User’s Guide
ES1100 Series
Unmanaged Fast Ethernet Switches
Copyright © 2019 Zyxel Communications Corporation
Version 1.00 Edition 5, 07/2019

ES1100 Series User’s Guide
2
IMPORTANT!
READ CAREFULLY BEFORE USE.
KEEP THIS GUIDE FOR FUTURE REFERENCE.
This is a User’s Guide for a series of products. Not all products support all firmware features. Screenshots
and graphics in this book may differ slightly from your product due to differences in your product
firmware or your computer operating system. Every effort has been made to ensure that the information
in this manual is accurate.
Related Documentation
•MoreInformation
Go to support.zyxel.com to find other information on the Switch.

Document Conventions
ES1100 Series User’s Guide
3
Document Conventions
Warnings and Notes
These are how warnings and notes are shown in this guide.
Warnings tell you about things that could harm you or your device.
Note: Notes tell you other important information (for example, other things you may need to
configure or helpful tips) or recommendations.
Syntax Conventions
• All models may be referred to as the “Switch” in this guide.
Icons Used in Figures
Figures in this user guide may use the following generic icons. The Switch icon is not an exact
representation of your device.
Switch Generic Router Wireless Router / Access Point
Generic Switch Server Desktop
Laptop Analog Camera Printer

Table of Contents
ES1100 Series User’s Guide
4
Table of Contents
Document Conventions ......................................................................................................................3
Table of Contents.................................................................................................................................4
Chapter 1
Getting to Know Your Switch ..............................................................................................................5
1.1 Overview ........................................................................................................................................... 5
1.1.1 Power over Ethernet (PoE) ..................................................................................................... 6
1.2 Applications ...................................................................................................................................... 6
1.2.1 Backbone Example Application ........................................................................................... 6
1.2.2 Bridging Example Application ............................................................................................... 7
1.2.3 PoE Example Application ....................................................................................................... 8
Chapter 2
Hardware Description and Connection.............................................................................................9
2.1 Rear Panel ...................................................................................................................................... 9
2.1.1 Rear Panel Power Connection ............................................................................................ 10
2.2 Front Panel ...................................................................................................................................... 10
2.2.1 RJ-45 Auto-negotiating Ports ............................................................................................... 10
2.2.2 IEEE 802.3az Energy Efficient Ethernet ................................................................................. 11
2.2.3 Front Panel Connections ...................................................................................................... 11
2.2.4 Front Panel LEDs .................................................................................................................... 11
2.3 Hardware Installation ..................................................................................................................... 12
2.3.1 Wall Mounting ....................................................................................................................... 13
2.3.2 Rack Mounting ...................................................................................................................... 14
2.3.3 Mounting the Switch on a Rack .......................................................................................... 15
Chapter 3
Troubleshooting..................................................................................................................................17
3.1 Improper Network Cabling and Topology .................................................................................. 18
Appendix A Customer Support ....................................................................................................... 19
Appendix B Legal Information ......................................................................................................... 25
Index...................................................................................................................................................29

ES1100 Series User’s Guide
5
CHAPTER 1
Getting to Know Your Switch
1.1 Overview
This User’s Guide covers the following models: ES1100-8P, ES1100-16, ES1100-16P, ES1100-24, and ES1100-
24E. The Switch can be used to build high-performance switched workgroup networks.
The following features apply to all models:
• Conforms to IEEE 802.3, 802.3u, and 802.3x wired Ethernet standards.
• 10/100 Mbps Fast Ethernet RJ-45 ports.
• Auto-negotiating Ethernet RJ-45 ports.
• Auto-sensing crossover for all RJ-45 ports.
• Supports N-Way protocol for speed (10/100/1000 Mbps) and duplex mode (Half/Full) auto-detection.
• Supports store-and-forward switching.
• Supports automatic address learning (8000 MAC addresses for ES1100-16, ES1100-16P, ES1100-24, and
ES1100-24E; 1000 MAC addresses for ES1100-8P).
• Full wire speed forwarding rate.
• 802.1p CoS support.
• Inactive link detection to reduce power usage on idle devices.
• Detects cable length and adjusts power usage based on this.
Table 1 ES1100 Series Comparison Table
PORT/SWITCH DETAILS ES1100-8P ES1100-16 ES1100-16P ES1100-24 ES1100-24E
16 10/100Base-TX Ethernet ports
24 10/100Base-TX Ethernet ports
8 10/100Base-TX Ethernet ports
(including 4 FE PoE ports)
16 10/100Base-TX Ethernet ports
(including 8 FE PoE ports)
IEEE 802.3az ON/OFF switch
Power ON/OFF switch
FE PoE ports
IEEE 802.3az EEE
Loop detection
Jumbo frame

