MP8760 Multimedia Projector
Operator’s Guide
Projecteur multimédia MP8760 Guide d’utilisation
MP8760 Multimedia-Projektor Bedienerhandbuch
Proyector de medios múltiples (multimedia) MP8760 Guía del operador
Guida dell’operatore del proiettore multimediale MP8760
Bruksanvisning för MP8760 Multimediaprojektor
3M MP8760 Multimediaprojector Gebruiksaanwijzing

Downloaded from Projector.com
3M IPC 2000 3MMultimedia Projector MP8760 i
ENGLISH
MP8760 Multimedia Projector
Table of Contents
SAFEGUARDS.......................................................................................................................................................................ii
WARRANTY.........................................................................................................................................................................iv
SECTION 1: UNPACK.........................................................................................................................................................1
1-1. CONTENTS OF SHIPPING BOX.....................................................................................................................................1
1-2. KEEP YOUR PACKING MATERIALS............................................................................................................................1
1-3. WHAT’S NEXT?..........................................................................................................................................................1
SECTION 2: PRODUCTION DESCRIPTION.................................................................................................................2
2-1. MACHINE CHARACTERISTICS....................................................................................................................................2
2-2. PARTS IDENTIFICATION LIST.....................................................................................................................................2
SECTION 3: SET UP/CONNECTIONS.............................................................................................................................3
3-1. TERMINAL CONNECTION PANEL...............................................................................................................................3
3-2. OPERATOR TOUCH PANEL KEYPAD..........................................................................................................................3
3-3. MOUSE CONNECTION.................................................................................................................................................4
3-4. CABLE CONNECTIONS................................................................................................................................................4
3-5. IMAGE SIZE (PROJECTOR-TO-SCREEN DISTANCE)....................................................................................................5
3-6. IMAGE HEIGHT...........................................................................................................................................................6
SECTION 4: OPERATING INSTRUCTIONS..................................................................................................................7
4-1. POWER UP PROJECTOR..............................................................................................................................................7
4-2. STANDBY MODE........................................................................................................................................................8
4-3. PROJECTOR POWER DOWN........................................................................................................................................8
4-4. USING SYSTEM MENUS..............................................................................................................................................8
4-5. MENU ADJUSTMENTS/SETTINGS...............................................................................................................................9
SECTION 5: REMOTE CONTROL.................................................................................................................................13
5-1. REMOTE CONTROL FUNCTIONS...............................................................................................................................13
5-2. MEANING OF THE ICONS.........................................................................................................................................14
5-3. BATTERY REPLACEMENT.........................................................................................................................................16
SECTION 6: MAINTENANCE.........................................................................................................................................17
6-1. REPLACING THE AIR FILTER....................................................................................................................................17
6-2. REPLACING PROJECTION LAMP...............................................................................................................................18
6-3. LAMP LIFE INDICATOR.............................................................................................................................................19
6-4. CLEANING THE PROJECTOR.....................................................................................................................................19
SECTION 7: TROUBLESHOOTING..............................................................................................................................20
7-1. TROUBLESHOOTING PROBLEMS AND SOLUTIONS...................................................................................................20
7-2. SERVICE INFORMATION...........................................................................................................................................22
SECTION 8: PRODUCT SPECIFICATIONS.................................................................................................................23
8-1. TECHNICAL SPECIFICATIONS...................................................................................................................................23
8-2. ACCESSORY & SPARE PARTS LIST..........................................................................................................................24
8-3. HOW TO ORDER.......................................................................................................................................................24
APPENDIX............................................................................................................................................................................25

