ZPE ZPE-THS-U01 User manual

Quick Install Guide
ZPESYSTEMS.COM
ZPE Temperature & Humidity USB Sensor
ZPE-THS-U01
COMPATIBLE WITH
ALL NODEGRID DEVICES
HARDWARE
Cable Included. Detached. USB Mini B to USB Type A.
3 Meters (10 feet)
Channels Channel ID: 00 (Temperature)
Channel ID 01 (Relative Humidity)
Temperature Probe operating range: -40°C to 70°C
Accuracy: ±0.3°C (-20°C to 70°C), max ±0.4°C
Resolution: 0.015°C (typical)
Repeatability: 0.06°C (typical)
Relative Humidity Operating range: 0 to 100% RH
Accuracy: (at 25°C)
Typical: ±2% from 0 to 90% RH
Max: ±2.5% from 0 to 90% RH, ±4.5%
from 90 to 100% RH
Resolution: 0.01% RH (typical)
Repeatability: 0.1% RH
Connecting Wire 0.8—1.5 mm²
DESCRIPTION
Acquire environmental temperature and relative humidity readings.
Easily integrate the compact probe in space-constrained locations,
and get precise measurements from the factory-calibrated, linearized,
and temperature-compensated digital sensor chip. The built-in particle
filter protects the components against dust, soot, and other particle
contaminants. Control and read status using CLI, Web, SNMP, or
Restful APIs.
All rights reserved. September 8, 2022
ASSEMBLED IN THE USA
ZPESYSTEMS.COM +1.844.4ZPESYS
Product Specifications ZPE-THS-U01

Quick Install Guide ZPE-THS-U01
Connect the sensor to any available USB 2.0 or USB 3.0 port on Nodegrid Serial Consoles, Services Routers, or USB hubs connected to Nodegrid hardware.
1
Let’s install your ZPE Temperature & Humidity USB Sensor.
1 2
PWR IN MONITOR USB
ETH 0
NET SERIAL
3 4 1 2 3 4 1 2 3 4 5 6 7 8
Any USB Port on a
Nodegrid Device
or USB hub connected
to Nodegrid hardware
USB Adapter
4 meters
Sensor Cable
0.85 meter
Temperature & Humidity
USB Sensor
Mating Connector
USB Mini B
We suggest placing this product here
*Rack cage may be a different model or size
All rights reserved. September 8, 2022
Inset: Nodegrid Bold SR
For more information, visit the "Sensor Quick Install Guide" section at:
https://www.zpesystems.com/user-manuals/
3
Ensure minimum Nodegrid OS version meets sensor requirements.
Upgrade Nodegrid OS to minimum version 5.4.1
2
OPTIONAL: To configure data collection in ZPE Data Lake, refer to Appendix C in the latest
ZPE Cloud Manual at: https://www.zpesystems.com/user-manuals/