Chapter 1 Getting to Know Your Switch
ES1100 Series User’s Guide
6
1.1.1 Power over Ethernet (PoE)
The Switch is a Power Sourcing Equipment (PSE) because it provides a source of power via its Ethernet
ports. Each device that receives power through an Ethernet port is a Powered Device (PD).
The Switch is configured in consumption mode, that is, it supplies the actual power the PD needs.
The Switch supports the IEEE 802.3af Power over Ethernet (PoE) standard.
The Switch supplies power with the lowest numbered port having the highest priority by default. For
example, port 1 has the highest priority, port 2 the next, and so on.
Not all models support PoE. See Table 1 on page 5.
Key PoE feature comparison is as follows:
1.2 Applications
This section provides two network topology examples in which the Switch is used.
1.2.1 Backbone Example Application
The Switch is an ideal solution for small networks where rapid growth can be expected in the near future.
The Switch can be used standalone for a group of heavy traffic users. You can connect computers and
servers directly to the Switch’s port or connect other switches to the Switch.
In this example, all computers can share high-speed applications on the server. To expand the network,
simply add more networking devices such as switches, routers, computers, print servers etc.
Table 2 PoE Comparison
FEATURE ES1100-8P ES1100-16P
PoE Ports 4 (ports 1-4) 8 (ports 1-8)
PoE Power Budget 64 W 130 W
Power management mode Consumption Consumption
PoE Standard IEEE 802.3af IEEE 802.3af
Maximum Power per Port 15.4W 15.4W

Chapter 1 Getting to Know Your Switch
ES1100 Series User’s Guide
7
Figure 1 Backbone Example Application
1.2.2 Bridging Example Application
With its large address table and high performance, the Switch is an ideal solution for department
networks to connect to the corporate backbone or for connecting network segments.
The following figure depicts a typical segment bridge application of the Switch in an enterprise
environment. The two networks (RD and Sales), the standalone server and the computers can all
communicate with each other and share all network resources.
Figure 2 Bridging Example

Chapter 1 Getting to Know Your Switch
ES1100 Series User’s Guide
8
1.2.3 PoE Example Application
The following example figure shows a Switch supplying PoE (Power over Ethernet) to Powered Devices
(PDs) such as an IP camera, a wireless router, an IP telephone and a general outdoor router that are not
within reach of a power outlet. For more information about PoE, see Section 1.1.1 on page 6.
Figure 3 Powered Device Examples

ES1100 Series User’s Guide
9
CHAPTER 2
Hardware Description and
Connection
2.1 Rear Panel
The three-pronged power receptacle is located on the rear panel of the Switch. Refer to the power
supply requirements on the panel.
Figure 4 Rear Panel
ES1100-8P
ES1100-16
ES1100-16P
ES1100-24
ES1100-24E

Chapter 2 Hardware Description and Connection
ES1100 Series User’s Guide
10
2.1.1 Rear Panel Power Connection
Connect one end of the supplied power cord to the power receptacle on the back of the Switch and
the other end to the appropriate power source.
For ES1100-8P, ES1100-16, ES1100-16P and ES1100-24E, use the POWER ON/OFF switch to have the Switch
power on or off.
2.2 Front Panel
The front panel of the Switch includes the auto-negotiating 10 Base-T/100 Base-TX RJ-45 ports and the
LEDs. The following shows the front panels of each ES1100 model.
Figure 5 Front Panels
2.2.1 RJ-45 Auto-negotiating Ports
All the RJ-45 ports in the ES1100 series are auto-negotiating and supports auto-crossover.
An auto-negotiating port can detect and adjust to the optimum Ethernet speed (10/100/1000 Mbps)
and duplex mode (full duplex or half duplex) of the connected device.
ES1100-8P
ES1100-16
ES1100-16P
ES1100-24
ES1100-24E

