Digimatic™
RADIO FREQUENCY (RF) CAPACITANCE
POINT LEVEL INDICATOR
INSTALLATION INSTRUCTIONS
OPERATION MANUAL
Part No DML4W

CUSTOMER SAFETY RESPONSIBILITIES Page 4 - 5
PRODUCT OVERVIEW Page 6
SPECIFICATIONS Page 6
DIMENSIONS Page 7
INSTALLATION Page 8
STANDARD WIRING DIAGRAM Page 9
SENSOR OPERATION Page 10 - 11
SENSOR CALIBRATION Page 12 - 13
POWER SHIELD OVERVIEW Page 14
TESTING AND COMMISSIONING Page 15
TROUBLESHOOTING GUIDE Page 15
PARTS AND ACCESSORIES Page 16
PRODUCT WARRANTY Page 17
TABLE OF CONTENTS

PAGE 4
Dear 4B Customer:
Congratulations on your purchase. 4B appreciates your business and is pleased you have chosen our
products to meet your needs.
Please read in its entirety and understand the literature accompanying the product before you place the
product into service. Please read the safety precautions carefully before operating the product. With each
product you purchase from 4B, there are some basic but important safety considerations you must follow
to be sure your purchase is permitted to perform its design function and operate properly and safely, giving
you many years of reliable service. Please read and understand the Customer Safety Responsibilities
listed below. Failure to follow this safety directive and the Operation Manuals and other material furnished
or referenced, may result in serious injury or death.
SAFETY NOTICE TO OUR CUSTOMERS
A. In order to maximize e󰀩ciency and safety, selecting the right equipment for each operation is vital.
The proper installation of the equipment, and regular maintenance and inspection is equally important
in continuing the proper operation and safety of the product. The proper installation and maintenance
of all our products is the responsibility of the user unless you have asked 4B to perform these tasks.
B. All installation and wiring must be in accordance with Local and National Electrical Codes and
other standards applicable to your industry. The installation of the wiring should be undertaken by
an experienced and qualied professional electrician. Failure to correctly wire any product and/or
machinery can result in the product or machine failing to operate as intended, and can defeat its design
function.
C. Periodic inspection by a qualied person will help assure your 4B product is performing properly. 4B
recommends a documented inspection at least annually and more frequently under high use conditions.
D. Please see the last page of this manual for all warranty information regarding this product.
CUSTOMER SAFETY RESPONSIBILITIES
1. READ ALL LITERATURE PROVIDED WITH YOUR PRODUCT
Please read all user, instruction and safety manuals to ensure that you understand your product operation
and are able to safely and e󰀨ectively use this product.
2. YOU BEST UNDERSTAND YOUR NEEDS
Every customer and operation is unique, and only you best know the specic needs and capabilities of
your operation. Please go to www.go4b.com or call the 24-hour hotline at [phone] for assistance
with any questions about the performance of products purchased from 4B. 4B is happy to discuss product
performance with you at any time.

