Aaeon PCM-6894 User manual

PCM-6894
All-in-One Single Board Computer
supporting Tualatin/Pentium III/
Celeron Processor with LCD, LVDS,
TV-out, Audio, Dual Ethernet, CFD, &
PC/104 Connector.

FCC STATEMENT
THISDEVICECOMPLIESWITHPART15FCCRULES.OPERA-
TIONISSUBJECTTOTHEFOLLOWINGTWOCONDITIONS:(1)
THISDEVICEMAYNOTCAUSEHARMFULINTERFERENCE.(2)
THISDEVICEMUSTACCEPTANYINTERFERENCERECEIVED
INCLUDINGINTERFERENCETHATMAYCAUSEUNDESIRED
OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO
COMPLY WITH THE LIMITS FOR A CLASS"A" DIGITAL
DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE
PROTECTION AGAINTST HARMFUL INTERFERENCEWHEN
THE EQUIPMENT IS OPERATED IN A COMMERCIAL
ENVIRONMENT. THIS EQUIPMENT GENERATES,USES, AND
CAN RADIATE RADIO FREQUENCY ENERGYAND, IFNOT
INSTATLLEDANDUSED IN ACCORDANCEWITH THE
INSTRUCTION MANUAL, MAY CAUSEHARMFUL INTER-
FERENCE TO RADIO COMMUNICATIONS.OPERATION OF
THIS EQUIPMENT IN A RESIDENTIALAREA IS LIKELY TO
CAUSE HARMFUL INTERFERENCE IN WHICH CASE THE
USER WILL BE REQUIRED TOCORRECT THE INTERFER-
ENCE AT HIS OWN EXPENSE.

Copyright Notice
This document is copyrighted, 2002.All rights are reserved. The
original manufacturer reserves the right to make improvements to
the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in
this manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, nor for
any infringements upon the rights of third parties which may result
from its use.
Acknowledgements
AMD is a trademark ofAdvanced Micro Devices, Inc.
AMI is a trademark of American Megatrends, Inc.
Award is a trademark ofAward Software International, Inc.
Cyrix is a trademark of Cyrix Corporation.
IBM, PC/AT, PS/2, and VGA are trademarks of International
Business Machines Corporation.
Intel and Pentium II are trademarks of Intel Corporation.
Microsoft Windows is a registered trademark of Microsoft Corp.
SMC is a trademark of Standard Microsystems Corporation.
RTL is a trademark of Realtek Semi-Conductor Co., Ltd.
C&T is a trademark of Chips and Technologies, Inc.
UMC is a trademark of United Microelectronics Corporation.
ITE is a trademark of Integrated Technology Express, Inc.
SiS is a trademark of Silicon Integrated Systems Corp.
VIA is a trademark of VIA Technology, Inc.
All other product names or trademarks are properties of their
respective owners.
Manual PCM-6894 1st Edition
Preparedin Taiwan Oct 2002

A Message to the Customer
AAEON Customer Services
Each and every AAEON product is built to the most exacting
specifications to ensure reliable performance in the harsh and
demanding conditions typical of industrial environments. Whether
your new AAEON equipment is destined for the laboratory or the
factory floor, you can be assured that your product will provide the
reliability and ease of operation for which the name AAEON has
come to be known.
Your satisfaction is our primary concern. Here is a guide toAAEON
customer services. To ensure you get the full benefit of our
services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products.
So if you run into technical difficulties, we are here to help. For the
most frequently asked questions, you can easily find answers in
your product documentation. These answers are normally a lot
more detailed than the ones we can give over the phone.
So please consult this manual first. If you still cannot find the
answer, gather all the information or questions that apply to your
problem, and with the product close at hand, call your dealer. Our
dealers are well trained and ready to give you the support you need
to get the most from your AAEON products. In fact, most problems
reported are minor and are able to be easily solved over the phone.
In addition, free technical support is available from AAEON
engineers every business day. We are always ready to give advice
on application requirements or specific information on the installa-
tion and operation of any of our products.

