ZOLL Base PowerCharger 1x1
Operator’s Manual
3DUW1XPEHU5HY%

The revision level for this document is shown on the front cover.
ZOLL, PowerCharger1x1, QuickCharge, and AutoTest are trademarks of ZOLL Medical Corporation.
© 2002 by ZOLL Medical Corporation. All rights reserved.
Service Policy Warranty
In North America: Consult your purchasing agreement for terms and conditions associated with your warranty.
Outside of North America, consult the ZOLL authorized representative.
In order to maintain this warranty, the instructions and procedures contained in this guide must be strictly followed.
For additional information, please call the ZOLL Technical Service Department 1-800-348-9011 in North America.
(International customers: 781-229-0020).

i
Table of Contents
6HFWLRQ  *HQHUDO,QIRUPDWLRQ  
3URGXFW'HVFULSWLRQ 
+RZWR8VH7KLV0DQXDO
6HFWLRQ'HVFULSWLRQV  
0DQXDO8SGDWHV 
8QSDFNLQ  
:DUQLQ V  
*HQHUDO 
3DWLHQW6DIHW\  
&DXWLRQ 
6SHFLILFDWLRQV 
'LVSOD\V  
&RQWUROV  
=2//%DWWHULHV  
6\PEROV8VHGRQWKH(TXLSPHQW  
6HUYLFH  
6HFWLRQ  2SHUDWLRQ  
2SHUDWLQ &RQWUROVDQG,QGLFDWRUV 
6HWXS  
%DWWHU\&KDU LQ  
&DXWLRQ 
0DQXDO%DWWHU\7HVWLQ 3URFHGXUH  
4XLFN5HIHUHQFH&KDUWIRU%DVH3RZHU&KDU HU [ZLWK$XWR7HVW  
4XLFN5HIHUHQFH&KDUWIRU%DVH3RZHU&KDU HU [ZLWK4XLFN&KDU H 
6HFWLRQ  0DLQWHQDQFHDQG7URXEOHVKRRWLQ  
,QVSHFWLRQ  
&OHDQLQ  
2SHUDWLRQDO&KHFNV  
7URXEOHVKRRWLQ  
6HFWLRQ  %DWWHU\0DQD HPHQW 
=2//%DWWHU\3DFNV  
%DWWHU\/LIH([SHFWDQF\ 
/RZ%DWWHU\0HVVD H 
%DWWHU\'LVSRVDO 
6HFWLRQ  (0&6SHFLILFDWLRQV 
*XLGDQFHDQG0DQXIDFWXUHU¶V'HFODUDWLRQ(OHFWURPD QHWLF(PLVVLRQV 
*XLGDQFHDQG0DQXIDFWXUHU¶V'HFODUDWLRQ(OHFWURPD QHWLF,PPXQLW\ 
*XLGDQFHDQG0DQXIDFWXUHU¶V'HFODUDWLRQ(OHFWURPD QHWLF,PPXQLW\1RQ/LIH
6XSSRUWLQ (TXLSPHQW  

ZOLL Base PowerCharger 1x1 Operator’s Manual
ii
5HFRPPHQGHG6HSDUDWLRQ'LVWDQFHVIRU5)&RPPXQLFDWLRQV(TXLSPHQW1RQ/LIH
6XSSRUWLQ (TXLSPHQW 

