3COM SWITCH 5500 FAMILY
QUICK REFERENCE GUIDE
Overview
This Quick Reference Guide applies to the following Switch 5500 models running software version 3.2:
About the Command Line Interface
To use and navigate the command line interface of your unit, please refer to the following points for assistance:
■When initially accessing the command line interface, press Enter when prompted. The User View menu for the unit
displays. This is indicated by the chevron brackets around the name of the unit at the prompt, for example,
<sw5500-xx> (where xx is either EI or SI).
■When in the System View menu, square brackets appear around the name of the unit at the prompt, for example,
[sw5500-xx].
■You must be in the System View menu to access the configurable CLI commands.
■Some commands can be entered directly at any prompt from anywhere in the interface.
■If you enter part of a command followed by a ? (with no space between), the CLI will show you all the commands
that begin in that way.
■The term ‘view’ may be used interchangeably with the term ‘menu’.
■The undo command is placed before the command you wish to undo, for example, undo setauthentication password.
■<CTRL-A> places the cursor back to the start of the command line.
■Enter the first few characters of a command and press TAB to enter the full command without having to input the
entire command (where there is only one command that starts with the entered characters).
■Use the Up Arrow key at the prompt to repeat the previous command string.
■Use the Delete key to delete the character after the cursor; the Backspace key deletes the character before the cursor.
■When entering physical port numbers, Enter the port number as x/0/z, where x is the unit number and z is the
physical port number.
Switch 5500-SI 28-Port (3CR17151-91)
Switch 5500-SI 52-Port (3CR17152-91)
Switch 5500-EI 28-Port (3CR17161-91)
Switch 5500-EI 52-Port (3CR17162-91)
Switch 5500-EI PWR 28-Port (3CR17171-91)
Switch 5500-EI PWR 52-Port (3CR17172-91)
Switch 5500-EI 28-Port FX (3CR17181-91)
Switch 5500G-EI 24-Port (3CR17250-91)
Switch 5500G-EI 48-Port (3CR17251-91)
Switch 5500G-EI PWR 24-Port (3CR17252-91)
Switch 5500G-EI PWR 48-Port (3CR17253-91)
Switch 5500G-EI 24-Port SFP (3CR17258-91)
Copyright © 2006, 3Com Corporation. All rights reserved.
www.3Com.com
Part Number: 10014924-AA Rev. AA
Published: June, 2006

3Com Switch 5500 Family
Quick Reference Guide
Displaying Command Parameters
At the prompt, enter the name of the command followed by a space and ?. For example:
<sw5500-xx>boot ?
The following parameters are displayed:
attribute-switch Exchange the file main-attribute and backup-attribute.
boot-loader Select a file to boot at the next time
bootrom Update Bootrom
web-package Set web resource package
To specify boot loader, enter the command as follows:
<sw5500-xx>boot boot-loader ?
You only need to enter ? if parameters exist for the command.
Displaying Parent Menus
At the prompt, enter quit.
Displaying the User View Menu
Press <CTRL-Z>.
Obtaining Help
At the prompt, enter ?.
Further Information
For further information about how to use the command line interface, refer to the Command Reference Guide and
the Configuration Guide, which are both available as PDF documents on the CD that accompanied the unit.
Commands
abr-summary
Use the abr-summary command to configure route aggregation on the area border router.
OSPF Area view
access-limit
Use the access-limit command to configure a limit to the amount of supplicants in the current ISP domain.
ISP Domain view
accounting
Use the accounting command to configure an accounting scheme for the current ISP domain.
ISP Domain view
accounting domain
Use the accounting domain command to enable the DHCP accounting function.
DHCP Address Pool view
accounting-on enable
Use the accounting-on enable command to enable user re-authentication at reboot.
RADIUS Scheme view
accounting optional
Use the accounting optional command to enable the selection of the RADIUS accounting option.
ISP Domain view

