AboutThisManual
Purpose
TheZXA10C320OpticalAccessConvergenceEquipment(ZXA10C320forshort)isa
2U-heightOLTdevice,whichsatisesthemarketrequirementforsmall-capacityOLT s.
ThismanualdescribesthehardwarestructureoftheZXA10C320.
IntendedAudience
Thismanualisintendedfor:
lPlanningengineer
lInstallationsupervisionengineer
lDebuggingengineer
WhatIsinThisManual
Thismanualcontainsthefollowingchapters:
ChapterSummary
1,ShelfDescribestheshelfstructureandcongurations.
2,CardsDescribesthecards.
3,CablesDescribesthecables.
I
SJ-20130520170233-004|2013-08-31(R1.0)ZTEProprietaryandCondential

II
SJ-20130520170233-004|2013-08-31(R1.0)ZTEProprietaryandCondential

Chapter1
Shelf
Appearance
TheZXA10C320shelfisa19-inchshelfwith2Uinheight.Figure1-1showsthe
appearanceoftheZXA10C320shelf.
Figure1-1ShelfAppearance
Congurations
Figure1-2showsthecongurationsoftheshelf.
Figure1-2ShelfCongurations
Note:
WhentheZXA10C320usesACpowersupply,theACpowercardPRAMisinstalledin
slot3.
TechnicalSpecications
Table1-1liststhetechnicalspecicationsoftheshelf.
1-1
SJ-20130520170233-004|2013-08-31(R1.0)ZTEProprietaryandCondential

ZXA10C320HardwareDescription
Table1-1TechnicalSpecicationsoftheShelf
ItemSpecication
Dimensions86.1mm×482.6mm×270mm(height×width×depth)
Weight2.5kg(empty)
6.9kg(fullconguration)
1-2
SJ-20130520170233-004|2013-08-31(R1.0)ZTEProprietaryandCondential

Chapter2
Cards
TheZXA10C320iscomposedofcardsandafanunit,seeT able2-1.
Table2-1CardList
NameDescriptionFunctionInterface
SMXASwitchingandcontrol
card
Controlsthesystemand
switchesservices.
Providespowersupplytothe
system.
Oneout-of-bandNetwork
Management(NM)interface
Onedebuggingserialport
One10GEopticalinterface
(canbeconguredasoneGE
opticalinterface)
OneGEopticalinterface
OneGEelectricalinterface
Oneenvironmentmonitoring
interface
One-48VDCpowerinterface
GTGH16-portGPON
interfacecard
ProvidesGPONaccess.16GPONinterfaces
GTGO8-portGPONinterface
card
ProvidesGPONaccess.8GPONinterfaces
FTGK48-portP2Pinterface
card
ProvidesP2Paccess.48GE/FEinterfaces
PRAMACpowercardProvidespowersupplytothe
system.
OneACpowerinputinterface
OneDCpoweroutputinterface
Onebatteryinterface
Onetemperaturesensor
interface
MWMTBackplaneProvidestheelectrical
interconnectionofeachcard
inthesystem.
-
FAN-
C320
FanunitProvidesventilationforthe
system.
-
TableofContents
SMXACard................................................................................................................2-2
GPONInterfaceCards...............................................................................................2-5
2-1
SJ-20130520170233-004|2013-08-31(R1.0)ZTEProprietaryandCondential

ZXA10C320HardwareDescription
P2PInterfaceCard.....................................................................................................2-8
PowerCard..............................................................................................................2-10
Backplane................................................................................................................2-12
FanUnit...................................................................................................................2-13
2.1SMXACard
Overview
TheswitchingandcontrolcardSMXAistheserviceswitching,management,andcontrol
centeroftheZXA10C320.
Panel
Figure2-1showsthepaneloftheSMXAcard.
Figure2-1TheSMXAPanel
Indicators
Table2-2describestheindicatorsontheSMXAcard.
Table2-2SMXAIndicatorsDescription
IndicatorStatusDescription
LEDisOFF.Thepoweroftheequipmentisnotsuppliedfromthepanel,
butcanbesuppliedfromthebackplane.
GreenLEDisON.Thepowersupplyfromthepanelisproper.
PWR
RedLEDisON.Thepowersupplyfromthepanelisproper.
LEDisOFF.Thecardisnotpoweredon,ortheCentralProcessingUnit
(CPU)isnotstarted.
GreenLEDashes
slowly(0.5Hz).
Thecardrunsproperly.
GreenLEDisON.lThecardpassestheselftest,butfailstoobtaindata
fromtheswitchingandcontrolcardorNMS.
lThecardisrunningthebootingprogram,orisdown-
loadingasoftwareversionfromtheswitchingandcon-
trolcard.
lThecardcannotoperatebecausethereisnolegalsoft-
wareversion.
RUN
2-2
SJ-20130520170233-004|2013-08-31(R1.0)ZTEProprietaryandCondential