1
Section 1
General Information
3URGXFW'HVFULSWLRQ
The ZOLL Base PowerCharger 1x1 (with QuickCharge or AutoTest) is a battery charger and testing system designed for
management of Battery Packs used in ZOLL Medical Corporation resuscitation devices.
The ZOLL Base PowerCharger 1x1 can be configured in either the AutoTest or QuickCharge mode. This configuration is
performed by ZOLL Medical Corporation prior to device shipment. The Base PowerCharger1x1 is clearly labeled AutoTest or
QuickCharge on the charger label directly beneath the product name.
$XWR7HVW
The ZOLL Base PowerCharger 1x1 with AutoTest automatically tests battery capacity with each battery recharge (when the
battery has been depleted for 10 minutes or more) and illuminates the BATT. READY indicator when the battery is fully
charged. With AutoTest, the full charging cycle is complete in eight (8) hours or less for the PD4410/Smart Battery and fifteen
(15) hours or less for the XL Smart Battery. The AutoTest feature virtually eliminates the need to periodically test battery
capacity since this test is performed each time a battery is recharged. See the M Series Operator's Manual for battery run
time information.
4XLFN&KDU H
The ZOLL Base PowerCharger 1x1 with QuickCharge illuminates the BATT. READY indicator when the battery is fully charged.
The full charging cycle is complete in four (4) hours or less for the PD 4410/Smart Battery and eight (8) hours or less for the
XL Smart Battery . The QuickCharge version provides no information regarding battery capacity because it does not test
capacity with each recharge. The ZOLL Base PowerCharger 1x1 with QuickCharge relies on the user to manually initiate the
battery test cycle at recommended intervals (see Manual Battery Testing Procedure) in order to confirm adequate battery
capacity.
+RZWR8VH7KLV0DQXDO
This manual provides information necessary for the use and care of the Base PowerCharger 1x1 and ZOLL Batteries. A
thorough understanding of this information is required for proper charging and maintenance of ZOLL Batteries. Reliable
operation of ZOLL Medical Corporation resuscitation devices requires proper battery care.
6HFWLRQ'HVFULSWLRQV
This manual is divided into five sections. The operator should read each section carefully.
6HFWLRQ*HQHUDO,QIRUPDWLRQ
Provides Cautions, Warnings and a general product overview of the Base PowerCharger 1x1. Includes detailed product
specifications and important ZOLL service information.
6HFWLRQ2SHUDWLRQ
Describes the function of all controls and indicator lights of the Base PowerCharger 1x1. Discusses proper setup of the Base
PowerCharger 1x1 and provides charging and testing instructions.
6HFWLRQ0DLQWHQDQFHDQG7URXEOHVKRRWLQ 
This section describes several routine checks to assure proper unit operation. It includes cleaning and maintenance
instructions and troubleshooting guides intended for use by nontechnical personnel.
6HFWLRQ%DWWHU\0DQD HPHQW
Provides information for determining your particular battery requirements and program implementation steps to setup a
comprehensive, effective and safe battery management program.
6HFWLRQ(0&6SHFLILFDWLRQV
Provides detailed product information pertaining to EMC Emissions and Immunity testing.

ZOLL Base PowerCharger 1x1 Operator’s Manual
2
0DQXDO8SGDWHV
If you purchased your product more than three years ago,
contact ZOLL to determine whether updates to your
documentation are available. For information relating to
recent manual updates, contact ZOLL Medical
Corporation's Technical Service Department at 1-781-229-
0020.
8QSDFNLQ
Carefully inspect each container for damage. If the shipping
container or cushion material is damaged, it should be kept
until the contents have been checked for mechanical and
electrical integrity. If the contents are incomplete, if there is
mechanical damage, or if the instrument does not pass its
electrical self-test, customers should call ZOLL's Technical
Service Department at 1-781-229-0020.
The following items are packed in the Base
PowerCharger 1x1 shipping container:
•Base PowerCharger 1x1
•Base PowerCharger 1x1 AC Power Cord
•1 Base PowerCharger 1x1 Operator’s Guide

