ZyXEL Communications MES3500-24S User manual

Default Login Details
User’s Guide
MES3500-24S/MGS3520 Series
Layer 2 Management Switch
Copyright © 2017 Zyxel Communications Corporation
LAN IP Address http://192.168.1.1
User Name admin
Password 1234
Version 4.10 Edition 1, 11/2017

MES3500-24S/MGS3520 Series User’s Guide
2
IMPORTANT!
READ CAREFULLY BEFORE USE.
KEEP THIS GUIDE FOR FUTURE REFERENCE.
Screenshots and graphics in this book may differ slightly from your product due to differences in your
product firmware or your computer operating system. Every effort has been made to ensure that the
information in this manual is accurate.
Related Documentation
•QuickStartGuide
The Quick Start Guide shows how to connect the Switch and access the Web Configurator.
•CLIReferenceGuide
The CLI Reference Guide explains how to use the Command-Line Interface (CLI) and CLI
commands to configure the Switch.
Note: It is recommended you use the Web Configurator to configure the Switch.
• Web Configurator Online Help
Click the help icon in any screen for help in configuring that screen and supplementary information.
•MoreInformation
Go to support.zyxel.com to find other information on the Switch.

Contents Overview
MES3500-24S/MGS3520 Series User’s Guide
3
Contents Overview
User’s Guide ......................................................................................................................................18
Getting to Know Your Switch .............................................................................................................. 19
Hardware Installation and Connection ............................................................................................. 23
Hardware Overview ............................................................................................................................. 26
The Web Configurator ......................................................................................................................... 35
Initial Setup Example ............................................................................................................................ 43
Tutorials .................................................................................................................................................. 47
Technical Reference ........................................................................................................................72
System Status and Port Statistics ......................................................................................................... 73
Basic Setting ......................................................................................................................................... 78
VLAN ...................................................................................................................................................... 99
Static MAC Forward Setup ................................................................................................................ 119
Static Multicast Forward Setup ......................................................................................................... 121
Filtering ................................................................................................................................................. 124
Spanning Tree Protocol ...................................................................................................................... 126
Bandwidth Control ............................................................................................................................. 144
Broadcast Storm Control ................................................................................................................... 147
Mirroring ............................................................................................................................................... 149
Link Aggregation ................................................................................................................................ 155
Port Authentication ............................................................................................................................ 162
Port Security ......................................................................................................................................... 170
Range Profile ....................................................................................................................................... 173
Classifier ............................................................................................................................................... 178
Policy Rule ........................................................................................................................................... 184
Queuing Method ................................................................................................................................ 189
VLAN Stacking .................................................................................................................................... 192
Multicast .............................................................................................................................................. 199
AAA ...................................................................................................................................................... 222
IP Source Guard .................................................................................................................................. 235
Loop Guard ......................................................................................................................................... 256
VLAN Mapping ................................................................................................................................... 259
Layer 2 Protocol Tunneling ................................................................................................................ 262
sFlow ..................................................................................................................................................... 266
PPPoE ................................................................................................................................................... 270
Error Disable ......................................................................................................................................... 278
Private VLAN ....................................................................................................................................... 284
Green Ethernet ................................................................................................................................... 286

Contents Overview
MES3500-24S/MGS3520 Series User’s Guide
4
Link Layer Discovery Protocol (LLDP) ................................................................................................ 288
Static Route ......................................................................................................................................... 313
Differentiated Services ....................................................................................................................... 316
DHCP .................................................................................................................................................... 320
ARP Setup ............................................................................................................................................ 334
Maintenance ...................................................................................................................................... 338
Access Control .................................................................................................................................... 347
Diagnostic ........................................................................................................................................... 370
Syslog ................................................................................................................................................... 372
Cluster Management ......................................................................................................................... 375
MAC Table ........................................................................................................................................... 381
ARP Table ............................................................................................................................................ 384
Path MTU Table ................................................................................................................................... 386
Configure Clone ................................................................................................................................. 387
Neighbor Table ................................................................................................................................... 390
Troubleshooting .................................................................................................................................. 392

