A&D ULTRACONNECT UB-1100BLE User manual

Model UB-1100BLE
Instruction Manual
Original
Manuel d’instructions
Traduction
Manual de Instrucciones
Traducción
Manuale di Istruzioni
Traduzione
使用手冊
翻譯
ﻝﻳﻟﺩﺍﺩﺎﺷﺭﻹﺍﺕ
ﺔﻣﺟﺭﺗﻟﺍ
English
Español
Français
Italiano
Wrist Digital Blood Pressure Monitor
1WMPD4003739
ﻟﺍﻳﺑﺭﻌﺔ
中文

English 1
Contents
Dear Customers ................................................................................................................................................... 2
Preliminary Remarks ........................................................................................................................................... 2
Precautions .......................................................................................................................................................... 2
Parts Identification ............................................................................................................................................... 5
Contents .............................................................................................................................................................. 5
Symbols ............................................................................................................................................................... 6
Using the Monitor ............................................................................................................................................... 10
Measurements ................................................................................................................................................... 17
What Is The IHB/AFib Indicator? ....................................................................................................................... 21
What Is The AFib? ............................................................................................................................................. 21
WHO Classification Indicator ............................................................................................................................. 21
About Blood Pressure ........................................................................................................................................ 22
Settings by App .................................................................................................................................................. 24
Settings .............................................................................................................................................................. 25
Troubleshooting ................................................................................................................................................. 27
Maintenance ...................................................................................................................................................... 28
Technical Data ................................................................................................................................................... 28

English 2
Dear Customers
Congratulations on purchasing a state-of-the-art A&D blood pressure monitor, one of the most advanced monitors
available today. Designed for ease of use and accuracy, this monitor will facilitate your daily blood pressure
regimen.
We recommend that you read through this manual carefully before using the device for the first time.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such
marks by A&D is under license. Other trademarks and trade names are those of their respective owners.
Preliminary Remarks
This device conforms to the European Directive 93/42 EEC for Medical Products. This is made evident by the
mark of conformity. (0123: The reference number to the involved notified body)
Hereby, A&D Company, Limited declares that the radio equipment type UB-1100BLE is in compliance with
Directive 2014/53/EU. The full text of the EU declaration is available at the following internet address:
http://www.aandd.jp/products/manual/manual_medical.html
The device is designed for use on adults, not newborns or infants.
Environment for use. The device is for use to operate by yourself in the home healthcare environment.
This device is designed to measure blood pressure and pulse rate of people for diagnosis.
Precautions
Precision components are used in the construction of this device. Extremes in temperature, humidity, direct
sunlight, shock or dust should be avoided.
Clean the device and cuff with a dry, soft cloth or a cloth dampened with water and a neutral detergent. Never use
alcohol, benzene, thinner or other harsh chemicals to clean the device or cuff.

English 3
The device and cuff are not water resistant. Prevent rain, sweat and water from soiling the device and cuff.
Measurements may be distorted if the device is used close to televisions, microwave ovens, cellular telephones,
X-ray or other devices with strong electrical fields.
When reusing the device, confirm that it is clean.
Used equipment, parts and batteries are not treated as ordinary household waste, and must be disposed of
according to the applicable local regulations.
Do not modify the device. It may cause accidents or damage to the device.
To measure blood pressure, the wrist must be squeezed by the cuff hard enough to temporarily stop blood flow
through the artery. This may cause pain, numbness or a temporary red mark to the wrist. This condition will
appear especially when measurement is repeated successively.
Any pain, numbness, or red marks will disappear with time.
If you feel strong pain during the measurement, please remove the cuff.
Measuring blood pressure too frequently may cause harm due to blood flow interference.
Avoid tightly folding the cuff for long periods, as such treatment may shorten the life of the components.
When the AC adapter is used, make sure that it can be readily removed from the electrical outlet when
necessary.
Sometimes the temperature of the cuff can reach 44°C in an ambient temperature of 40°C. If you feel the cuff is
too hot, please remove the cuff immediately.
Please do not simultaneous use HF surgical equipment.
Clinical testing has not been conducted on newborn infants and pregnant woman. Do not use on newborn infants
or pregnant woman.
If you have had a mastectomy, please consult a doctor before using the device.
Do not let children use the device by themselves and do not use the device in a place within the reach of infants. It
may cause accidents or damage.
There are small parts that may cause a choking hazard if swallowed by mistake by infants.
Do not touch the batteries and the patient at the same time. That may result in electrical shock.
Wireless communication devices, such as home networking devices, mobile phones, cordless phones and their
base stations, walkie-talkies can affect this blood pressure monitor. Therefore, a minimum distance of 1 meter/3.2
feet should be kept from such devices.