3
General Information
Warnings and Cautions
:DUQLQ V
*HQHUDO
•The Base PowerCharger 1x1 has been tested against
interference from radio frequency emissions typical
of two-way radios used in emergency service/public
safety activities. Users of the Base
PowerCharger 1x1 should refer to Section 5 to
determine recommended operation distances from
RF transmission equipment.
•Use only the AC power line cord supplied with the
device. Failure to use the proper line cord could
result in excess leakage currents and reduced
safety.
•Do not disassemble the Base PowerCharger 1x1. A
shock hazard exists. Refer all problems to ZOLL
Technical Service.
•Follow all recommended maintenance instructions.
If a problem occurs, obtain service immediately. Do
not use the Base PowerCharger 1x1 until the unit has
been inspected by the appropriate personnel.
•Do not place anything on top of or beneath the Base
PowerCharger 1x1, such as blankets or cloths. Doing
so may block the vents on the unit, preventing
proper dissipation of heat during operation.
•Do not use adjacent to or stacked with other
equipment. If adjacent or stacked use is necessary
the Base PowerCharger 1x1 should be observed to
verify normal operation.
•Do not sterilize the Base PowerCharger 1x1.
•Do not use alcohol or ketones (MEK, acetone, etc.)
on the Base PowerCharger 1x1.
•Always wait until the Base PowerCharger 1x1 has
completed its charge cycle before removing
batteries.
•Repeated use of partially charged batteries will
reduce their capacity and operating life.
•Do not use a battery unless the BATT. READY
indicator is lit and the FAULT light is off. Failure to do
so may result in the use of a fully depleted battery.
•Do not install batteries into Monitor/Defibrillators
when storage may exceed 90 days. Battery damage
may occur.
2SHUDWRU6DIHW\
•Do not operate the Base PowerCharger 1x1 in the
presence of flammable agents (such as gasoline),
oxygen-rich atmospheres, nitrous oxide, or
flammable anesthetics. Using the device near the
site of a gasoline spill may cause an explosion.
•Do not immerse or set the Base 3RZHU&KDUJHU [ in
liquid. Using the device near or within puddles of
water may present a shock hazard to the operator,
patient, and nearby personnel.
3DWLHQW6DIHW\
•Do not mount the device directly above the patient.
Locate the Base 3RZHU&KDUJHU [ and ZOLL
resuscitation devices where they cannot harm the
patient if they fall.
&DXWLRQ
•When a fully charged battery is placed into the Base
PowerCharger 1x1 with the AutoTest, the AutoTest
will NOT activate and the BATT. READY indicator
will illuminate within a few minutes after inserting the
battery into the charger. Since the AutoTest
sequence is not performed, it is possible to have a
shorter battery run time than expected.

ZOLL Base PowerCharger 1x1 Operator’s Manual
4
6SHFLILFDWLRQV
%DVH3RZHU&KDU HU [
*HQHUDO
'LVSOD\V
&RQWUROV
=2//%DWWHULHV
Size 8.2 cm H x 15.8 cm W x 31.8 cm L
(3.2 in. x 6.2 in. x 12.5 in.)
Weight 2.1 kg (4.5lbs) without batteries.
Equipment
Classification
Class 1, No Patient Applied Parts,
Ordinary, Portable, Continuous Operation
Input Rating 100-120 VAC, 50/60 Hz, 340mA. (or)
220-240 VAC, 50/60 Hz, 170mA.
Safety
Standards
Designed to meet or exceed:
EN60601-1 Medical Electrical Equipment
Part 1: General Requirements for Safety.
Designed to meet or exceed:
IEC 60601-1-2 Medical Electrical
Equipment Part 1-2: General
Requirements for Safety.
Collateral standard:
Electromagnetic Compatibility -
Requirements and Tests.
UL2601-1 Standard for Medical Electrical
Equipment. Part 1: General Requirements
for Safety with respect to Electrical Shock,
Fire and Mechanical Hazards only.
(UL Classification mark associated with
100-120 VAC input only.)
Recharge Time
QuickCharge Four hours or less for total recharge of fully
depleted battery for PD 4410/Smart
Battery. Eight hours or less for XL Smart
Battery.
AutoTest Eight hours or less for AutoTest and total
recharge of battery for PD 4410/Smart
Battery. Fifteen hours or less for XL Smart
Battery.
Temperature 5 °C to 40 °C(operating)
15°C to 35°C (optimal battery charging)
-40°C to 70°C (storage and transportation)
Humidity 5% to 95% (relative humidity - non
condensing).
External Fuses (2 ) 400 mA/250V Time Delay fuses for
100-120 VAC input.
(2) 200mAL/250V, Type T fuses for
220-240 VAC input.
POWER Illuminates when Base PowerCharger 1x1 is
plugged into live AC mains.
CHARGER ON Indicates battery is being charged.
BATT. READY Illuminates when the charge cycle is
complete.
FAULT Illuminates when battery capacity test or
battery compartment test fails
TESTING Illuminates when either a battery test or a
battery compartment test is in progress.
Base PowerCharger1x1 with AutoTest only:
Illuminates with the CHARGER ON light
during AutoTest and recharge of the battery.
TEST Button Illuminates TESTING indicator light and
initiates battery test cycle or battery
compartment test.
Automatically charges, discharges and
recharges the battery.
Type Rechargeable , sealed lead acid.
ZOLL Battery Pack PD 4410
ZOLL Smart Battery
ZOLL XL Smart Battery
Weight PD 4410/Smart Battery: 1 kg (2.2 lbs)
XL Smart Battery: 1.68 kg (3.7 lbs)
Size PD 4410/Smart Batttery:
4 cm H x 7 cm W x 18.9 cm L
(1.58 in. x 2.78 in. x 7.44 in.)
XL Smart Battery:
9.4 cm H x 7 cm W x 20 cm L
(3.7 in. x 2.78 in. x 7.9 in.)
Capacity PD 4410/Smart Batttery:
2.5 Amp Hour rating for new batteries
XL Smart Battery:
4.5 Amp Hour rating for new batteries
Nominal Battery
Voltage
2.0 V/cell; 5 cells.
Temperature 0 °C to 50 °C(operating)
15°C to 35°C (optimal battery charging)
-40°C to 70°C (storage and transportation)
Humidity 5% to 95% (relative humidity - non
condensing).
Capacity Test At a minimum, test batteries every three
months. Refer to ZOLL’s Battery
Management Program brochure.

