Aaeon RTC-1200 User manual

2016

R
u
La
s
R
T
u
gged T
a
Use
r
2
s
t Updated: No
v
T
C-1
2
a
blet Co
m
r
’s Manua
2
016/9/23
v
ember 15,
2
00

m
puter
l 1
st
Ed


Preface II
Rugged Tablet Computer RTC-1200SK
Copyright Notice
This document is copyrighted, 2016. All rights are reserved. The original
manufacturer reserves the right to make improvements to the products described
in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or transmitted in
any form or by any means without the prior written permission of the original
manufacturer. Information provided in this manual is intended to be accurate and
reliable. However, the original manufacturer assumes no responsibility for its use,
or for any infringements upon the rights of third parties that may result from its
use.
The material in this document is for product information only and is subject to
change without notice. While reasonable efforts have been made in the
preparation of this document to assure its accuracy, AAEON assumes no
liabilities resulting from errors or omissions in this document, or from the use of
the information contained herein.
AAEON reserves the right to make changes in the product design without notice
to its users.


Preface III
Rugged Tablet Computer RTC-1200SK
Acknowledgement
All other products’ name or trademarks are properties of their respective owners.
Core & Celeron is registered trademark of Intel Corp.
Windows is the trademark of Microsoft Corp.
All other product names or trademarks are properties of their respective owners.


Preface IV
Rugged Tablet Computer RTC-1200SK
Packing List
Before setting up your product, please make sure the following items have been
shipped:
Item Quantity
RTC-1200 with Windows 10 1
AC/DC power adapter 1
Product DVD with User’s Manual (in pdf) 1
If any of these items are missing or damaged, please contact your distributor or
sales representative immediately.


Preface V
Rugged Tablet Computer RTC-1200SK
About this Document
This User’s Manual contains all the essential information, such as detailed
descriptions and explanations on the product’s hardware and software features (if
any), its specifications, dimensions, jumper/connector settings/definitions, and
driver installation instructions (if any), to facilitate users in setting up their product.
Users may refer to the AAEON.com for the latest version of this document.


Preface VI
Rugged Tablet Computer RTC-1200SK
Safety Precautions
Please read the following safety instructions carefully. It is advised that you keep
this manual for future references
1. All cautions and warnings on the device should be noted.
2. Make sure the power source matches the power rating of the device.
3. Position the power cord so that people cannot step on it. Do not place
anything over the power cord.
4. Always completely disconnect the power before working on the system’s
hardware.
5. No connections should be made when the system is powered as a sudden
rush of power may damage sensitive electronic components.
6. If the device is not to be used for a long time, disconnect it from the power
supply to avoid damage by transient over-voltage.
7. Always disconnect this device from any AC supply before cleaning.
8. While cleaning, use a damp cloth instead of liquid or spray detergents.
9. Make sure the device is installed near a power outlet and is easily
accessible.
10. Keep this device away from humidity.
11. Place the device on a solid surface during installation to prevent falls
12. Do not cover the openings on the device to ensure optimal heat dissipation.
13. Watch out for high temperatures when the system is running.
14. Do not touch the heat sink or heat spreader when the system is running
15. Never pour any liquid into the openings. This could cause fire or electric
shock.
16. As most electronic components are sensitive to static electrical charge, be
sure to ground yourself to prevent static charge when installing the internal


Preface VII
Rugged Tablet Computer RTC-1200SK
components. Use a grounding wrist strap and contain all electronic
components in any static-shielded containers.
17. If any of the following situations arises, please the contact our service
personnel:
i. Damaged power cord or plug
ii. Liquid intrusion to the device
iii. Exposure to moisture
iv. Device is not working as expected or in a manner as described
in this manual
v. The device is dropped or damaged
vi. Any obvious signs of damage displayed on the device
18. DO NOT LEAVE THIS DEVICE IN AN UNCONTROLLED ENVIRONMENT
WITH TEMPERATURES BEYOND THE DEVICE’S PERMITTED
STORAGE TEMPERATURES (SEE CHAPTER 1) TO PREVENT
DAMAGE.


Preface VIII
Rugged Tablet Computer RTC-1200SK
FCC Statement


This device complies with Part 15 FCC Rules. Operation is
subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must
accept any interference received including interference
that may cause undesired operation.
Caution:
There is a danger of explosion if the battery is incorrectly replaced. Replace only
with the same or equivalent type recommended by the manufacturer. Dispose of
used batteries according to the manufacturer’s instructions and your local
government’s recycling or disposal directives.
Attention:
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte.
Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le
constructeur. Recycler les batteries usées en accord avec les instructions du
fabricant et les directives gouvernementales de recyclage.


