ZyXEL Communications P-660HW-DX V2 - V3.40 User manual

P-660HW-Dx v2
802.11g Wireless ADSL2+ 4-port Gateway
Quick Start Guide
Version 3.40
3/2007
Edition 1

P-660HW-Dx v2 Quick Start Guide
2
Overview
The P-660HW-Dx v2 is a wireless ADSL router with a four-port built-in switch.
This Quick Start Guide shows you how to use the P-660HW-Dx v2 to connect to the Internet and how to
configure the device settings to connect wirelessly.
See your User’s Guide for background information on all features.
Quick Login Information
How to use the included CD
For a multimedia animation of how to make hardware connections, see the installation tutorial on the included
CD.
1On the included CD, click Setup > Multimedia Auto Provisioner
2At the end of the tutorial, use Configuration Genie to set up your P-660HW-Dx v2 to connect to the
Internet.
LAN IP address http://192.168.1.1
default administrator password 1234

P-660HW-Dx v2 Quick Start Guide
3
1 Hardware Connections
1DSL: Use the gray telephone wire to connect your P-660HW-Dx v2’s DSL port to a telephone jack (or to
the modem port on a splitter if you are using one).
2ETHERNET: Use the yellow Ethernet cable to connect a computer to an ETHERNET port for initial
configuration and/or Internet access.
3POWER: Use the included power adaptor to connect an appropriate power source to the POWER socket.
Make sure the power source is on.
4Push in the POWER button.
5Look at the lights on the front panel.

P-660HW-Dx v2 Quick Start Guide
4
•ThePOWER light blinks while your P-660HW-Dx v2 starts up and stays on once it is ready.
• Each ETHERNET light stays on if the corresponding ETHERNET port is properly connected and blinks when
there is traffic.
•TheDSL light is on when the P-660HW-Dx v2 has a DSL connection.
•TheINTERNET light is on when you are able to access the Internet and blinks when the P-660HW-Dx v2 is
sending or receiving data. Wait a couple of minutes while your device checks the connection.
If any of these lights are not on, check your connections and inspect your cables for damage. If the lights are
still off, contact your local vendor.
2 Internet Connection Setup: Automatic
Use this section to have your P-660HW-Dx v2 automatically detect and set up your Internet connection.
1Open your web browser to a website. Wait while your P-660HW-Dx v2 tries to detect your DSL connection
to your ISP. This may take a few minutes.
2After it detects the connection, the DSL light shows green on your device and the Internet light comes on
when the Internet is ready for you to use. If you have a PPPoE connection, you will have to enter your user
name and password.
3Go to section 3if you wish to configure your wireless settings.
4If you do not see the connection test screen, or the connection test is not successful, follow the instructions
in the screen below, or check your connections and restart the P-660HW-Dx v2. If you still cannot access
the Internet, follow the steps in section 3.
3 Internet and Wireless Setup Wizard
Use this wizard to connect to the Internet and configure your wireless settings.
Follow these steps to access the Internet and Wireless Setup Wizard:
1Open your browser and enter the following URL address: http://192.168.1.1.

P-660HW-Dx v2 Quick Start Guide
5
2Type the admin password 1234 (default). Click Login.
Note: If your browser does not display the login screen, see Troubleshooting on page 10 for details.
3Type (and retype) a new password and click Apply. It is strongly recommended that you change the P-
660HW-Dx v2’s password and write it down.
4You have to use a new password other than the default password 1234.
5Enter your new password to log in again.
6Select Go to Wizard setup. Then, click Apply.
4 Connecting to the Internet Using the Wizard
Use this wizard if you could not automatically connect to the Internet in section 2.
The first step of the Internet/Wireless Setup Wizard connects your P-660HW-Dx v2 to the Internet.
1Click INTERNET/WIRELESS SETUP to start the wizard.
2If the Internet Connection test is successful, go to step 7.
3If no DSL connection is detected, check your connections and restart the Internet/Wireless Setup Wizard.

P-660HW-Dx v2 Quick Start Guide
6
4If no ISP settings are detected, click next to go to the following screen. Enter your Internet connection
information exactly as provided by your ISP.
5If you do not see this screen, or your ISP has given you Internet access settings not available on this
screen, see section 6. If you wish to set up a wireless network, complete the Internet/Wireless Setup
Wizard before going to this section.
6Next, select either Obtain an IP Address Automatically or Static IP Address. If you select Static IP
Address then fill out the required fields based on the information provided by your ISP and click Apply.
7If the Internet connection test is successful, either browse to your favorite website or click Next on your
screen to go to section 5to configure your wireless settings.
5 Configuring your Wireless Settings
To create a wireless network, the P-660HW-Dx v2 and your wireless computer must all use the same SSID
(network name), channel and security settings.
If you do not set wireless security then anyone within range could use your P-660HW-Dx v2 to access your
network and the Internet.
Choose WPA-PSK wireless security if your wireless device supports it as it is stronger than WEP. Otherwise
choose WEP.

P-660HW-Dx v2 Quick Start Guide
7
1Select Active and click Next to continue. It is strongly recommended that Enable OTIST is NOT selected.
See section 7 for more information.
2Configure your wireless settings in the screen. Click Next.
3) If you select either WEP or WPA-PSK security (recommended), then follow the directions to enter the
appropriate key. Click Next to continue and Apply to save your wireless LAN settings.