5
General Information
6\PEROV8VHGRQWKH(TXLSPHQW
Any or all of the following symbols may be used in this
manual or on this equ equipment:
6HUYLFH
Should the Base PowerCharger 1x1 require service, return it
in its orginal container, to the nearest authorized ZOLL
Medical Corporation service center.
Attention Refer to manual for more
information
Protective (earth) ground terminal
Alternating current
Conformité Européenne Complies with
the medical device directive 93/42/EEC

ZOLL Base PowerCharger 1x1 Operator’s Manual
6
(This page intentionally left blank.)

7
Section 2
Operation
Refer to the Operating Controls and Indicators section on the next page for a description of each number.All references to
Base PowerCharger 1x1 refer to AutoTest and QuickCharge unless otherwise specified.
2345 1 6

ZOLL Base PowerCharger 1x1 Operator’s Manual
8
2SHUDWLQ &RQWUROVDQG,QGLFDWRUV
The ZOLL Base PowerCharger 1x1 with AutoTest
automatically tests battery capacity with each battery
recharge. In addition, the ZOLL Base PowerCharger 1x1 with
AutoTest illuminates the BATT. READY indicator when the
battery is fully charged. Fully charged batteries whose
capacity is insufficient will cause the FAULT light to
illuminate. See the M Series Operator's Manual for run time
information. With AutoTest, the full charging cycle is
complete in 8 hours or less for the PD 4410/Smart Battery
and 15 hours or less for the XL Smart Battery.
The ZOLL Base PowerCharger 1x1 with QuickCharge
provides no information regarding battery capacity because
it does not test the battery capacity with each recharge. The
ZOLL Base PowerCharger 1x1 with QuickCharge relies on
the user to manually initiate the battery test cycle at
recommended intervals (see Manual Battery Testing
Procedure) in order to confirm adequate battery
capacity.The Base PowerCharger 1x1 with QuickCharge
illuminates the BATT. READY indicator when the battery is
fully charged. The full charging cycle is complete in 4 hours
or less for the PD 4410/Smart Battery and 8 hours or less
for the XL Smart Battery.
 32:(5
Illuminates when the Base PowerCharger 1x1 is connected to
live AC mains and the unit is ready for charging and/or
testing.
 &+$5*(521
Illuminates when a battery is properly installed in the
charging/testing compartment and the test/charge cycle is in
progress.
Illuminates with the TESTING light during AutoTest and
recharge of the battery.
 %$775($'<
AutoTest
Illuminates at the end of a test/charge cycle to indicate that
the battery has been charged to 100% of its present
capacity and is ready for use.
Indicates the battery compartment or battery has passed the
capacity test and is operating properly.
QuickCharge
Illuminates at the end of a charge cycle to indicate that the
battery has been charged to 100% of its present capacity
and is ready for use.
If using a QuickCharge unit the BATT. READY light does
NOT give any indication as to the available run time left in
the battery.
 )$8/7
Illuminates, with the TESTING light, when battery capacity
test fails. Also, illuminates when a battery compartment or
any other failure occurs.
 7(67,1*
Illuminates when either battery capacity test cycle is in
progress or battery compartment test is completed.
Illuminates with the BATT. READY light (Manual Test Only)
indicating a good fully charged battery.
Illuminates with the FAULT light to indicate a battery that
has failed the capacity test.
Illuminates with the CHARGER ON light during AutoTest
and recharge of the battery.
 7(67EXWWRQ
Initiates battery test cycle or battery compartment test. The
battery capacity test cycle automatically charges,
discharges and recharges the battery.
If a battery is installed in the battery compartment and the
TEST button is pressed, a capacity test is performed. If the
battery compartment is empty and the TEST button is
pressed, a compartment test is performed.
6HWXS
Place the Base PowerCharger 1x1 on a stable secure
