2K FURNITURE DESIGN TAF-31M User manual

A11PC-Top panel
A21PCS-Side panels A41PC-Middlepanel A51PC-Back panel
A61PC-Front panel A71PC-Bottompanel A81PC-Low Top
B2 2SETS-Hinges
and screws
B3 1SET-Safety Hinge
and screws
B115SETS-Camlocks
A31PCS-Side panels
Style# 31W &31M
Storage step stool

Step1
Step3
A2
A3
A4
A5
A4
A5
A7
A4
A5
A6
B1
B1
B1
B1
B1
B1
Assemblethefront panelA6,themiddlepanelA4and theback
panelA5to thesidepanel A2using camlocks B1.
Insert thebottompanel A7 into thegrooves of
middlepanelA4andbackpanel A5.
Assemblethesidepanel A3 to thefront panelA6,themiddlepanel
A4 and theback panelA5using camlocks B1 .
A6
B1
A6

Step4 Step5
A3
A8 A1
B1 B1 B2
B3
A6
A2
1. Connecting the top panel A1tothe back panel A5
using hinges B2.
2. Assemblethe safetyhinge B3 tothe top paenl A1and
the side panel A2.
Warning: The MaximumLoad of the top panel is 200lbs.
A2
A3
B2
A5
A5
1. Assemblethe lowtop A8ontothe side panels A2,A3
and front panel A6using camlocks B1.
2. Attach the hinges B2 tothe top of back panel A5.
B2
B2 B2
B3
B3 A1