Downloaded from Projector.com
ii 3MMultimedia Projector MP8760 3M IPC 2000
ENGLISH
WARNING
Safeguards
INTENDED USE
Before operating the machine, please read the entire manual thoroughly. The 3M Multimedia Projector MP8760
was designed, built, and tested for use indoors, using 3M lamps, 3M ceiling mount hardware and nominal local
voltages. The use of other replacement lamps, outdoor operation, operation in environments containing heavy
cigarette smoke or different voltages has not been tested and could damage the projector or peripheral equipment
and/or create a potentially unsafe operating condition.
IMPORTANT SAFEGUARDS
1. Read and understand all instructions before using. Pay particular attention to areas where this symbol !is
shown.
Indicates a potentially hazardous situation which, if not avoided, could result in death
or serious injury.
!Caution - Indicates a potentially hazardous situation which, if not avoided, could result in minor or
moderate injury. It may also be used to alert against unsafe practices.
!Note - Used to emphasis important conditions or details.
2. Close supervision is necessary when any appliance is used by or near children. Do not leave appliance
unattended while in use.
3. Never look directly into the projector lens when the lamp is on. The NTP (New Tip Placement) lamp produces
a strong light that could damage your eyesight.
!4. Care must be taken as burns can occur from touching hot parts.
5. Do not operate appliance with a damaged cord or if the appliance has been dropped or damaged - until it has
been examined by a qualified service technician.
!6. Position the cord so that it will not be tripped over, pulled or contact hot surfaces.
7. If an extension cord is necessary, a cord with an earth/ground and a current rating at least equal to that of the
appliance should be used. Cords rated for less amperage than the appliance may overheat.
8. Always unplug appliance from electrical outlet before cleaning and servicing and when not in use. Grasp plug
and pull to disconnect.
9. To reduce the risk of electric shock, do not immerse this appliance in water or other liquids.
10. To reduce the risk of electric shock, do not disassemble this appliance or attempt to service it yourself. Take it
to a qualified technician when service or repair work is required.
Incorrect reassembly can cause electric shock when the appliance is subsequently used.
11. The use of an accessory attachment not recommended by the manufacturer may cause a risk of fire, electric
shock, or injury to persons.
12. Connect this appliance to a grounded outlet.
!13. This unit is equipped with optical lenses and should not be exposed to direct sunlight.
14. Keep ventilation openings free of any obstructions.
15. Always operate machine on a flat, sturdy surface.
16. The projection lamp contains mercury. Always dispose of it in a proper manner according to local regulations.
17. To avoid premature lamp failure, do not change the mounting position of the projector (desktop ⇒ceiling
mount or ceiling mount ⇒desktop mount) and continue to use the same lamp.
18. To avoid deposits from forming on internal components, do not operate projector in extremely humid
environments (RH > 80%) or near any type of fine mist.

Downloaded from Projector.com
3M IPC 2000 3MMultimedia Projector MP8760 iii
ENGLISH
PRODUCT SAFETY LABELS
The following safety labels are used on or within the MP8760 projector to alert you to items or areas
requiring your attention:
LOCATION OF LABELS
SAVE THESE INSTRUCTIONS
The information contained in this manual will help you operate and maintain your 3M MP8760 Multimedia
Projector.
Inside of projector gets very HOT! Allow internal
parts to cool before replacing the lamp.

Downloaded from Projector.com
iv 3MMultimedia Projector MP8760 3M IPC 2000
ENGLISH
Warranty
LIMITED WARRANTY
3M warrants this product against any defects in material and workmanship, under normal use and storage, for a period
of two years from date of purchase. Proof of purchase date will be required with any warranty claim. In the event this
product is found to be defective within the warranty period, 3M’s only obligation and your exclusive remedy shall be
replacement of any defective parts (labor included).
To obtain warranty service, immediately notify the dealer from which you purchased the product of any defects. In the
USA call 1–800–328–1371 for warranty or repair service.
Exclusion to Warranty
The projection lamps are considered a consumable item and are warrantied for 90 days or 180 hours of operation
whichever occurs first.
LIMITATION OF LIABILITY
THE FOREGOING WARRANTY IS MADE IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, AND
3M SPECIFICALLY DISCLAIMS ANY IMPLIED WARRANTY OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. 3M SHALL NOT BE LIABLE FOR ANY DAMAGES, DIRECT, CONSEQUENTIAL, OR
INCIDENTAL, ARISING OUT OF THE USE OR INABILITY TO USE THIS PRODUCT.
Important: The above warranty shall be void if the customer fails to operate product in accordance with 3M’s written
instructions. This warranty gives you specific legal rights and you may have other rights that vary from state to state.
FCC STATEMENT - CLASS A: This equipment generates, uses and can radiate radio frequency energy, and if not
installed and used in accordance with the instruction manual may cause interference to radio communications. It has
been tested and found to comply with the limits for a Class “A” computing device pursuant to Subpart B of Part 15 of
the FCC Rules, which are designed to provide reasonable protection against such interference when operated in a
commercial environment. Operation of this equipment in a residential area is likely to cause interference in which case
the user at his/her own expense will be required to take whatever measures may be required to correct the interference.
EEC STATEMENT: This machine was tested against the 89/336/EEC (European Economic Community) for EMC
(Electro Magnetic Compatibility) and fulfills these requirements.
Video signal cables: Only use cables delivered by the manufacturer.
Video inputs: The input signal amplitude must not exceed the specified level.
PATENTS, TRADEMARKS & COPYRIGHTS
IBM and PS/2 are registered trademarks of International Business Machines Corporation. Apple Macintosh and
ADB are registered trademarks of AppleComputer, Inc. Microsoft Windows is a trademark of the Microsoft
Corporation. DLPis a trademark of Texas Instruments Incorporated. All other products are trademarks or registered
trademarks of their respective companies.

