2SAN ADR-7104 User manual

User Manual
Version 1.0
Copyright © 2008 2SAN INC.
Release: May 2008
4CH MPEG4 Standalone DVR
ADR-7104

2
Copyright and Trademark
The information of the product in this quick guide is subject to change without prior notice and does
not represent a commitment on the part of vendor, who assumes no liability or responsibility for any
errors that may appear in this quick guide.
2SAN is the trademark of 2SAN Inc. Windows is the trademark of Microsoft Corporation. All brands
and trademarks are the properties of their respective owners.
This quick guide contains materials protected under International Copyright Laws. All rights
reserved. No part of this quick guide may be reproduced, transmitted or transcribed without the
written consent of the manufacturer.

3
WEEE Statement English
In order to cope with the increasing waste electrical and electronic equipment, reduce the use of landfill and
incinerator, and prevent the harmful matter of waste equipment from entering the environment, the European
Union (EU) has set the Directive on Waste Electrical and Electronic Equipment (WEEE) asking manufacturers
to collect, recycle and treat waste electrical and electronic equipment properly. Member nations already
established their free of charge recycle systems of WEEE before August 13, 2005. Accordingly, 2SAN has to
be responsible for recycling all products exported to Germany. You can return your 2SAN product that needs
recycling to a local collector.
WEEE Erklärung German
Mit dem Ziel die steigende Menge elektrischer und elektronischer Altgeräte zu bewältigen ohne hierzu unnötig
Mülldeponien und Verbrennungsanlagen zu belasten und um die Verschmutzung der Umwelt durch
freiwerdende Stoffe aus den Altgeräten zu vermeiden, hat die Europäische Union (EU) die Richtlinie über
Elektro- und Elektronik-Altgeräte erlassen. Die Richtlinie verpflichtet Hersteller, elektrische und elektronische
Altgeräte umweltgerecht einzusammeln, zu recyceln und zu entsorgen. Die Mitgliedsstaaten der EU haben
bereits ihre kostenfreien Recyclesysteme konform der WEEE vor dem 13. August 2005 eingerichtet.
Entsprechend der Richtlinie ist 2SAN verantwortlich für die umweltgerechte Entsorgung aller nach
Deutschland exportierten 2SAN Produkte. Sie können Ihr zu entsorgendes 2SAN Produkt zu Ihrer örtlichen
Sammelstelle bringen.
AEEA verklaring Dutch
Met het doel de stijgende hoeveelheid afgedankte elektrische en elektronische apparatuur te beheersen
zonder hiervoor onnodig stortplaatsen en verbrandingsovens te belasten en om de vervuiling van het milieu
door vrijkomende stoffen uit de afgedankte apparatuur te voorkomen, heeft de Europese Unie (EU) de richtlijn
betreffende afgedankte elektrische en elektronische apparatuur besloten. Deze richtlijn verplicht fabrikanten
afgedankte elektrische en elektronische apparatuur in te zamelen, te recyclen en te verwijderen. De lidstaten
van de EU hebben reeds de kosteloze recyclesystemen volgens de AEEA vóór de 13 augustus 2005 ingericht.
Conform de richtlijn is 2SAN verantwoordelijk voor de verwijdering van alle naar Nederland geëxporteerde
2SAN producten. U kunt uw afgedankt 2SAN product naar uw locale inzamelplaats brengen.
Elektrik ve Elektronik Madde Atıkları Demeci Turkish
Elektrik ve electronik madde atıklarının yukselmesiyle basedebilmek ,arazi doldurma ve cop yakma fırını
kullanımını azaltmak,atık madde zararlarının cevreye yayılmasını onlemek icin Avrupa Birligi