Table of Contents
MES3500-24S/MGS3520 Series User’s Guide
5
Table of Contents
Contents Overview .............................................................................................................................3
Table of Contents.................................................................................................................................5
Part I: User’s Guide..........................................................................................18
Chapter 1
Getting to Know Your Switch ............................................................................................................19
1.1 Introduction ..................................................................................................................................... 19
1.1.1 Backbone Application ......................................................................................................... 19
1.1.2 Bridging Example .................................................................................................................. 20
1.1.3 High Performance Switching Example ............................................................................... 20
1.1.4 IEEE 802.1Q VLAN Application Examples ........................................................................... 21
1.1.5 IPv6 Support ........................................................................................................................... 22
1.2 Ways to Manage the Switch ......................................................................................................... 22
1.3 Good Habits for Managing the Switch ........................................................................................22
Chapter 2
Hardware Installation and Connection ...........................................................................................23
2.1 Installation Scenarios ...................................................................................................................... 23
2.2 Desktop Installation Procedure .................................................................................................... 23
2.3 Mounting the Switch on a Rack .................................................................................................. 23
2.3.1 Rack-mounted Installation Requirements .......................................................................... 23
2.3.2 Attaching the Mounting Brackets to the Switch ............................................................... 24
2.3.3 Mounting the Switch on a Rack .......................................................................................... 24
Chapter 3
Hardware Overview...........................................................................................................................26
3.1 Front & Rear Panels ....................................................................................................................... 26
3.1.1 Console Port .......................................................................................................................... 27
3.1.2 Ethernet Ports ........................................................................................................................ 28
3.1.3 Transceiver Slots .................................................................................................................... 29
3.1.4 Power Connector ................................................................................................................. 30
3.1.5 Signal Slot (MGS3520 Series) ................................................................................................ 31
3.2 LEDs ................................................................................................................................................. 33
Chapter 4
The Web Configurator........................................................................................................................35

Table of Contents
MES3500-24S/MGS3520 Series User’s Guide
6
4.1 Introduction ..................................................................................................................................... 35
4.2 System Login ................................................................................................................................. 35
4.3 The Web Configurator Layout ..................................................................................................... 36
4.3.1 Change Your Password ..................................................................................................... 40
4.4 Saving Your Configuration ............................................................................................................. 40
4.5 Switch Lockout .............................................................................................................................. 40
4.6 Resetting the Switch .................................................................................................................... 41
4.6.1 Reload the Configuration File ............................................................................................. 41
4.7 Logging Out of the Web Configurator .......................................................................................42
4.8 Help ................................................................................................................................................. 42
Chapter 5
Initial Setup Example.........................................................................................................................43
5.1 Overview ......................................................................................................................................... 43
5.1.1 Creating a VLAN ................................................................................................................... 43
5.1.2 Setting Port VID ...................................................................................................................... 44
5.2 Configuring Switch Management IP Address ............................................................................. 45
Chapter 6
Tutorials...............................................................................................................................................47
6.1 How to Use DHCP Snooping on the Switch ................................................................................. 47
6.2 How to Use DHCP Relay on the Switch ........................................................................................50
6.2.1 DHCP Relay Tutorial Introduction ........................................................................................ 50
6.2.2 Creating a VLAN ................................................................................................................... 51
6.2.3 Configuring DHCPv4 Relay .................................................................................................. 53
6.2.4 Troubleshooting ..................................................................................................................... 54
6.3 How to Use PPPoE IA on the Switch .............................................................................................. 54
6.3.1 Configuring Switch A ............................................................................................................ 55
6.3.2 Configuring Switch B ............................................................................................................. 58
6.4 How to Use Error Disable and Recovery on the Switch .............................................................. 60
6.5 How to Set Up a Guest VLAN ........................................................................................................ 62
6.5.1 Creating a Guest VLAN ........................................................................................................ 62
6.5.2 Enabling IEEE 802.1x Port Authentication ........................................................................... 65
6.5.3 Enabling Guest VLAN ........................................................................................................... 66
6.6 How to Do Port Isolation in a VLAN .............................................................................................. 67
6.6.1 Creating a VLAN ................................................................................................................... 68
6.6.2 Creating a Private VLAN Rule .............................................................................................. 70
Part II: Technical Reference...........................................................................72
Chapter 7
System Status and Port Statistics.......................................................................................................73