Chapter2Cards
IndicatorStatusDescription
GreenLEDashes
quickly.
Thecardisdownloadingdatafromtheswitchingandcontrol
cardortheNMS.
RedLEDisON.lAseriousfaultoccurstothehardwareofthecard(such
as,thecardfailstopasstheselftest,orthesoftware
versionisincompatiblewiththehardwareversion).
lTheNMSissendingarestartingcommand.
RedLEDashes
slowly(0.5Hz).
Thiscardshouldnotbeinsertedinthisslot(differentfrom
thecongurationontheNMS).
YellowLEDashes
slowly(0.5Hz).
Thesoftwareversionofthecardisincompatiblewiththatof
theswitchingandcontrolcard(auto-updatefunctionisnot
conguredonthecard).Theservicesareproper.
GreenLEDisON.Thecardisamastercard(active). MS
LEDisOFF.Thecardisaslavecard(backup).
HDDRedLEDisON.Thecardisoperatingtheash.Cardplug-in/plug-outis
notallowed.
LEDisOFF.Theopticalinterfaceisdisconnectedorthelinksare
disconnected.
GreenLEDisON.Linksareestablishedontheopticalinterface.
ACT1–ACT2
GreenLEDashes.Theopticalinterfaceisreceivingandsendingdata.
Interfaces
Table2-3describestheinterfacesontheSMXApanel.
Table2-3SMXAInterfacesDescription
InterfaceDescription
CLIThelocaldebuggingserialinterface
10/100MTheout-of-bandNMinterface
MTheenvironmentmonitoringinterface
TTheGEelectricalinterface
E1TheGEopticalinterface
E2The10GEorGEopticalinterface
-48V/-48VGNDThe-48Vpowersocket
Buttons
Table2-4describesthebuttonsontheSMXApanel.
2-3
SJ-20130520170233-004|2013-08-31(R1.0)ZTEProprietaryandCondential

ZXA10C320HardwareDescription
Table2-4SMXAButtonsDescription
ButtonDescription
ON/OFFToenable/disablethepowersupplyoftheequipment
RSTToresetthecard
PrincipleDiagram
Figure2-2showstheprinciplediagramoftheSMXAcard.
Figure2-2SMXAPrincipleDiagram
Table2-5describesthemodulefunctionsofswitchingandcontrolcards.
Table2-5SwitchingandControlCardModuleFunctions
ModuleFunction
SwitchingmoduleTheswitchingcenterofdataservice,implementsdataswitching,
Ethernet,VLAN,multicast,IProute,QoS,andsecurityfunctions.
Managementandcontrol
module
Consistsofcontrolsoftware,protocolprocessingsoftware,overhead
processing,Ethernetswitchingchip,andcontrolCPU,provides
interfacesforcardstoforcedlydownloadversionsandreset
hardware/software,providesonlinedetectionforcards,implements
fandetectionandcontrolfunctions.
ClockmoduleProcessessystemclockandtime,complieswithITU-TG.8262,
G.8264,andG.781.
PowermoduleProvidesinputinterfaceforDCpower,providespowerprotection,
monitoring,lteringfunctions,includinglightning-proof,powerltering,
andpreventionofoverload/underload.
2-4
SJ-20130520170233-004|2013-08-31(R1.0)ZTEProprietaryandCondential

Chapter2Cards
TechnicalSpecications
Table2-6liststhetechnicalspecicationsoftheSMXAcard.
Table2-6TechnicalSpecicationofSMXA
ItemSpecication
Powerconsumption27.5W
Dimensions200.25mm×37mm×225mm(height×width×depth)
Weight1.14kg
2.2GPONInterfaceCards
Overview
TheGPONinterfacecardsprovideGPONaccess.TheZXA10C320supportsthefollowing
GPONinterfacecards:
lGTGH:16-portGPONinterfacecard
lGTGO:8-portGPONinterfacecard
Panel
Figure2-3Figure2-4,andFigure2-4showtheGPONinterfacecardpanels.
Figure2-3GTGHPanel
Figure2-4GTGOPanel
Indicators
Table2-7describestheindicatorsoftheGPONinterfacecards.
2-5
SJ-20130520170233-004|2013-08-31(R1.0)ZTEProprietaryandCondential

