Zoovilla PTH0351720100 Installation guide

WHITE CAGE WITH COVER
PTH0351720100-PTH0361720100-PTH0371720100
CARE INSTRUCTIONS
Thank you for choosing zoovilla With little care and
maintenance, will provide your pet with comfort
and enjoyment for many years to come!
• To clean panels, use clean water on a damp cloth.
• When assembling zoovilla WHITE CAGE WITH COVER, please handle all
panels and/or hardware with care to avoid any possibilities of damages and/or injuries.
NOTE: Please read all instructions carefully before starting assembly.
Also, we recommend that the unit is fully assembled on a level surface.
Two people are recommended to assemble this product.
zoovilla
WHITE CAGE WITH COVER.
zoovilla WHITE CAGE WITH COVER.

AB
C D
E
BOTTOM COVER X 1PC
CAGE X 1PC FRONT LEFT LEG X 1PC
PARTS LIST
FRONT RIGHT LEG X 1PC
1
NOTE: Please read all instructions carefully before starting assembly.
Also, we recommend that the unit is fully assembled on a level surface.
Two people are recommended to assemble this product.
PTH0351720100-PTH0361720100-PTH0371720100
WHITE CAGE WITH COVER
zoo
villa
TOP COVER X 1PC
FBACK LEGS X 2PCS
GFRONT COVER X 1PC HCAGE DIVIDER X 1PC

ASSEMBLY
2
1
2
PTH0351720100-PTH0361720100-PTH0371720100
WHITE CAGE WITH COVER
zoovilla
Unfold back panel and firmly push into place.
*Note. Ensure the back panel has locked underneath
hooks on top and sides of cage.
Unlatch hook used to lock folded cage together.
Unfold cage as shown below leaving front and back panels folded down
3

ASSEMBLY
3
4
PTH0351720100-PTH0361720100-PTH0371720100
WHITE CAGE WITH COVER
zoovilla
Lift cage and carefully place on Cover Bottom (A)
Unfold front panel and firmly pull into place.
*Note. Ensure the front panel has locked underneath
hooks on top and sides of cage.
If using the separator, insert it on an angle then str
at desired position and lock into place by hooking
onto the sides.
5
6
H
UP
A

ASSEMBLY
4
7
PTH0351720100-PTH0361720100-PTH0371720100
WHITE CAGE WITH COVER
zoovilla
Place Front Cover (G) on Cover Bottom (A) and line up
magnets.
8Insert pieces D (x1), E (x1) and F (x2) as shown below.
G
D
F
F
E

ASSEMBLY
7
9
PTH0351720100-PTH0361720100-PTH0371720100
WHITE CAGE WITH COVER
zoovilla
Guide Cover Top (B) onto unit aligning Front and Back Legs.
To quickly and easily remove tray, remove Front Cover (G)
and slide tray out.
10
B

CONTACT
PTH0351720100-PTH0361720100-PTH0371720100
WHITE CAGE WITH COVER
NOTE: Please read all instructions carefully before starting assembly.
Also, we recommend that the unit is fully assembled on a level surface.
Two people are recommended to assemble this product.
Please check contents before assembly. If any items are missing or
damaged, do not take the unit back to the store. Call [phone]
for customer service and we will save you time by correcting any
problems directly for you.
or email: [email protected]
zoovilla
