ZyXEL Communications RGS Series User manual

1
RGS Series
Rugged Switch Series
Version 1
Edition 3, 07/2019
Hardware and Web User’s Guide
Default Login Details
LAN IP Address
http://192.168.1.1
User Name
admin
Password
1234
Copyright © 2019 Zyxel Communications Corporation

2
IMPORTANT!
READ CAREFULLY BEFORE USE.
KEEP THIS GUIDE FOR FUTURE REFERENCE.
This is a User’s Guide for a series of products. Not all products support all firmware features.
Screenshots and graphics in this book may differ slightly from your product due to differences in your
product firmware or your computer operating system. Every effort has been made to ensure that the
information in this manual is accurate.
Related Documentation
• CLI Reference Guide
The CLI Reference Guide explains how to use the Command-Line Interface (CLI) to configure
the Switch.
Note: It is recommended you use the Web Configurator to configure the Switch.
• Web Configurator Online Help
Click the help icon in any screen for help in configuring that screen and supplementary
information.
• More Information
Go to support.Zyxel.com to find other information on the Switch.

3