Table of Contents
MES3500-24S/MGS3520 Series User’s Guide
7
7.1 Overview ......................................................................................................................................... 73
7.2 Port Status Summary .................................................................................................................. 73
7.2.1 Status: Port Details ............................................................................................................ 74
Chapter 8
Basic Setting ......................................................................................................................................78
8.1 System Information ...................................................................................................................... 78
8.2 General Setup ............................................................................................................................. 80
8.3 Introduction to VLANs ................................................................................................................... 81
8.4 Switch Setup ................................................................................................................................. 82
8.5 IP Setup ........................................................................................................................................... 84
8.5.1 Management IP Addresses ..................................................................................................84
8.6 Port Setup ....................................................................................................................................... 86
8.7 Interface Setup ............................................................................................................................... 87
8.8 IPv6 ................................................................................................................................................... 88
8.8.1 IPv6 Interface Status ............................................................................................................. 89
8.8.2 IPv6 Configuration ................................................................................................................ 91
8.8.3 IPv6 Global Setup .................................................................................................................. 91
8.8.4 IPv6 Interface Setup .............................................................................................................. 92
8.8.5 IPv6 Link-Local Address Setup .............................................................................................. 93
8.8.6 IPv6 Global Address Setup ................................................................................................... 94
8.8.7 IPv6 Neighbor Discovery Setup ........................................................................................... 95
8.8.8 IPv6 Neighbor Setup ............................................................................................................. 96
8.8.9 DHCPv6 Client Setup ............................................................................................................ 97
Chapter 9
VLAN....................................................................................................................................................99
9.1 Introduction to IEEE 802.1Q Tagged VLANs ............................................................................ 99
9.1.1 Forwarding Tagged and Untagged Frames ...................................................................... 99
9.2 Automatic VLAN Registration .................................................................................................... 100
9.2.1 GARP .................................................................................................................................... 100
9.2.2 GVRP .................................................................................................................................... 100
9.3 Port VLAN Trunking ...................................................................................................................... 101
9.4 Select the VLAN Type .................................................................................................................. 101
9.5 Static VLAN .................................................................................................................................... 101
9.5.1 VLAN Status ......................................................................................................................... 101
9.5.2 VLAN Details ........................................................................................................................ 102
9.5.3 Configure a Static VLAN ................................................................................................ 103
9.5.4 Configure VLAN Port Settings ........................................................................................ 105
9.6 Subnet Based VLANs ................................................................................................................... 106
9.6.1 Configuring Subnet Based VLAN ...................................................................................... 107
9.7 Protocol Based VLANs ................................................................................................................. 109
9.7.1 Configuring Protocol Based VLAN ................................................................................... 109

Table of Contents
MES3500-24S/MGS3520 Series User’s Guide
8
9.7.2 Create an IP-based VLAN Example .................................................................................. 111
9.8 MAC Based VLAN ......................................................................................................................... 112
9.9 VLAN MAC Learning .................................................................................................................... 113
9.10 Port-based VLAN Setup ......................................................................................................... 115
9.10.1 Configure a Port-based VLAN ......................................................................................... 116
Chapter 10
Static MAC Forward Setup ..............................................................................................................119
10.1 Overview ..................................................................................................................................... 119
10.2 Configuring Static MAC Forwarding ................................................................................... 119
Chapter 11
Static Multicast Forward Setup .......................................................................................................121
11.1 Static Multicast Forwarding Overview ..................................................................................... 121
11.2 Configuring Static Multicast Forwarding .................................................................................. 122
Chapter 12
Filtering..............................................................................................................................................124
12.1 Configure a Filtering Rule ........................................................................................................ 124
Chapter 13
Spanning Tree Protocol ...................................................................................................................126
13.1 STP/RSTP Overview .................................................................................................................... 126
13.1.1 STP Terminology ................................................................................................................ 126
13.1.2 How STP Works .................................................................................................................. 127
13.1.3 STP Port States ................................................................................................................... 127
13.1.4 Multiple RSTP .................................................................................................................... 127
13.1.5 Multiple STP ........................................................................................................................ 128
13.2 Spanning Tree Protocol Status Screen ..................................................................................... 130
13.3 Spanning Tree Configuration ................................................................................................... 131
13.4 Configure Rapid Spanning Tree Protocol ............................................................................. 131
13.5 Rapid Spanning Tree Protocol Status ....................................................................................134
13.6 Configure Multiple Rapid Spanning Tree Protocol .............................................................. 135
13.7 Multiple Rapid Spanning Tree Protocol Status .................................................................. 137
13.8 Configure Multiple Spanning Tree Protocol ......................................................................... 138
13.8.1 Multiple Spanning Tree Protocol Port Configuration .................................................... 140
13.9 Multiple Spanning Tree Protocol Status ..............................................................................142
Chapter 14
Bandwidth Control...........................................................................................................................144
14.1 Bandwidth Control Overview .................................................................................................. 144
14.2 Bandwidth Control Setup .......................................................................................................... 144
14.2.1 The Egress Queue Rate Screen ....................................................................................... 145

