Aaeon EMB-9658T Mini-ITX User manual

Mini-ITX EMB-9658T
EMB-9658T
Intel® CoreTM 2 Duo/
Celeron®MProcessor,
Mini-ITX
Intel®82573L, 82566MM Ethernet
TPM 1.2
VIA VT1708B Audio & Mini PCI
EMB-9658T Manual Rev.A 1
st Ed.
July, 2009

Mini-ITX EMB-9658T
i
Copyright Notice
This document is copyrighted, 2009. All rights are reserved.
The original manufacturer reserves the right to make
improvements to the products described in this manual at any
time without notice.
No part of this manual may be reproduced, copied, translated,
or transmitted in any form or by any means without the prior
written permission of the original manufacturer. Information
provided in this manual is intended to be accurate and reliable.
However, the original manufacturer assumes no responsibility
for its use, or for any infringements upon the rights of third
parties that may result from its use.
The material in this document is for product information only
and is subject to change without notice. While reasonable
efforts have been made in the preparation of this document to
assure its accuracy, AAEON assumes no liabilities resulting
from errors or omissions in this document, or from the use of
the information contained herein.
AAEON reserves the right to make changes in the product
design without notice to its users.

Mini-ITX EMB-9658T
ii
Acknowledgments
All other products’ name or trademarks are properties of their
respective owners.
 Award is a trademark of Award Software International, Inc.
 CompactFlash™is a trademark of the Compact Flash
Association.
 Intel®, CoreTM 2 Duo/ CoreTM Duo/ CoreTM Solo and Celeron®
M are trademarks of Intel®Corporation.
 Microsoft Windows®is a registered trademark of Microsoft
Corp.
 ITE is a trademark of Integrated Technology Express, Inc.
 IBM, PC/AT, PS/2, and VGA are trademarks of International
Business Machines Corporation.
 SoundBlaster is a trademark of Creative Labs, Inc.
Please be notified that all other products’ name or trademarks
not be mentioned above are properties of their respective
owners.

Mini-ITX EMB-9658T
iii
Packing List
Before you begin installing your card, please make sure that
the following materials have been shipped:
 1 1709070500 SATA Cable
 1 1702151200 Onboard SATA Power Cable
 1 M206908T00 Metal I/O Bracket
 1 Quick Installation Guide
 1 Utility CD
 1 EMB-9658T
If any of these items should be missing or damaged, please
contact your distributor or sales representative immediately.

Mini-ITX EMB-9658T
iv
Contents
Chapter 1 General Information
1.1 Introduction................................................................1-2
1.2 Features....................................................................1-3
1.3 Specifications............................................................1-4
Chapter 2 Quick Installation Guide
2.1 Safety Precautions ..................................................2-2
2.2 Location of Connectors and Jumpers ......................2-3
2.3 Mechanical Drawing ................................................2-5
2.4 List of Jumpers ........................................................2-7
2.5 List of Connectors .....................................................2-8
2.6 Setting Jumpers .....................................................2-10
2.7 LCD INVERTER Voltage Selection (JP1)...............2-11
2.8 COM2 Ring/+5V/+12V Selection (JP2)...................2-11
2.9 LCD Voltage Selection (JP3) ..................................2-11
2.10 Auto Power Button (JP4).......................................2-11
2.11 Clear CMOS (JP5) ................................................2-11
2.12 ATX Power Simulate AT Power (JP6)...................2-12
2.13 Connector Pin Assignment....................................2-12
2.14 DVI+CRT Connector (CN1)...................................2-12
2.15 Audio Speaker Output (CN2)................................2-13
2.16 COM1&2 RS-232/422/485 (CN3)..........................2-14
2.17 Audio 5.1 Channel / SPDIF Connector (CN4).......2-14