Downloaded from Projector.com
3M IPC 2000 3MMultimedia Projector MP8760 1
ENGLISH
Section 1: Unpack
1-1. Contents of Shipping Box
The MP8760 is shipped with the necessary cables required for standard VCR, PC or laptop computer connections.
Carefully unpack and verify that you have all of the items shown below in Figure 1–1. If any of these items are
missing, please contact your place of purchase.
Item Quantity
1. MP8760 Multimedia Projector 1
2. IR Remote control transmitter 1
(Two AAA batteries included) 2
3. Power cord set (US, UK, Europe) 1
4. VGA cable (2m) 1
5. RCA Video/ Audio (3m) 1
Item Quantity
6. S-VHS video cable (3m) 1
7. PS/2-Mouse-Adapter 1
8. Serial Mouse cable 1
9. Operator’s Guide, 7 languages(not shown) 1
10. Registration card 1
11. Telephone (800#) stickers 2
Figure 1-1. Packing List
1-2. Keep Your Packing Materials
Save the shipping box and packing materials in the event the MP8760 should require shipping to a 3M Service Center
for repair. Use packing material to protect projector.
1-3. What’s Next?
Take a few minutes to review Section 2 to familiarize yourself with the MP8760 machine characteristics and then turn
to Section 3 to set up the projector.
We hope you will enjoy using this high performance product in your meetings, presentations and training sessions.
This product has been produced in accordance with 3M’s highest quality and safety standards to ensure smooth and
trouble-free use in the years to come.
3
12
4756
ENTER
FOCUSZOOM
PC MENU
VIDEO AUDIO
12 3
4 5 6
789
0
VOL BRIGHT
REVEAL
—+
BLANK
DRAG
CH—CH+
TIMER
OPTIMIZE TEXT WINDOW
MOUSE
POINTER
MODE
1-2-3-4 INFO
MAGNIFY
FREEZE
8
!!
!! Note
A set of cables/adapters for connection
to Apple Macintosh computers is
available as an option.

Downloaded from Projector.com
23M
Multimedia Projector MP8760 3M IPC 2000
ENGLISH
Section 2: Production Description
2-1. Machine Characteristics
The MP8760 integrates NTP lamp and Digital Light Processor (DLP) technology. It accepts input from computer
and/or video sources and projects a super bright image.
The MP8760 Multimedia Projector is easy to set up and use. It offers the following features:
•Extremely light weight and portable
•NTP projection lamp 350W
•VGA (640 x 480) expansion
•SVGA (800 x 600) expansion
•XGA (1024 x 768) native resolution
•SXGA (1280 x 1024) compressed
•NTSC, PAL, SECAM compatible
•Ability to display 16.7 million colors
•Two computer input connections each with a
separate audio-in connection
•Built-in Serial, PS/2 and ADB mouse
emulation
•Three video/audio input connections
•Power focus, zoom and height shift
•Full function remote control
•Surround sound system
•Horizontal and vertical image inverting
function allows rear screen and ceiling
mounted projection
•On-screen menu for easy projector set up
•Menus display in English, German, French,
Spanish, Italian, Dutch, Swedish
•0-12 degree adjustable keystone correction
2-2. Parts Identification List
1. Infrared Remote Control Transmitter
2. 3 Speakers (Surround Sound System)
3. Operator Touch Panel
4. Exhaust Fan
5. Terminal Connections
6. Height Adjustment Foot
7. Projection Lens
8. Air intake/air filter
9. Carry Handle
10. Release Button (height adjustment foot)
11. AC Power Connection
12. AC Power Switch
13. Lamp Door
14. Lamp Door Release Button
15. Infrared Sensor
AUX SVHS/ AUDIO IN VIDEO 1 / AUDIO IN VIDEO 2 / AUDIO IN MONITOR
RS232
PC / RGB 2
PC / RGB 1
AUDIO IN AUDIO OUT
OI
1
6
EPS-19A
12
5
8
2
4
3
7
9
10 14
11
13
15
ENTER
FOCUSZOOM
PC MENU
VIDEO AUDIO
12 3
4 5 6
789
0
VOL BRIGHT
REVEAL
—+
BLANK
DRAG
CH—CH+
TIMER
OPTIMIZE TEXT WINDOW
MOUSE
POINTER
MODE
1-2-3-4 INFO
MAGNIFY
FREEZE
Figure 2-1. Parts Identification