PAGE 5
3. SELECT A QUALIFIED AND COMPETENT INSTALLER
Correct installation of the product is important for safety and performance. If you have not asked 4B to
perform the installation of the unit on your behalf, it is critical for the safety of your operation and those
who may perform work on your operation that you select a qualied and competent electrical installer to
undertake the installation. The product must be installed properly to perform its designed functions. The
installer should be qualied, trained, and competent to perform the installation in accordance with local
and national electrical codes, all relevant regulations, as well as any of your own standards and preventive
maintenance requirements, and other product installation information supplied with the product. You
should be prepared to provide the installer with all necessary installation information to assist in the
installation.
4. ESTABLISH AND FOLLOW A REGULAR MAINTENANCE AND INSPECTION SCHEDULE FOR
YOUR 4B PRODUCTS
You should develop a proper maintenance and inspection program to conrm that your system is in good
working order at all times. You will be in the best position to determine the appropriate frequency for
inspection. Many di󰀨erent factors known to the user will assist you in deciding the frequency of inspection.
These factors may include but are not limited to weather conditions; construction work at the facility; hours
of operation; animal or insect infestation; and the real-world experience of knowing how your employees
perform their jobs. The personnel or person you select to install, operate, maintain, inspect or perform
any work whatsoever, should be trained and qualied to perform these important functions. Complete
and accurate records of the maintenance and inspection process should be created and retained by you
at all times.
5. RETAIN AND REFER TO THE OPERATION MANUAL FOR 4B’S SUGGESTED MAINTENANCE
AND INSPECTION RECOMMENDATIONS
As all operations are di󰀨erent, please understand that your specic operation may require additional
adjustments in the maintenance and inspection process essential to permit the monitoring device to
perform its intended function. Retain the Operation Manual and other important maintenance and service
documents provided by 4B and have them readily available for people servicing your 4B equipment.
Should you have any questions, please call go to www.go4b.com or call the 24-hour hotline at +1-309-
698-5611.
6. SERVICE REQUEST
If you have questions or comments about the operation of your unit or require the unit to be serviced
please contact the 4B location who supplied the product or call us via our 24-hour hotline number in the
USA (309-698-5611). Please have available product part numbers, serial numbers, and approximate
date of installation. In order to assist you, after the product has been placed into service, complete the
online product registration section which is accessed via our website www.go4b.com.

PRODUCT OVERVIEW
The DIGIMATIC is a  xed point Level Controller incorporating a microcomputer which is used to automatically
calibrate the probe to suit the material being detected. Full manual override facilities are included.
The DIGIMATIC employs a power shield to minimise the e󰀨ect of material adhering to the probe making it
ideal for detecting most materials including sticky or viscous types. It is equally suited to both liquids and
solids. The probe may be a solid rod, metal plate or wire rope. The self contained DIGIMATIC is normally
supplied with a loose probe, available as a stainless steel rod in standard lengths of 100mm, 1 metre or 2
metres, or as a 10 metre wire rope suspension probe and weight.
The probe should be screwed to the DIGIMATIC. Prior to attachment, the probe length can be reduced or
increased, if desired, but see notes a) and b) regarding minimum surface area.
NOTES:-
The DIGIMATIC sensitivity is proportional to the surface area of the probe. When using a 16mm dia. probe the minimum length
to use, for the majority of materials, is 200mm. This should be treated as the minimum if
possible.
If the probe length needs to be reduced to less than 200mm, the surface area should be maintained. This can be achieved by
increasing the diameter, by tting a metal tube over the probe, or by bending the probe rod. In certain high density materials it
may be possible to reduce the length without compensation.
SPECIFICATIONS
Power Supply - 110V/230V ac 50/60 Hz or 24V dc (Stabilised) (+6.5% to -10%).
Operating Temp. - -20° C to 50° C
Output - S.P.C.O 240 VAC Contacts Rated at 2.5 Amps non-inductive
Mounting - Via 1” BSP Parallel thread
Fail Safe - Low Level or High Level (Selectable)
Calibration - Push Button (With or Without Material)
LED Display - Measured Values (Covered, Uncovered, Trip)
LED Indicator - Material Detection
Time Delay - 0 - 128 second variable. (prevents false signaling from splashing).
Probes - Stainless Steel, available in 100mm, 1 metre, 2 metre, or 10 metre wire rope
Conduit Entry - Two conduit entry tapped 20mm (One blind, drill out to use).
Enclosure - Modied Polyamide 66.
Protection - IP65
Earth Bonding - Earth stud located on exterior of main case. This stud must be connected to earth, bonded to container or metalwork of container and exterior of armour
cabling, if used
PAGE 6

