ZyXEL Communications SHD2110 User manual

www.zyxel.com
Quick Start Guide
SHD2110/3110
Power On/Off Switch
Power On/Off Switch with
Power Metering
Version 1.00
Edition 1, 7/2011
2011 ZyXEL Communications Corporation
C

2

3
Overview
The SHD2110/3110 is a plug-in Power On/Off Switch and the SHD3110
supports power metering. It is a Z-WaveTM enabled transceiver which is
fully compatible with any Z-Wave enabled network.
The SHD2110/3110 can be connected to a maximum resistive electricity
load of 3000 watts.
The SHD2110 has fuse protection when overload happens while the
SHD3110 is able to detect overload. The SHD3110 will be disabled and
its On/Off button will be locked. The LED will flash quickly for 30
seconds. Unplug and re-connect the SHD3110 to reset it.
Placing the SHD2110/3110
1. Do not place the SHD2110/3110 facing direct sunlight, or in a humid,
or dusty area.
2. The suitable temperature for the SHD2110/3110 is 0°C~40°C.
3. Do not place the SHD2110/3110 near flammable substances or any
source of heat (e.g. fires, radiators, boiler... etc).
4. It is normal that the SHD2110/3110 becomes a bit warm during use.
SHD2110 SHD3110
On/Off Button &
LED Indicator
ENGLISH

44
Installation
1. Plug the SHD2110/3110 into a wall outlet near the appliance to be
controlled.
2. Plug the appliance into the SHD2110/3110. Ensure the power load
does not exceed 3000 watts.
3. Turn the appliance on.
4. The ON/OFF button on the SHD2110/3110 can now control the power
of your appliance. Press it to manually turn the appliance on/off.
Adding to Z-Wave Network
When power is initially applied, the LED on the front of the SHD2110/
3110 flashes on and off repeatedly at a 2-second interval. This implies
that it has not been allocated a node ID and cannot work with Z-Wave
enabled devices.
You can use the On/Off button in front of the SHD2110/3110 to include,
exclude, associate with a Z-Wave Network, or reset.
Function Description LED Indication
No node ID The Z-Wave Controller does
not allocate a node ID to the
SHD2110/3110.
On and off repeatedly at a 2-
second interval
Inclusion 1. Have the Z-Wave Controller
enter inclusion mode. The LED is on if you press On. It is off if you press Off.
2. Press the On/Off button 3
times within 1.5 seconds to
enter inclusion mode.

5
Note: See the User’s Guide for the SHD2110/3110’s advanced programming.
Exclusion 1. Have the Z-Wave Controller
enter exclusion mode. The LED is on if you press On.
It is off if you press Off.
2. Press the On/Off button 3
times within 1.5 seconds to
enter exclusion mode.
3. Node ID has been
excluded. On and off repeatedly at a 2- second interval
Reset 1. Press the On/Off button 3
times within 1.5 seconds. The LED is on if you press On.
It is off if you press Off.
2. Within 1 second, press
the On/Off button for 5
seconds until the LED is off.
3. Node ID has been
excluded, restores to
factory default.
On and off repeatedly at a 2-
second interval
Association 1. Have the Z-Wave Controller
enter association mode. The LED is on if you press On. It is off if you press Off.
2. Or press On/Off button 3
times within 1.5 seconds to
enter association mode.
3. There are two groupings - 1
and 2. (Refer to Z-Wave's
Groupings in the User’s
Guide)
• The Z-Wave Controller will display whether the inclusion/exclusion of the
node ID has succeeded or failed.
Function Description LED Indication

66
Socket Type
Refer to the following for the socket type suited for your country:
SHD2110
SHD3110
Make sure that the current used by the plug of the appliance is
under 14.5A and has the same head as the enclosed plug before
inserting into the socket.

7
Toubleshooting
Symptom Possible Cause Recommendation
The SHD2110/
3110 is not
working.TheLED
display is off.
1. The SHD2110/3110 is
not plugged to an
electrical outlet
properly.
Check the power connections.
2. A malfunction has
occurred. Contact your vendor for repairment.
I cannot control
the appliance
plugged to the
SHD2110/3110.
Check if the appliance
plugged to the SHD2110/
3110 has its own power
switch.
Set the appliance’s power
switch to On.
The Z-Wave
Controller cannot
control the
SHD2110/3110.
1. The SHD2110/3110 is
notassociated withthe
Z-Wave Controller.
Associate the SHD2110/3110
with the Z-Wave Controller.
See Adding to Z-Wave
Network.
2. There is frequency
interference. Wait for a while and try again.
(SHD3110 only)
The LED kept
flashing for 30
seconds and the
modulecannotbe
controlled.
An overload has
occurred. Remove the appliance attached to the SHD3110.
Check the electricity load of
the appliance. It cannot
exceed 3000W.

8
ENGL
I
SH
DEUTSCH
ESPAÑOL
FRANÇAIS