Downloaded from Projector.com
3M IPC 2000 3MMultimedia Projector MP8760 3
ENGLISH
Section 3: Set Up/Connections
3-1. Terminal Connection Panel
The MP8760 projector has terminal connections on the backside of the projector. Refer to Section 3.4-Cable
Connections for more detail.
1. AUX: Only compatible with 3M devices.
2. SVHS/AUDIO IN: SVHS and audio input.
3. VIDEO1/AUDIO IN: Video1 and audio input.
4. VIDEO2/AUDIO IN: Video2 and audio input.
5. RS-232C: Mouse emulation/external projector control.
6. MONITOR: Output to external monitor.
7. PC/RGB1: Video input #1 from computer.
8. PC/RGB2: Video input #2 from computer.
9. AUDIO IN2: Audio L/R input from computer #2
10. AUDIO IN1: Audio L/R input from computer #1.
11. AUDIO OUT: Audio L/R output to external audio system.
3-2. Operator Touch Panel Keypad
The MP8760 operator touch panel keypad (Figure 3-2) is located on top of the projector. Refer to Section 4 for more
detail on using the keypad.
1. Zoom: Adjust (decrease/increase) image size.
2. Video: Select Video1, Video2 or S-VHS input
3. PC: Select PC/RGB 1/2 input.
4. Enter: Initiate drop windows, toggle check box
(on/off), display Info sub-menu or press and hold
then use Disc Pad to reposition menu location.
5. Volume (-/+): Adjust (increase/decrease) audio
level.
6. Mute: Toggle speakers on/off.
7. Brightness (-/+): Adjust image brightness. (See
Menu.)
8. Disc/Pad: Move cursor up/down, left/right.
9. Menu: Display/remove menus.
Menu (-/+): Increase/decrease menu value.
10. Aux: Toggle On/Off a 3M compatible device.
11. Focus: Adjust image focus.
12. Standby: Switch between standby mode (lamp
off, fan off after cool down) and projection mode
(lamp on, fan on).
Figure 3-2. Operator Panel Keypad
ENTER
FOCUS
ZOOM
PC MENU
VIDEO AUX
++
——
1
2
3
11
10
9
8
7
6
12
4
5
AUX SVHS / AUDIO IN VIDEO 1 / AUDIO IN VIDEO 2 / AUDIO IN MONITOR
RS232
PC / RGB 2
PC / RGB 1
AUDIO IN AUDIO OUT
21 3 46 8 9 10
5 7
AUX SVHS / AUDIO IN VIDEO 1 / AUDIO IN VIDEO 2 / AUDIO IN MONITOR
RS232
PC / RGB 2
PC / RGB 1
AUDIO IN AUDIOOUT
OI
Figure 3-1. Input Connection Terminals

Downloaded from Projector.com
43M
Multimedia Projector MP8760 3M IPC 2000
ENGLISH
3-3. Mouse Connection
The MP8760 has mouse emulation capability. Connect your computer mouse to the MP8760 and control computer
mouse functions using the remote control.
1. Power down the computer and projector.
2. Remove the mouse cable connection from your computer mouse port.
3. Connect the 9-pin D-Sub plug on the mouse cable to the RS-232 port on the projector.
4. RS-232 Serial Mouse: Connect 9-pin D-Sub plug on mouse cable to the serial port on the computer.
PS/2 Mouse: Connect 9-pin D-Sub plug on mouse cable to PS/2 adapter and connect the 6-pin Mini-DIN adapter
plug to the PS/2 port on the computer.
MAC ADB: Connect 9-pin D-Sub plug on mouse cable to the Mac ADB adapter and connect the 4-pin Mini-DIN
plug on ADB adapter to the ADB port on the computer.
(The Mac ADB adapter is an accessory item that must be ordered separately)
!!
!! Note
For serial mouse connections to a laptop computer,
refer to the manufacturer’s operating instructions.
The internal pointing device or serial port
configurations may need to be changed.
5. First, power on the projector, then power on the computer.
!!
!! Note
Mouse emulation only works, when all cable
connections are established and the proper start up
sequence is followed. See section 4–1.
!!
!! Note
The recommended mouse drivers for mouse
emulation is the Standard Microsoft Mouse, Serial
or PS/2.
3-4. Cable Connections
1. Turn off all power to the projector and input sources during cable hook up.
!
Caution
To prevent damage to equipment, all power to MP8760 and input
sources must be turned OFF during cable hook up.
2. Connect cables being careful not to bend any pins in the cable plug or input terminal (Figure 3-1).
3. Start up projector then start up input sources. Section 4–1.