PAGE 7
DIMENSIONS
ALL DIMENSIONS
IN MM

PAGE 8
INSTALLATION
A thread locking compound is already applied to the probe xing stud of the Digimatic. This will prevent the
probe rod from vibrating loose. Once tted, the compound is fully hardened after 20 minutes.
IMPORTANT: If the probe rod is removed from the unit for any reason, a thread locking compound must
be applied before the rod is retted.
When mounting all versions of the Digimatic, care must be taken to ensure that the power shield is properly
installed.
DIGIMATIC will operate on 110V/230V ac 50/60Hz or 24V dc supplies. The unit may be wired in ordinary
un-screened cable of any length and need not be separated from other cables.
A SUPPLY EARTH IS ESSENTIAL!
When mounting the DIGIMATIC, care must be taken to ensure that the exposed end of the power shield
protrudes into the container.
Mount unit securely to minimise vibration. Connect in accordance with the standard wiring diagram, and
set High/Low switch to required position (see below), ensure that cable gland and back cover are fully
tightened when nished. The DIGIMATIC has two 20mm cable entries, one of which is blank, the blank
may be drilled out carefully if required; it must not be knocked out.
The unit should be wired and earthed in accordance with appropriate Electrical Regulations. The unit must
beearthedandtheterminalMUSTbe bonded to the earth bond stud.Onmetalcontainers,unitearthMUST
be bonded to the container. If the container is non-metallic, metal  anges or couplings used to mount probe
should be bonded to earth. This also applies to probes mounted in wooden or plastic tops of metal bins.
Fail Safe Setting
The “High/Low” switch, sets the fail safe mode. In the “High” position, the relay is de-energised with material present. In the
“Low” position, the relay is energised with material present. Normally, the “High” position is used for high level probes and the
“Low” for low level probes. Intermediate probe settings depend upon individual requirements.
WARNING
Proper spacing of the power shield is vital for correct operation. For questions regarding proper spacing
of the power shield to the vessel wall, contact 4B.

PAGE 9
All wiring must be In accordance with local and national electrical codes and should
be undertaken by an experienced and qualied electrician.
A thread locking compound is already applied to the probe xing stud of the
DIGIMATIC. This will prevent the probe rod from vibrating loose. Once tted, the
compound is fully hardened after 20 minutes.
IMPORTANT: If the probe rod is removed from the unit for any reason. a thread
locking compound must be applied before the rod is retted.
STANDARD WIRING DIAGRAM

SENSOR OPERATION
PAGE 10
FAIL SAFE SETTING -
The “High/Low” switch (D - Image D), sets the fail safe mode. In the “High” position, the relay is energized
without material present. In the “Low” position, the relay is energized with material present. Normally,
the “High” position is used for high level probes and the “Low” position for low level probes. Intermediate
probe settings depend upon individual requirements.
ELECTROSTATIC RISK - Ensure that the enclosure is not subject to charging in end application.
PARK MODE -
In normal operation, the LED display shows a value representing the capacitance measured by the probe
at the time.
Pressing and holding the “Probe Covered / Raise” button (E - Image D) will cause the display to
show CXXX followed by RXXX.
Pressing and holding the “Probe Un-Covered / Lower” button (F - Image D) will cause the display
to show UXXX followed by RXXX.
CXXX is the probe covered value measured during calibration, UXXX is the uncovered value and RXXX is
the relay operating point which theAuto-Set calculates and is half way between the two measured values.
NOTE
In park mode, settings are “View Only” and cannot be altered.
Image D

PAGE 11
CAL MODE (AUTO/MAN SWITCH SET TO AUTO) -
In this mode, pressing and holding the “Probe Covered / Raise” button (E - Image D) with the probe
covered, will cause the unit to measure and display the covered value, and recalibrate the relay
operating point if necessary.
Pressingandholdingthe“Probe Un-Covered / Lower” button(F-ImageD)withtheprobeuncovered,
will cause the unit to measure and display the uncovered value, again recalibrating the relay
operating point if necessary.
CAL MODE (AUTO/MAN SWITCH SET TO MAN) -
In this mode, pressing and holding the “Probe Covered / Raise” button (E - Image D) will cause the
display to momentarily display the present relay operating point and then to increment the setting
slowly and then rapidly to set a higher operating point.
Pressing and holding the “Probe Un-Covered / Lower” button (F - Image D) will cause the display
to momentarily show the current relay operating point, and then decrement the setting, slowly and
then rapidly.
Once adjusted in manual mode, any previous settings will be lost. The CXXX reading will be 1 above the
relay operating point and the UXXX reading 1 below.
NOTE
Always return to “Park” after calibration.

