Aaeon EMB-9459T User manual

Mini-ITX EMB-9459T Rev.B
EMB-9459T Rev.B
Onboard Intel®AtomTM N270
Processor
Mini-ITX
Realtek 8111C Ethernet
8 USB2.0, 6 COM, 1 Parallel
1PCI,1MiniPCI,2PCI-E
ATXPowerType
EMB-9459T Manual Rev.B 2nd Ed.
August 2010

Mini-ITX EMB-9459T Rev.B
Copyright Notice
This document is copyrighted, 2010. All rights are reserved. The
original manufacturer reserves the right to make improvements to
the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, or for
any infringements upon the rights of third parties that may result
from its use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have
been made in the preparation of this document to assure its
accuracy, AAEON assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information
contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.
i

Mini-ITX EMB-9459T Rev.B
Acknowledgments
All other products’ name or trademarks are properties of their
respective owners.
zAward is a trademark of Award Software International, Inc.
zCompactFlash™is a trademark of the Compact Flash
Association.
zIntel®, AtomTM are trademarks of Intel®Corporation.
zMicrosoft Windows®is a registered trademark of Microsoft
Corp.
zITE is a trademark of Integrated Technology Express, Inc.
zIBM, PC/AT, PS/2, and VGA are trademarks of International
Business Machines Corporation.
zSoundBlaster is a trademark of Creative Labs, Inc.
Please be notified that all other products’ name or trademarks
not be mentioned above are properties of their respective
owners.
ii

Mini-ITX EMB-9459T Rev.B
Packing List
(For Standard only, not for Bulk Pack)
Before you begin installing your card, please make sure that
the following materials have been shipped:
z1 1701400453 IDE Cable
z1 9657666600 Jumper Cap
z1 1709070500 Serial ATA Cable
z1 1702151200 Onboard Serial ATA Power Cable
z1 M209459000 Metal I/O Bracket
z1 Quick Installation Guide
z1 Utility CD
z1 EMB-9459T Rev.B
If any of these items should be missing or damaged, please
contact your distributor or sales representative immediately.
iii

Mini-ITX EMB-9459T Rev.B
Contents
Chapter 1 General Information
1.1 Introduction................................................................1-2
1.2 Features....................................................................1-3
1.3 Specifications............................................................1-4
Chapter 2 Quick Installation Guide
2.1 Safety Precautions ..................................................2-2
2.2 Location of Connectors and Jumpers ......................2-3
2.3 Mechanical Drawing ................................................2-5
2.4 List of Jumpers ........................................................2-7
2.5 List of Connectors .....................................................2-8
2.6 Setting Jumpers .....................................................2-10
2.7 LCD Inverter Voltage Selection (JP1-18 bits, JP7-24
bits) ..............................................................................2-11
2.8 COM2 Ring/ +5V/ +12V Selection (JP2).................2-11
2.9 LCD Voltage Selection (JP3-18 bits, JP5-24 bits) ..2-11
2.10 Clear CMOS (JP4) ................................................2-11
2.11 AT/ATX Power Mode Selection (JP6)...................2-11
2.12 HDD Power Connector (PWR1)............................2-11
2.13 Audio 2Watt Speaker Output (CN2)......................2-12
2.14 COM1 RS-232 & COM2 RS-232/422/485 Serial Port
Connector (CN3)...........................................................2-12
iv

Mini-ITX EMB-9459T Rev.B
2.15 TV Out Connector (CN4).......................................2-13
2.16 LCD Inverter Connector (CN5, CN26) .................2-13
2.17 LVDS LCD Connector (CN6, CN7).......................2-13
2.18 USB Connector (CN8, CN9) ................................2-14
2.19 LPT Port Connector (CN10)..................................2-14
2.20 COM5, COM6, COM4, COM3 RS-232 Serial Port
Connector (CN12, CN13, CN15, CN16) .......................2-15
2.21 Digital I/O (CN14) ................................................2-15
2.22 Front Panel Connector (CN20) .............................2-16
2.23 SPDIF Connector (CN23) .....................................2-16
2.24 Audio Connector (Surround) (CN24).....................2-16
2.25 ATX Power Connector (CN25)..............................2-17
Chapter 3 Award BIOS Setup
3.1 System Test and Initialization. ..................................3-2
3.2 Award BIOS Setup....................................................3-3
Chapter 4 Driver Installation
4.1 Installation……………………………………………..4-3
Appendix A Programming The Watchdog Timer
A.1 Programming .........................................................A-2
A.2 IT8712 Watchdog Timer Initial Program................A-6
Appendix B I/O Information
B.1 I/O Address Map....................................................B-2
B.2 Memory Address Map............................................B-3
v

