator in places subject to direct sunlight. Install the product at
least 11 3/4" away from heat sources such as microwaves, ovens, heater units, and gas
ranges, and at least 2" away from electrical ovens.
• Store food and liquids in your refrigerator inside closed containers.
• You can remove the drawer shelf of the freezer compartment to fill it with the maximum
amount of food. The energy consumption value of the freezer is determined with the
shelves and drawers removed and the freezer filled with maximum amount of food. There
is no harm in using a shelf to store appropriately sized food items.
• Thawing frozen foods in the refrigerator compartment both saves energy and preserves
the quality of the foods.
ATTENTION
The temperature of the room where your refrigerator is located should at
least be 61°F (16°C). Operating your refrigerator under cooler conditions
is not recommended in terms of energy efficiency.
ATTENTION
The inside of your refrigerator must be cleaned thoroughly.
ATTENTION
If two units are to be installed side by side, there should be at least 1 1/2"
of distance between them.
7
Energy Saving Tips
IMPORTANT SAFETY INSTRUCTIONS

RECOMMENDATIONS FOR THE REFRIGERATOR COMPARTMENT
• Make sure that the food does not touch the temperature sensor in the refrigerator
compartment. To allow the refrigerator to maintain its ideal storage temperature, the
sensor must not be hindered by food.
• Do not place hot foods or liquids inside the refrigerator.
INITIAL USE
• Before using the product, make sure that all preparations have been made in accordance
with the instructions provided in the built-in refrigerator installation manual.
• Clean the interior of the refrigerator as recommended in the "Maintenance and Cleaning"
section of this manual (page 23). Before plugging in the refrigerator for the first time,
make sure that the interior is dry.
• Plug the refrigerator into a grounded socket. The interior becomes illuminated when the
door of the refrigerator is opened.
• Plug the unit in for a minimum of 6 hours without placing any food in it and do not open
the door unless it is necessary.
ATTENTION
You will hear a noise when the compressor starts up. The liquids and
gases sealed within the cooling system may also create noise even if
the compressor is not running; this is quite normal.
ATTENTION
Front edges of the refrigerator may feel warm. This is normal. These
areas are designed to be warm to avoid condensation.
• Take necessary measures against risk of freezing in the unit's water hoses.
• The water temperature operating range must be 0.6°C (33°F) minimum and 38°C
(100°F) maximum.
WARNING
Never connect the product to a cold water main with a pressure of
5.5 bars (80 psi) and above.
8
Initial Use
IMPORTANT SAFETY INSTRUCTIONS

1. Water filter
2. Door bin
3. Body shelf (adjustable height)
4. Water dispenser
5. Gallon door bin (adjustable height)
6. Odor filter
7. Crisper
8. Control display
9. Flex drawer
10. Ice maker
11 . Ice storage bin (includes ice scooper)
12. Upper freezer drawer
13. Lower freezer drawer
14. Condenser cover
9
Product Specifications
OPERATION 30" REFRIGERATORS
1
4
6
8
9
7
12
10
11
13
14
3 2
5

1. Water filter
2. Door bin
3. Body shelf (adjustable height)
4. Water dispenser
5. Gallon door bin (adjustable height)
6. Odor filter
7. Crisper
8. Control display
9. Flex drawer
10. Ice maker
11 . Ice storage bin (includes ice scooper)
12. Condenser cover
13. Upper freezer drawer
14. Lower freezer drawer
10
Product Specifications
OPERATION 36" REFRIGERATORS

iFigures in this user manual are schematic and may not match the product
exactly. If your product does not have relevant parts and/or exact
figures, the information may still apply to other models.
INFO
11
Keys and Controls
OPERATION
CONTROL PANEL

On/Off button
• Serves to turn the appliance On and Off. Press the button to switch on the product — the
product will be switched on in 5 seconds. Press the On/Off button for 1.5 seconds to
switch off.
Function election / Child lock button
• The child lock is a feature for preventing children from changing the product settings. By
pressing the MENU button for 3 seconds, you may lock/unlock the control panel.
• The lock symbol will illuminate on the display when this function is enabled.
Refrigerator compartment temperature adjustment button
• Press the REF TEMP button to adjust the temperature between 36°F (2°C) to 46°F (8°C).
• Super Cool function will be enabled if button is pressed below 36°F (2°C). When the
cool symbol illuminates in the upper temperature display, the Super Cool function will be
enabled and the refrigerator will quick cool to 35°F (1°C).
• The best temperature for refrigerator compartment is 39°F (4°C).
Flex drawer temperature adjustment button
• Press the SPE TEMP button to change the flex drawer temperature between 30°F (-1°C)
and 41°F (5°C).
Freezer compartment adjustment button
• Press the FRE TEMP button to change the freezer compartment temperature between 5°F
(-15°C) to -11°F (-24°C).
• Super Freeze function will be enabled if the button is pressed below -11°F (-24°C).
• When the snow symbol illuminates in the lower temperature display, the Super Freeze
function will be enabled and the refrigerator will quick freeze to -12°F (-24.5°C).
12
Keys and Controls
OPERATION