PAGE 12
SENSOR CALIBRATION
The Digimatic can be calibrated automatically, manually or by a combination of the two methods.
Usually, automatic calibration is the simplest method, particularly when the vessel can be lled to cover
the probe.
Manual calibration is useful when a number of probes in similar applications need to be set. Once the
correct calibration has been determined and noted, on one system, the remainder can be set to the
same setting.
AUTOMATIC CALIBRATION (MATERIAL AVAILABLE) -
1. Set Park/Cal switch (A - Image D) to Cal and Auto/Man switch (C - Image D) to Auto. The Cal
LED will ash.
2. Ensure that the probe is uncovered and press and hold the “Probe Un-Covered / Lower”
button (F - Image D) button. The display will show UXXX followed by RXXX.
3. Fill the vessel su󰀩ciently to cover the probe and then press the “Probe Covered / Raise”
button (E - Image D) button. Display will show CXXX followed by RXXX.
4. Return the Park/Cal switch (A - Image D) to park. The unit is now calibrated. UXXX and
CXXX values can be viewed but not altered by pressing the “Probe Un-Covered / Lower” and
“Probe Covered / Raise” buttons.
SEMI-AUTOMATIC CALIBRATION (MATERIAL NOT AVAILABLE) -
5. Follow steps 1 & 2 above.
6. Set Cal/Park switch (A - Image D) to Park and press the “Probe Un-Covered / Lower” button
(F - Image D) button. Note the UXXX reading but ignore the RXXX reading. Return the Cal/
Park switch (A - Image D) to Cal and set the Auto/Man switch (C - Image D) to Man.
7. From Table A below, select the nearest material type to be detected for your application and
add the value to the UXXX reading determined in step 6.
8. Press the “Probe Covered / Raise” button (E - Image D) button to raise the reading and
the “Probe Un-Covered / Lower” button (F - Image D) to lower the reading to achieve the
calculated setting from step 7.
9. Return the Cal/Park switch (A - Image D) to Park and press and hold the “Probe Covered /
Raise” button (E - Image D) to conrm that the relay operating point RXXX is correctly set.
The UXXX and CXXX settings will be one below and one above the readings.
Material Type Increment
Light +15
Medium +30
Heavy +60 or Greater
Table A - Typical Settings

PAGE 13
TIME DELAY -
The Auto-Set has an adjustable delay from 0 to 60 seconds, the timer operating on both material arriving
and leaving.
To set the time delay, proceed as follows:
10.Set the Cal/Park switch (A - Image D) to Cal.
11.Press and hold the timer button (G - Image D), the display will show T000 (zero delay). To
set a time delay, continue to hold the timer button and the display will start to increase by
1 second increments (maximum delay is 128 seconds). When the required delay time is
shown, release the timer button. To reset the delay, press and hold the timer button again to
restart the entire process from T000 (zero delay).
12.Return the Cal/Park switch (A - Image D) to Park and press the timer button (G - Image D) to
conrm the timer setting.
13.The timer can be altered to a longer or shorter delay by repeating the entire procedure from
steps 10 to 12.
NOTE
For questions regarding non-standard Digimatic probe lengths or diameters, contact 4B.

PAGE 14
POWER SHIELD OVERVIEW
The Digimatic detects material by radiating a high frequency (RF) signal from the probe. The advanced
electronics of the Digimatic use this signal to measure the capacitance inside the vessel with respect to
ground and thus indicate when material has reached the Digimatic probe.
The power shield creates a barrier and enables the unit to ignore a certain amount of material built up on
the probe, helping to prevent false readings. The Digimatic’s standard power shield is 121mm in length,
with options for a 160mm and 221mm available on request. Other specic lengths may be available.
Please contact us for more information.
The standard (121 mm) power shield can be used with walls that are up to 115 mm (4.5 inches) thick.
Installation through thick concrete silos only requires a 25.4 mm (1 inch) diameter hole for probe
insertion.
NOTE
The actual amount of material build up that the Digimatic is able to ignore is dependant upon several
factors, including the density of the material, the moisture content of the material and the type/style of
the vessel.