English 4
Unplug the ac adapter when not in use during the measurement.
Use of accessories not detailed in this manual may compromise safety.
Should the battery short-circuit, it may become hot and potentially cause bums.
Allow the device to adapt to the surrounding environment before use (about one hour).
Do not inflate without wrapping the cuff around the upper arm.
The automatic blood pressure monitor's performance may be afficted by excessive temperature or humidity, or
altitude.
Contraindications
The following are precautions for proper use of the device.
Do not apply the cuff on wrist in which another medical device is attached. The equipment may not function
properly.
People who have a severe circulatory deficit in the wrist must consult a doctor before using the device, to avoid
medical problems.
Do not self-diagnose the measurement results and start treatment by yourself. Always consult your doctor for evaluation of
the results and treatment.
Do not apply the cuff on wrist with an unhealed wound.
Do not apply the cuff on wrist receiving an intravenous drip or blood transfusion. It may cause injury.
Do not use the device where flammable gases such as anesthetic gases are present. It may cause an explosion.
Do not use the device in highly concentrated oxygen environments, such as a high-pressure oxygen chamber or an oxygen
tent. It may cause a fire or explosion.

English 5
Parts Identification
Contents
・1 Blood Pressure Monitor
・1 Instruction Manual
・1 Charging Cable
OLED
RED LED
Start Switch
Cuff
Reset Switch
USB Connecto
r

English 6
Symbols
Symbols that are printed on the device case and cuff
Symbols Function / Meaning
Standby and Turn the device on.
Direct current
Type BF: Device and cuff are designed to provide special protection against electrical shocks.
EC directive medical device label
EU-representative
Manufacturer
Date of manufacture
IP International protection symbol: IP classification is degrees of protection provided by enclosures in
accordance with IEC 60529. This device is protected against solid foreign objects of 12mm diameter and
greater such as a finger. This device is not protected against water.
WEEE label
SN Serial number
BT Bluetooth address
Refer to instruction manual/booklet
To indicate generally elevated, potentially hazardous, levels of non-ionizing radiation, or to indicate
equipment or systems e.g. in the medical electrical area that include RF transmitters or that intentionally
apply RF electromagnetic energy for diagnosis or treatment.
Keep dry
Universal Serial Bus

English 7
Symbols that appear on the display
Symbols Function / Meaning Recommended Action
SYS Systolic blood pressure in mmHg
DIA Diastolic blood pressure in mmHg
PUL Pulse per minute
The battery power is low Charge the device
User Select mode Select the user
Application is connected with the device
Application has disconnected from the device
C.P.G(Correct Position Guidance)
The C.P.G. Indicator:
LOW. The height of the blood pressure monitor
Is lower than your heart.
Place the blood pressure monitor at the same
level as your heart.
The C.P.G. Indicator:
LEVEL. The height of the blood pressure monitor
Is the same level as your heart.
The C.P.G. Indicator:
HIGH. The height of the blood pressure monitor is
higher than your heart.
Place the blood pressure monitor at the same level
as your heart.
Appears while measurement is in progress. Measurement is in progress. Remain as still as
possible.
PUL
/min The pulse is not detected correctly. Apply the cuff correctly, and take another
measurement.
E