Table of Contents
MES3500-24S/MGS3520 Series User’s Guide
9
Chapter 15
Broadcast Storm Control.................................................................................................................147
15.1 Broadcast Storm Control Setup ............................................................................................... 147
Chapter 16
Mirroring............................................................................................................................................149
16.1 Port Mirroring Overview ............................................................................................................. 149
16.2 Local Port Mirroring Screen ....................................................................................................... 151
16.3 RMirror-Source Screen ................................................................................................................ 152
16.4 RMirror-Destination Screen ....................................................................................................... 153
Chapter 17
Link Aggregation .............................................................................................................................155
17.1 Link Aggregation Overview ...................................................................................................... 155
17.2 Dynamic Link Aggregation ...................................................................................................... 155
17.2.1 Link Aggregation ID ......................................................................................................... 156
17.3 Link Aggregation Status ............................................................................................................ 156
17.4 Link Aggregation Setting .......................................................................................................... 157
17.5 Link Aggregation Control Protocol ........................................................................................ 159
17.6 Static Trunking Example ............................................................................................................. 160
Chapter 18
Port Authentication..........................................................................................................................162
18.1 Port Authentication Overview ................................................................................................. 162
18.1.1 IEEE 802.1x Authentication ............................................................................................... 162
18.1.2 MAC Authentication ........................................................................................................ 163
18.2 Port Authentication Configuration ........................................................................................... 164
18.2.1 Activate IEEE 802.1x Security ........................................................................................ 164
18.2.2 Guest VLAN ....................................................................................................................... 165
18.2.3 Activate MAC Authentication ....................................................................................... 167
Chapter 19
Port Security......................................................................................................................................170
19.1 About Port Security ..................................................................................................................... 170
19.2 Port Security Setup ...................................................................................................................... 170
Chapter 20
Range Profile ....................................................................................................................................173
20.1 Range Profile Overview ............................................................................................................ 173
20.2 Range Profile Screen .................................................................................................................. 173
20.3 VLAN Range Profile .................................................................................................................... 173
20.4 Port Range Profile ...................................................................................................................... 174
20.5 IP Address Range Profile ............................................................................................................ 175

Table of Contents
MES3500-24S/MGS3520 Series User’s Guide
10
20.6 Socket-Port Range Profile ......................................................................................................... 176
Chapter 21
Classifier............................................................................................................................................178
21.1 About the Classifier and QoS .................................................................................................... 178
21.2 Configuring the Classifier .......................................................................................................... 178
21.3 Viewing and Editing Classifier Configuration .......................................................................... 181
21.4 Classifier Example ....................................................................................................................... 182
Chapter 22
Policy Rule ........................................................................................................................................184
22.1 Policy Rules Overview ............................................................................................................... 184
22.1.1 DiffServ ................................................................................................................................ 184
22.1.2 DSCP and Per-Hop Behavior ........................................................................................... 184
22.2 Configuring Policy Rules ............................................................................................................ 184
22.3 Viewing and Editing Policy Configuration ............................................................................... 186
22.4 Policy Example ............................................................................................................................ 187
Chapter 23
Queuing Method..............................................................................................................................189
23.1 Queuing Method Overview ..................................................................................................... 189
23.1.1 Strictly Priority Queuing ..................................................................................................... 189
23.1.2 Weighted Fair Queuing .................................................................................................... 189
23.1.3 Weighted Round Robin Scheduling (WRR) .................................................................... 190
23.2 Configuring Queuing ................................................................................................................. 190
Chapter 24
VLAN Stacking..................................................................................................................................192
24.1 VLAN Stacking Overview .......................................................................................................... 192
24.1.1 VLAN Stacking Example ...................................................................................................192
24.2 VLAN Stacking Port Roles ........................................................................................................... 193
24.3 VLAN Tag Format ........................................................................................................................ 193
24.3.1 Frame Format .................................................................................................................... 194
24.4 Configuring VLAN Stacking ....................................................................................................... 194
24.4.1 Port-based Q-in-Q ............................................................................................................. 196
24.4.2 Selective Q-in-Q ............................................................................................................... 197
Chapter 25
Multicast............................................................................................................................................199
25.1 Multicast Overview .................................................................................................................... 199
25.1.1 IP Multicast Addresses ...................................................................................................... 199
25.1.2 IGMP Filtering ..................................................................................................................... 199
25.1.3 IGMP Snooping ................................................................................................................. 199