Preface IX
Rugged Tablet Computer RTC-1200SK
China RoHS Requirements (CN)

产品中有毒有害物质或元素名称及含量
AAEON Panel PC/ Workstation
部件名称
有毒有害物质或元素
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
印刷电路板
及其电子组件 ○○○○○○
外部信号
连接器及线材 ○○○○○○
外壳 ○○○○○○
中央处理器
与内存 ○○○○○○
硬盘 ○○○○○○
液晶模块 ○○○○○○
光驱 ○○○○○○
触控模块 ○○○○○○
电源 ○○○○○○
O：表示该有毒有害物质在该部件所有均质材料中的含量均在
SJ/T 11363-2006 标准规定的限量要求以下。
X：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出
SJ/T 11363-2006 标准规定的限量要求。
备注：
一、此产品所标示之环保使用期限，系指在一般正常使用状况下。
二、上述部件物质中央处理器、内存、硬盘、光驱、触控模块为选购品。


Preface X
Rugged Tablet Computer RTC-1200SK
China RoHS Requirement (EN)
Poisonous or Hazardous Substances or Elements in Products
AAEON Panel PC/ Workstation
Component
Poisonous or Hazardous Substances or Elements
Lead
(Pb) Mercury (Hg) Cadmium (Cd)
Hexavalent
Chromium
(Cr(VI))
Polybrominated
Biphenyls
(PBB)
Polybrominated
Diphenyl
Ethers (PBDE)
PCB & Other
Components OO O O O ○
Wires &
Connectors
for External
Connections
OO O O O O
Chassis OO O O O O
CPU & RAM OO O O O O
Hard Disk OO O O O O
LCD OO O O O O
Optical Drive OO O O O O
Touchscreen OO O O O O
PSU OO O O O O
O：The quantity of poisonous or hazardous substances or elements found in each of the
component's parts is below the SJ/T 11363-2006-stipulated requirement.
X: The quantity of poisonous or hazardous substances or elements found in at least one of
the component's parts is beyond the SJ/T 11363-2006-stipulated requirement.
Note: The Environment Friendly Use Period as labeled on this product is applicable
under normal usage only



Preface XI
Rugged Tablet Computer RTC-1200SK
Table of Contents

Chapter 1 - Product Specifications................................................................... 1
1.1Specifications ..................................................................................... 2
Chapter 2 – Getting Started............................................................................... 6
2.1Product Overview ............................................................................... 7
2.2Notes Before Use ............................................................................. 12
2.3Turning On the Device...................................................................... 14
2.4Touch Controls ................................................................................. 15
Chapter 3 – Setting Up..................................................................................... 16
3.1Settings Screen ................................................................................ 17
3.1.1System.................................................................................. 20
3.1.2Device................................................................................... 23
3.1.3Network &Internet................................................................. 24
3.1.4Personalization Settings ....................................................... 26
3.1.5Accounts Settings................................................................. 27
3.1.6Time&Language Settings ..................................................... 27
3.1.7Ease of Access Settings ....................................................... 27
3.1.8Privacy Settings.................................................................... 27
3.1.9Update&Security Settings..................................................... 27
Chapter 4 – Optional Accessories ................................... 錯誤! 尚未定義書籤。
4.11D/2D Code Scanner ........................................錯誤! 尚未定義書籤。
4.2Magnetic Stripe Reader (MSR) .........................錯誤! 尚未定義書籤。
4.3Smart Card Reader (SCR) ................................錯誤! 尚未定義書籤。
4.4Docking Station .................................................錯誤! 尚未定義書籤。
Appendix A - Statements ................................................................................. 32
A.1Statements ....................................................................................... 33
A.2Canadian Notice............................................................................... 39


Preface XII
Rugged Tablet Computer RTC-1200SK
A.4Safety Caution.................................................................................. 40
A.5Battery Disposal ............................................................................... 39
A.6Battery Caution................................................................................. 41
A.7Adapter Caution ............................................................................... 42
A.8FCC Interference Statement............................................................. 43



Rugged Tablet Computer RTC-1200SK


Chapt
e
C
h
e
r 1 - Prod
u
h
apt
e
u
ct Specifi
c
e
r 1

c
ations


Chapter 1 – Product Specifications 2
Rugged Tablet Computer RTC-1200SK
1.1 Specifications