4
(AB),ureticilerden elektrik ve elektronik madde atıklarını gerektigi gibi toplamalarını,geri donusturmelerini ve
kimyasal isleme tabi tutmalarını talep etmek icin Elektrik ve Elektronik Madde Atıkları uzerine bir direktif
hazırladı.Topluluk uyeleri,13 Agustos 2005' ten once elektrik ve elektronik madde atıklarının ucretsiz geri
donusum sistemlerini coktan olusturmuslardı.Bundan dolayı, 2SAN, Almanya'ya ihrac ettigi butun urunlerin
geri donusumunden sorumludur. 2SAN urunleri geri donusum gerektirirse yerel toplayıcılara geri
verebilirsiniz.
WEEE бюлетень Russian
Чтобы справиться сувеличивающимся ненужным электрическим иэлектронным
оборудованием, уменьшите использование закапывания мусора ииспользования установки
для сжигания отходов, препятствуйте вредному выбросам загрязнять окружающую среду,
Европейский союз (Е )установил Директиву по Ненужному Электрическому и
Электронному Оборудованию (WEEE) для того, чтобы изготовителей собрали,
перерабатывали ивообще проявили внимание кненужному электрическому иэлектронному
оборудованию должным образом. Члены нации установили бесплатную систему переработки
WEEE до 13 августа 2005. оответственно, 2SAN обязан быть ответственным за то, что
переработал все продукты, экспортируемые вГерманию. Вы можете возвратить ваш продукт
2SAN, который нуждается врециркуляции местному сборщику.
WEEE Statement French
Afin de gérer la quantité croissante de déchets électriques et électroniques, de réduire l’utilisation des
décharges et des incinérateurs et d’éviter que des déchets nocifs ne polluent l’environnement, l’Union
Européenne a publié la directive WEEE sur les déchets électriques et électroniques. Celle-ci spécifie que les
fabricants doivent collecter, recycler et traiter l’équipement électronique et électrique usagé. Depuis le 13 août
2005, les pays membres ont mis en place un système de recyclage gratuit selon le WEEE.
De ce fait, 2SAN est responsable du recyclage de tous les produits exportés vers l’Allemagne. Vous pouvez
mettre au rebut votre équipement 2SAN usagé dans votre centre local de recyclage.
Pour plus d’informations sur les lieux de mise au rebut des équipements usagés destinés au recyclage,
veuillez contacter votre mairie, votre service de traitement des déchets ménagers ou le magasin où vous avez
acheté le produit.
RAEE Spanish
Con la finalidad de reducir el incremento de residuos eléctricos y de material electrónico, reduciendo el uso
de los vertederos e incineradoras y prevenir el preocupante aumento del contacto de estos residuos con el
medio ambiente. Por este motivo la Unión Europea ha fijado la Directiva de Residuos de Aparatos Eléctricos
y Electrónicos (RAEE) solicitando a los fabricantes la recolección, reciclaje y tratamiento de ests residuos
correctamente. Los paises miembros ya han establecido su sistema de reciclaje gratuito de RAEE antes del
13 de Agosto del 2005. Por este motivo 2SAN es el responsable del reciclaje de todos los productos
exportados a Alemania. Usted puede devolver su producto 2SAN a un punto de recogida local cuando desee
reciclarlo.

5
Dichiarazione WEEE Italian
Per far fronte all’aumento dei residui delle apparecchiature elettriche ed elettroniche, ridurre l'uso di materiale
di riporto e degli inceneritori, ed impedire che il materiale nocivo delle apparecchiature residue entri a contatto
con l'ambiente, l’ Unione Europea (UE) ha stabilito le Direttive sui Residui delle apparecchiature Elettriche ed
Elettroniche (WEEE) chiedendo ai fornitori di raccogliere correttamente, riciclare e trattare le apparecchiature
elettriche ed elettroniche residue. Le nazioni facenti parte dell’ Unione Europea hanno già stabilito il loro
sistema gratuito di riciclaggio di questo materiale (WEEE) prima del 13 agosto 2005. Di conseguenza, 2SAN
è responsabile del riciclaggio di tutti i prodotti esportati in Germania. Potete restituire il vostro prodotto
acquistato da 2SAN che deve essere riciclato da un’ azienda specifica locale.

