2PrintBeta Beta Prusa Basic User manual

Assembly Instructions Beta Prusa Minimal 30/05/13
Assembly Instructions
Beta Prusa Basic
3D Printer
Version 1.5
Date: 30/05/13
Page 1 / 57

Assembly Instructions Beta Prusa Minimal 30/05/13
General data about the assembly instructions for an incomplete machine
according to annex VI of the EG machinery directive 006/4 /EG
Manu acturer:
Wenger & Krautwasser GbR - 2PrintBeta
Sche elstrasse 8
78462 Konstanz
Description o the machine:
Identi ication: Beta Prusa 3D printer
Type: Minimal with bushings
Year: 2012
Conditions that must be met or the incomplete machine so that it can properly, and
without compromising the sa ety and health o peoples, be assembled with other
parts to orm a complete machine:
Condition 1: Let an expert check the electrical connections o the machine.
In ormation over the undersigned:
Name: Dominik Wenger
Function: Shareholder Wenger & Krautwasser GbR
01 11 2012
_________________________________________
Date, Signature
This work is licensed under a Creative Commons Attribution-NonCommercial 3.0 Germany License
Page 2 / 57

Assembly Instructions Beta Prusa Minimal 30/05/13
Congratulations on purchasing a Beta Prusa 3D Printer!
Please read the ollowing assembly instructions care ully and keep the document on a sa e
place. Please ollow care ully all instructions and lookout or the warning symbols.
Table of Contents
SAFETY INSTRUCTIONS....................................................................................................................................4
ASSEMBLY OF THE FRAME..............................................................................................................................5
STEP 1 1 6
STEP 1 2 7
STEP 1 3 9
STEP 1 4 10
STEP 1 5 11
STEP 1 6 12
STEP 1 7 13
STEP 1 8 14
STEP 1 9 17
ASSEMBLY OF THE AXES................................................................................................................................18
STEP 2 1 19
STEP 2 2 21
STEP 2 3 24
STEP 2 4 26
STEP 2 5 28
STEP 2 6 30
STEP 2 7 32
ASSEMBLY OF THE EXTRUDER....................................................................................................................34
STEP 3 1 35
STEP 3 2 37
STEP 3 3 39
STEP 3 4 40
STEP 3 5 42
ASSEMBLY OF THE PRINT BED.....................................................................................................................43
STEP 4 1 44
ASSEMBLY OF THE ELECTRONICS..............................................................................................................45
STEP 5 1 46
STEP 5 2 48
Page 3 / 57

Assembly Instructions Beta Prusa Minimal 30/05/13
Safety Instructions
Only assemble a Beta Prusa 3D printer according to the assembly instructions written here.
Please take notice o the ollowing Symbols and Notices. They are structured into danger
levels according to ISO 3864-2.
DANGER
Refers to an imminent Danger.
If the information is not followed, it can result in death or serious injury
(invalidity).
Indicates a possible dangerous situation.
If the information is not followed, it can result in death or serious injury
(invalidity).
ATTENTION
Indicates a potentially dangerous situation.
If the information is not followed, damage to property or light to
medium personal injuries are possible.
NOTICE
Indicates general notes, useful operator tips and operating
recommendations which do not affect the safety and health of
personnel.
Page 4 / 57
WARNING

Assembly Instructions Beta Prusa Minimal 30/05/13
Chapter I
Assembly of the Frame
Page 5 / 57

Assembly Instructions Beta Prusa Minimal 30/05/13
Step 1.1
Needed parts for step 1.1
The ollowing parts are needed or this step:
2x Frame vertex with oot
1x Bar clamp
6x Washer M8
6x Nut M8
1x Threaded rod M8 x 370 mm
Assembly Step 1.1
Assemble the bar clamp between two rame vertices like its shown in the picture above.
Don't completely asten the nuts yet.
Page 6 / 57

Assembly Instructions Beta Prusa Minimal 30/05/13
Step 1.2
Needed parts for step 1.2
The ollowing parts are needed or this step:
1x Pre-assembled part rom step 1.1
1x Frame vertex without oot
8x Washer M8
8x Nut M8
2x Threaded rod M8 x 370 mm
Assembly Step 1.2
Page 7 / 57

Assembly Instructions Beta Prusa Minimal 30/05/13
Connect the part rom step 1.1 with the rame vertex and the rods to a triangle.
Make sure that all sides o the triangle are exactly the same length. The distance between
the outer edges o the plastic parts should be 291 mm.
Repeat the previous two steps and build a second triangle.
NOTICE
Make sure all sides of both triangles are exactly the same length.
Now asten all nuts on the rame vertices.
Assembly of step 1.2 repeated
Page 8 / 57

Assembly Instructions Beta Prusa Minimal 30/05/13
Step 1.3
Needed parts for step 1.3
The ollowing parts are needed or this step:
4x Washer M8
4x Nut M8
1x Threaded rod M8 x 294 mm
Assembly Step 1.3
Position the nuts and washer on the threaded rod as shown in the picture above.
Page 9 / 57