Product Warranty
AAEON warrants to you, the original purchaser, that each of its
products will be free from defects in materials and workmanship for
two year from the date of purchase.
This warranty does not apply to any products which have been
repaired or altered by persons other than repair personnel autho-
rized by AAEON, or which have been subject to misuse, abuse,
accident or improper installation. AAEON assumes no liability
under the terms of this warranty as a consequence of such events.
Because of AAEON high quality-control standards and rigorous
testing, most of our customers never need to use our repair service.
If an AAEON product is defective, it will be repaired or replaced at
no charge during the warranty period. For out-of-warranty repairs,
you will be billed according to the cost of replacement materials,
service time, and freight. Please consult your dealer for more
details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For
example, CPU type and speed, AAEON products used, other
hardware and software used, etc.) Note anything abnormal and
list any on-screen messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your
manual, product, and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA
(return material authorization) number from your dealer.This
allows us to process your return more quickly.
4. Carefully pack the defective product, a fully-completed Repair
and Replacement Order Card and a photocopy proof of pur-
chase date (such as your sales receipt) in a shippable container.
A product returned without proof of the purchase date is not
eligible for warranty service.
5. Write the RMA number visibly on the outside of the package
and ship it prepaid to your dealer.

Packing List
Before you begin installing your card, please make sure that the
following materials have been shipped:
1.PCM-6894All-in-OneSingleBoardComputer
2.Quick InstallationGuide
3.CD-ROM contains the followings:
lUser Manual(this manual in PDF file)
lSystem drivers and utilities
lEthernet drivers and utilities
lVGA drivers and utilities
lAudio drivers and utilities
lLastest BIOS (as of the CD-ROM was made)
The PCM-6894 requires several cables for operation. You can make
them yourself or pruchase an optioanl cable kit, PCM-10489-7 .
If any of these items are missing or damaged, contact your distri-
buitor or sales represntative immediately.

Notice
DearCustomer,
Thank you for purchasing the PCM-6894 board. This user manual is
designed to help you to get the most out of the PCM-6894, please
read it thoroughly before you install and use the board. The
product that you have purchased comes with an two-year limited
warranty, but AAEON will not be responsible for misuse of the
product. Therefore, we strongly urge you to first read the manual
before using the product.
To receive the lastest version of the user manual, please visit our
Web site at:
http://www.aaeon.com.tw

Contents
Chapter 1: General Information .................................. 1
Introduction.... ................................................................. 2
Features..................................................................................3
Specifications .........................................................................4
Chapter 2: Installation .................................................. 7
Locating Jumpers & Connectors .......................................8
Mechanical Drawing ............................................................10
Jumpers and Connectors ...................................................12
CMOS Status Setup(JBAT1) ............................................14
LVDS Voltage Select(J2) ....................................................14
Serial Port 2 Status Setup(J3, J4 & J5)...........................15
Serial Port 3 RING Status Setup(J6) ................................15
Serial Port 4 RING Status Setup(J7) ................................16
Watchdog Timer Status Setup(J8) ....................................16
LAN Status Setup(J9).........................................................17
TV Output Connector(CN1)..............................................18
CRT Connector(CN2) ........................................................18
LVDS Connector(CN3).......................................................19
10/100Base-Tx Ethernet 1 Connector(CN4)..................19
10/100Base-Tx Ethernet 2 Connector(CN5)..................19
Audio Output Connector(CN7).........................................20
Inverter Power Supply Connector for LCD(CN8) .........20
LAN1 & LAN2 Status Connector(CN9) .........................21
Keyboard & PS/2 Mouse Connector(CN10) ..................21
Serial Port 1/2/3/4 Connector(CN12)...............................22
Front Panel Connector(CN13) ..........................................23
ATX Power Connector(PWR1A).......................................24
AT Power Connector(PWR1B) .........................................24
CPU Fan Connector(CPU_FAN).......................................25

