ZUMEX Speed Pomegranates Configuration guide

Zumex Group S.A. Tel. [phone]. [e-mail]. Zumex Service Tel: [phone]. www.zumex.com
Disassembly instructions
Cleaning instructions
Speed Pomegranates
CAUTION! For a correct cleaning process, please follow the instructions
below. Before getting started, make sure that the machine is nplugged
from mains power.
Take off the feeder basket.
Press the side tabs to remove the bin.
Take off the automatic PulpOut System,
by lifting the assembly with the part
closest to you.
Pull off the peel ejectors.
Take off the feeder plate by unscrewing
the central knob.
Take off the Pulp cover.
Turn the knobs towards us
counterclockwise to their vertical position
and extract the side outlets.
Remove the blade by pressing on the centre
and pulling the handle towards you.
Caution! Put the protector on the cutting zone.
Remove the Speed Up Tap by easily
unscrewing it.
Clean the front zone of the machine,
following the steps shown and removing
all the particles which have adhered.
Unscrew the securing knobs of the
pressing units.
Take off the pressing units in pairs.
Clean the inside of the podium, following
the steps shown and removing all the
particles which have adhered.
Turn the knobs 90º degrees until they are
aligned with the holes in the cover.
Then extract it.
Remove the stainless-steel peel guides.
Remove the waste trolleys from the base
to empty them.
The cleaning process will be explained in details for each one of the machine’s components below.
15
1
7
4
10
13
2
8
5
11
14
3
9
6
12

Zumex Group S.A. Tel. [phone]. [e-mail]. Zumex Service Tel: [phone]. www.zumex.com
Speed Pomegranates
All the parts, with the exception of the cover and the tap,
can be put in a dishwasher to clean them.
The juicing zone and its removable components must be
cleaned using Citric Active*. Leave to act for one minute
and then proceed to remove the remains of dirt with a
moist sponge.
Do not use scourers which may scratch the surfaces.
Sanitise with a hydroalcoholic disinfectant** after the first
rinse, and leave it to rest for 1 minute.
Rinse with plenty of water after sterilising, in order to
remove any remaining disinfectant.
Dry the parts completely.
Instructions for cleaning the components
Blade, sub-filter, bin, peel guides, feed plate, front cover, and tap
Daily cleaning
Warnings and steps for cleaning and sanitation
It is necessary to clean all parts that come into contact with the juice each day.
* Detergent for food use specific to Zumex Juicers. ** Disinfectant for food use recommended.
Follow the cleaning process indicated, for
all the parts: blade, sub-filter, tank, peel
chutes, etc.
Spray the parts with Citric Active and
allow it to work for 30 seconds.
Clean the cover, following the steps shown
and removing all the particles which have
adhered.
Wash the feeder plate with Citric Active
and a soft sponge, removing all the particles
which have stuck to it.
Unscrew the top part of the tap by
turning the matte ring, and clean the
inside with the brush provided.
21 3
4 5

Zumex Group S.A. Tel. [phone]. [e-mail]. Zumex Service Tel: [phone]. www.zumex.com
Speed Pomegranates
Remove the black upper lid by pushing
upwards on the tabs sticking out.
Clean the conveyor belt and the rest of the
components of the Pulp Out with the
cleaning steps indicated.
Remove the sweeping belt together with
the other roller and remove both parts.
Turn the assembly around and place your
fingers on the sweeping belt by pushing it
outwards to release it.
All the parts can also be washed in a
dishwasher.
From the back, grab the belt and the other
roller and pull towards the other end to
place it on the guides.
Insert the sweeping belt with the roller into
the stainless steel tray.
Place the top cover by lining up the pins
with the grooves on the frame and pressing
on the other end until it clips into place.
Assembly instructions
Automatic PulpOut System
Automatic PulpOut System
Instructions for cleaning the components
2
5
1
4
3
21 3

Zumex Group S.A. Tel. [phone]. [e-mail]. Zumex Service Tel: [phone]. www.zumex.com
Speed Pomegranates
Cover, Juicing system and PulpOut system
Midday cleaning
Turn the knobs 90º degrees until they are
aligned with the holes in the cover.
Then extract it.
Pull off the peel ejectors.
Take off the automatic PulpOut System,
by lifting the assembly with the part
closest to you.
Unscrew the securing knobs of the
pressing units.
Take off the pressing units in pairs.
Remove the blade by pressing on the
centre and pulling the handle towards you.
Caution! Put the protector on the cutting
zone.
Clean the front zone of the machine,
following the steps shown and removing
all the particles which have adhered.
Clean all the parts with the
steps described.
Replacing parts.
For quick cleaning in the middle
of the day, we recommend
having a kit with spare parts.
This Kit is made up of: a cover,
juicing system and PulpOut
system.
Recommended cleaning instructions
Turn the knobs towards us
counterclockwise to their vertical position
and extract the side outlets.
21
65
3
7
4

Zumex Group S.A. Tel. [phone]. [e-mail]. Zumex Service Tel: [phone]. www.zumex.com
Speed Pomegranates
Assembly instructions
Insert the filter tray.
Insert the blade by pressing down until it
clips into place.
Clip the juice tray into place, making sure
that the latches are facing outwards.
Place the stainless steel peel chutes on
either end.
Line up the bottom of the side outlet and
lift up the upper part, ensuring that it
closes by turning the knob 90º.
Place the waste collection trays with new
waste bags on the podium.
Put the peel ejectors in place on their
supports.
Place the PulpOut system on the machine
by attaching it to the guides.
Place the cover and turn the knob 90º.
Install the feeder basket.
Install the pressing units in pairs and screw
on the wheels.
Place the tap next to the bottle holder and
screw the two parts on.
Attach the feeder plate by screwing it onto
the central knob.
Insert the pulp cover.
2
5 6
7
10
13 14
1
4
9
12
3
8
11
