A&D TM-2440 User manual

A&D Ambulatory
Monitoring System
Quick Start Guide
TM-2440 and TM-2441
andmedical.com

Step 1: Software installation
1. Insert the A&D Medical USB stick into your PC to start installation.
2. In your File Explorer, open your removable disc or USB drive.
Find and open the Setup.exe application.
3. Click on Install.
4. Follow the guided instructions. This may take a few minutes.
5. To open the application, navigate to your desktop and double click
the A&D Client application. If it is not on your desktop, search for
A&D Client in recently installed programs.

Step 2: Inserting the batteries
1. Open the battery cover.
2. Refer to the symbol inside the battery compartment. Insert two
new AA batteries into the proper “+” and “-” direction.
3. Close the battery cover.
Step 3: Connecting the monitor
1. Connect the micro USB cable between the monitor and computer.
2. The buzzer will sound and OFF appears on the OLED display.
The monitor enters its standby mode.
Battery Tips
1. New AA batteries will last approximately 200 measurements. This varies
depending on the quality of batteries used and operating temperatures.
2. We recommend using high quality AA batteries.
3. If the AA batteries die, there is an internal coin cell battery that will retain
measurement results and clock settings. This is automatically recharged
when new AA batteries are inserted.
TM-2440 TM-2441

Step 4: Programming the monitor
1. Open the A&D software.
2. Click on Recorder icon.
3. Select settings for a new ABPM study. Once complete, select Save.
The device is now programmed.
4. Disconnect the micro USB cable from the device.
5. Turn the ABPM function ON. For the TM-2440 only, press and hold
Event for at least three seconds. The icon should appear on
the display. For the TM-2441 only, slide the Auto Switch to ON,
then lock it.
LOCK switch
AUTO switch to "O
O
N
N
"
TM-2440 TM-2441
Interval
Settings
From 7AM
to 10 PM -->
30 minute
intervals
From 10 PM
to 7AM -->
60 minute
intervals
Operation Time
Select 24 for a full 24 hour study.
The ABPM will stop operating after
24 hours. If OFF is selected, the
monitor will continue to operate until
the batteries die.
Auto Start Time
To manually
start the
measurements
when nished
setting the
patient up,
select OFF. To
automatically
start at a future
time, select the
time from the
drop down menu.

Step 5: Setting up the patient
1. Wrap the cu󰀨 around the patients’ upper arm (refer to below cu󰀨 guide).
2. Position tube around the back of the neck and attach monitor to the belt
loop. Clip the tube to the undershirt. If user does not have undershirt,
tape to skin. Wrap the belt loop around waist. Fasten the air plug from
the air hose into the air socket. Secure monitor into the carrying case.
3. Press the START/STOP button on the top of the device to start the
rst measurement. The programmed intervals will automatically begin.
Air Hose
Carrying holder
Belt
Cu
Clip
Tape Air plug
Air socket
Part Number Cu󰀨 Size
TM-CF202A Small Cu󰀨 5.9-8.7” (15-22 cm)
TM-CF302A Medium Cu󰀨 7.8-12.2” (20-31 cm)
TM-CF402A Large Cu󰀨 11.0-15.0” (28-38 cm)
TM-CF502A Extra Large Cu󰀨 14.2-19.7” (36-50 cm)
Have room to
inser
t two ngers
.5”
(1-2 cm)

Step 6: Downloading the data
1. Connect the micro USB cable between the monitor and computer.
Please ensure you are using the cable that came with your
monitor.
2. Open the A&D Client application from your computer.
3. Click the Download icon. The download will begin.
4. Enter the patient information. Ensure to enter accurate sleep
information. The reporting is based on this sleep input.
TM-2440 TM-2441

Step 7: Reviewing data and printing report
1. The datalist for all measurements appear.
2. To generate report, click the Layout icon on the top menu.
3. Customize your report by selecting and deselecting items in the report
layout. Click Apply and Save to set layout for future report generation.
4A. Click on the Print icon to print results.
To enter a
comment,
double click
here and enter
comment
To manually
exclude a
measurement
from the
report, click
on the box and
a check mark
will appear

4B. To save as .PDF, choose Views. Then, click on the Export icon.
Choose the le location and le name. Click Save As. It will
automatically generate a .CSV and .PDF le and save it in the
selected le location.
Patient Tips
DO
1. When ination begins, relax arm, stay still and quiet.
2. Ensure the tube is not compressed or kinked.
3. Track your bed time and awake time then report to clinician.
DO NOT
1. Operate heavy machinery. Vibrations may disrupt measurements.
2. Remove batteries during session.
3. Drop or shock the device.
4. Expose the device to rain or water.
5. Arrange the cu󰀨 hose around your neck during sleep.
andmedical.com
©2021 A&D Medical. All rights reserved. TM2440/41-QSG
