Aaeon RTC-900R User manual

10.1” Rugged Tablet RTC-900R
Computer
RTC-900R
NVIDIA®TEGRA™ 2
1.0 GHz Dual Core Processor
Rugged Tablet Computer
10.1” WXGA TFT LCD Display
1 Mini HDMI, 1 Mini USB
RTC-900R Manual 1st Ed
July 2013

10.1” Rugged Tablet RTC-900R
Computer
i
Copyright Notice
This document is copyrighted, 2013. All rights are reserved. The
original manufacturer reserves the right to make improvements to
the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in
this manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, or for
any infringements upon the rights of third parties that may result
from its use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have
been made in the preparation of this document to assure its
accuracy, AAEON assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information
contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.

10.1” Rugged Tablet RTC-900R
Computer
ii
Acknowledgments
All other products’ name or trademarks are properties of their
respective owners.
NVIDIA®and TEGRATM are trademarks of NVIDIA®
Corporation.
Android™is a registered trademark of Google.
Adobe®Flash®Player Support
+Flash Player 10.2 is now
available for download on the
Android™Market. This is a
production GA (General Availability)
release for Android™2.2 (Froyo) and
2.3 (Gingerbread) devices and an
initial beta release forAndroid™3.x
(Honeycomb) tablets that include at
least Google’s 3.0.1 system update.
For more details, please visit
http://blogs.adobe.com/flashplayer/
All other product names or trademarks are properties of their
respective owners.

10.1” Rugged Tablet RTC-900R
Computer
iii
Packing List
Before you begin operating your tablet computer, please make sure
that the following materials are enclosed:
1 RTC-900R Rugged Tablet with Android™
1 AC Adapter with Power Cord
1 DVD-ROM for USB driver & manual
(in PDF format)
If any of these items could be missing or damaged, please contact
your distributor or sales representative immediately.

10.1” Rugged Tablet RTC-900R
Computer
iv
Options
The following items are normally optional, but some vendors may
include them in the standard package. Some items may not be
available in some countries, or some vendors may choose not to carry
all the times.
3G Modem module
Caution:when purchasing any of the accessories listed above,
purchase only those accessories that are approved for use with your
Rugged Tablet Computer. The above accessories are proprietary
items. Our system vendor can obtain these approved accessories.
If you use items that are not approved for use with this Rugged Tablet
Computer, you may cause your Rugged Tablet Computer to
malfunction, or to emit or receive electro-magnetic radiation in excess
of local regulations. For non-proprietary accessories such as PC
cards or printers, ensure that the accessory functions properly in your
Rugged Tablet Computer before making the purchase. Your system
vendor may be able to recommend reliable brands and models.

10.1” Rugged Tablet RTC-900R
Computer
v
Safety & Maintenance
You can use your Rugged Tablet Computer under a wide range of
environmental conditions. However, to ensure long use and continued
high performance, consider the following factors when setting up your
Rugged Tablet Computer (RTC):
Follow all warnings and instructions noted in this documentation
and in the Android™Help program.
The input voltage range between the wall outlet and this adapter is
AC 100V–240V, and the output voltage of this adapter is DC 12V,
2A.
The first time you use your RTC, we recommend that you carefully
read the Making Connections section of this manual and initialize
the battery to ensure optimum battery performance.
Unplug the RTC from the power outlet before cleaning. Use a damp
cloth for cleaning. Do not use aerosols, solvents, or strong
detergents.
Slots and openings in the system cabinet are for ventilation
purposes. Do not block or cover these openings or the system could
overheat. Do not use or store the RTC near a source of heat or dust.
On the base or rear panel of this RTC, there is a label with
information on the power requirements of this system. These
requirements must be followed. If you are unsure of your local
power supply, consult your dealer or local Power Company.
Do not step on or place anything on the power cord.
If you use the RTC with an extension cord, ensure that the total

10.1” Rugged Tablet RTC-900R
Computer
vi
ampere ratings of all the devices sharing the extension do not
exceed the rating of the extension cord or the rating of the wall
outlet.
Never push foreign objects into the RTC through any of the slots
or openings. Dangerous voltages are present, which could
cause electric shock or fire, or damage sensitive components.

10.1” Rugged Tablet RTC-900R
Computer
vii
FCC
This device complies with Part 15 FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received including interference that may cause
undesired operation.
Caution:
There is a danger of explosion if the battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the
manufacturer. Dispose of used batteries according to the
manufacturer’s instructions and your local government’s recycling or
disposal directives.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.

10.1” Rugged Tablet RTC-900R
Computer
viii
Below Table for China RoHS Requirements
产品中有毒有害物质或元素名称及含量
AAEON Panel PC/ Workstation
有毒有害物质或元素
部件名称 铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
印刷电路板
及其电子组件 ×○○○○○
外部信号
连接器及线材 ×○○○○○
外壳 ×○○○○○
中央处理器
与内存 ×○○○○○
硬盘 ×○○○○○
液晶模块 ×○○○○○
光驱 ×○○○○○
触控模块 ×○○○○○
电源 ×○○○○○
O：表示该有毒有害物质在该部件所有均质材料中的含量均在
SJ/T 11363-2006 标准规定的限量要求以下。
X：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出
SJ/T 11363-2006 标准规定的限量要求。
备注：
一、此产品所标示之环保使用期限，系指在一般正常使用状况下。
二、上述部件物质中央处理器、内存、硬盘、光驱、触控模块为选购品。

