ANI-AOC: Fiber Optic HDMI Active Optical Cable
4K@60Hz / HDMI 2.0 / High Speed 18Gbps
PRODUCT FEATURES:
• Plug and play, no need for extra power or signal amplier
• Available Lengths: 25M / 82ft, 30M / 98ft, 40M / 131ft, 50M / 164ft, 60M / 197ft, 80M / 262ft, 90M / 295ft and 100M / 328ft
• Standard HDMI Type A plug
• Compatible to Latest HDMI 2.0
• Max. bandwidth up to 18Gbps(Single 6Gbps each*3)
• Max. resolution support up to 4K@60HZ(4:4:4)
• Support HDCP2.2/CEC/EDID/HDR/ARC/3D
• Supports HDR10 and Dolby Vision
• EMI & RFI Immunity
• Outer Diameter 0.189 inch (4.8mm) Fiber Optic cables are slim for Pro AV installation.
PRODUCT SPECIFICATIONS:
• Connector: HDMI Type A
• Bandwidth: 18G (Single Channel 6G)
• Resolution: 4K@60Hz (4:4:4), 3D, 1080p,1080i, 720p, 480p
• HDCP: HDCP 2.2
• Wire Spec.: Copper: 30AWG, 28AWG, 24AWG; Optical: 50/125um multimode
• Photoelectric Converter: 4 Array 850nm VCSEL/PD
• Power: HDMI +5V (No external power)
• Currency: ≤50mA
• Power Consumption: ≤250mW
• Lengths Available: 25M / 82ft, 30M / 98ft, 40M / 131ft, 50M / 164ft, 60M / 197ft, 80M / 262ft, 90M / 295ft and 100M / 328ft
• Ethernet: No
• ARC: Yes
IMPORTANT NOTE:
• Please treat the ber HDMI cable gently as it passes through any building structure.
• The ber-optic cable must be installed in the correct direction: The Cable with “Source” plug connects to an HDMI source device (ex:
Blu-ray player, STBox, Xbox one etc.); “Display” plug connects to your display HDMI devices (ex: TV, Projector, Monitor etc.).
• For 4K video output with this HDMI Cable, please make sure your source devices and display devices both support 4K resolution.
• Do not subject the ber-optic cable to impact or side pressure so that the shell itself will be deformed, which may cause the ber to
be stuck when in use, and the resolution will be reduced. Otherwise, there may be the worst interruption.
• When wiring, please be careful not pinch the ber-optic cable by using cable ties.
• Do not pull the ber-optic cable by its ends (HDMI connector).
• The ber-optic cable should have a small amount of surplus at each end make a good drop bend at the corner. Do not let the optical
ber touch sharp objects, when winding the ber, the force should be uniform, and the optical ber should not be subjected to hard
bending.
• To prevent deterioration and breaking of the internal ber, always ensure minimum bending radius is above 2 inches (40mm).
• When laying the cable, pay attention to the angle of the machine, etc., be careful not to touch the sharp angle of the machine and
equipment.
Version 1.0 JULY 2019