System
Processor
Intel® Core™ i3-6100U Processor
(3M Cache, 2.30 GHz)
(opt.)Intel® Core™ i5-6300U Processor
(3M Cache, up to 3.00 GHz)
(opt.) Intel® Core™ i7-6600U Processor
(4M Cache, up to 3.40 GHz)
(opt.)Intel® Celeron® Processor 3955U
(2M Cache, 2.00 GHz)
System Memory SO-DIMM DDR3L 4GB
LCD Display
FHD (1920x1080) 1000nit LCD with 10-point P-cap
Anti-Scratch Screen
Communication
WiFi /b/g/n
Bluetooth 4.0 (EDR) with integrated class 1 PA and BLE
Support
I/O Port
Two USB 2.0 x 2 (Type-A)
One USB 3.0 x 1(Type-A)
One 3.5mm 4 pole Audio jack for Line-in and Line-out
One DC-In Jack (DC 19V)
One RJ-45 jack for 10/100/1000 LAN
One DB-9 (RS-232/RS-422/RS-485)
One HDMI port
One docking connector (contact pin with GPIO, DC-IN,
USB3.0 x1, pass through antenna x2(WWAN, GPS))
Built-In Speaker & Microphone


Chapter 1 – Product Specifications 3
Rugged Tablet Computer RTC-1200SK
One SIM Card Slot
One Micro SD card slot
Storage 64 GB eMMC Flash
(opt.) 128 GB eMMC Flash
Navigation
GPS/ Glonass/ AGPS (when 3G is enabled)
E-Compass
Camera 2MP Front Camera, 5MP Rear Camera with Flash
Sensor
Built-in Light Sensor
Built-in G-Sensor
Built-in 3-axis Digital Gyroscope
Built-in Vibration Motor
OS Window 10 Enterprise

Mechanical
Color Black & Dark Grey
Dimension (W x H x
D)
310.4x200x24.5mm
Gross Weight 3.3 lbs (1.5 kg)
Carton Dimension 350 x 270 x 110mm

Environmental
Operating -20°C ~ 50°C (-4 ~ 122°F)


Chapter 1 – Product Specifications 4
Rugged Tablet Computer RTC-1200SK
Temperature
Storage Temperature
-55°C ~ 70°C (-67 ~ 158°F)
Operating Humidity 10 ~ 95%
Water/ Dust
Protection Rating
IP65
Vibration
Met MIL-STD-810G-514.6 Procedure I Cat.24, Fig
514.6E-1 & 514.6E-2 (Unit is non-operating)
ASTM 4169-99 Truck Assurance Level II, Schedule E (Unit
is non-operating)
Drop
26 drops from 150 cm height to 2“ plywood over concrete
with bumpers & unit off
2 units to pass
MIL-STD-810G-516.6, Procedure IV
ESD Air +/- 8KV, Contact +/- 4KV
EMI/ Safety CE/ FCC Class B/ UL
Power Supply
AC/DC Adapter AC Power Input: 100 ~ 240 V, 50 ~ 60 Hz, 65 W output:
19V
Battery 2 Lithium-Polymer High Capacity Battery swappable;
14.8V 2200mAh 33Wh
LCD
Display Type TFT LCD Module with LED Backlight
Max. Resolution 1920 x 1080
Luminance (cd/m2)
1000 nit
300 nit (opt.)


Chapter 1 – Product Specifications 5
Rugged Tablet Computer RTC-1200SK
Viewing Angle
Horizontal: 178°
Vertical: 178°



Rugged Tablet Computer RTC-1200SK


C
h
C
h
h
apter 2
–
h
apt
e
–
Getting
S
e
r 2

S
tarted


Chapter 2 – Getting Started 7
Rugged Tablet Computer RTC-1200SK
2.1 Product Overview
Front View


Chapter 2 – Getting Started 8
Rugged Tablet Computer RTC-1200SK
Side View (Left)
Part Function
NFC Reader Support NFCIP-1 and NFCIP-2, ISO/IEC 14443, ISO/IEC 15693,
ISO/IEC 18000-3, MIFARE and FeliCa specifications
Power Button Shut down/power on & sleep mode by Power Options in System
Settings
LED Indicator Battery Charge Status; Orange or Green (full)
3.5 mm Audio
Jack
Usable with any audio device with a 3.5 mm jack.
mSD card Slot support up to SDXC 2TB
SIM Card Slot Usable with standard-size SIM cards only.
Light Sensor Ambient Light Sensr
2MP camera 1080p FHD Webcam
COM Port
SIM Card Slot
3.5 mm Audio Jack
mSD Card Slot
DC-in Port
Cradle Port &
GNSS/WLAN Pass-through Port
Power Button &
LED Indicator
NFC Reader
Light Sensor, 2MP camera &
Microphone