3Com Switch 5500 Family 3
Quick Reference Guide
acl
Use the acl command to reference ACL and implement the ACL control to the TELNET users.
User Interface view
acl
Use the acl command to define an ACL identified by a number, and enter the corresponding ACL View.
System view
active region-configuration
Use the active region-configuration command to activate the settings of an MST (multiple spanning
tree) region.
MST Region view
add-member
Use the add-member command to add a candidate device to a cluster.
Cluster view
address-check
Use the address-check command to enable or disable DHCP relay security on a VLAN interface, so as to
start the validity check on user addresses under the VLAN interface.
VLAN Interface view
administrator-address
Use the administrator-address command to store the MAC address of the management device on a
member device.
Cluster view
am enable
Use the am enable command to enable address management IP address pool.
System view
am ip-pool
Use the am ip-pool command to set an address management IP address pool for a port, permitting the
packets in this IP address pool whose IP addresses are the source IP addresses to pass the port for layer
3 forwarding.
Ethernet Port view
am trap enable
Use the am trap enable command to enable the access management trap function.
System view
am user-bind
Use the am user-bind command to bind the MAC address and IP address of a legal user to the specified
port.
System view
Ethernet Port view
apply cost
Use the apply cost command to configure the route cost value of route information.
Route Policy view
apply poe-profile
Use the apply poe-profile command to apply the existing PoE Profile configuration to the specified
Ethernet port.
System view
apply qos-profile
Use the apply qos-profile command to apply the QoS profile to the current port.
Ethernet Port view
apply qos-profile interface
Use the apply qos-profile interface command to apply a QoS profile to one or more consecutive ports.
System view
apply tag
Use the apply tag command to configure to set the tag area of OSPF route information.
Route Policy view
area
Use the area command to enter an OSPF area view.
OSPF view

3Com Switch 5500 Family
Quick Reference Guide
arp check enable
Use the arp check enable command to enable the checking of an ARP entry so the device does not learn
the ARP entry where the MAC address is a multicast MAC address.
System view
arp static
Use the arp static command to manually configure the static ARP mapping entries in the ARP mapping
table.
Ethernet Port view
arp static
Use the arp static command to manually configure the static ARP mapping entries in the ARP mapping
table.
System view
arp timer
Use the arp timer aging command to configure the dynamic ARP aging timer.
System view
asbr-summary
Use the asbr-summary command to configure a summary of imported routes for OSPF.
OSPF view
ascii
Use the ascii command to configure data transmission mode as ASCII mode.
FTP Client view
attribute
Use the attribute command to configure some attributes for specified local user.
Local User view
authentication
Use the authentication command to configure an authentication scheme for the current ISP domain.
ISP Domain view
authentication-mode
Use the command authentication-mode to configure login authentication.
User Interface view
authentication-mode
Use the authentication-mode command to configure an OSPF area to use a specified authentication
mode.
OSPF Area view
authorization
Use the authorization none command to allow users in the current ISP domain to use network services
without being authorized.
ISP Domain view
auto-build
Use the auto-build command to configure a cluster automatically.
Cluster view
auto-execute command
Enter auto-execute command text to configure the Switch to automatically run a specified command.
User Interface view
backup current-configuration to
Use the backup current-configuration to command to back up either all configurations or the current
configuration of a specified switch to a file on a TFTP server.
User view
binary
Use the binary command to configure file transmission type as binary mode.
FTP Client view
boot attribute-switch
Use the boot attribute-switch command to toggle between the main and backup attributes of file.
User view
boot boot-loader
Use the boot boot-loader command to assign the main attribute to an App file on one switch or all switches
in the fabric, so as to use this App file as the preferred boot file upon next startup of switch.
User view