PAGE 15
TESTING AND COMMISSIONING
1. Check that the unit is correctly installed (see standard wiring diagram).
2. After going through the sensor calibration steps, the green LED should be “ON”.
3. Introduce material to the Digimatic. If calibrated correctly, the Digimatic will activate when material
has been detected. Machinery shut down will depend on your specic monitoring setup. 4B
recommends an instant shutdown when maximum ll level or a plug condition has been detected.
WARNING
If the system does not immediately shutdown as expected or alarm as required, then remove the
machine from service until the problem has been diagnosed and corrected.
TROUBLESHOOTING GUIDE
FAULT REMEDY
Readings uctuate
when the weather
changes. Ground the Digimatic to the bin using the unit ground connection (Image C).
Relays operate
backwards. Verify that the “High/Low” switch is in the correct position (D - Image D).
Relay activates
sporadically. Set the timer delay to 1 or 2 seconds to ignore sporadic material issues.
Manufactured by SYNATEL Instrumentation Limited, WS11 9TB, UK

PAGE 16
PARTS & ACCESSORIES
NOTE
These parts and accessories are not used with Auto-Set ush probe (ATS8V0AI-FP).
220 mm
320 mm
1 m
2 m
Stainless Steel Wire Probe
Lengths Up To 10 meter Long
ATSP10 ATSP11ATSP12 ATSP13 ATWP11
10m
Long
MOUNTING PLATE (SMP1)
The SMP is a zinc plated steel mounting
plate for installing the Digimatic. A
stainless steel version is also available.
6 x 8.7 mm Holes
on 177 mm Diameter 1” BSP
Coupler
203 mm
Diameter
STAINLESS STEEL PROBES/WIRE
The Digimatic is available with 303 solid
stainless steel probes. For applications up
to 10 meter 33 feet long (maximum), 303
stainless steel wire is used to extend the
probe length.
Probe Length Diameter
ATSP10* 220 mm 21 mm
ATSP11* 320 mm 16 mm
ATSP12* 1 m 16 mm
ATSP13* 2 m 16 mm
ATWP11 10 m 16 mm
*Note: Total length when tted to DML4W. Actual loose
probe length = stated length minus 120mm.