Vacation Mode
• Press the MENU button until the vacation symbol illuminates, then press the SELECT button
to enable the function.
• When the Vacation Mode function is enabled, the refrigerator temperature will be set at
63°F (17°C) and freezer temperature set at 0°F (-18°C) automatically.
Note: Do not place food in the refrigerator compartment when Vacation
Mode is enabled. To cancel Vacation mode, press the REF TEMP button to
adjust the temperature of the refrigerator to the desired setting.
Sabbath Mode
Press the MENU button until the Sabbath mode symbol illuminates, then press the SELECT
button to enable the function. When the Sabbath mode function is enabled, all lights,
buzzers, and display panels will be switched off.
Eco Mode
Press the MENU button until the Eco Mode illuminates, then press the SELECT button to
enable the function. When the Eco Mode function is enabled, the refrigerator temperature
will be set at 46°F (8 °C) and freezer temperature set at 5°F (-15°C) automatically.
Water Dispenser
Press the MENU button until the water dispenser symbol illuminates, then press the SELECT
button to enable the function. When the water dispensing function is enabled, fresh water can
be provided from the dispenser fitted on the internal wall.
13
Modes and Features
OPERATION

Ice Making
Press the MENU button till the ice making symbol illuminates, then press the SELECT
button to enable the function. When the ice making function is enabled, ice maker will be
automatically operating, and the ice cubes will be accumulated in the ice tray.
Note: Prepare the water filter for use before using the ice. After connecting
the refrigerator to a water source or after replacing the water filter, fill and
discard two full containers of ice.
Water filter Replacement
The water filter symbol flashes and beeps to advise the user to replace the water filter.
After the replacement is completed, press the SELECT button for 5 seconds to reset. The set
replacement time is 130 days. To replace the water filter, search for "water filter" on
www.zlineparts.com, ZLINE's official parts distribution partner.
Celsius and Fahrenheit Selection
Press the MENU button until the Celsius and Fahrenheit selection symbol illuminates to
change between Celsius and Fahrenheit. After that press the SELECT button to confirm.
14
Models and Features
OPERATION

DUAL COOLING SYSTEM
Your refrigerator is equipped with two separate cooling systems to cool the refrigerator
compartment and freezer compartment. Thus, the air and odor in the refrigerator
compartment and the freezer compartment do not get mixed. Thanks to these two separate
cooling systems, cooling speeds are much higher than that of other refrigerators. Also,
additional power saving is provided since the defrosting is performed separately.
FREEZING FRESH FOOD
• Take care to wrap foods or place them in a covered container before putting them in the
freezer compartment.
• Hot foods and beverages must cool down to at least room temperature before you put
them in the freezer compartment. Placing warm food into the freezer compartment causes
the cooling system to operate continuously until the food is frozen solid, which is not ideal
for saving energy.
• Freeze foods only that are fresh and in good quality.
• Pack the foods in an airtight manner to prevent them from drying, even if they are going to
be stored for a short time.
• Materials used for packaging must be tear-proof and resistant to cold, humidity, odor,
oils, and acids, and they must also be airtight. Moreover, they must be made from easy-
to-use materials that are suitable for deep-freezing.
• Frozen foods should be used immediately after they are thawed and should never be
refrozen.
• Do not freeze quantities of food that are too large. The quality of the food is best
preserved when it is frozen right through to the core as quickly as possible.
• Placing warm food into the freezer compartment causes the cooling system to operate
continuously until the food is frozen solid.
OPERATION
15
Keys and Controls

RECOMMENDATIONS FOR STORING FROZEN FOOD
• Frozen foods you purchase must be stored according to the conditions and temperatures
determined by the food manufacturer.
• Check the following steps to ensure optimal food quality from the manufacturer and/or
food retailer is maintained:
1. Put packages in the freezer as quickly as possible after purchase.
2. Make sure that the content of the package is labeled and dated.
3. Check whether the "Use By" or "Best Before" date on the packaging is expired or not.
WHERE TO PLACE FOOD
Freezer compartment shelves Various frozen food such as meat, fish, ice
cream, vegetables, etc.
Egg tray Eggs
Refrigeratorcompartmentshelves Food in pans, covered plates, and closed
containers
Door shelvesof refrigerator compartment Small and packaged foods or beverages
(such as milk,fruit juice, beer, etc.)
Crisper Vegetables and fruits
Flex drawer Delicatessen products (cheese, butter, salami,
etc.)
OPERATION
16
Food Storage