Chapter 2 Hardware Description and Connection
ES1100 Series User’s Guide
11
An auto-crossover (auto-MDI/MDI-X) port automatically works with a straight-through or crossover
Ethernet cable.
2.2.2 IEEE 802.3az Energy Efficient Ethernet
The Switch supports the IEEE 802.3az EEE (Energy Efficient Ethernet) standard to help reduce power
consumption. This allows the Switch to go into power saving mode and switch off part of receive and
transmit circuitry when it is not transmitting or receiving data through an Ethernet connection. See
Section 1.1 on page 5 to check which devices support EEE.
An EEE-enabled device initiates Low Power Idle (LPI) signals to negotiate and wake up the remote
device when there is data to be transmitted. To use EEE, both devices should be EEE compliant.
EEE is configured on a per-system basis in the Switch. If one of the networking devices that connect to
the Switch doesn't support EEE, EEE may not work in the Switch to save power.
The EEE feature is enabled by default on the ES1100-16, ES1100-24 and ES1100-24E. Press in the IEEE
802.3az EEE ON/OFF button on the ES1100-8P and ES1100-16P front panel to turn on the EEE feature.
Disable it if the remote side doesn't support it or you don't want the network performance to be
impacted due to the latency from the additional time required for the sleep and wake transition.
2.2.3 Front Panel Connections
You can use unshielded twisted pair (UTP) or shielded twisted-pair (STP) Ethernet cables for RJ-45 ports.
The following table describes the types of network cable used for the different connection speeds.
You can use either crossover or straight-through cables for all the ports.
2.2.4 Front Panel LEDs
The LED Indicators give real-time information about the status of the Switch. The following tables provide
descriptions of the LEDs.
Figure 6 LEDs for ES1100-16/24/24E
Table 3 Network Cable Types
SPEED NETWORK CABLE TYPE
10 Mbps Category 3, 4 or 5 UTP/STP
100 Mbps Category 5 UTP/STP
ES1100-16 ES1100-24 ES1100-24E

Chapter 2 Hardware Description and Connection
ES1100 Series User’s Guide
12
The following table describes the LEDs.
Figure 7 LEDs for ES1100-8P/16P
The following table describes the LEDs.
2.3 Hardware Installation
See the following table for a comparison of the hardware installation methods of each ES1100 model:
Table 6 ES1100 Series Installation Comparison Table
Note: Ask an authorized technician to attach the Switch to the rack/wall.
Table 4 LED Descriptions for ES1100-16/24/24E
LED COLOR STATUS DESCRIPTION
PWR Green On The Switch is on and is receiving power.
Off The Switch is not receiving power.
LINK/ACT Green On The port is connected to an Ethernet network at 10M or 100M speed.
Blinking
(Normal)
The port is receiving or transmitting data.
Blinking
(Slow)
The Ethernet network link is down due to loop detection.
Off The port is not connected to an Ethernet network.
Table 5 LED Descriptions for ES1100-8P/16P
LED COLOR STATUS DESCRIPTION
PWR Green On The Switch is on and receiving power.
Off The Switch is not receiving power.
LINK/ACT Green On The port is connected to an Ethernet network at 10M or 100M speed.
Off The port is not connected to an Ethernet network.
PoE Green On Power is supplied to the FE PoE port.
Off Power is not supplied to the FE PoE port.
ES1100-8P ES1100-16P
MODEL FEATURE ES1100-8P ES1100-16 ES1100-16P ES1100-24 ES1100-24E
Desktop Installation
Wall-mounting
Rack-mounting