surface. There must be at least 4 inches of clear space
around the unit to allow for proper heat dissipation during
charging or testing batteries. Do not place anything on top of
or beneath the unit, such as blankets or cloths. Doing so
may block the vents on the unit, preventing proper
dissipation of heat during operation.
Turn the unit on by plugging the line cord into the power
module at the rear of the unit and then into live AC mains.
%DWWHU\&KDU LQ
When using AutoTest, proper placement of the battery into
the compartment will automatically initiate the test and
charging cycle, however, when using QuickCharge units,
only the charging cycle will be initiated.
To charge a battery:
1. Check to see that the unit is connected to live AC mains.
The POWER light should be lit.
&DXWLRQ
•:KHQDIXOO FKDUJHGEDWWHU LVSODFHGLQWRWKH%DVH
3RZHU&KDUJHU [ZLWKWKH$XWR7HVWWKH$XWR7HVWZLOO
127DFWLYDWHDQGWKH%$775($'<LQGLFDWRUZLOO
LOOXPLQDWHZLWKLQDIHZPLQXWHV6LQFHWKH$XWR7HVW
VHTXHQFHLVQRWSHUIRUPHGLWLVSRVVLEOHWRKDYHD
VKRUWHUEDWWHU UXQWLPHWKDQH[SHFWHG7RLQLWLDWHD
WHVWRIDIXOO FKDUJHGEDWWHU IROORZWKHLQVWUXFWLRQV
XQGHUWKH0DQXDO%DWWHU\7HVWLQ 3URFHGXUH

9
Operation
2. Insert battery into the compartment. Make sure the
battery is fully seated (A click can be heard).
3. The CHARGER ON and TESTING indicators illuminate
and remain on during complete AutoTest and recharge
cycle (shown). Only the CHARGER ON indicator
illuminates during a QuickCharge recharge cycle.
4. In 8 hours or less for the PD 4410/Smart Battery or 15
hours or less for the XL Smart Battery (using AutoTest)
the CHARGER ON light will go off and the BATT.
READY light will illuminate indicating the battery has
passed the capacity test and is fully charged and ready
for use.
In 4 hours or less for the PD 4410/Smart Battery or 8
hours or less for the XL Smart Battery (using
QuickCharge) the CHARGER ON light will go off and the
BATT. READY light will illuminate indicating the battery
has been charged to 100% of its present capacity and is
ready for use.
If the battery or charger is not capable of charging, the
FAULT light will illuminate and the CHARGER ON light
may stay on. Before discarding the battery, test the
battery compartment for defective operation (see
Operational Checks Section) and perform a second
battery test.
5. To remove the battery, insert a finger into the recess at
the top of the battery compartment, press against the
battery to disengage the battery locking clip and lift the
battery out. A charger test is performed illuminating all
LED's briefly followed by the BATT. READY and
TESTING indicators illuminating for 2 seconds and then
all LED's go off except for the POWER LED.
0DQXDO%DWWHU\7HVWLQ 3URFHGXUH
Although this test is available, the Auto Test feature
eliminates the need to manually test batteries since battery
capacity is automatically tested with each battery recharge
(except when a fully charged battery is placed in the unit).
It is not necessary to insert a fully charged battery for
testing; the Base PowerCharger 1x1 will automatically test the
battery regardless of charge status.
To test a battery:
1. Check to see that the Base PowerCharger 1x1 is con-
nected to live AC mains. The POWER light should be
lit.
2. ,QVHUWEDWWHU LQWRWKHFKDUJHU0DNHVXUHWKHEDWWHU 
LVIXOO VHDWHG(A click can be heard).
3. Press the TEST button. The TESTING indicator light will
illuminate for the duration of the test cycle.
4. If the battery passes the test, the BATT. READY light will
illuminate while the TESTING light remains lit indicating
the battery is fully charged and ready to use. See the M
Series Operator's Manual for run time information.
5. If a battery fails the test, the FAULT light will illuminate
while the TESTING light remains lit. Before discarding
the battery, test the battery compartment for possible
defective operation (See Operational Checks Section).
Repeat Battery test.
6. Record the date and results of the test on the battery
label.