Mini-ITX EMB-9459T Rev.B
B.3 IRQ Mapping Chart................................................B-4
B.4 DMA Channel Assignments.……………………….B-4
Appendix C Mating Connector
C.1 List of Mating Connectors and Cables.................. C-2
vi

Mini-ITX EMB-9459T Rev.B
Chapter 1 General Information 1- 1
General
Chapter
1
Information

Mini-ITX EMB-9459T Rev.B
Chapter 1 General Information 1-2
1.1 Introduction
The EMB-9459T Rev.B supports Intel®AtomTM N270 processor
which when paired with the Intel®945GSE + ICH7M chipset
offers a high performance computing platform with low power
consumption. This new product supports 240-pin DDRII DIMM
at speeds of 400/533, up to 2GB. One CompactFlash, two
SATA ports and one EIDE interfaces provide ample storage.
With dual Gigabit Ethernet, six COM ports, eight USB2.0, one
parallel port, the EMB-9459T Rev.B meets the requirements of
today’s demanding applications.
Display requirements are met with an abundance of interfaces
such as CRT, TV-out, 18-bit dual-channel LVDS, 24-bit
dual-channel LVDS and DVI. Simultaneous / Dual View is
available in LCD/CRT, LCD/LCD, LCD/DVI, CRT/DVI, CRT/TV,
LCD/ TV configurations. Display memory is shared from the
system memory up to 224MB/DVMT3.0.
With all of its integrated features, the EMB-9459T Rev.B strikes
a balance of performance and price. This versatile product
targets Industrial Automation, Entertainment, Networking,
KIOSK/POS, Transportation, Banking, Healthcare and Digital
Signage applications that require high performance and high
reliability.

Mini-ITX EMB-9459T Rev.B
Chapter 1 General Information 1-3
1.2 Features
zOnboard Intel®AtomTM N270 Processor (Fanless)
zIntel®945GSE + ICH7M
zDDRII 400/533 Memory, Max. 2GB
zGigabit Ethernet x 2 or 10/100Base-TX x 2
zCRT, TV-out, DVI, 18-bit Dual-channel LVDS and 2nd
18/24-bit Dual-channel LVDS
zHD 2CH Audio (Optional 5.1CH S/PDIF)
zSATA II x 2, EIDE x 1 & CompactFlash Type II x 1
zUSB2.0 x 8, COM x 6, Parallel x 1
zPCI x 1, Mini PCI x 1, PCI-E [x1] x 2 in PCI-E [x4]
(Through Riser Card)
zAT/ATX Power Operation
zOnboard SATA Power Connector x 1
zOptional TPM

Mini-ITX EMB-9459T Rev.B
Chapter 1 General Information 1-4
1.3 Specifications
System
zProcessor Supports onboard Intel®
AtomTM N270 Processor
1.6GHz, FSB533MHz
zSystem Memory 240-pin DDRII DIMM x 1,
DDRII 400/533 up to 2GB
zChipset Intel®945GSE + ICH7M
zI/O Chipset ITE8712
zEthernet Realtek 8111C for
10/100/1000Base-TX, RJ-45
x 2; Realtek 8102E for
10/100Base-TX, RJ-45 x 2
zBIOS Award Plug & Play SPI
BIOS – 2MB ROM
zWake On LAN Yes
zWatchdog Timer Generates a time-out system
reset
zH/W Status Monitoring Supports power supply
voltages and temperature
monitoring
zExpansion Interface PCI x 1, Mini PCI x 1, PCI-E
［x1］x 2 in PCI-E［x4］
(Through Riser Card)