Table of Contents
MES3500-24S/MGS3520 Series User’s Guide
11
25.1.4 IGMP Snooping and VLANs ............................................................................................. 200
25.1.5 MLD Snooping-proxy ........................................................................................................ 200
25.1.6 MLD Messages ................................................................................................................... 201
25.2 Multicast Setup ........................................................................................................................... 201
25.3 IPv4 Multicast Status .................................................................................................................. 201
25.3.1 IGMP Snooping ................................................................................................................. 202
25.3.2 IGMP Snooping VLAN ...................................................................................................... 205
25.3.3 IGMP Filtering Profile ........................................................................................................ 206
25.4 IPv6 Multicast Status .................................................................................................................. 207
25.4.1 MLD Snooping-proxy ........................................................................................................ 208
25.4.2 MLD Snooping-proxy VLAN .............................................................................................. 208
25.4.3 MLD Snooping-proxy VLAN Port Role Setting ................................................................. 210
25.4.4 MLD Snooping-proxy Filtering .......................................................................................... 212
25.4.5 MLD Snooping-proxy Filtering Profile ............................................................................... 214
25.5 MVR Overview ........................................................................................................................... 215
25.5.1 Types of MVR Ports ............................................................................................................ 215
25.5.2 MVR Modes ........................................................................................................................ 215
25.5.3 How MVR Works ................................................................................................................ 215
25.6 General MVR Configuration ...................................................................................................... 216
25.6.1 MVR Group Configuration .............................................................................................. 218
25.6.2 MVR Configuration Example ........................................................................................... 220
Chapter 26
AAA...................................................................................................................................................222
26.1 Authentication, Authorization and Accounting (AAA) ......................................................... 222
26.1.1 Local User Accounts ......................................................................................................... 222
26.1.2 RADIUS and TACACS+ .....................................................................................................222
26.2 AAA Screens ............................................................................................................................... 223
26.2.1 RADIUS Server Setup ....................................................................................................... 223
26.2.2 TACACS+ Server Setup ................................................................................................. 225
26.2.3 AAA Setup ......................................................................................................................... 227
26.2.4 Vendor Specific Attribute ................................................................................................ 230
26.2.5 Tunnel Protocol Attribute .................................................................................................. 231
26.3 Supported RADIUS Attributes .................................................................................................... 231
26.3.1 Attributes Used for Authentication .................................................................................. 232
26.3.2 Attributes Used for Accounting ....................................................................................... 232
Chapter 27
IP Source Guard...............................................................................................................................235
27.1 IP Source Guard Overview ........................................................................................................ 235
27.1.1 DHCP Snooping Overview ............................................................................................... 235
27.1.2 ARP Inspection Overview .................................................................................................237
27.2 IP Source Guard .......................................................................................................................... 238

Table of Contents
MES3500-24S/MGS3520 Series User’s Guide
12
27.3 IP Source Guard Static Binding ................................................................................................. 239
27.4 DHCP Snooping .......................................................................................................................... 241
27.5 DHCP Snooping Configure ........................................................................................................ 244
27.5.1 DHCP Snooping Port Configure ...................................................................................... 246
27.5.2 DHCP Snooping VLAN Configure .................................................................................... 247
27.5.3 DHCP Snooping VLAN Port Configure ............................................................................ 248
27.6 ARP Inspection Status ................................................................................................................. 249
27.6.1 ARP Inspection VLAN Status ............................................................................................. 250
27.6.2 ARP Inspection Log Status ................................................................................................ 251
27.6.3 ARP Inspection Configure ................................................................................................252
27.6.4 ARP Inspection Port Configure ........................................................................................ 253
27.6.5 ARP Inspection VLAN Configure ..................................................................................... 254
Chapter 28
Loop Guard ......................................................................................................................................256
28.1 Loop Guard Overview .............................................................................................................. 256
28.2 Loop Guard Setup ...................................................................................................................... 257
Chapter 29
VLAN Mapping.................................................................................................................................259
29.1 VLAN Mapping Overview ......................................................................................................... 259
29.1.1 VLAN Mapping Example .................................................................................................. 259
29.2 Enabling VLAN Mapping ........................................................................................................... 259
29.3 Configuring VLAN Mapping ...................................................................................................... 260
Chapter 30
Layer 2 Protocol Tunneling..............................................................................................................262
30.1 Layer 2 Protocol Tunneling Overview ......................................................................................262
30.1.1 Layer-2 Protocol Tunneling Mode ................................................................................... 263
30.2 Configuring Layer 2 Protocol Tunneling ................................................................................... 263
Chapter 31
sFlow..................................................................................................................................................266
31.1 sFlow Overview ........................................................................................................................... 266
31.2 sFlow Port Configuration ............................................................................................................ 266
31.2.1 sFlow Collector Configuration ......................................................................................... 268
Chapter 32
PPPoE.................................................................................................................................................270
32.1 PPPoE Intermediate Agent Overview ..................................................................................... 270
32.1.1 PPPoE Intermediate Agent Tag Format .......................................................................... 270
32.1.2 Sub-Option Format ........................................................................................................... 270
32.1.3 Port State ............................................................................................................................ 271