Mini-ITX EMB-9658T
v
2.18 USB Connector/10/100/1000 Base-Tx Ethernet
Connector(1) (CN5).......................................................2-15
2.19 USB Connector/10/100/1000 Base-Tx Ethernet
Connector(2) (CN6).......................................................2-15
2.20 TV_Out Connector (CN7)......................................2-16
2.21 LCD Inverter Connector (CN8) ..........................2-16
2.22 CD-IN Connector (CN9)........................................2-16
2.23 Internal Keyboard Connector (CN10)....................2-17
2.24 Internal Mouse Connector (CN11)........................2-17
2.25 LVDS-LCD Connector (CN12)..............................2-17
2.26 SDVO Connector (CN13)......................................2-18
2.27 System Fan Connector (CN14).............................2-19
2.28 RTC Battery Connector (CN16)............................2-19
2.29 GPS Connector (CN17) ........................................2-19
2.30 ATX Power Connector (CN18)..............................2-19
2.31 LPT Port Connector (CN19)..................................2-20
2.32 AT POWER Connector(CN20)..............................2-21
2.33 PCI Express Slot (CN21) ......................................2-21
2.34 USB Connector (CN22).........................................2-22
2.35 USB Connector (CN23).........................................2-23
2.36 Digital I/O Connector (CN24)................................2-23
2.37COM4 RS-232 Serial Port Connector (CN25) .......2-23
2.38 COM3 RS-232 Serial Port Connector (CN26) ......2-23
2.39 COM6 RS-232 Serial Port Connector (CN27) ......2-24
2.40 IrDA Connector (CN28).........................................2-24

Mini-ITX EMB-9658T
vi
2.41 CPU Fan Connector (CN29) ...............................2-24
2.42 Front Panel Connector (CN30) .............................2-25
2.43 CompactFlash Connector (CN31).........................2-25
2.44 ATX Power_12V Connector(CN32) ......................2-26
2.45 SATA Power Connector (CN33) ...........................2-26
Chapter 3 Award BIOS Setup
3.1 System Test and Initialization. ..................................3-2
3.2 Award BIOS Setup....................................................3-3
Chapter 4 Driver Installation
4.1 Installation……………………………………………..4-4
Appendix A Programming The Watchdog Timer
A.1 Programming .........................................................A-2
A.2 IT 8712 Watchdog Timer Initial Program...............A-6
Appendix B I/O Information
B.1 I/O Address Map....................................................B-2
B.2 Memory Address Map............................................B-4
B.3 IRQ Mapping Chart................................................B-5
B.4 DMA Channel Assignments.……………………….B-6
Appendix C Mating Connector
C.1 List of Mating Connectors and Cables.................. C-2

Mini-ITX EMB-9658T
Chapter 1 General Information 1- 1
General
Chapter
1
Information

Mini-ITX EMB-9658T
Chapter 1 General Information 1-2
1.1 Introduction
The EMB-9658T adopts the latest Intel®Core™ 2 Duo/
Celeron®M (Socket-P based) processors and Intel®
GME965+ICH8M chipset for better power-management
capabilities and enhanced performance.
The system memory of EMB-9658T features two 200-pin DIMM
and DDRII 533/667 up to 4GB. The LCD interface is 18/ 24
bit dual-channel LVDS share memory up to 384 MB with DVMT
4.0.
The EMB-9658T features one PCI slot, one PCI-E［x4］slot
(through riser card ), one Mini PCI slot, four RS-232 ports, one
RS-232/422/485 port, eight USB 2.0 ports, multiple Digital I/O
ports, and Type II CFD storage, providing versatile expansion
options for many embedded applications.
EMB-9658T with mobile-optimized Intel dual-core processors is
the latest embedded motherboard designed to cope with
increasingly heavily work-loaded embedded systems found in
POS (Point-of-Sale) machines, automated kiosks, medical
instruments, advanced automation for buildings and homes,
and gaming machines.

Mini-ITX EMB-9658T
Chapter 1 General Information 1-3
1.2 Features
 Intel® Core™ 2 Duo/ Celeron® M (Socket-P Based)
Processors
 Intel® GME965 + ICH8M (-E Optional for RAID)
 DDRII 533/667 Memory, Max. 4GB
 Gigabit Ethernet x 2, with one 82566MM support iAMT 2.5
 18/24 bit Dual-Channel LVDS, DVI/TV/CRT, SDVO
Connector for 2nd 18/24 bit Dual-Channel LVDS/DVI
 HD 5.1CHAudio
 SATAII x 2, EIDE x 1, CompactFlash™
 USB2.0 x 8, COM x 5, Parallel x 1, 8-bit Digital I/O
 PCI x 1, Mini PCI x 1 , PCI-Express [x4] x 1 (Through
Riser Card)
 DC12V /AT/ATX
 SATAPower Connector Onboard x 1, Optional RAID, TPM