Printer Port Connector(LPT1)..........................................25
Wake On LAN Connector(WOL1)...................................26
USB Connector(USB1).......................................................26
IrDA Connector(IR1) .........................................................27
Primary LCD Connector(LCD1) .......................................28
Chapter 3: Award BIOS Setup ................................... 29
Starting setup.......................................................................30
Setup keys ............................................................................31
Getting help..........................................................................32
Main Setup Menu ...............................................................33
Standard CMOS Features ..................................................35
Advanced BIOS Features ..................................................40
Advanced Chipset Features...............................................46
Integrated Peripherals........................................................51
Power Management Setup .................................................57
PnP/PCI Configurations .....................................................62
PC Health Status .................................................................65
Load Fail-Safe Defaults.......................................................66
Load Uptimized Defaults ....................................................67
Set Supervisor Password....................................................68
Set User Password ..............................................................69
Save & Exit Setup ...............................................................70
Exit Without Saving ............................................................71
Chapter 4:Drivers Installation.................................... 73
System Driver Installation .................................................74
VGA Driver Installation ......................................................75
Audio Driver Installation....................................................76
Ethernet Driver Installation ..............................................79

Appendix A: WatchDog Timer.................................... 81
Appendix B: Optional Extras...................................... 89

Chapter 1 General Information 1
General
Information
This chapter gives background informa-
tion on the PCM-6894.
Sections include:
•Board Introduction
•Board Features
•Board Specificaitons
CHAPTER

2PCM-6894 User Manual
AAEON new compact size board PCM-6894 targets high-end
multimedia and networking applications. This board is supported
by Intel Celeron , Pentium III and Tualatin CPUs. Easy upgrading
allows full utilization of Intel Development of even-higher speed
CPUs. This is a perfect choice for embedded applications that
require cost-effective high computing power communications
Products whether video, voice, or data convergence over Internet
Protocol network infrastructures.
The PCM-6894 features power management to minimize power
consumption. It complies with the ACPI standard and supports
three types of power-saving features: Doze mode, Standby and
Suspend modes. The board watchdog timer automatically resets
the system or generates an interrupt in case the system stops due
to a program bug or EMI.
Onboard SMI Lynx3DM 722 display chip with embedded 4MB
SGRAMcomeswith128-bit2D/3DGraphicsEngine, built-in TV
encoder forNTSC/PAL support, enhanced multi-display and
hardwareaccelerated MPEG2/DVD playback. For advanced panel
display, SMI Lynx3DM+ adds an integrated LVDStransmitter
DualRTL8139CPCI-bus 10/100Base-Tx Ethernet controllers
onboard provide superior networking access ability. The Ethernet
interface and Sound Blaster-compatible audio opens up worlds of
possibilities for kiosks, gaming systems, POS systems, medical and
education markets.
The onboard compact flash will offer a larger memory bank for data
storage of all types. Compact Flash requires a fraction of power
used to drive floppy disk or CD-ROMs, also no battery is required
to save the data when the computer powers down.
PCM-6894 also includes four high-speed serial ports (three RS-232,
oneRS-232/422/485), one multimode (ECP/EPP/SPP) parallelport,
dual USB ports, 2 floppy drives, an UltraDMA/100 Enhanced IDE
controller supporting up to two devices with data transfer rate up
to 100MB per second, and a keyboard/PS/2 mouse interface. This
AAEON embedded PC includes almost everything you need for
Introduction

Chapter 1 General Information 3
Features
lSupports Intel Tualatin/ Pentium III/ Celeron and compatible
processors
lOnboardVT82C694T/VT82C686Bchipset
lSMILynx3DMSM722G4LCDcontroller with built-in 4MB
SGRAM supports 24-bit TFT Panels
lSM 722G4 integrated single channel LVDS function
lTwo 10/100Base-T Fast Ethernet
lIntegratedAC-97 2.2 Compatible 3DAudio
lSupports TV-Out function with RCA and S terminal header on
board
lSupports Type II Compact Flash Memory
fast, worry-free embedded PC performance.
The addition of PCI slot and PC/104 connector will allow a wide
selection of accessory cards to be added to the PCM-6894 such as
Ultra Wide 2 SCSI, fax modem, vehicle power supply, extraDiskOn-
Chip, PCMCIA module, etc.