Table of Contents
MES3500-24S/MGS3520 Series User’s Guide
13
32.2 PPPoE Screen .............................................................................................................................. 272
32.3 PPPoE Intermediate Agent ....................................................................................................... 272
32.3.1 PPPoE IA Per-Port .............................................................................................................. 274
32.3.2 PPPoE IA Per-Port Per-VLAN ............................................................................................ 275
32.3.3 PPPoE IA for VLAN ............................................................................................................ 277
Chapter 33
Error Disable......................................................................................................................................278
33.1 CPU Protection Overview .......................................................................................................... 278
33.2 Error-Disable Recovery Overview ............................................................................................. 278
33.3 Error Disable Screen .................................................................................................................... 278
33.4 Error-Disable Status .................................................................................................................... 279
33.5 CPU Protection Configuration .................................................................................................. 280
33.6 Error-Disable Detect Configuration ......................................................................................... 281
33.7 Error-Disable Recovery Configuration .....................................................................................282
Chapter 34
Private VLAN.....................................................................................................................................284
34.1 Private VLAN Overview ............................................................................................................. 284
34.2 Configuring Private VLAN .......................................................................................................... 284
Chapter 35
Green Ethernet.................................................................................................................................286
35.1 Green Ethernet Overview ......................................................................................................... 286
35.2 Configuring Green Ethernet ...................................................................................................... 286
Chapter 36
Link Layer Discovery Protocol (LLDP) .............................................................................................288
36.1 LLDP Overview ............................................................................................................................ 288
36.2 LLDP-MED Overview ................................................................................................................... 289
36.3 LLDP Screens ............................................................................................................................... 290
36.4 LLDP Local Status ....................................................................................................................... 291
36.4.1 LLDP Local Port Status Detail ..........................................................................................292
36.5 LLDP Remote Status ................................................................................................................... 296
36.5.1 LLDP Remote Port Status Detail ...................................................................................... 297
36.6 LLDP Configuration .................................................................................................................... 304
36.6.1 LLDP Configuration Basic TLV Setting ............................................................................. 305
36.6.2 LLDP Configuration Org-specific TLV Setting ................................................................ 306
36.7 LLDP-MED Configuration ........................................................................................................... 307
36.8 LLDP-MED Network Policy ......................................................................................................... 309
36.9 LLDP-MED Location ................................................................................................................... 310
Chapter 37
Static Route.......................................................................................................................................313