ZOLL Base PowerCharger 1x1 Operator’s Manual
10
4XLFN5HIHUHQFH&KDUWIRU%DVH3RZHU&KDU HU [ZLWK$XWR7HVW
7KHIROORZLQJFKDUWGHVFULEHVWKHRSHUDWLRQRIWKH%DVH3RZHU&KDUJHU[ZLWK$XWR7HVW7KHFKDUWRQWRSUHSUHVHQWV
QRUPDO/('RSHUDWLRQIRUWKH%DVH3RZHU&KDUJHU[ZLWK$XWR7HVWZKHQDJRRGEDWWHU LVLQVWDOOHGLQWKH
FRPSDUWPHQW7KHERWWRPFKDUWUHSUHVHQWVWKH%DVH3RZHU&KDUJHU[ZLWK$XWR7HVWZKHQDEDGEDWWHU LVLQVWDOOHGLQ
WKHFRPSDUWPHQW,OOXPLQDWLRQRIVSHFLILFLQGLFDWRUOLJKWVWRJHWKHUUHSUHVHQWDVSHFLILFPRGHRIRSHUDWLRQGHVFULEHGLQ
WKH'HVFULSWLRQFROXPQ
/('1250$/23(5$7,21*22'%$77(5<
&+$5*(521 %$77
5($'<
)$8/7 7(67,1* 'HVFULSWLRQ
$XWR7HVW
ZLWK%DWWHU\LQ
&RPSDUWPHQW
ON ON AutoTest is in progress.
ON AutoTest is complete and the
battery is in good condition.
0DQXDO7HVWZLWK
%DWWHU\LQ
&RPSDUWPHQWDQG
³7(67´EXWWRQSXVKHG
ON Manual Test is in progress.
ON ON Manual Test is complete and the
battery is in good condition.
/('23(5$7,21%$'%$77(5<
&+$5*(521 %$77
5($'<
)$8/7 7(67,1* 'HVFULSWLRQ
$XWR7HVW
ZLWK%DWWHU\LQ
&RPSDUWPHQW
ON ON AutoTest is in progress.
ON ON AutoTest is complete and the
battery is NOT usable.
0DQXDO7HVWZLWK
%DWWHU\LQ
&RPSDUWPHQWDQG
³7(67´EXWWRQSXVKHG
ON Manual Test is in progress.
ON ON Manual Test is complete and the
battery is NOT usable.