Assembly Instructions Beta Prusa Minimal 30/05/13
Step 1.4
Needed parts for step 1.4
The ollowing parts are needed or this step:
1x Belt guide
2x Bar clamp
10x Washer M8
8x Nut M8
1x Bearing 608ZZ
1x Threaded rod M8 x 294 mm
Bearing 608zz in belt guide
Press the 608ZZ bearing into the belt guide until it's lush with one side o the guide.
Assembly step 1.4
Position the parts on the threaded rod as shown in the picture above.
Notice
Place the bearing with the belt guide so that the protruding side of the
belt guide points to the M8 nut.
Page 10 / 57

Assembly Instructions Beta Prusa Minimal 30/05/13
Step 1.5
Needed parts for step 1.
The ollowing parts are needed or this step:
2x Bar clamp
8x Washer M8
8x Nut M8
1x Belt guide
1x Bearing 608zz
1x Threaded rod M8 x 294 mm
Assembly step 1.
Position the parts on the threaded rod as shown in the picture above.
Page 11 / 57

Assembly Instructions Beta Prusa Minimal 30/05/13
Step 1.6
Needed parts for step 1.6
The ollowing parts are needed or this step:
2x Washer M8
2x Nut M8
1x Threaded rod M8 x 294 mm
Assembly Step 1.6
Position the parts on the threaded rod as shown in the picture above.
Page 12 / 57

Assembly Instructions Beta Prusa Minimal 30/05/13
Step 1.7
Needed parts for step 1.7
The ollowing parts are needed or this step:
4x Nut M8
4x Washer M8
2x Threaded rod M8 x 440 mm
Assembly Step 1.7
Position the parts on the threaded rod as shown in the picture above.
Page 13 / 57

Assembly Instructions Beta Prusa Minimal 30/05/13
Step 1.8
Needed parts for step 1.8
The ollowing parts are needed or this step:
1x Y motor holder
2x Z motor holder
20x Washer M8
16x Nut M8
and all previously assembled parts
Assembly Step 1.8
Insert the two triangles rom the outside into the prepared threaded rods and ix them
together with a washer and a nut each. The longer threaded rods (440 mm) go into the rame
vertices without eet, the shorter ones (294 mm) in the Frame vertexes without eet like it's
shown in the picture above.
Page 14 / 57

Assembly Instructions Beta Prusa Minimal 30/05/13
Distance between the frame triangles.
Measure the distances between the triangles, as shown above, on all three sides o the
rame.
Position of the nuts on the outside of the frame.
Now adjust the distance between the triangles by turning the nuts on the rame vertices until
all distances are exactly the same. Make sure the triangles are as ar out as possible, as
shown above. The distance between the bolts should be around 260 mm.
Assembly of a z motor holder
Page 15 / 57

Assembly Instructions Beta Prusa Minimal 30/05/13
Now push the z motor holders, lat side down, onto the longer rods as shown above. Secure
them with a washer and a nut each.
Assembly of the y motor holder
At last, push the y motor holder onto the rods, besides the belt guide and secure it with the
nuts on the threaded rods.
Page 16 / 57

Assembly Instructions Beta Prusa Minimal 30/05/13
Step 1.9
Needed parts for step 1.9
The ollowing parts are needed or this step:
2x Bar clamps
4x Washer M8
4x Nut M8
1x Threaded rod M8 x 440 mm
and the structure rom the previous step
Assembly Step 1.9
Push the threaded rod through the two bar clamps at the bottom o the rame and attach the
bar clamps on both sides with washers and nuts as shown in the picture above.
Assembly detail
Page 17 / 57

Assembly Instructions Beta Prusa Minimal 30/05/13
Chapter II
Assembly of the Axes
Page 18 / 57

Assembly Instructions Beta Prusa Minimal 30/05/13
Step 2.1
Needed parts for step 2.1
The ollowing parts are needed or this step:
1x Gear
4x Bushing
1x Motor Nema17 with cable and plug
3x Washer M3
3x Screw M3 x 10 mm
1x Grub screw M3 x 8 mm
2x Smooth rod 8mm x 406 mm
and the structure rom the previous step
Assembly Step 2.1
Push the smooth rods through the bar clamps on the rame and click the bushings onto the
rods. Do not asten the nuts on the rod clamps yet.
Page 19 / 57

Assembly Instructions Beta Prusa Minimal 30/05/13
Assembly of the Y Axis motor
Be ore you attach the motor onto the holder, you should create a lat onto the motor sha t
with a ile so the gear has a good it.
Then push the gear onto the motor sha t and secure it with the 8mm grub screw. The gear
has holes with integrated nuts or this.
Now attach the motor to the Y motor holder with three M3 screws and washers as shown in
the picture above. Make sure the motor cables on the motor are pointing downwards.
Page 20 / 57