ZXA10C320HardwareDescription
Table2-7GPONInterfaceCardsIndicatorDescription
IndicatorStatusDescription
LEDisOFF .lThecardispoweredoff.
lThecarddoesnotmatch.
lCPUisnotstarted.
GreenLEDisON.Thecardself-checkingcompletesbutfailstoreceive
datafromtheswitchingandcontrolcardorNM.
GreenLEDashesquickly.Thecardisdownloadingdatafromthenetwork
managementserver.
GreenLEDashesslowly
(0.5Hz).
Thecardrunsproperly.
RedLEDisON.Thecardhardwareisfaulty.
RedLEDashesslowly(0.5
Hz).
Thecardisinstalledinthewrongslot.
RUN
YellowLEDashesslowly
(0.5Hz).
Thesoftwareversionofthecarddoesnotmatchthat
oftheswitchingandcontrolcard.Auto-updateisnot
conguredonthecard.
LEDisOFF .lNoONUisconguredontheGPONinterface.
lTheGPONinterfacehasnoopticalmodule
installed.
lTheGPONinterfaceisshutdown.
lTheGPONinterfaceisTypeBprotectionport.
GreenLEDashes.TheGPONinterfaceandconnectedONUswork
properly.
ACTi(i=
1–16)
RedLEDisON.TheGPONinterfacehasLOSalarms.
Interfaces
GPONinterfacecardsprovide16/8GPONinterfaces.
Button
TheRSTbuttonisusedforresettingcard.
PrincipleDiagram
Figure2-5showstheprinciplediagramoftheGPONinterfacecards.
2-6
SJ-20130520170233-004|2013-08-31(R1.0)ZTEProprietaryandCondential

Chapter2Cards
Figure2-5GPONInterfaceCardsPrincipleDiagram
Table2-8describesthemodulefunctionsofGPONinterfacecards.
Table2-8GPONInterfaceCardsModuleFunctions
ModuleFunction
Managementandcontrol
module
Managesandcontrolsthecard,implementcardconguration.
PONMACmoduleImplementthePONfunctionsdenedbyITU-TG.984.3.
TMmoduleProcessesdatainservicelayer,includingbandwidthmanagementand
QoSprocess,satisestheSLArequirement.Theprocessfunction
iscompatiblewithTR156.
PONopticalmoduleProvidesPON-Copticalinterface,complieswithITU-TG.984.2.
ClockmoduleProcesssystemclock,complieswithITU-TG.8262,G.8264,and
G.781.
TechnicalSpecications
Table2-9liststechnicalspecicationsoftheGPONinterfacecards.
Table2-9GPONInterfaceCardsTechnicalSpecications
ItemSpecication
PowerconsumptionGTGH:55W
GTGO:30W
Dimensions395.5mm×22.5mm×225mm(Height×Width×Depth)
WeightGTGH:1.000kg
GTGO:0.925kg
2-7
SJ-20130520170233-004|2013-08-31(R1.0)ZTEProprietaryandCondential

ZXA10C320HardwareDescription
2.3P2PInterfaceCard
Overview
TheFTGKcardisa48-portP2Pinterfacecard.ItusesWDMtechnologyandsingleoptical
berfortransmittingandreceiving.
Panel
Figure2-6showstheFTGKpanel.
Figure2-6FTGKPanel
Indicator
Table2-10describestheindicatorsoftheFTGKcard.
Table2-10FTGKIndicatorDescription
IndicatorStatusDescription
LEDisOFF.Thecardispoweredoff,orCPUisnotstarted.
GreenLEDisON.lThecardpassestheselftest,butfailstoobtaindata
fromtheswitchingandcontrolcardorNMS.
lThecardisrunningthebootingprogram,oris
downloadingasoftwareversionfromtheswitching
andcontrolcard.
lThecardcannotoperatebecausethereisnolegal
softwareversion.
GreenLEDashes
quickly.
Thecardisdownloadingdatafromtheswitchingand
controlcardortheNMS.
GreenLEDashes
slowly(0.5Hz).
Thecardrunsproperly.
RedLEDisON.lAseriousfaultoccurstothehardwareofthecard(such
as,thecardfailstopasstheselftest,orthesoftware
versionisincompatiblewiththehardwareversion).
lTheNMSissendingarestartingcommand.
RedLEDashes
slowly(0.5Hz).
Thiscardshouldnotbeinsertedinthisslot(differentfrom
thecongurationoftheNMS).
RUN
YellowLEDashes
slowly(0.5Hz).
Thesoftwareversionofthecardisincompatiblewiththat
oftheswitchingandcontrolcard(auto-updatefunctionis
notconguredonthecard).Theservicesareproper.
2-8
SJ-20130520170233-004|2013-08-31(R1.0)ZTEProprietaryandCondential