Operation
11
4XLFN5HIHUHQFH&KDUWIRU%DVH3RZHU&KDU HU [ZLWK4XLFN&KDU H
7KHIROORZLQJFKDUWGHVFULEHVWKHRSHUDWLRQRIWKH%DVH3RZHU&KDUJHU[ZLWK4XLFN&KDUJH7KHFKDUWRQWRS
UHSUHVHQWVQRUPDO/('RSHUDWLRQIRUWKH%DVH3RZHU&KDUJHU[ZLWK4XLFN&KDUJHZKHQDJRRGEDWWHU LVLQVWDOOHGLQ
WKHFRPSDUWPHQW7KHERWWRPFKDUWUHSUHVHQWVWKH%DVH3RZHU&KDUJHU[ZLWK4XLFN&KDUJHZKHQDEDGEDWWHU LV
LQVWDOOHGLQWKHFRPSDUWPHQW,OOXPLQDWLRQRIVSHFLILFLQGLFDWRUOLJKWVWRJHWKHUUHSUHVHQWDVSHFLILFPRGHRIRSHUDWLRQ
GHVFULEHGLQWKH'HVFULSWLRQFROXPQ
/('1250$/23(5$7,21*22'%$77(5<
&+$5*(521 %$77
5($'<
)$8/7 7(67,1* 'HVFULSWLRQ
4XLFN&KDU H
ZLWK%DWWHU\LQ
&RPSDUWPHQW
ON Charging is in progress.
ON Charging is complete
.
0DQXDO7HVWZLWK
%DWWHU\LQ
&RPSDUWPHQWDQG
³7(67´EXWWRQSXVKHG
ON Manual Test is in progress.
ON ON Manual Test is complete and the
battery is in good condition.
/('23(5$7,21%$'%$77(5<
&+$5*(521 %$77
5($'<
)$8/7 7(67,1* 'HVFULSWLRQ
4XLFN&KDU H
ZLWK%DWWHU\LQ
&RPSDUWPHQW
ON Charging is in progress.
ON Charging is complete and the
battery is NOT usable.
0DQXDO7HVWZLWK
%DWWHU\LQ
&RPSDUWPHQWDQG
³7(67´EXWWRQSXVKHG
ON Manual Test is in progress.
ON ON Manual Test is complete and the
battery is NOT usable.

ZOLL Base PowerCharger 1x1 Operator’s Manual
12
(This page intentionally left blank.)

13
Section 3
Maintenance and Troubleshooting
Following is a list of nontechnical operational checks. These
checks should be performed periodically to ensure proper
equipment operation. If during this procedure, the operator
discovers a malfunction, contact ZOLL Technical Service.
,QVSHFWLRQ
Assure that the unit is clean (with no fluid spills) and nothing
is stored on the unit.
Inspect all batteries for good condition.
&OHDQLQ
Clean the Base PowerCharger 1x1, with a soft cloth, mild
soap and water.
Do not immerse any part of the Base PowerCharger 1x1 in
water. Do not use alcohol or ketones (MEK, acetone, etc.).
Do not autoclave the Base PowerCharger 1x1.
2SHUDWLRQDO&KHFNV
1. Connect the unit to live AC mains. All four indicator lights
will illuminate for approximately 4-5 seconds.The
POWER indicator will remain lit while the other lights go
off.
2. With the battery compartment empty, check that all
indicator lights except POWER are off.
3. Press the TEST button to check that the unit is fully
operational.
4. All four indicator lights will illuminate for approximately 4-
5 seconds.
5. If the TESTING light and BATT. READY light remain lit
for three seconds while the other lights go off, the unit is
fully operational without any defects.
6. If the FAULT light remains lit, the unit is defective.
 ,QVHUWDEDWWHU LQWRWKHFRPSDUWPHQW9HULI WKDWWKH
&+$5*(521OLJKWLOOXPLQDWHVLPPHGLDWHO 
7URXEOHVKRRWLQ
The troubleshooting guide provided below is intended for
use by nontechnical personnel during operation. This
section answers many of the common problems or
questions that arise during operation.
If trouble persists after consulting this guide, call ZOLL and
ask for the Technical Service Department.
1. POWER light does not illuminate.
•Check that unit is plugged into an appropriate power
source.
•Check for defective power cord.
•Plug unit into another power source.
•Check for blown fuse.
2. CHARGER ON indicator light does not illuminate when
battery is in compartment.
•Check that battery is properly seated in compartment.
•Check that battery contacts are clean and not
damaged.
•Check that unit is plugged into an appropriate power
source.
•Test the battery compartment for functionality.
•Place another battery in the compartment.
3. TESTING light does not illuminate when TEST button is
pressed.
•Check that battery is properly seated in compartment.
•Check that unit is plugged into an appropriate power
source.
•Verify that battery compartment is fully operational with
no defects.
•Repeat test cycle.
•,IEDWWHU IDLOVVHFRQGWHVWUHPRYHEDWWHU IURPuse.

ZOLL Base PowerCharger 1x1 Operator’s Manual
14
(This page intentionally left blank.)