P-660HW-Dx v2 Quick Start Guide
8
4Check your configuration and write down your wireless LAN settings for later use. Click Finish to complete and
save the wizard setup.
5Your Internet is ready for you to use. Open your browser and navigate to your favorite website.
6 Internet Connection Setup Using Advanced Settings
Use this section to set up your Internet connection manually if you do not see the ISP Parameters for Internet
Access screen when you run the wizard (see section 4, step 4).
1Login again. (Follow steps 1to 5in section 3.)
2Select Go to Advanced setup. Then, click Apply.
3The Status screen appears. Click Network > WAN in the navigation panel on the left of the screen.
4) Enter the information exactly as provided by your ISP. Click Apply.

P-660HW-Dx v2 Quick Start Guide
9
Note: The fields available in this screen depend on the Mode and Encapsulation you select
5If you still cannot access the Internet, see Troubleshooting and/or contact your Internet Service Provider
(ISP) for assistance.
7 Setting Up a Wireless Network with OTIST
7.1 About OTIST
ZyXEL's One-Touch Intelligent Security Technology (OTIST) feature allows you to automatically
configure the SSID and WPA-PSK on all OTIST-equipped wireless clients within range of the P-
660HW-Dx v2.
Enable OTIST only if your wireless clients support WPA and OTIST.
You should have already configured wireless settings on the P-660HW-Dx v2 using the wizard.
If you select Disable wireless security using the wireless wizard, the P-660HW-Dx v2 will create a
WPA-PSK automatically.
If you select Manually assign a WEP key using the wireless wizard, the P-660HW-Dx v2 will replace
the WEP key with a WPA-PSK.
You must enable OTIST on the P-660HW-Dx v2 and all wireless clients within three minutes in any
order.

P-660HW-Dx v2 Quick Start Guide
10
7.2 Enabling OTIST
To enable OTIST on the P-660HW-Dx v2, you can either use the wizard (see section 3) or hold in the RESET
button (see section 1) for about three seconds. Do not hold the RESET button in for too long, as this will reset
the P-660HW-Dx v2 to the factory defaults.
To enable OTIST on wireless clients, click Start in the Adapter screen. The Setup Key is 01234567 by default.
If you have previously saved a setup key on the P-660HW-Dx v2, use it instead of the default.
For more information, see Wireless LAN in the User's Guide.
Troubleshooting
1If you cannot access the web configurator,
• Your computer may be set to use a static IP address in a different subnet from the ZyXEL device. See the
appendix in the User’s Guide for information on setting up your IP address.
• If you are using Internet Explorer in Windows XP or Windows Server 2003, make sure you allow pop-up
windows, JavaScripts and Java permissions or set the Internet security level lower than High in Internet
Explorer (in Internet Explorer, click Tools > Internet Options > Security > Custom Level...). See the
appendix in the User’s Guide for more information.
2If you cannot access the Internet when your computer is connected to the ETHERNET port, follow these
steps.
A) Check the lights on the front panel. If they are different from what is described in section 1, make sure
the P-660HW-Dx v2 is correctly connected. (See section 1.) If the lights are still different, turn off the
device, wait a few seconds, and turn it on again.
B) Check you have correctly entered the informatinon your ISP gave you. For example, if your account has
a user name and password, make sure you type it correctly. In addition, if you are not sure which
encapsulation your ISP uses, contact your ISP. If your ISP did not give you Internet connection
information, follow the steps in section 2.
C) If you are using a new Internet account, contact your ISP to make sure it is active.
D) If you still have problems, see Troubleshooting in the User’s Guide.
If you cannot access the Internet after you take the steps above, either try the following or contact your ISP:
E) Turn your P-660HW-Dx v2 off and on. Open your Internet browser if it is not already open.
Let the P-660HW-Dx v2 complete the DSL connection test (this may take several minutes). See section 2for
details.
If the test is successful, check whether you can access the Internet.
F) If the test is unsuccessful or if you cannot access the Internet, log in to the P-660HW-Dx v2’s web
configurator (see section 3).
• Click Network > WAN > Internet Connection. Ensure that the settings in this screen are the same as
those your ISP gave you. If your ISP gave you a static IP address to use, select Static IP Address in
the IP Address section and enter it in the IP Address field. If not, select Obtain an IP Address Auto-
matically. Click Apply.

P-660HW-Dx v2 Quick Start Guide
11
• Click the wizard icon ( ). Run the Internet/Wireless Setup wizard again. Check whether you can
access the Internet.
If you still cannot access the Internet, take the following steps:
• If you are using Bridge mode (check Mode in the Network > WAN > Internet Connection screen) click
NAT > General and ensure Active Network Address Translation (NAT) is not selected. Click LAN >
DHCP Setup and ensure that DHCP is set to None. Your ISP gives your computer an IP address
directly. If you want to access the P-660HW-Dx v2 again, you need to use a static IP address in the
same subnet as your P-660HW-Dx v2 (the P-660HW-Dx v2’s default IP address is http://192.168.1.1).
• Click the wizard icon ( ). Run the Internet/Wireless Setup wizard again. Check whether you can
access the Internet.
If you still cannot access the Internet, contact your Internet Service Provider.
3If you cannot access the Internet using the wireless network, follow these steps.
A) On a computer in the wireless network, open your browser, and go to http://192.168.1.1. If you see the
login screen in section 3, follow suggestions A- Fabove. If you do not, go to the next step.
B) On a computer connected to the P-660HW-Dx v2, make sure your P-660HW-Dx v2 and the computers
on your wireless network are using the same wireless and wireless security settings. See the chapter on
Wireless LAN in the User’s Guide for more information.
Viewing Your Product’s Certifications
1Go to www.zyxel.com.
2Select your product from the drop-down list box on the ZyXEL home page to go to that product's page.
3Select the certification you wish to view from this page.