NOTE
These parts and accessories are not used with Auto-Set ush probe (ATS8V0AI-FP).
PAGE 17
1. EXCLUSIVE WRITTEN LIMITED WARRANTY
ALL PRODUCTS SOLD ARE WARRANTED BY THE COMPANY 4B COMPONENTS
LIMITED AND 4B BRAIME COMPONENTS LIMITED HEREIN AFTER REFERRED TO
AS 4B TO THE ORIGINAL PURCHASER AGAINST DEFECTS IN WORKMANSHIP OR
MATERIALS UNDER NORMAL USE FOR ONE (1) YEAR AFTER DATE OF PURCHASE
FROM 4B. ANY PRODUCT DETERMINED BY 4B AT ITS SOLE DISCRETION TO BE
DEFECTIVE IN MATERIAL OR WORKMANSHIPAND RETURNED TO A 4B BRANCH
OR AUTHORIZED SERVICE LOCATION, AS 4B DESIGNATES, SHIPPING COSTS
PREPAID, WILL BE, AS THE EXCLUSIVE REMEDY, REPAIRED OR REPLACED AT
4B’S OPTION.
2. DISCLAIMER OF IMPLIED WARRANTY
NO WARRANTY OR AFFIRMATION OF FACT, EXPRESSED OR IMPLIED, OTHER
THAN AS SET FORTH IN THE EXCLUSIVE WRITTEN LIMITED WARRANTY
STATEMENT ABOVE IS MADE OR AUTHORIZED BY 4B. 4B SPECIFICALLY
DISCLAIMS ANY LIABILITY FOR PRODUCT DEFECT CLAIMS THATARE DUE TO
PRODUCT MISUSE,ABUSE OR MISAPPLICATIONS,AS AUTHORIZED BY LAW,
4B SPECIFICALLY DISCLAIMS ALL WARRANTIES THAT THE PRODUCT IS FIT OR
MERCHANTABLE FOR A PARTICULAR PURPOSE.
3. NO WARRANTY “BY SAMPLE OR EXAMPLE”
ALTHOUGH 4B HAS USED REASONABLE EFFORTS TO ACCURATELY ILLUSTRATE
AND DESCRIBE THE PRODUCTS IN ITS CATALOGS, LITERATURE, AND WEBSITES,
SUCH ILLUSTRATIONS AND DESCRIPTIONS ARE FOR THE SOLE PURPOSE OF
PRODUCT IDENTIFICATION AND DO NOT EXPRESS OR IMPLYA WARRANTY
AFFIRMATION OF FACT, OF ANY KIND OR A WARRANTY OR AFFIRMATION
OF FACT THAT THE PRODUCTS WILL CONFORM TO THEIR RESPECTIVE
ILLUSTRATIONS OR DESCRIPTIONS. 4B EXPRESSLY DISCLAIMS ANY WARRANTY
OR AFFIRMATION OF FACT, EXPRESSED OR IMPLIED, OTHER THAN AS
SET FORTH IN THE EXCLUSIVE WRITTEN LIMITED WARRANTY STATEMENT
ABOVE, INCLUDING, WITHOUT LIMITATION, THE IMPLIED WARRANTIES OF
MERCHANTABILITYAND FITNESS FOR A PARTICULAR PURPOSE.
4. LIMITATION OF DAMAGES
ANY LIABILITY FOR CONSEQUENTIAL, INCIDENTAL, SPECIAL, EXEMPLARY, OR
PUNITIVE DAMAGES, OR FOR LOSS OF PROFIT WHETHER DIRECT OR INDIRECT,
IS EXPRESSLY DISCLAIMED.
PRODUCT WARRANTY

PAGE 18
NOTES

NOTES
PAGE 19

Copyright © 2018 4B Group - All Rights Reserved
With subsidiaries in North America, Europe,
China, Asia, Africa and Australia along with
a worldwide network of distributors, 4B
can provide practical solutions for all your
applications no matter the location.
www.go4b.com
REV031423 M2605(B)
4B FRANCE
35 Bis Rue Du 8 Mai 1945
80800 Villers, Bretonneux
France
Tel: [phone]
Email: [email protected]
4B AFRICA
14 Newport Business Park
Mica Drive, Kya Sand
2163 Johannesburg
South Africa
Tel: [phone]
Email: [email protected]
4B AUSTRALIA
Building 1, 41 Bellrick Street
Acacia Ridge
Queensland 4110
Australia
Tel: [phone]
Email: [email protected]
4B COMPONENTS LTD.
625 Erie Avenue
Morton, IL 61550
USA
Tel: [phone]
Fax: [phone]
4B BRAIME COMPONENTS LTD.
Hunslet Road
Leeds
LS10 1JZ
United Kingdom
Tel: [phone]
Email: [email protected]
4B DEUTSCHLAND
35 Bis Rue Du 8 Mai 1945
80800 Villers, Bretonneux
France
Tel: [phone]
Email: [email protected]
4B ASIA PACIFIC
Build No. 899/1 Moo 20
Soi Chongsiri, Bangplee-Tam
Ru Road, Tanbon Bangpleeyai,
Amphur Bangplee,
Samutprakarn 10540
Thailand
Tel: [phone]
Email: 4b-asiapaci[email protected]
4B China
F1, Building 5A,
Jintong Industrial Park,
8 West Lake Road,
Wujin High & New TDZ,
Changzhou, Jiangsu, PRC
Tel: [phone]
Email: [email protected]