Chapter 2 Hardware Description and Connection
ES1100 Series User’s Guide
13
Make sure you connect the Switch’s power cord to a socket-outlet with
an earthing connection or its equivalent.
For ES1100-8P/16/16P/24E, you can place the Switch directly on top of your desk or have it rack-
mounted. Take note of the following:
• The Switch should have a minimum 25 mm space around it for ventilation.
• The Switch should be placed in a desk that has a level surface and that is able to support the weight
of the Switch.
To start using it, simply connect the power cables and turn on the Switch.
2.3.1 Wall Mounting
Do the following to attach your Switch to a wall. See which models can be wall mounted in Section 2.3
on page 12.
See Table 7 on page 13 for the distance between screws.
The following figure shows the screw specifications used for wall mounting.
• D = 7.00 mm
• H = 2.00 mm
• L= 15.50 mm
• d = 3.50 mm
1Screw the two screws provided with your Switch into the wall (see the figure in step 2). Do not screw
them all the way in to the wall; leave a small gap between the head of the screw and the wall.
The gap must be big enough for the screw heads to slide into the screw slots and the power cord to run
down the back of the Switch.
Table 7 Distance between the centers of the holes for wall mounting
MODEL DISTANCE
ES1100-8P and ES1100-16P 198 mm
ES1100-16 150 mm
ES1100-24E 210 mm

Chapter 2 Hardware Description and Connection
ES1100 Series User’s Guide
14
Note: Make sure the screws are securely fixed to the wall and strong enough to hold the
weight of the Switch with the connection cables.
2Use the mounting holes on the Switch to hang the Switch on the screws.
Wall-mount the Switch with the Ethernet ports facing down and the
ventilation holes on the side.
2.3.2 Rack Mounting
The Switch can be mounted on an EIA standard size, 19-inch rack or in a wiring closet with other
equipment. Follow the steps below to mount your Switch on a standard EIA rack using a rack-mounting
kit. See Section 2.3 on page 12 for a list of models that can be rack mounted.
Rack-mounted Installation Requirements
• Two mounting brackets.
• Eight M3 flat head screws and a #2 Philips screwdriver.
• Four M5 flat head screws and a #2 Philips screwdriver.
Failure to use the proper screws may damage the unit.
Precautions
• Make sure the rack will safely support the combined weight of all the equipment it contains.
• Make sure the position of the Switch does not make the rack unstable or top-heavy. Take all
necessary precautions to anchor the rack securely before installing the unit.
Attaching the Mounting Brackets to the Switch
1Position a mounting bracket on one side of the Switch, lining up the four screw holes on the bracket with
the screw holes on the side of the Switch.

Chapter 2 Hardware Description and Connection
ES1100 Series User’s Guide
15
Figure 8 Attaching the Mounting Brackets (ES1100-8P/16/16P/24E)
Figure 9 Attaching the Mounting Brackets (ES1100-24)
2Using a #2 Philips screwdriver, install the M3 flat head screws through the mounting bracket holes into
the Switch.
3Repeat steps 1and 2to install the second mounting bracket on the other side of the Switch.
4You may now mount the Switch on a rack. Proceed to the next section.
2.3.3 Mounting the Switch on a Rack
1Position a mounting bracket (that is already attached to the Switch) on one side of the rack, lining up
the two screw holes on the bracket with the screw holes on the side of the rack.
Figure 10 Mounting the Switch on a Rack (ES1100-8P/16/16P/24E)

Chapter 2 Hardware Description and Connection
ES1100 Series User’s Guide
16
Figure 11 Mounting the Switch on a Rack (ES1100-24)
2Using a #2 Philips screwdriver, install the M5 flat head screws through the mounting bracket holes into
the rack.
3Repeat steps 1and 2to attach the second mounting bracket on the other side of the rack.