15
Section 4
Battery Management
Safe, reliable use of all ZOLL devices require a well
designed battery management program to ensure that
adequate battery power is always available.
The 6 key steps to developing a battery program are:
1. Obtain proper equipment.
Plan to have a sufficient number of battery packs and
chargers to insure an adequate supply of fully charged
primary use and spare use batteries.
2. Assign a responsible individual.
Assign the responsibility to an individual who can
oversee all aspects of the program as well as educate
other ZOLL Monitor/Defibrillator users.
3. Define battery exchange and charging routines.
Clinical and technical staff should determine desired use
patterns and an optimum sequence to insure consistent
charging and exchange routines.
4. Ensure sufficient spare battery capability.
A fully-charged spare battery should be kept
immediately available with all ZOLL Monitor/Defibrillator
devices. The availability of more than one spare battery
is recommended in cases where prolonged or repeated
use of the device may be required, such as long
transport situations.
5. Develop backup procedures.
Procedures to maintain appropriate life support (such as
cardiopulmonary resuscitation) should be pre-planned in
the event of a device failure and another battery or
device must be sought.
6. Test batteries regularly.
'HYHORSDWHVWLQJVFKHGXOHDVSDUWRI RXU
RUJDQL]DWLRQ¶VEDWWHU PDQDJHPHQWSURJUDP7KH
DSSURSULDWHIUHTXHQF RIWHVWLQJGHSHQGVRQWKHDJH
RIWKHEDWWHU SDFNDQGWKHIUHTXHQF DQGW SHRI
XVH$VWKHEDWWHU DJHVWHVWLQJVKRXOGEHPRUH
IUHTXHQWVLQFHIDLOXUHZLOORFFXUUDSLGO DWWKHEDWWHU ¶V
HQGRIOLIH$WDPLQLPXP=2//UHFRPPHQGVWHVWLQJ
HYHU WKUHHPRQWKV)RUDGGLWLRQDOLQIRUPDWLRQRQ
%DWWHU 0DQDJHPHQWUHIHUWRWKH=2//%DWWHU 
0DQDJHPHQW3URJUDPRUGHU
=2//%DWWHU\3DFNV
The ZOLL Battery Pack is a five-cell assembly of sealed
lead-acid batteries specifically designed for use with all
ZOLL Monitor/Defibrillator devices.
Lead acid battery packs require full recharging after use.
Continuous short cycle recharging will result in reduced
capacity and early battery pack failure.
%DWWHU\/LIH([SHFWDQF\
Frequency of use, number of batteries used, and the pattern
of discharging and recharging batteries contribute to the
loss of battery charge capacity. Because of this ZOLL
recommends that operators replace and discard used
batteries on a preventive, scheduled basis. The most
effective preventive replacement interval should be based
on anticipated use patterns, battery pack testing results and
experience with the device in actual operation. ZOLL
recommends battery replacement every eighteen months or
sooner.
For more information about such a schedule, contact your
ZOLL Technical Service Representative.
/RZ%DWWHU\0HVVD H
As individual battery capacity diminishes, the amount of
operating time remaining after a LOW BATTERY message
also diminishes. For newer or lesser-used batteries, the
operating time remaining after this warning will be
significantly longer than the operating time remaining on
batteries having seen more use. In either case, this warning
will ultimately lead to defibrillator shut-off, and consequently,
the low battery should be replaced with a fully-charged
battery as soon as possible.
When a LOW BATTERY message is displayed, replace the
battery pack immediately to ensure continuous operation.
%DWWHU\'LVSRVDO
3ODFHWKHEDWWHU LQDQDFLGUHVLVWDQWFRQWDLQHU'LVSRVH
RIWKHEDWWHU LQDFFRUGDQFHZLWKIHGHUDOVWDWHDQGORFDO
UHJXODWLRQV'RQRWLQFLQHUDWHEDWWHULHV%DWWHULHVVKRXOG
EHVKLSSHGWRDUHFODPDWLRQIDFLOLW IRUUHFRYHU RIPHWDO
DQGSODVWLFFRPSRXQGVDVWKHSURSHUPHWKRGRIZDVWH
PDQDJHPHQW

ZOLL Base PowerCharger 1x1 Operator’s Manual
16
(This page intentionally left blank.)