4PCM-6894 User Manual
Specifications
CPU IntelFC-370Tualatin/PentiumIII/CeleronCPU
(with system bus frequencies of 66/100/133MHz)
CPUSocket Intel socket 370
BIOS Award256KBFlashBIOS
Chipset VIAApolloPro133A,VT82C694T
I/OChipset VT82C686B.Winbond83977EF(TF)-AWas2ndSIO
forCOM3, COM4 port.
Memory Onboard One 168-pinDIMM socket supports up to
512 MBbytes SDRAM (PC 100/133 support)
EnhancedIDE Supports four IDE devices. Two devices supports
UltraDMA100modewithtransferrate upto100MB/
sec.
FDDinterface Supports up to two floppy disk drives, 5.25 inch
(360KBand1.2MB) and/or3.5inch(720KB,1.44MB
and2.88MB)
Parellel Port Onebi-directionalparallelport. SupportsSPP, ECP,
and EPP modes
Serial Port Three RS-232 serial ports andone RS-232/422/
485(COM2)can be configured as COM1, COM2,
COM3,COM4,ordisabledindividually. (16C550
equivalent)
IrDAport Supports one IrDA Tx/Rx header
KB/Mouseconnector A 7(4*2-1)-pin header supports PC/AT Keyboard
and PS/2 mouse.

Chapter 1 General Information 5
USBconnectors One 5x2-pin header onboard supports dual USB
ports
Battery Lithium battery for data retention
WatchdogTimer Can generate a system reset. Software selectable
time-out interval (32 sec.~254 min., 1 min./step)
DMA 7DMA channels (8237 equivalent)
Interrupt 15 interrupt levels (8259 equivalent)
Powermanagement Supports ATX or ATpower supply. Supports PC97,
LAN wake up and modem ring-in functions. I/O pe
ripheral device support power saving and doze/
standby/suspend modes. APM 1.2 compliant
AudioInterface
Chipset VIAVT82C686B,ALC201codec
AudioController AC97 ver. 2.0 compliant interface, Multi-stream
Direct Sound andDirect Sound 3D acceleration.
AudioInterface MIC in, line in, line out, CD audio in.
FlatPanel/CRTInterface
Chipset SMILynx3DMSM722,highperformance 128-bit
GUI,3Dengine
Displaymemory 4MB of SGRAM frame buffer on Lynx3DM SM 722G4
DisplayType Supportsnon-interlaced CRT and 24bitLVDS/TTL TFT
LCD,candisplay bothCRT and flatpanel(DF-13 1.25V)
simultaneously
Resolution Upto1024X 768 @ 24bpp colors

6PCM-6894 User Manual
TVoutput interface Onboard header supports both RCA jack and S
terminal
EthernetInterface
Chipset Dual RTL8139CPCI-busEthernetcontrollers
onboard
Ethernetinterface Onboard dual 10/100Base-T RJ-45connector
ExpansionInterface
PC/104Connector One 16-bit 104-pin connector onboard
PCISlot One 32-bit PCI slot onboard
SDDInterface One type II Compact Flash Socket
MechanicalandEnvironmental
PowerSupplyvoltage +5V, +12V,ATorATXtype
Operatingtemperature 32 to 140 degrees F (0 to 60 degrees C)
BoardSize 8(L)x5.75(W) (203mmx146mm)
Weight 1.2lb. (0.5Kg)

Chapter 2 Installation 7
2
Installation
This chapter describes how to set up the
board hardware, including instructions on
setting jumpers and connecting peripher-
als, switches, and indicators.
CHAPTER

PCM-6894
8PCM-6894 User ManualBC-599/596
Locating Jumpers & Connectors

Chapter 2 Installation 9
Locating Jumpers & Connectors

PCM-6894
10 PCM-6894 User ManualBC-599/596
Mechanical Drawing