Mini-ITX EMB-9459T Rev.B
Chapter 1 General Information 1-5
zBattery Lithium battery
zPower Requirement AT/ATX
zPower Consumption
(Typical) Intel®AtomTM N270
0.65A @ +12V, 1.02A @ +5V
zBoard Size 6.7”(L) x 6.7”(W) (170 mm x
170 mm)
zGross Weight 1.2 lb (0.5 Kg)
zOperating Temperature 32˚F~ 140˚F (0˚C ~ 60˚C)
zStorage Temperature -40˚F~ 176˚F (-40˚C ~ 80˚C)
zOperating Humidity 0%~90% relative humidity,
non-condensing
Display: Supports CRT/LCD, CRT/DVI, LCD/DVI, CRT/TV,
LCD/TV simultaneous/ dual view displays
zChipset Intel®945GSE integrated
zMemory Shared system memory up to
224MB w/ DVMT3.0
zResolution Up to 2048 x 1536 @ 32bpp
colors for CRT; Up to 1600 x
1200 @ 18bpp colors for
LCD
zLCD Interface 18-bit dual-channel LVDS,
24-bit dual-channel LVDS
and DVI
zTV-out Supports NTSC and PAL

Mini-ITX EMB-9459T Rev.B
Chapter 1 General Information 1-6
standard, S-Terminal and
Composite Video
zDVI DVI-I x 1
I/O
zStorage EIDE x 1 (UDMA100 for one
device, slave only), SATA II x
2, Type II CompactFlash x 1
zSerial Port RS-232 x 5, RS-232/422/485
x 1
zAudio MIC-In, Line-out (Optional
Line-in), Stereo amplifier
included
zUSB USB 2.0 x 8
zParallel Port Supports SPP/ EPP/ ECP
mode
zPS/2 Port Keyboard x 1, Mouse x1

Mini-ITX EMB-9459T Rev.B
Chapter 2 Quick Installation Guide 2-1
Quick
Installation
Chapter
2
Guide
Notice:
The Quick Installation Guide is derived
from Chapter 2 of user manual. For other
chapters and further installation
instructions, please refer to the user
manual CD-ROM that came with the
product.
Part No. 2007945921 Printed in Taiwan August 2010

Mini-ITX EMB-9459T Rev.B
Chapter 2 Quick Installation Guide 2 - 2
2.1 Safety Precautions
Always completely disconnect the power cord
from your board whenever you are working on
it. Do not make connections while the power is
on, because a sudden rush of power can
damage sensitive electronic components.
Always ground yourself to remove any static
charge before touching the board. Modern
electronic devices are very sensitive to static
electric charges. Use a grounding wrist strap at
all times. Place all electronic components on a
static-dissipative surface or in a static-shielded
bag when they are not in the chassis

Mini-ITX EMB-9459T Rev.B
Chapter2QuickInstallationGuide2 - 3
2.2 Location of Connectors and Jumpers
Component Side

Mini-ITX EMB-9459T Rev.B
Chapter 2 Quick Installation Guide 2 - 4
Solder Side

Mini-ITX EMB-9459T Rev.B
Chapter2QuickInstallationGuide2 - 5
2.3 Mechanical Drawing
Component Side

Mini-ITX EMB-9459T Rev.B
Chapter 2 Quick Installation Guide 2 - 6
Solder Side

Mini-ITX EMB-9459T Rev.B
Chapter2QuickInstallationGuide2 - 7
2.4 List of Jumpers
The board has a number of jumpers that allow you to configure your
system to suit your application.
The table below shows the function of each of the board's jumpers:
Label Function
JP1 1st 18-bit LCD Inverter Voltage selection
JP2 COM2 Ring +5V/+12V selection
JP3 1st 18-bit LCD Voltage selection
JP4 Clear CMOS
JP5 2nd 24-bit LCD Voltage selection
JP6 AT/ATX selection
JP7 2nd 24-bit LCD Inverter Voltage Selection