10.1” Rugged Tablet RTC-900R
Computer
ix
Contents
Chapter 1 Settings
1.1 Introduction................................................................1-2
1.2 Features....................................................................1-3
1.3 Android™ ..................................................................1-4
1.4 Quick Start.................................................................1-5
1.5 Touch Panel Control..................................................1-11
1.6 Settings .....................................................................1-12
Chapter 2 Applications
2.1 File Manager .............................................................2-2
2.2 Google Play...............................................................2-6
2.3 Music.........................................................................2-8
2.4 Image ........................................................................2-10
2.5 Mail............................................................................2-15
2.6 Location.....................................................................2-21
2.7 Documents................................................................2-23
2.8 Sharing......................................................................2-27
Chapter 3 Connectors
3.1 Right Side Connectors .............................................. 3-3
3.2 Top Side Connectors.................................................3-4
Chapter 4 Frequently Asked Questions
4.1 Frequently Asked Questions (FAQ)..........................4-2

10.1” Rugged Tablet
Computer RTC-900R
x
Appendix A Statements
A.1 Statements.............................................................A-2
A.2 Canadian Notice ....................................................A-5
A.3 CE Mark Notice......................................................A-7
A.4 Safety Caution .......................................................A-8
A.5 Battery Disposal.....................................................A-9
A.6 Battery Caution....................................................A-11
A.7 Adapter Caution...................................................A-12

10.1” Rugged Tablet RTC-900R
Computer
Chapter 1 Settings 1- 1
Settings
Chapter
1

10.1” Rugged Tablet RTC-900R
Computer
Chapter 1 Settings 1- 2
1.1 Introduction
This Rugged Tablet Computer (RTC) is a fully functional PC with
built-in wireless connectivity, Bluetooth®and an optional 3G modem
module. With your RTC you will be able to organize and access
important business and personal information. In addition, you will
be able to send and receive e-mail and access the Internet.
About Your RTC
This User Manual contains set-up information and describes key
elements of the RTC. Moreover, this manual describes all the
features of the RTC in an easy-to-read yet thorough manner. New
users can find a simple step-by-step orientation in each chapter.

10.1” Rugged Tablet RTC-900R
Computer
Chapter 1 Settings 1-3
1.2 Features
Included Software
Google Android™ v3.2 which includes:
• Google Text
• Google Applications
High performance Processor
NVIDIA®Tegra™ 2 1.0 GHz Dual Core Processor
Storage
The Rugged Tablet Computer has a 16 GB eMMC Flash to store
your favorite programs and multimedia files.
Built-in Wireless LAN, Bluetooth®and optional 3G Modem
Module
A built-in 802.11 b/g/n and Bluetooth®allows you to access the
Internet or a Wireless Local Area Network (WLAN).

10.1” Rugged Tablet RTC-900R
Computer
Chapter 1 Settings 1- 4
1.3 Android™
About Android™
Android™ for Developers offers an online orientation for Android
developers to answer any questions. Find it in:
http://developer.android.com/sdk/index.html

10.1” Rugged Tablet RTC-900R
Computer
Chapter 1 Settings 1-5
1.4 Quick Start
Turning on the Rugged Tablet Computer for the First Time
Use only the power adapter that comes with your device.
Using a different power adapter may damage your device.
Using the provided power adapter to connect the RTC-900R
to a power outlet is the best way to charge it.
The input voltage range between the wall outlet and this
adapter is AC 100V–240V, and the output voltage of this
adapter is DC 12V, 2A.
When using the RTC-900R for the first time, fully charge the

10.1” Rugged Tablet RTC-900R
Computer
Chapter 1 Settings 1- 6
battery for up to 12 hours to prolong battery life and whenever
the battery power is depleted. We suggest you to charge the
machine battery at least one time per month if the machine
has not been operated.
If the computer does not provide enough power to charge the
RTC-900R, use the wall outlet instead.
The RTC-900R CANNOT be charged via the USB port on the
computer.
The IP65 Waterproof protection may be damaged by
improper shocks or drops (over RTC-900R specifications:
MIL-STD-810G Method 516.6 Procedure IV). Moreover,
the IP65 protection will be influenced if the rubber connector
did not cover or close firmly. For more IP65 limitations,
please refer to the IP65 test report of RTC-900R.
Note: The battery is not fully charged. Allow your battery to fully charge
before using it (i.e., before disconnecting AC power). Calibrating the
battery before use is also highly recommended.
The power button turns your RTC on and off. Hold the button for two
seconds to power on. To start or wake it up from sleep mode, hold the
power button for 0.5 seconds to display the shutdown confirmation. If the
system is unresponsive, hold the power button to power off. A forced
power off may result in data loss. It is strongly recommended that
important data is backed up on a regular basis.

10.1” Rugged Tablet RTC-900R
Computer
Chapter 1 Settings 1-7
Getting Started
Before you begin using your RTC, read this chapter to familiarize
yourself with the main components installed in the system.
Front View
Top View
Light Sensor
1.2M Pixel
Camera

10.1” Rugged Tablet RTC-900R
Computer
Chapter 1 Settings 1- 8
Power Button
Micro-SD Card
Slot
DC-in
Mini USB
Right and Bottom View
Mini HDMI
SIM Card slot
Earphone
Rear View

10.1” Rugged Tablet RTC-900R
Computer
Chapter 1 Settings 1-9
5MP AF Camera