Table of Contents
MES3500-24S/MGS3520 Series User’s Guide
14
37.1 Static Routing Overview ............................................................................................................ 313
37.2 Static Routing .............................................................................................................................. 313
37.3 IPv4 Static Route ........................................................................................................................ 314
Chapter 38
Differentiated Services ....................................................................................................................316
38.1 DiffServ Overview ...................................................................................................................... 316
38.1.1 DSCP and Per-Hop Behavior ........................................................................................... 316
38.1.2 DiffServ Network Example ...............................................................................................316
38.2 Activating DiffServ ..................................................................................................................... 317
38.3 DSCP-to-IEEE 802.1p Priority Settings ....................................................................................... 318
38.3.1 Configuring DSCP Settings ...............................................................................................319
Chapter 39
DHCP .................................................................................................................................................320
39.1 DHCP Overview ......................................................................................................................... 320
39.1.1 DHCP Modes .................................................................................................................... 320
39.1.2 DHCP Configuration Options ........................................................................................... 320
39.2 DHCP Configuration ................................................................................................................... 320
39.3 DHCPv4 Status ........................................................................................................................... 321
39.4 DHCPv4 Relay ............................................................................................................................ 321
39.4.1 DHCPv4 Relay Agent Information ................................................................................... 321
39.4.2 DHCPv4 Option 82 Profile ................................................................................................. 322
39.4.3 Configuring DHCPv4 Global Relay ................................................................................. 323
39.4.4 DHCPv4 Global Relay Port Configure ........................................................................... 324
39.4.5 Global DHCPv4 Relay Configuration Example .............................................................. 325
39.4.6 Configuring DHCPv4 VLAN Settings ............................................................................. 326
39.4.7 DHCPv4 VLAN Port Configure ........................................................................................ 327
39.4.8 Example: DHCPv4 Relay for Two VLANs ......................................................................... 328
39.5 DHCPv6 Relay ............................................................................................................................. 329
39.5.1 DHCPv6 Options Profile .................................................................................................... 331
39.5.2 DHCPv6 Port Configure ................................................................................................... 332
Chapter 40
ARP Setup..........................................................................................................................................334
40.1 ARP Overview ............................................................................................................................ 334
40.2 ARP Setup .................................................................................................................................... 336
40.2.1 ARP Learning .................................................................................................................... 336
Chapter 41
Maintenance....................................................................................................................................338
41.1 The Maintenance Screen ........................................................................................................ 338
41.2 Load Factory Default ................................................................................................................ 339

Table of Contents
MES3500-24S/MGS3520 Series User’s Guide
15
41.3 Save Configuration .................................................................................................................... 339
41.4 Reboot System ............................................................................................................................ 339
41.5 Firmware Upgrade ................................................................................................................... 341
41.6 Restore a Configuration File ................................................................................................... 342
41.7 Backup a Configuration File ................................................................................................... 342
41.8 Tech-Support .............................................................................................................................. 343
41.9 FTP Command Line .................................................................................................................... 344
41.9.1 Filename Conventions ..................................................................................................... 344
41.9.2 FTP Command Line Procedure ....................................................................................... 345
41.9.3 GUI-based FTP Clients ....................................................................................................... 346
41.9.4 FTP Restrictions .................................................................................................................. 346
Chapter 42
Access Control.................................................................................................................................347
42.1 Access Control Overview ...................................................................................................... 347
42.2 The Access Control Main Screen .............................................................................................. 347
42.3 About SNMP .............................................................................................................................. 347
42.3.1 SNMP v3 and Security ....................................................................................................... 348
42.3.2 Supported MIBs ................................................................................................................ 348
42.3.3 SNMP Traps ......................................................................................................................... 349
42.3.4 Configuring SNMP ............................................................................................................ 353
42.3.5 Configuring SNMP Trap Group ..................................................................................... 355
42.3.6 Enabling/Disabling Sending of SNMP Traps on a Port ................................................. 356
42.3.7 Configuring SNMP User .................................................................................................. 357
42.4 Setting Up Login Accounts .................................................................................................... 358
42.5 SSH Overview .............................................................................................................................. 360
42.6 How SSH works ............................................................................................................................ 360
42.7 SSH Implementation on the Switch ..........................................................................................361
42.7.1 Requirements for Using SSH ..............................................................................................362
42.8 Introduction to HTTPS .................................................................................................................. 362
42.9 HTTPS Example ............................................................................................................................ 363
42.9.1 Internet Explorer Warning Messages ............................................................................... 363
42.9.2 Mozilla Firefox Warning Messages ................................................................................... 364
42.9.3 Google Chrome Warning Messages .............................................................................. 366
42.9.4 The Main Screen ................................................................................................................ 366
42.10 Service Port Access Control ................................................................................................. 367
42.11 Remote Management ........................................................................................................ 368
Chapter 43
Diagnostic.........................................................................................................................................370
43.1 Diagnostic .................................................................................................................................. 370
Chapter 44
Syslog................................................................................................................................................372

