Zmodell Marklin 87210 User manual

Technical data
Operating mode: DCC/MM/SelecTRIX 1 and 2
Max. voltage: 12 V
Type of LEDs: Warm white SMD 0402/RGB SMD 0807
The board is equipped with 2200 µF power buffer.
Functions
F0 - Directionally controlled tail lights (if installed)
F1 - Disco lights
F2 – Lighting of entrance area
F3 – Normal lighting for dance area
F8 – Sound (only with optional sound module)
Default address: 3 (DCC), 01 (SelecTRIX)
Warm white interior lighting (F2, F3) is connected to the
logical level outputs (unamplified); thus, its brightness
cannot be adjusted and already set to the optimal value.
Directionally controlled red tail lights optionally available
(no external resistors required; please inquire your dealer
or manufacturer). The brightness of the red tail lights is
adjustable via configuration variables (CV) in DCC mode:
CV Function Range Default
52 Brightness of tail lights 0-31 31
Installation
1. Carefully remove the roof of the Märklin 87210
Entertainment Car.
2. Unscrew two screws and remove original analog
circuit board.
3. Install the digital circuit board and fix it with two
screws (don’t overtighten them). Make sure the spring
contacts coming from the floor reliably touch soldered
pads on the bottom side of the circuit board.
4. Carefully install the roof back to its place (please note
that the roof can be installed only in one position; check
corresponding pin and hollow on the body of the car and
the bottom side of the roof).
Programming
This digital circuit board comes already programmed; no
adjustments needed. To reset decoder to the factory
defaults, “8" should be written to CV8. In order to restore
all functions after reset, the following values should be
written manually: CV33=1, CV34=2, CV35=4, CV36=16,
CV37=32, CV38=128, CV39=64, CV42=8, CV47=4,
CV64=16, CV137=2.
Digital interior lighting board is based on Doehler &
Haass FH05B function decoder. For more info about
programming, visit Doehler & Haass official website:
https://doehler-haass.de
ATTENTION: This product is intended only for
experienced users! Please perform all operations with all
precautions that apply to work with ESD sensitive
devices. The manufacturer is not responsive for any
damage to the train model and/or digital decoder caused
by improper installation or exceeding the maximum
allowed operating voltage.
facebook.com/zmodelltrains
Email: [email protected]
Made in Ukraine
Art. No: ZDL-MRK-87210
Märklin and SelecTRIX ® are registered trademarks of Gebr. Märklin
& Cie. GmbH, Postfach 860, D-73008 Göppingen, Germany
Doehler & Haass ® is a registered trademark of Doehler & Haass
GmbH & Co. KG, D-81249 Munich, Germany