Mini-ITX EMB-9658T
Chapter 1 General Information 1-4
1.3 Specifications
System
 Form Factor Mini-ITX
 Processor Intel® Core™ 2 Duo/
Celeron® M (Socket-P based)
Processors
 System Memory 200-pin DDRII SODIMM x 2,
Max. 4GB (DDRII 533/667)
 Chipset Intel® GME965 + ICH8M(-E
optional for RAID)
 I/O Chipset ITE8712
 Ethernet Intel® 82566MM/82573L for
10/100/1000Base-TX, RJ-45 x
2
 BIOSAward Plug & Play SPI BIOS - 2MB
ROM
 Wake on LAN Yes
 Watchdog Timer ITE.IT8712F/KX-L
 H/W Stauts Monitoring Supports power supply
voltages and temperature
monitoring
 Expansion Interface PCI x 1, Mini PCI x 1 &
PCI-Express [x4] slot x 1
(through Riser card)

Mini-ITX EMB-9658T
Chapter 1 General Information 1-5
 Battery Lithium battery
 Power Requirement DC 12V /AT/ ATX
 Board Size 6.7" (L) x 6.7" (W) (170mm x
170mm)
 Gross Weight 1.1lb (0.5kg)
 Operating Temp. 32°F ~ 140°F (0°C ~ 60°C)
 Storage Temp. -40°F ~ 176°F (-40°C ~ 80°C)
 Operating Humidity 0% ~ 90% relative humidity,
non-condensing
 MTBF (Hours) —
Display: Supports LCD/CRT, LCD/DVI, LCD/TV, CRT/DVI,
TV/DVI, Dual Simultaneous/ Dual View Displays
 Chipset Intel® GME965 integrated
 Memory Shared system memory up to
384 MB/DVMT4.0
 Resolutions Up to 2048 x 1536 (QXGA) @
60Hz for CRT
Up to 2048 x 1536 (QXGA) for
LCD
 LCD Interface Up to 24-bit dual-channel
LVDS
 SDVO Supports SDVO x 1
 TV-Out IntelR GME965 integrated,
supports NTSC/ PAL/ HDTV
HDTV supports: 480p/720p/

Mini-ITX EMB-9658T
Chapter 1 General Information 1-6
1080i/1080p
 DVI DVI-I x 1
I/O
 Storage EIDE x 1 (shared signals with
CompactFlash™) SATAII x 2
 Serial Port RS-232 x 4, RS-232/422/485 x
1, TTL x 1
 Parallel Port SPP/ EPP/ ECP mode
 USB USB2.0 x 8
 PS/2 Port Keyboard x 1, Mouse x 1
 Digital I/O Support 8-bit (Programmable)
 IrDA One IrDATx/Rx header
 Audio HD 5.1 channel

Mini-ITX EMB-9658T
Chapter 2 Quick Installation Guide 2-1
Quick
Installation
Chapter
2
Guide
Notice:
The Quick Installation Guide is derive
d
f
rom Chapter 2 of user manual. For othe
r
chapters and further installation
instructions, please refer to the use
r
manual CD-ROM that came with th
e
p
roduct.
Part No. 2007965810 Printed in Taiwan July 2009

Mini-ITX EMB-9658T
Chapter 2 Quick Installation Guide 2 - 2
2.1 Safety Precautions
Always completely disconnect the power cord
from your board whenever you are working on
it. Do not make connections while the power is
on, because a sudden rush of power can
damage sensitive electronic components.
Always ground yourself to remove any static
charge before touching the board. Modern
electronic devices are very sensitive to static
electric charges. Use a grounding wrist strap at
all times. Place all electronic components on a
static-dissipative surface or in a static-shielded
bag when they are not in the chassis

Mini-ITX EMB-9658T
Chapter2QuickInstallationGuide2 - 3
2.2 Location of Connectors and Jumpers
Locating Connectors and Jumpers (Component Side)

Mini-ITX EMB-9658T
Chapter 2 Quick Installation Guide 2 - 4
Locating Connectors and Jumpers (Solder Side)

Mini-ITX EMB-9658T
Chapter2QuickInstallationGuide2 - 5
2.3 Mechanical Drawing
Component Side

Mini-ITX EMB-9658T
Chapter 2 Quick Installation Guide 2 - 6
Solder Side

Mini-ITX EMB-9658T
Chapter2QuickInstallationGuide2 - 7
2.4 List of Jumpers
The board has a number of jumpers that allow you to configure
your system to suit your application.
The table below shows the function of each of the board's
jumpers:
Jumpers
Label Function
JP1 LCD INVERTER Voltage Selection
JP2 COM2 Ring/+5V/+12V Selection
JP3 LVDS Voltage Selection
JP4 Auto power button
JP5 Clear CMOS
JP6 ATX Power simulate AT Power