Table of Contents
MES3500-24S/MGS3520 Series User’s Guide
16
44.1 Syslog Overview .......................................................................................................................... 372
44.2 Syslog Setup ............................................................................................................................... 372
44.3 Syslog Server Setup .................................................................................................................... 373
Chapter 45
Cluster Management.......................................................................................................................375
45.1 Cluster Management Status Overview ................................................................................... 375
45.2 Cluster Management Status .................................................................................................... 376
45.2.1 Cluster Member Switch Management .......................................................................... 376
45.3 Clustering Management Configuration ................................................................................ 378
Chapter 46
MAC Table........................................................................................................................................381
46.1 MAC Table Overview ................................................................................................................ 381
46.2 Viewing the MAC Table ............................................................................................................ 382
Chapter 47
ARP Table..........................................................................................................................................384
47.1 ARP Table Overview .................................................................................................................. 384
47.1.1 How ARP Works .................................................................................................................. 384
47.2 The ARP Table Screen ............................................................................................................... 384
Chapter 48
Path MTU Table.................................................................................................................................386
48.1 Path MTU Overview .................................................................................................................. 386
48.2 Viewing the Path MTU Table ..................................................................................................... 386
Chapter 49
Configure Clone...............................................................................................................................387
49.1 Configure Clone ........................................................................................................................ 387
Chapter 50
Neighbor Table.................................................................................................................................390
50.1 IPv6 Neighbor Table Overview ................................................................................................. 390
50.2 Viewing the IPv6 Neighbor Table ............................................................................................. 390
Chapter 51
Troubleshooting................................................................................................................................392
51.1 Power, Hardware Connections, and LEDs ............................................................................... 392
51.2 Switch Access and Login ........................................................................................................... 393
51.3 Switch Configuration .................................................................................................................. 395
Appendix A Customer Support ..................................................................................................... 396

Table of Contents
MES3500-24S/MGS3520 Series User’s Guide
17
Appendix B Common Services...................................................................................................... 402
Appendix C IPv6.............................................................................................................................. 405
Appendix D Legal Information ...................................................................................................... 413
Index.................................................................................................................................................417

18
PART I
User’s Guide

MES3500-24S/MGS3520 Series User’s Guide
19
CHAPTER 1
Getting to Know Your Switch
This chapter introduces the main features and applications of the Switch.
1.1 Introduction
The Switch is a layer-2 standalone Ethernet switch. The Switch has two or four GbE dual personality
interfaces with each interface comprising one mini-GBIC slot and one 100/1000 Mbps RJ-45 port, with
either port or slot active at a time.
This User’s Guide covers the following models: MES3500-24S, MGS3520-28, MGS3520-28F and MGS3520-
50.
With its built-in web configurator, managing and configuring the Switch is easy. In addition, the Switch
can also be managed via Telnet, any terminal emulator program on the console port, or third-party
SNMP management.
This section shows a few examples of using the Switch in various network environments.
1.1.1 Backbone Application
The Switch is an ideal solution for small networks where rapid growth can be expected in the near future.
The Switch can be used standalone for a group of heavy traffic users. You can connect computers and
servers directly to the Switch’s port or connect other switches to the Switch.
In this example, all computers can share high-speed applications on the server. To expand the network,
simply add more networking devices such as switches, routers, computers, print servers etc.
Table 1 Switch Comparison Table
PORT/SWITCH
DETAILS MES3500-24S MG3520-28 MGS3520-28F MGS3520-50
24 10/100/1000Base-T
Ethernet ports VV
44 10/100/1000Base-T
Ethernet ports V
2 100BASE-FX/
1000BASE-X SFP Slots V
24 100BASE-FX/
1000BASE-X SFP Slots V
4 Dual Personality
Interfaces VVV
2 Dual Personality
Interfaces V

Chapter 1 Getting to Know Your Switch
MES3500-24S/MGS3520 Series User’s Guide
20
Figure 1 Backbone Application
1.1.2 Bridging Example
In this example, the Switch connects different company departments (RD and Sales) to the corporate
backbone. It can alleviate bandwidth contention and eliminate server and network bottlenecks. All
users that need high bandwidth can connect to high-speed department servers via the Switch. You can
provide a super-fast uplink connection by using a Gigabit Ethernet/mini-GBIC port on the Switch.
Moreover, the Switch eases supervision and maintenance by allowing network managers to centralize
multiple servers at a single location.
Figure 2 Bridging Application
1.1.3 High Performance Switching Example
The Switch is ideal for connecting two networks that need high bandwidth. In the following example, use
trunking to connect these two networks.