6
Table of Contents
Chapter1. About ADR-7104 9
1.1 OVERVIEW ............................................................................................................................. 9
1.2 FEATURES .............................................................................................................................. 9
1.3 SPECIFICATION ....................................................................................................................... 9
1.4 PACKAGE ............................................................................................................................. 10
Chapter2. System Appearance 11
2.1 THE FRONT PANEL................................................................................................................ 11
2.2 THE REAR PANEL.................................................................................................................. 12
Chapter3. Installation 13
3.2 CONNECT CAMERAS ............................................................................................................. 15
3.3 CONNECT THE MONITOR........................................................................................................ 15
3.4 CONNECT THE POWER ADAPTER ............................................................................................ 15
Chapter4. Menu Flow 17
4.1 LIVE VIEW ............................................................................................................................ 17
Chapter5. SYSTEM 20
5.1 TIME SETUP ...................................................................................................................... 20
5.2 SYSTEM PASSWORD ....................................................................................................... 21
5.3 SYSTEM INFO ................................................................................................................... 21
5.4 VIDEO FORMAT................................................................................................................ 21
5.5 LOG VIEW ......................................................................................................................... 21
5.6 LOG SET ............................................................................................................................ 22
5.7 FIRMWARE UPGRADE..................................................................................................... 22
5.8 FACTORY RESET .............................................................................................................. 22
5.9 LANGUAGE....................................................................................................................... 23
Chapter6. CAMERA 24
6.1 CHANNEL.......................................................................................................................... 24
6.2 COLOR............................................................................................................................... 24
6.3 TITLE ................................................................................................................................. 24
6.4 PROTOCOL........................................................................................................................ 25
6.5 PTZ ADDRESS ................................................................................................................... 25
6.6 EVENT POPUP................................................................................................................... 25
6.7 MAIN ROT. TIME .............................................................................................................. 25
Chapter7. RECORD 26
7.1 CHANNEL.......................................................................................................................... 26

7
7.2 RESOLUTION.................................................................................................................... 26
7.3 PRE RECORD..................................................................................................................... 26
7.4 FPS...................................................................................................................................... 27
7.5 QUALITY........................................................................................................................... 27
7.6 RECORD MODE ................................................................................................................ 27
7.7 AUDIO................................................................................................................................ 27
7.8 SCHEDULE........................................................................................................................ 27
7.9 SCHEDULE RECORD........................................................................................................ 28
Chapter8. MOTION 29
8.1 CAMERA CHANNEL......................................................................................................... 29
8.2 MOTION ENABLE............................................................................................................. 29
8.3 SENSITIVITY .................................................................................................................... 29
8.4 MOTION AREA.................................................................................................................. 29
8.5 POST-RECORD TIME........................................................................................................ 31
8.6 BUZZER TIME................................................................................................................... 31
8.7 ALARM TIME .................................................................................................................... 31
8.8 MOTION TRACE ............................................................................................................... 31
Chapter9. SENSOR 32
9.1 SENSOR CHANNEL .......................................................................................................... 32
9.2 SENSOR TYPE................................................................................................................... 32
9.3 POST-RECORD TIME........................................................................................................ 32
9.4 BUZZER TIME................................................................................................................... 32
9.5 ALARM TIME .................................................................................................................... 32
Chapter10. DISKMAN 33
10.1 DISK FORMAT................................................................................................................. 33
10.2 SMART COPY MODE ...................................................................................................... 33
10.3 BACKUP ............................................................................................................................. 34
Chapter11. NETWORK 35
11.1 IP MODE ............................................................................................................................ 35
11.2 PORT................................................................................................................................. 35
11.3 IP....................................................................................................................................... 35
11.4 NETMASK........................................................................................................................ 35
11.5 GATEWAY........................................................................................................................ 35
11.6 NAME SERVER................................................................................................................ 36
11.7 DDNS................................................................................................................................ 36
Chapter12. Search & Playback 37
12.1 SEARCH.............................................................................................................................. 37

8
12.2 PLAYBACK ......................................................................................................................... 38
Chapter13. Network Remote Control 40
13.1 CONNECT ........................................................................................................................... 40
13.2 SETTING ............................................................................................................................. 41
13.3 AVI.................................................................................................................................... 42
13.4 BACKUP ............................................................................................................................. 42
13.5 REC START /REC STOP........................................................................................................ 42
13.6 LIVE................................................................................................................................... 43
13.7 PLAYBACK ......................................................................................................................... 43
13.8 FILEPLAY ........................................................................................................................... 44
Appendix A （
（（
（FIRMWARE UPGRATE）
））
）45