English 8
Symbols that appear on the display (continued)
Symbols Function / Meaning Recommended Action
Err 1
Unstable blood pressure due to movement during
measurement. The systolic and diastolic values are
within 10mmHg of each other.
Take another measurement.
Remain still during measurement.
Err 3 The pressure value did not increase during inflation.
The cuff is not applied correctly.
Apply the cuff correctly, and take another
measurement.
Err 9 Blood pressure monitor internal error.
Press the reset button.
After reset, clock data will disappear.
If the error still appears, contact A&D Medical.
Data is transferring
Airplane mode Measurements can be taken but device will not
transmit data wirelessly.
Appears when a body or wrist movement is detected.
The reading may yield an incorrect value.
Take another measurement.
Remain still during measurement.
Appears during measurement when the cuff is
attached loosely.
The reading may yield an incorrect value.
Apply the cuff correctly, and take another
measurement.
Firmware is updating.
Appears when irregular heart beat is detected.
Appears when your arm was in the Incorrect position
during measurement, either higher than your heart or
lower than your heart.
Take another measurement and ensure your wrist is at
the same height as your heart.

English 9
Symbols that appear on the display (continued)
Symbols Function / Meaning Recommended Action
Appears when your arm is in the
correct position during measurement.

English 10
Using the Monitor
UB-1100BLE Digital Blood Pressure Monitor features 5 measurement modes.
1. In-App Mode Measurement:
User can take measurements and view their trends in the A&D Connect app.
2. Offline Mode Measurement:
Measurement can also be completed without the A&D Connect app.
Data will be stored on the monitor and transferred to the app on next connection.
3. Multiuser Mode Measurement(In-app):
Up to 6 users (5 accounts and 1 visitor) can use and store data on the app. Each user must have a mobile device
paired with the monitor.
4. Guest Mode Measurement(In-app):
User can take a measurement as Guest, without account registration in the A&D Connect app. The data is saved
on the mobile device memory but not in your account.
5. Visitor Mode Measurement (Offline):
Select “0 Visitor” to take a measurement in visitor mode from the monitor only. Data is not stored in visitor mode.

English 11
Using the Monitor
Charging the Device
Battery may be partially charged but be sure to charge the device completely upon first use after purchase.
1. Remove the USB connector cover.
2. Connect the charging cable.
3. During charging, the red LED will illuminate.
4. When charging is complete, the red LED will turn off.
5. Once charging is complete, remove the charging cable.

English 12
Using the Monitor
CAUTION!
 The battery life varies with the ambient temperature and may be shorter at low temperatures.
 Please use the specified charging cable shipped with the device.
 Blood pressure measurement cannot be done during charging.
 When disconnecting the AC adapter from the electrical outlet, grasp and pull the AC adapter body out
the outlet.
 When disconnecting the charging cable from the blood pressure monitor, grasp and pull the charging
cable out of outlet.
 Do not connect to equipment other than those specified.
 Do not change the battery.
 If the battery can no longer charged, please contact the dealer.
 Overcharging the battery may reduce its lifetime.
 Lithium battery replacement by inadequately trained personnel could result in a hazard such as a fire
or explosion.

English 13
Wireless Function
 In the unlikely event that this monitor causes radio wave interference to a different wireless station, change the location
where this monitor is used or stop use immediately.
 Be sure to use in a location where visibility between the two devices that you want to connect is good. The connection
distance is reduced by the structure of buildings or other obstructions. In particular, connection may be impossible
when devices are used on either side of reinforced concrete.
 Do not use Bluetooth® connection in the range of a wireless LAN or other wireless devices, near devices that emit
radio waves such as microwaves, in locations where there are many obstructions, or in other locations where signal
strength is weak. Doing so may result in frequent loss of connection, very slow communication speeds and errors.
 Using close to an IEEE802.11g/b/n wireless LAN device may cause mutual interference to occur, which may result in
reduced communication speeds or which may prevent connection.
In this case, switch off the power supply to the device that is not being used, or use the monitor in a different location.
 If the monitor does not connect normally when used near a wireless station or broadcast station, use the monitor in a
different location.
 A&D Company, Limited cannot accept liability for any damages incurred due to impaired operation or data loss, etc. that
occur through the use of this product.
 This product is not guaranteed to connect to all Bluetooth® compatible devices.