ES1100 Series User’s Guide
17
CHAPTER 3
Troubleshooting
This section describes common problems you may encounter with the Switch and possible solutions.
Troubleshoot the Switch using the LEDs to detect problems.
The PWR LED on the front panel does not light up.
• Check the connections from your Switch to the power source. Make sure you are using the supplied
power cord and that you are using an appropriate power source. Refer to the product specifications.
• Make sure the power source is turned on and that the Switch is receiving sufficient power.
• If these steps fail to correct the problem, contact your local distributor for assistance.
The LINK/ACT LED does not light up when a device is connected.
• Verify that the attached device(s) is turned on and properly connected to your Switch.
• Make sure the network adapters are working on the attached devices.
• Verify that proper network cable type is used and its length does not exceed 100 meters. For more
information on network cable types, see Section 3.1 on page 18.
Power is not being supplied to my PoE-enabled device.
•SeeSection 1.1 on page 5 to check if your Switch supports PoE. Make sure it is connected to the PoE-
enabled port (see Section 1.1.1 on page 6).
• If the PWR LED is off, check to see that the power cord is securely connected to the Switch and an
appropriate power source. Make sure the power source is on and functioning properly.
• Check that the Ethernet cables are connected properly and that you are using the correct type of
Ethernet cable.
• Make sure your powered device’s power consumption does not exceed the maximum power that
the port can supply. See Section 1.1.1 on page 6.
• Make sure that the total power consumption of all your connected powered devices is within the
power budget of the Switch. See Section 1.1.1 on page 6.
• Contact your local distributor if the problem persists.

Chapter 3 Troubleshooting
ES1100 Series User’s Guide
18
3.1 Improper Network Cabling and Topology
Improper network cabling or topology setup is a common cause of poor network performance or even
network failure.
Figure 12 Troubleshooting Improper Network Cabling and Topology
PROBLEM CORRECTIVE ACTION
Faulty cables Using faulty network cables may affect data rates and have an impact on your network
performance. Replace with new standard network cables.
Non-standard
network cables
Non-standard cables may increase the number of network collisions and cause other network
problems that affect your network performance. Refer to Section 2.2.3 on page 11 for more
information on network cable types.
Cabling Length If you use longer cables than are needed, transmission quality may be affected.
The network cables should not be longer than the limit of 100 meters.
Too many hubs
between the
computers in the
network
Too many hubs (or repeaters) between the connected computers in the network may increase
the number of network collision or other network problems. Remove unnecessary hubs from the
network.
A loop in the
data path
A data path loop forms when there is more than one path or route between two networked
computers. This results in broadcast storms that will severely affect your network performance.
Make sure there are no loops in your network topology.

ES1100 Series User’s Guide
19
APPENDIX A
Customer Support
In the event of problems that cannot be solved by using this manual, you should contact your vendor. If
you cannot contact your vendor, then contact a Zyxel office for the region in which you bought the
device.
See https://www.zyxel.com/homepage.shtml and also
https://www.zyxel.com/about_zyxel/zyxel_worldwide.shtml for the latest information.
Please have the following information ready when you contact an office.
Required Information
• Product model and serial number.
• Warranty Information.
• Date that you received your device.
• Brief description of the problem and the steps you took to solve it.
Corporate Headquarters (Worldwide)
Taiwan
• Zyxel Communications Corporation
• http://www.zyxel.com
Asia
China
• Zyxel Communications (Shanghai) Corp.
Zyxel Communications (Beijing) Corp.
Zyxel Communications (Tianjin) Corp.
• https://www.zyxel.com/cn/zh/
India
•ZyxelTechnologyIndiaPvtLtd
• https://www.zyxel.com/in/en/
Kazakhstan
•ZyxelKazakhstan
• https://www.zyxel.kz

Appendix A Customer Support
ES1100 Series User’s Guide
20
Korea
• Zyxel Korea Corp.
• http://www.zyxel.kr
Malaysia
• Zyxel Malaysia Sdn Bhd.
• http://www.zyxel.com.my
Pakistan
• Zyxel Pakistan (Pvt.) Ltd.
• http://www.zyxel.com.pk
Philippines
• Zyxel Philippines
• http://www.zyxel.com.ph
Singapore
• Zyxel Singapore Pte Ltd.
• http://www.zyxel.com.sg
Taiwan
• Zyxel Communications Corporation
• https://www.zyxel.com/tw/zh/
Thailand
• Zyxel Thailand Co., Ltd
• https://www.zyxel.com/th/th/
Vietnam
• Zyxel Communications Corporation-Vietnam Office
• https://www.zyxel.com/vn/vi
Europe
Belarus
•ZyxelBY
• https://www.zyxel.by
Belgium
• Zyxel Communications B.V.
• https://www.zyxel.com/be/nl/