9
Chapter1. About ADR-7104
1.1 Overview
Designed for globally increasing surveillance requirements, ADR-7104 is a high
performance standalone Digital Video Recorder. It takes the advanced MPEG4
compression format to solve the storage problem of huge amount of video, and the friendly
UI design also enables users even unfamiliar with computer operations can easily control
this DVR. Specially, ADR-7104 features the SMART COPY function pioneered by 2SAN
DVR series. With this function, data can be backed up automatically without affecting other
DVR operations even while recording. This product also supports Triplex, which enables
Live, Record, and Network to be performed simultaneously. This high-quality DVR is
absolutely the best choice for your security surveillance.
1.2 Features
•MPEG4 compression format, D1 resolution
•4ch all real-time recording & display
•SMART COPY function for automatic HDD backup
•eSATA interface for external storage expansion
•SATA HDD hot-swappable
•Multiple recording modes
•User-friendly GUI & Multi-language OSD
•USB Interface for firmware update & data archiving
•Mouse control
•LCD panel
•Triplex：Live, Record & Network
•Network function
1.3 Specification
Video
•Video Input：4ch (BNC)
•Loop Out：4ch (BNC)
•Main Monitor Out：BNC*1, VGA*1 & S-video*1 (Option)
•Video Compression Format：MPEG4
•Display Mode：Full, 4 & PIP
Audio
•Audio Input：4
•Audio Output：1

10
Record
•Resolution (Max.)：D1:720x480 (NTSC), D1:720x576 (PAL)
•FPS：up to 120fps at CIF (NTSC), up to 100fps at CIF (PAL)
(Adjustable: 60fps at Half-D1 (NTSC), 50fps at Half-D1 (PAL) ;
30fps at D1 (NTSC), 25fps at D1 (PAL))
•Mode：Urgent, Schedule, Alarm, Motion & Always
Storage
•HDDs：Internal SATA HDD*1, Hot-swap SATA HDD*1
•External Storage Expansion：eSATA Interface
Alarm
•Alarm Input：4
•Alarm Output：1
Network
•Live video access
•Recorded video access
•Remote control
Others
•PTZ Control：Pelco-D & Pelco-P protocol
•Power：DC 12V / 5A
•Dimension：430 (W) x 73 (H) x 260(D) mm
1.4 Package
1. Digital Video Recorder (ADR-7104) x 1
2. Power Adapter x1
3. Infrared Remote Controller x1
4. Quick Installation Guide x1

11
Chapter2. System Appearance
2.1 The Front Panel
No.
Name
Function
1 Hot-swappable HDD Tray For hot-swappable HDD use
2 LCD Panel Indicates the system status
3 Setup Used for quick selecting the setup menu
4


Arrow Key
Used for changing the settings or for moving the cursor
up/down/left/right.
5 ESC Back to the menu.
6
REC Shows the recording status
LOCK Lights when all the buttons are locked
ALARM Lights when event occurs
NET Indication light for network
HDD Indication light for hard disk
POWER Shows power on/off status
7 USB Port For USB mouse use, archive, and firmware update
8
(REC) Record: emergency recording
（FR）Used for quick backward search in playback
 (PLAY / PAUSE) Pauses and resumes the video recording in playback
（STOP）Ends search during playback
（FF）Used for quick forward search in playback
LOCK Press to lock all the buttons
FREEZE Runs the FREEZE function in live mode
SEARCH Popup the search menu to search the video
MODE Press to change different display modes
ROTATE The single channel mode switches according to the specified
time on the menu
9 PTZ Used for PTZ camera control
10 ? (HELP) Q & A
11
0 ～9 (Channel Key) Press the button to display the single channel.
F+ / F- Used for PTZ camera control: Focus In & Out.
Z+ / Z- Used for PTZ camera control: Zoom In & Out
○
1
○
2
○
6
○
5
○
3
○
7
○
8
○
4
○
9
○
10
○
11

12
2.2 The Rear Panel
Video In Video Loop Alarm In & Out Power Fan
Audio In & Out Video Input
Ethernet
eSATA port Power

13
Chapter3. Installation
3.1 Install SATA HDD
Install Internal HDD
1. Remove the cover and pull the hot-swap HDD tray out.
2. Disconnect the SATA cable & 4-pin HDD power cord.
3. Loosen the screws and take the HDD bracket out.
4. Install the HDD into the lower part of the HDD bracket and tighten it. Make sure the HDD is firmly
connected with SATA connector.

