ZyXEL Communications DMA-2500 User manual

DMA-2500
Full HD Digital Media
Streamer
DMA-2500
Full HD Digital Media
Streamer
Easily Stream and Enjoy High-Definition
Videos on Your TV
Benefits
Streams 1080p High-Definition Videos from Networked Storage to HDTV
Complying with the high-definition video format and screen specification,home users can enjoy
high-definition video on HDTV and have crisp and clear visual entertainments.
DLNA 1.5 Certified Digital Media Streamer Enhances Media Sharing Experience
Certified with the latest DLNA1.5 standard, the DMA-2500 ensures digital content such as photos,
music and videos to be shared with consumer electronics, PC and mobile devices anywhere at home
without barrier. Moreover, it automatically finds media servers on your home network and allows
home users to access easily
More Media Formats and Subtitles for Hassle-free Enjoyment
DMA-2500 is capable of decoding most popular video and audio codec formats (H.264,WMV9,VC1,
DivX, Xvid,WMA, etc.), as well as playing most popular video files (.MKV, .AVI, .WMV,.ISO,.IFO,.VOB,
.MOV and .MPG, etc.) without limitations.
Built-in DRM-ND Enables Playback of Encrypted Digital Contents
The built-in license keys from Microsoft allow DRM (Digital Rights Management)-protected video to
play via the DMA-2500 without restriction, offering greater flexibility in playing encrypted video and
music files.
Built-in Access to Web TV & Internet Radio Live365
Live365 is an Internet radio network providing about 6,500 active stations for subscribers to access.
By offering such a great feature, home users can listen to their favorite music and radio stations from
all around the world.
Supports ZyXEL Wireless N USB Adapters for Networking Flexibility
DMA-2500 offers the mobility to allow playing media files through a wireless home network, and
now it is also compatible with ZyXEL’s Wireless N USB Adapters such as NWD-211AN and
NWD-270N.
ł
Streams 1080p High-Definition Videos from Networked Storage to HDTV
ł
DLNA 1.5 Certified Digital Media Streamer Enhances Media Sharing
Experience
ł
More Media Formats and Subtitles for Hassle-free Enjoyment
ł
Built-in DRM-ND Enables Playback of Encrypted Digital Contents
ł
Built-in Access to Web TV and Internet Radio Live365
ł
Compatible with Wireless N USB Adapter for Networking Flexibility
ł
Green Product Powered by ENERGY STAR® Qualified Adapter
ł
Compact Design & Friendly User Interface
Powered by an
ENERGY STAR®
qualified adapter
for a better
environment

DMA-2500
Full HD Digital Media Streamer
DMA-2500
Full HD Digital Media Streamer
System Specifications
• Supports media formats and subtitles
- Video standards: H.264, WMV9, MPEG
1/2/4/SD/HD,VC1, DivX, Xvid
- Video file formats: MKV, AVI, WMV, ISO, IFO, MP4,
VOB, ASF, M2TS, MOV,TP,TS, MPG, DivX
- Audio standards:MPEG 1 Layer 1&2,MP3,
MPEG 2 AAC, MPEG 4 AAC, AC3, WMA, OGG
Vorbis, LPCM, DTS pass through, FLAC
- Audio file formats: AAC, AC3, WAV, PCM, MP3,
OGG, WMA, MKA
- Photo formats: JPEG, TIFF, PNG, GIF, BMP
- Subtitles: SRT, SSA, IDX and SUB
• Supports Windows and Linux network file
systems (NFS and SAMBA)
• Supports Live365 Internet radio and Web TV
• Supports BGM (Background Music) to allow
viewing photos and listening to music
simultaneously
• Screen saver
• Support picture zoom in, zoom out,move and
rotate
• View photo in thumbnails mode
• Support photo slide show
• Video resume playing
• Language support—English/German/French/
Italian/Spanish/Dutch/Russian/Polish/Czech/
Traditional Chinese
Network Connections
• Ethernet LAN: 10/100 Mbps, RJ-45
• Wireless 802.11n USB adapter (Compatible with
ZyXEL Wireless N USB Adapters including
NWD-211AN & NWD-270N)
Security
• WEP Encryption 64/128 bit
• WPA-PSK/WPA2-PSK
Power
• Input power: AC 100 ~ 240 Volts/47 ~ 63 Hz/
0.31 A
• Out power: DC 5 Volts/2.5 A/12.5 W
• Power consumption: 12.5 W maximum
Hardware Specifications
• IR receiver
• A/V output: HDMI 1.1, CVBS, S-Video/
Component, S/PDIF (Coaxial)
• Status LED indicator:
- Power
- Network media traffic:Receiving media traffic
through Ethernet
• One LAN port,10/100 Mbps Ethernet RJ-45
• One USB 2.0 mass storage interface
Physical Specifications
• Item weight: 400 g (0.88 lb)
• Item dimensions:
186 (W) x 114 (D) x 38 (H) mm
(7.32 (W) x 4.49 (D) x 1.5 (H) inch)
• Packing weight: 972 g (2.15 lb)
• Packing dimensions:
279 (W) x 162 (D) x 102 (H) mm
(10.98 (W) x 6.38 (D) x 4.01 (H) inch)
Environmental Specifications
• Operating environmental:
- Temperature: 0ºC ~ 50ºC
- Humidity: 10% ~ 90% (Non-condensing)
• Storage environmental:
- Temperature: -40ºC ~ 70ºC
- Humidity: 5% ~ 90% (Non-condensing)
Package Contents
• Digital Media Streamer (DMA-2500)
• Remote control (2 AA batteries included)
• Stand
• Power adapter
• Quick start guide
• HDMI cable
• RCA cable
• Ethernet cable
• Support CD
• Warranty card
Certification
• FCC/CE/DLNA 1.5/HDMI
Specifications
Application Diagram
N
B
G
-460
N
G
i
g
a
b
it Wire
l
ess N
Rout
er wi
t
h VP
N
xDSL/Cable
Modem
I
n
t
erne
t
N
SA-220 Plu
s
Centra
l
Di
g
ita
l
M
e
d
ia Li
b
rary
NWD-2
Dual-
Wire
USB
Front Panel Rear Panel
ON/OFF
HDMI CVBS
VIDEO OUT AUDIO OUT
RIGHT LEFT
ETHERNET
POWER
USB
S/PDIFS-VIDEO
YPbPr
IR Receiver
LED Indicator:
Network Media Traffic
LED Indicator:
Power
Press hotkey on remote
control to easily select
media you want.
65-100-250002B 03/09
For more product information, visit us on the web at www.ZyXEL.com
Copyright © 2009 ZyXEL Communications Corp. All rights reserved. ZyXEL, ZyXEL logo are registered trademarks of
ZyXEL Communications Corp. All other brands, product names, or trademarks mentioned are the property of their
respective owners. All specifications are subject to change without notice.
