3M Littmann CORE User manual

CORE Stethoscope

1 2
a3M™ Littmann®CORE Digital Stethoscope
Quick Start Guide
Download the Eko App from the Apple App
Store®or Google Play Store®.
Turn on Bluetooth®Wireless Technology on
your phone or tablet, launch the app, and turn
on the CORE stethoscope.
In the Box
• Eko CORE Digital Attachment and 3M™ Littmann®
Cardiology IV™ Stethoscope
• Additional set of 3M Littmann Snap Tight Soft-Sealing
Eartips (small)
• Nonchill Bell Sleeve
• USB Charging Cable
• Quick Start Guide
Eartips
Insert eartips in a forward direction.
Volume
Use the (+) and (-) buttons to adjust volume. There are
7 volume steps.
Turn On and Off
When the CORE stethoscope is off, it functions as an
unamplified stethoscope.
To turn the CORE stethoscope on, press the power toggle in.
The light will begin flashing. You will now hear amplified and
filtered sound in the eartips.
Telemedicine and AI Features
Eko offers telemedicine and AI features that require a
software subscription (where available, sold separately).
You can setup a subscription online at ekohealth.com
Active Noise Cancelling
The CORE stethoscope includes active noise cancelling to
remove ambient noise from the surrounding environment.
Active noise cancelling can be turned off or on through the
Eko App.
Notifications
(blinking) (yellow) (yellow)
CORE stethoscope
is on & seeking
device
CORE stethoscope
is off & charging
CORE stethoscope
is low on battery
(green) (blue)
CORE stethoscope
is on & connected
CORE stethoscope
is fully charged
CORE stethoscope
is recording
Recording
When connected to the Eko App, press
the (o) button to begin recording.

1 2
a
Charging
Connect the micro USB cable to the CORE stethoscope and
use a UL-certified or CE-marked 5V USB wall charger. The
CORE stethoscope will take about 2 hours to fully charge. The
light will turn green when it is fully charged.
User Manual
Review the user manual before using your Littmann CORE
Stethoscope. To view the manual visit:
ekohealth.com/getstarted
For more information on 3M devices,
see HCBGregulatory.3M.com
Service and Support
In the USA, please visit littmann.com/service or
call 1-800-228-3957. If you are outside of the USA,
please visit littmann.com for the contact information of your
local 3M office.
Apple App Store is a trademark of Apple Inc.
Google Play and the Google Play logo are trademarks of
Google LLC.
Bluetooth®is a registered trademark of Bluetooth SIG
LBL 143 Rev B

Cardiology Stethoscopes
Littmann®
CardiologyIV™
Stethoscope

Figures
1
2 3
4 5
6 7
8 9
1

a
2
3M™Littmann
®
Cardiology IV™Stethoscope UserManual
Intended Use: The 3M™ Littmann
®
Cardiology IV™ Stethoscope is intended for use by healthcare professionals for medical diagnostic purposes
only. It can be used for auscultation of heart, lung, and other body sounds.
Please report a serious incident occurring in relation to the device to 3M and the local competent authority (EU) or local regulatory authority.
Instructions for Use (see Figures pp. 1):
• Place the Stethoscope in Your Ears: The eartips should point forward toward your nose (Figure 1).
• Adjust the Headset Tension for Comfort and Sound Quality: Pull the eartubes apart (Figure 2) or squeeze them together (Figure 3).
• Select the Active Side of the Chestpiece: A mark on the stem identifies which side of the chestpiece is acoustically active. Rotate the
chestpiece to change which side is active.
o
Use the large side of the chestpiece for adults. Use the small side for pediatric or thin patients, around bandages, and for carotid assessment.
• Listen to Low and High Frequency Sounds with Littmann Tunable Diaphragms:
o
To emphasize lower frequency sounds, use light pressure against the patient (Figure 4).
o
To emphasize higher frequency sounds, use firm pressure against the patient (Figure 5).
• Convert to a Traditional Open Bell:
To remove the diaphragm from the small side, hold the large side of the chestpiece in one hand.While wearing an exam glove on your other hand,
use your gloved thumb to peel the pediatric diaphragm off the small side of the chestpiece (Figure 6). Install the non-chill sleeve on the open
bell(Figure 7).
Cleaning, Disinfection and Storage
Clean between exams using a 70% isopropyl alcohol wipe or disposable wipe with soap and water. A 2% bleach solution may be used to disinfect
your stethoscope; however, the tubing may become discolored after exposure to bleach.
The diaphragms, non-chill bell sleeve, and eartips may be removed for cleaning (Figure 6, 7 and 8). Ensure all parts and surfaces are dry before
reassembly. To attach the eartips, push the small side firmly onto the eartube until it snaps fully into place (Figure 9). To prevent ear canal injury, be
sure eartips are firmly attached to the headset before inserting them into your ears.
To prevent stethoscope damage, do not: immerse your stethoscope in any liquid, subject your stethoscope to any sterilization process, or store in
extreme heat. To prevent staining of stethoscope tubing, avoid contact with pens, markers, newsprint, or other printed material. It is good practice to
wear your stethoscope over a collar whenever possible.
Disposal: Dispose of contents/container in accordance with the local/regional/national/international regulations.
Littmann Stethoscope Service and Warranty Program: The Littmann Cardiology IV stethoscope is warranted against any defects in material and
workmanship for a period of seven (7) years. Within the warranty period, repairs will be made without charge upon the return of the stethoscope
to 3M, except in cases of obvious abuse or accidental damage. For service and repair in the USA, please visit www.littmann.com/service or call
1-800-292-6298. If you are outside of the USA, please visit www.littmann.com for the contact information of your local 3M office.
For more information, visit www.littmann.com.