3Com Switch 5500 Family 5
Quick Reference Guide
boot boot-loader backup-attribute
Use the boot boot-loader backup-attribute command to assign the backup attribute to an App file on
one switch or all switches in the fabric, so as to use this App file as the backup boot file upon next startup
of switch.
User view
boot bootrom
Use the boot bootrom command to upgrade bootrom.
User view
boot web-package
Use the boot web-package command to assign the main or backup attribute to a Web file on the fabric, so
as to use this file as the main or backup Web file upon next startup.
User view
broadcast-suppression
Use the broadcast-suppression command to globally set the size of the broadcast traffic allowed to pass
through each Ethernet port.
System view
broadcast-suppression
Use broadcast-suppression to configure the amount of broadcast traffic that will be accepted on a port.
Ethernet Port view
bsr-policy
Use the bsr-policy command to limit the range of legal BSRs to prevent BSR spoofing.
PIM view
build
Use the build command to configure a cluster with the current switch as the management device. Argument
name specifies the name of the cluster.
Cluster view
bye
Use the bye command to terminate the connection to the remote SFTP server and return to system view.
SFTP Client view
cache-sa-enable
Use the cache-sa-enable command to enable the SA message cache mechanism.
MSDP view
c-bsr
Use the c-bsr to configure a candidate BSR.
PIM view
c-rp
Use the c-rp to configure the router to advertise itself as a candidate RP.
PIM view
cd
Use the cd command to change the current path on the remote SFTP server. If you did not specify the
remote-path argument, the current path is displayed.
SFTP Client view
cdup
Use the cdup command to return to the upper directory.
SFTP Client view
change self-unit
Use the change unit command to change the unit ID of the current Switch.
System view
change unit-id
Use the change unit-id command to change the unit ID of a Switch in the Fabric.
System view
check region-configuration
Use the check region-configuration command to display the configurations of the MST regions that are
not activated, including region name, revision level, and VLAN mapping table.
MST Region view
checkzero
Use the checkzero command to check the zero field of RIP-1 packets. By default, RIP-1 performs zero field
checking.
RIP view

3Com Switch 5500 Family
Quick Reference Guide
clock datetime
Use the clock datetime command to set the current system time and date.
User view
clock summer-time
Use the clock summer-time command to set the name, time range and offset of the daylight saving time.
User view
clock timezone
Use the clock timezone command to set local time zone information.
User view
close
Use the close command to disconnect FTP client side from FTP server side without exiting FTP client side
view so that you terminate the control connection and data connection with the remote FTP server at the
same time.
FTP Client view
cluster
Use the cluster command to enter cluster view.
System view
cluster enable
Use the cluster enable command to enable the cluster function on a switch.
System view
cluster-mac
Use the cluster-mac command to configure a multicast MAC address for cluster management. Run this
command only on the management device.
Cluster view
cluster-mac syn-interval
Use the cluster-mac syn-interval command to set the interval for the management device to send
multicast packets. This command can be executed on the management device only.
Cluster view
cluster switch-to
Use the cluster switch-to command to switch between the management device and member devices
for configuration and management.
User view
command-privilege level
Use the command-privilege level command to configure the priority level assigned to any command
within a selected view.
System view
copy
Use the copy command to copy a file.
User view
copy configuration
Use the copy configuration command to copy the configuration of a specific port to other ports, to ensure
consistent configuration.
System view
count
Use the count command to configure the packet sending times in each test.
Remote-Ping Test Group view
crp-policy
Use the crp-policy command to limit the range of legal C-RP, as well as target service group range of each
C-RP, prevent C-RP spoofing.
PIM view
cut connection
Use the cut connection command to disconnect a user or a category of users by force.
System view
data-flow-format
Use the data-flow-format command to configure the unit of data flow sent to TACACS Server.
HWTACACS view
databits
Use the databits command to configure the data bits for the AUX (Console) port to either 7 or 8.
User Interface view