Chapter2Cards
IndicatorStatusDescription
LEDisOFF.No.iGE/FEopticalportisnotconnected.
GreenLEDisON.No.iGE/FEopticalportisconnected(LINK).
LEDi(i=1–
48)
GreenLEDashes.No.iGE/FEopticalportissendingandreceivingthedata
(ACTIVE).
Interface
TheFTGKcardprovides48FE/GEopticalinterfaces(24ports,eachportprovides2
interfaces).
PrincipleDiagram
Figure2-7showstheprinciplediagramoftheFTGKcard.
Figure2-7FTGKPrincipleDiagram
Table2-11describesthemodulefunctionsoftheFTGKcard.
Table2-11FTGKModuleFunction
ModuleFunction
Managementandcontrol
module
Implementscardconguration,trafcmanagementandopticalmodule
management,andstatusdetectionofopticalmodule.
SwitchingmoduleImplementsconversionofopticalmoduleandbackplanebus,
implementsVLANandEthernetfunctions.
ClockmoduleSupportsallopticalinterfacetousesystemclockforclock
synchronization.Whenthecardisusedforuplink,thesynchronized
clockfromtheopticalportissenttotheswitchingandcontrolcard
worksasthesystemclock.
P2PopticalmoduleProvidesGE/FEopticalinterface.
2-9
SJ-20130520170233-004|2013-08-31(R1.0)ZTEProprietaryandCondential

ZXA10C320HardwareDescription
TechnicalSpecication
Table2-12liststechnicalspecicationsoftheFTGKcard.
Table2-12FTGKTechnicalSpecication
ItemSpecication
Powerconsumption85W
Dimensions395.5mm×22.5mm×225mm(Height×Width×Depth)
Weight1.51kg
2.4PowerCard
Overview
ThepowercardPRAMcarduses110Vor220VACpowerandprovidespowersupplyto
eachcard.
Panel
Figure2-8showsthePRAMcardpanel.
Figure2-8PRAMPanel
Indicators
Table2-13describestheindicatorsofthePRAMcard.
Table2-13PRAMIndicatorDescription
IndicatorStatusDescription
GreenLEDison.Powerison. PWR
GreenLEDisoffPowerisabnormal.
GreenLEDison.Thebatteryworksproperly.
GreenLEDashes
quickly.
Thebatteryisdischarging,orthebatteryis
reverselyconnected.
BATTERY
GreenLEDisoff.Thebatteryisnotavailable.
Interfaces
Table2-14describestheinterfacesofthePRAMcard.
2-10
SJ-20130520170233-004|2013-08-31(R1.0)ZTEProprietaryandCondential

Chapter2Cards
Table2-14PRAMInterfaceDescription
InterfaceDescription
ACpowerinterface
(100-240VAC50/60HZ)
Connectsto110V/220VACpower.
DCpowerinterface(48V
1.2A)
Provides-48VDCoutput.
48V+connectsto-48V.48-connectsto-48VRTN(-48Vground).
BatteryinterfaceConnectstoastoragebattery.
BAT-connectstothenegativeofthebattery.BAT+connectstothe
positiveofthebattery.
TEMPSENSORConnectstoatemperaturesensor,forbatterytemperature
compensation.
Withoutatemperaturesensor,thedefaulttemperatureissetto25℃
andtheoatingchargevoltageis53.5V.
Button
Table2-15describesthebuttononthePRAMpanel.
Table2-15PRAMButtonDescription
ButtonDescription
ON/OFFToenable/disablethepowersupplyoftheequipment
PrincipleDiagram
Figure2-9showstheprinciplediagramofthePRAMcard.
Figure2-9PRAMPrincipleDiagram
Table2-16describesfunctionsofeachmoduleofthePRAMcard.
2-11
SJ-20130520170233-004|2013-08-31(R1.0)ZTEProprietaryandCondential

ZXA10C320HardwareDescription
Table2-16PRAMModuleFunctions
ModuleFunction
EMI/lightning-proof/surge
protection
ImplementsthepowerinputEMI(ElectromagneticInterference)lter,
lightning-proof,andsurgeprotection.
Over-voltage/under-voltage
protection
Implementsthepowerinputover-voltage/under-voltageprotection.
PFCmoduleImplementsPFC(PowerFactorCorrection)function.
54VmoduleImplementstheconversionfromACvoltageto54VDCvoltage.
Over-temperature
protection
Implementsover-temperatureprotection,protectingthecardfromhigh
temperature.
3.4VmoduleImplements3.4VDCpoweroutput.
Current-limitingmoduleImplementsthechargemanagementandpower-offmanagement.
TechnicalSpecications
Table2-17liststechnicalspecicationsofthePRAMcard.
Table2-17PRAMTechnicalSpecications
ItemSpecication
Powerconsumption13.2W
Dimensions197.75mm×25mm×225mm(Height×Width×Depth)
Weight1.346kg
2.5Backplane
Overview
TheZXA10C320usesbackplanetoconnectthecardstogether.
Interfaces
Thebackplaneprovidesthefollowinginterfaces:
lTheinterfaceforswitchingandcontrolcard
lTheinterfaceforthePONinterfacecardorP2Pinterfacecard
lPowersocketinterface
lFansocketinterface
TechnicalSpecications
Table2-18liststhetechnicalspecicationsofthebackplane.
2-12
SJ-20130520170233-004|2013-08-31(R1.0)ZTEProprietaryandCondential