English 14
Bluetooth®
Transmission
This product is equipped with a Bluetooth® 4.1 wireless function and can connect to the following Bluetooth® devices.
Apple iOS v.8.0 or newer Android OS 4.4.4,5.1,6.0, and 7.0
iPhone 4s or newer, Bluetooth® devices Selected
iPad touch 5th gen; Android phones only.
iPad 3,4; iPad Air; iPad mini
For the latest compatibility list visit
www.wellnessconnected.jp/english/compatibility/
To connect with your mobile device – download and install the “A&D application” onto your mobile device.
Later referred to as “APP”.

English 15
Using the Monitor
Device Setup (Pairing)
1. Ensure the Bluetooth® function of the mobile device is ON.
2. Launch up A&D Medical CONNECT app.
The icon to the left will
Blink on the monitor.
3. Accept the paining request from the pop-up window.
Multiuser Pairing
The monitor can be registered for up to 5 users. Follow the above instructions to pair the mobile device for each user.
New users can be added anytime. The user who has the lowest frequency of measurement times will be cleared
once the device has reached the 5 user max.
Note: If new user uses the same mobile device, then re-paining is not required as this has been complete.
Note: Default is in visitor non memory mode with out paining.
CAUTION!
The communication distance between this monitor and the receiver device is about 33 feet (10m). This
distance can be reduced by the conditions in the surrounding environment, so be sure to check that the
distance is short enough for a connection to be made after measurement is complete.

English 16
Using the Monitor
Applying the Wrist Cuff
1. Wrap the cuff around your wrist about 1cm above your hand as shown in the figure below.
2. Apply the cuff tightly using the Velcro strip.
Note: For accurate measurements, apply the cuff tightly and measure on a bare wrist.
How to Take Accurate Measurements
For the most accurate blood pressure measurement:
Sit comfortably on a chair. Rest your arm on the table. Do not cross your legs. Keep your feet on the floor and
straighten your back.
Relax for about five to ten minutes before measurement.
Place the center of the cuff at the same height as your heart.
Remain still and keep quiet during measurement.
Do not measure immediately after physical exercise or a bath. Rest for twenty or thirty minutes before taking the
measurement.
Try to measure your blood pressure at the same time every day.

English 17
Measurements
In-App Mode Measurement
1. Ensure the Bluetooth® function of the mobile device is ON.
2. Open the A&D Connect app. The app will automatically detect the
presence of the monitor.
3. Press the Take Measurement button, followed by the Start button
on the app screen.
4. The C.P.G. indicator will display the correct wrist position briefly.
5. The cuff starts to inflate. It is normal for the cuff to feel tight. The app displays the pressure value once inflation starts.
6. When the measurement is complete, the app and the monitor will display
results similar to the icon on the right.
(Systolic, diastolic and pulse rate will be displayed in rotation.)
Note: Press the start button again to turn the monitor off. The monitor is also
provided with an automatic power shut-off function. Allow at least
one minute between measurements on the same person.
Take measurement Start App Display
User number Username
Monitor Display
Monitor Display
App Display
Result Notification
Icons(Refer to pg.8,21
For details)

English 18
Measurements
Offline Mode Measurement
1. Press the Start button on the monitor.
After the A&D logo appears for 1 second, the User Select screen will display.
2. Press the Start button again to select a user or switch between username from User Select screen.
Username can be changed in the app under Settings.
When this is not set, the first name will display as the username.
3. Measurement starts automatically after 3 seconds.
4. Zero(0) is displayed blinking briefly. Then the display changes, as measurement begins.
5. The cuff starts to inflate. It is normal for the cuff to feel tight. Monitor displays the
pressure value once inflation starts.
6. When the measurement is complete, the monitor will display result similar to the icon on
the right. (Systolic, diastolic and pulse rate will scroll.)
Note: Press the start button again to turn the monitor off. The monitor is also provided with
an automatic power shut-off function. Allow at least one minute between measurements
on the same person.
User number User name
Select User