3Com Switch 5500 Family 7
Quick Reference Guide
debugging
Use the debugging command to enable the system debugging.
User view
debugging arp packet
Use the debugging arp command to enable ARP debugging.
User view
debugging dhcp client
Use the debugging dhcp client command to enable DHCP client debugging.
User view
debugging dhcp-relay
Use the debugging dhcp-relay command to enable DHCP relay debugging.
User view
debugging dhcp server
Use the debugging dhcp server command to enable a specified type or all types of debugging on a DHCP
server.
User view
debugging dhcp xrn xha
Use the debugging dhcp xrn xha command to enable BOOTP client hot backup debugging.
User view
debugging dhcp xrn xha
Use the debugging dhcp xrn xha command to enable DHCP client hot backup debugging.
User view
debugging DLDP
Use the debugging dldp command to enable specific debugging for DLDP on all ports with DLDP enabled.
User view
debugging hwtacacs
Use the debugging hwtacacs command to enable HWTACACS debugging.
User view
debugging igmp
Use the debugging igmp command to enable IGMP debugging functions.
User view
debugging lacp packet
Use the debugging lacp packet command to enable LACP packets debugging at a designated port or
ports.
User view
debugging lacp state
Use the debugging lacp state command to enable LACP state machines debugging on a designated port
or ports.
User view
debugging link-aggregation error
Use the debugging link-aggregation error command to enable link aggregation error debugging.
User view
debugging link-aggregation event
Use the debugging link-aggregation event command to enable link aggregation events debugging.
User view
debugging mac-authentication event
Use the debugging mac-authentication event command to enable debugging for centralized MAC
address authentication events.
User view
debugging msdp
Use the debugging msdp command to enable debugging for MSDP.
User view
debugging multicast forwarding
Use the debugging multicast forwarding to enable multicast packet forwarding debugging functions.
User view
debugging multicast kernel-routing
Use the debugging multicast kernel-routing to enable multicast kernel routing debugging functions.
User view

3Com Switch 5500 Family
Quick Reference Guide
debugging multicast status-forwarding
Use the debugging multicast status-forwarding to enable multicast forwarding status debugging
functions.
User view
debugging ntp-service
Use the debugging ntp-service command to debug different NTP services.
User view
debugging pim common
Use the debugging pim common to enable common PIM debugging functions.
User view
debugging pim dm
Use the debugging pim dm to enable PIM-DM debugging functions.
User view
debugging pim sm
Use the debugging pim sm to enable PIM-SM debugging functions.
User view
debugging resilient-arp
Use the debugging resilient-arp command to enable resilient ARP debugging.
User view
debugging ssh server
Use the debugging ssh server command to send the negotiation process and other information prescribed
in SSH 2.0 to the information center as debugging information, and to enable debugging for a single user
interface.
User view
debugging udp-helper
Use the debugging udp-helper command to enable UDP Helper debugging.
User view
debugging vrrp
Use the debugging vrrp command to enable VRRP debugging.
User view
debugging webcache
Use the debugging webcache command to enable the debugging for Webcache redirection.
User view
default cost
Use the default cost command to configure the default routing cost of an external route imported by
OSPF.
OSPF view
default-cost
Use the default-cost command to configure the cost of the route transmitted by OSPF to a Stub or NSSA
area.
OSPF Area view
default cost
Use the default cost command to set the default routing cost of an imported route.
RIP view
default interval
Use the default interval command to configure the default interval for OSPF to import external routes.
OSPF view
default limit
Use the default limit command to configure maximum number of allowed imported routes.
OSPF view
default-route-advertise
Use the default-route-advertise command to import the default route into the OSPF Autonomous
System.
OSPF view
default tag
Use the default tag command to configure the default tag of OSPF when it redistributes an external route.
OSPF view