14
5. Put the HDD bracket back, and make sure to fasten the screws firmly.
6. Put the hot-swap HDD tray back.
Install Hot-Swap HDD：
：：
：
1. Slightly press the blue plastic tenon (joint) downward, and the silver shaft will spring out.
2. Pull the silver shaft forward slightly to the end, and the hot-swap tray will slide a bit.
3. Hold the silver shaft, and pull the whole hot-swap tray out of case.
4. Install SATA HDD into the Hot-swap tray, and use screws to tighten it.
5. Insert the hot-swap tray into the case, and push to the end.

15
6. Follow the direction to get silver shaft & blue tenon geared. After a “click”, DONE.
Install eSATA device (Option)：
：：
：
1. External storage device with eSATA Interface can be used for storage expansion.
2. Connect the eSATA cable between the DVR and eSATA storage device.
3.2 Connect Cameras
Connect cameras to the video BNC inputs marked Video In 1~4.
3.3 Connect the monitor
ADR-7104 provide BNC, VGA, S-Video (Option) connectors for video out (for main monitor
use)
1. Connect a monitor to the connector marked CVBS.
2. Connect a monitor to the connector marked S-Video (Option).
3. Connect a monitor to the connector marked VGA
3.4 Connect the power adapter
1. Connect the power adapter to the connector marked DC-12V.
CH 1 CH 2
CH 3 CH 4

16
2. Then the DVR system will boot up automatically and start to record.

17
Chapter4. Menu Flow
4.1 Live view
The Live Display Mode supports 4 Modes, they are signal full picture, quad display
(CH1~CH4) and Picture-in-Picture (PIP) display.
At the bottom is a status bar
FUNCTIONS:
○
○○
○
1
MENU options
○
○○
○
2
Recording Status
○
○○
○
3
Used HDD capacity shown in percentages
○
○○
○
4
System date and time
○
1
○
2
○
3
○
4
Click the MENU with the mouse or press the ENTER key to open the operation menu as below

18
The operation menu has the following functions:
LIVE：
：：
：2X2 / PIP1 / PIP2，shown below
SETUP：
：：
：to enter the Main Menu shown below. It includes Camera, Record, Motion,
Sensor, Diskman, Network, Backup and System. These will be described in more
detail in next Chapter.
Note: There are three ways to enter the Main Menu:
(1) Front Panel: Press the SETUP key on the front panel to enter the Main Setup
Menu
(2) IR Remote Controller: Press the SETUP key on the remote controller to enter the
Main Menu
(3) Mouse: Please click on the MENU button in the lower left corner of the interface
then select SETUP to open the Main Setup Menu.
SEARCH: Opens the search options. See Chapter 13 for more information
MOTION: Opens or closes the motion detection grid
ZOOM: Zooms in on the Live display
PTZ: Opens the PTZ icons to control the PTZ camera. Direction Keys Up/Down/Left
Right pans/tilts the camera: Z+/Z- controls the camera zoom; F+/F- changes the
camera focus.
PIP1 PIP2

19
ROTATION: Enables display cycling
AUDIO: Turns the Live audio feed on or off
MOUSE_ON: Redetects the USB mouse
QUIT: When pressed, the system will prompt the user to confirm system shutdown. Select
YES to turn off the power.

20
Chapter5. SYSTEM
5.1 TIME SETUP
After starting the system, please set the correct system time through
SETUPSYSTEMTIME SETUP as shown below:
TIME: Year / Month / Day / Hour / Minute / Second
FORMAT：ASIA / EURO / US