3Com Switch 5500 Family 9
Quick Reference Guide
default type
Use the default type command to configure the default type when OSPF redistributes external routes.
OSPF view
delete
Use the delete command to delete a specified file from the storage device of the switch.
User view
delete
Use the delete command to delete the specified file.
This command is used to delete a file.
FTP Client view
delete
Use the delete command to delete the specified file from the server.
SFTP Client view
delete-member
Use the delete-member command to remove a member from the cluster.
Cluster view
delete static-routes all
Use the delete static-routes all command to delete all the static routes.
System view
description
Use the description command to enter a description of an Ethernet port.
Use the undo description command to cancel the description.
Ethernet Port view
description
Use the description command to set a description for the current VLAN.
Use the undo description command to cancel the description of current VLAN.
VLAN view
destination-ip
Use the destination-ip command to configure the destination IP address of the test.
Remote-Ping Test Group view
detect-group
Use the detect-group command to create a detecting group and enter detecting group view.
System view
detect-list
Use the detect-list command to specify the IP address to be detected in the detecting group. This
command also specifies the order in which the IP addresses in a detecting group are detected.
Detecting Group view
dhcp enable
Use the dhcp enable command to enable DHCP.
System view
dhcp relay information enable
Use the dhcp relay information enable command to enable option 82 supporting on a DHCP relay,
through which you can enable the DHCP relay to insert option 82 into DHCP request packets sent to a
DHCP server.
System view
dhcp relay information strategy
Use the dhcp relay information strategy command to instruct a DHCP relay to perform specified
operations to DHCP request packets that carry option 82.
System view
dhcp select global
Use the dhcp select global command to configure the specified interface(s) or all interfaces to operate
in global DHCP address pool mode.
System view
VLAN Interface view
dhcp select interface
Use the dhcp select interface command to configure the specified interface(s) to operate in DHCP
interface address pool mode.
System view
VLAN Interface view

3Com Switch 5500 Family
Quick Reference Guide
dhcp-server
Use the dhcp-server command to map the current VLAN interface to a DHCP server group.
VLAN Interface view
dhcp server detect
Use the dhcp server detect command to enable the private DHCP server detecting function.
System view
dhcp server dns-list
Use the dhcp server dns-list command to configure DNS server IP address(es) for the DHCP address
pool(s) of specified interface(s).
System view
VLAN Interface view
dhcp server domain-name
Use the dhcp server domain-name command to configure a domain name for the DHCP clients whose IP
addresses are from the specified interface address pool(s).
System view
VLAN Interface view
dhcp server expired
Use the dhcp server expired command to configure the lease time of the IP addresses in the specified
interface address pool(s).
System view
VLAN Interface view
dhcp server forbidden-ip
Use the dhcp server forbidden-ip command to forbid the specified IP addresses in a DHCP address pool
to be automatically assigned.
System view
dhcp-server ip
Use the dhcp-server ip command to configure the DHCP server IP address(es) in a specified DHCP
server group.
System view
dhcp server ip-pool
Use the dhcp server ip-pool command to create a global DHCP address pool and enter DHCP address
pool view.
System view
dhcp server nbns-list
Use the dhcp server nbns-list command to configure NetBIOS server IP address(es) for the specified
DHCP interface address pool(s).
System view
VLAN Interface view
dhcp server netbios-type
Use the dhcp server netbios-type command to configure the NetBIOS node type of the DHCP clients
whose IP addresses are from the specified interface address pool(s).
System view
VLAN Interface view
dhcp server option
Use the dhcp server option command to customize DHCP options for the specified DHCP interface
address pool(s).
System view
VLAN Interface view
dhcp server ping
Use the dhcp server ping command to set the maximum number of the ICMP packets a DHCP server
sends in a ping test and the maximum response timeout time of each ICMP packet.
System view
dhcp server static-bind
Use the dhcp server static-bind command to statically bind an IP address of the current address pool
to a MAC address.
VLAN Interface view
dhcp server voice-config
Use the dhcp server voice-config command to configure option 184 and its sub-options, which will be
sent to DHCP clients by a DHCP server as well when the DHCP server assigns IP addresses of the current
address pool to DHCP clients.
VLAN Interface view
