AAON Orion BACnet General Controller Quick start guide

BACnet®General Controller
Technical Guide

AAON, Inc.
2425 South Yukon Ave.
Tulsa, OK 74107-2728
www.aaon.com
Factory Technical Support Phone: [phone]
Controls Support Phone: [phone]
Copyright January 2020 AAON
AAON Part Number: G042460, Rev. 01E
AAON®is registered trademark of AAON, Inc., Tulsa, OK.
Windows®10 is a registered trademark of Microsoft Corporation.
BACnet®is a registered trademark of ASHRAE Inc., Atlanta, GA.
AAON®assumes no responsibility for errors or omissions in
this document. This document is subject to change without notice.
All rights reserved throughout the world.
www.aaon.com

TABLE OF CONTENTS
3BACnet®General Controller Technical Guide
GENERAL INFORMATION...................................................................................... 4
Overview.................................................................................................................................................. 4
Features .................................................................................................................................................. 4
Environmental Requirements .................................................................................................................. 4
Mounting.................................................................................................................................................. 4
Power Supply .......................................................................................................................................... 4
Dimensions.............................................................................................................................................. 5
INSTALLATION & WIRING..................................................................................... 6
Important Wiring Considerations ............................................................................................................. 6
Wiring ...................................................................................................................................................... 7
INPUTS / OUTPUTS............................................................................................... 8
LCD DISPLAY SCREENS........................................................................................ 9
TROUBLESHOOTING........................................................................................... 14
LED Diagnostics .................................................................................................................................... 14
LED Locations ....................................................................................................................................... 15
APPENDIX A - BACnet®Points ............................................................................ 16

OVERVIEW
4BACnet®General Controller Technical Guide
Overview
The BACnet®General Controller (BGC) is an Input/Output module
that has BACnet® MS/TP communication capability. The BGC has
no internal logic, but allows a BACnet®front end to read its inputs
and to command its outputs. The BGC has (8) analog inputs, (8)
wet contact binary inputs, (8) relay outputs and (4) analog outputs.
Features
The BGC Controller:
• Operates as a stand-alone controller connecting to a
BACnet®Bus
• Contains a 2 x 8 LCD character display and 4 buttons
that allow for status display and BACnet®conguration
settings
NOTE: The BGC contains no user-serviceable parts.
ContactqualiedtechnicalpersonnelifyourBGC
is not operating correctly.
General Information
Power Supply
The BGC requires an 18-30 VAC power connection with a minimum
rating of 15 VA.
WARNING: Observe polarity! All boards must be wired
GND-to-GND and 24 VAC-to-VAC. Failure
to observe polarity could result in damage to
the board.
Environmental Requirements
The BGC needs to be installed in an environment that can maintain
a temperature range between -30°F and 150°F and not exceed 95%
RH levels (non-condensing).
Mounting
The BGC is housed in a plastic enclosure. It is designed to be
mounted by using the 3 mounting holes in the enclosure base. It is
important to mount the module in a location that is free from extreme
high or low temperatures, moisture, dust, and dirt. Be careful not to
damage the electronic components when mounting the module. See
Figure 1, page 5 for Controller dimensions (in inches).

OVERVIEW
5BACnet®General Controller Technical Guide
Figure 1: BACnet®General Controller Dimensions (In Inches)
Dimensions

WIRING
6BACnet®General Controller Technical Guide
Important Wiring Considerations
Important Wiring Considerations
Please read carefully and apply the following information when wir-
ing the BGC. The BGC requires the following electrical connections:
1. 18 gauge minimum wire unless otherwise noted.
2. 24 VAC power connection with an appropriate VA rating.
3. All 24 VAC wiring must be connected so that all ground
wires remain common. Failure to follow this procedure can
result in damage to the module and connected devices.
4. All wiring is to be in accordance with local and
nationalelectricalcodesandspecications.
5. Check all wiring leads at the terminal block for tightness.
Be sure that wire strands do not stick out and touch
adjacentterminals.Conrmthatalltransducersrequiredfor
your system are mounted in the appropriate location and
wired into the correct terminals.
WARNING: Observe polarity! All boards must be wired
GND-to-GND and 24 VAC-to-VAC. Failure
to observe polarity could result in damage
to the board.
POWER LED Operations
WhentheBGCisrstpoweredup,thePOWERLED(SeeFigure
5, page 15 for location) should light up and stay on continuously.
If it does not light up, check to be sure that you have 24 VAC con-
nected to the controller, that the wiring connections are tight, and that
they are wired for the correct polarity. The 24 VAC power must be
connected so that all ground wires remain common. If after making
allthesechecks,thePOWERLEDdoesnotlightup,pleasecontact
AAON Controls Technical Support for assistance.

WIRING
7BACnet®General Controller Technical Guide
BGC Wiring
Figure 2: BGC Wiring Diagram
Inputs and Outputs Wiring
See Figure 2 below for wiring.

INPUTS & OUTPUTS
8BACnet®General Controller Technical Guide
Inputs and Outputs
Analog Inputs (Hard-Wired)
Theanaloginputscanbeconguredfor10Kohm,TypeIIItherm-
istor sensors or for user-scaled 0-5 VDC, 0-10 VDC, or 4-20 mA
inputs. Orion communicating temperature sensors, communicating
combination temperature/humidity sensors, or communicating CO2
sensors can also be used as analog inputs. These communicating
sensors require the use of pre-terminated Orion E-BUS modular
cables. See the next section for details.
Theinitialcongurationoftheanaloginputsisaccomplishedusing
points AV:5 through AV:12. AV:5 is associated with analog input
#1, AV:6 with analog input #2, etc. For each point (AV:5 through
AV:12),abitvaluecanbeenteredtocongurethatinputforthetype
of sensor or signal that will be used on that input. See the BACnet®
Parameters Table for the available options.
The jumpers next to each input must be set to match the selected
congurationforthatinput.
Once the Analog Input types have been selected, any of those inputs
conguredfor0-5VDC,0-10VDC,or4-20mAsignalscanbescaled
using points AV:13 through AV:20 to set the maximum scaled value
and points AV:21 through AV:28 to set the minimum scaled value
for each input.
Analog Inputs Using Communicating
Sensors
Inadditiontohard-wiredinputs,dierenttypesofE-BUScommuni-
cating sensors may be used as analog inputs with the BGC Controller.
If multiple communicating sensors are used, it may require the use of
anE-BUSAdapterBoardor an E-BUSAdapter Hub in order to
provideadditional E-BUS connection ports. An E-BUS cable is
required to connect either device to the BGC as well as to connect
the sensors to these devices.
ThefollowingOrionE-BUScommunicatingsensorsareavailable
to use with the BGC:
• ASM01819 - Space Temperature Sensor with
Digital Display
• ASM01820 - Combination Space Temperature/
Humidity Sensor with Digital Display
• ASM02221 - Combination Space Temperature/
Humidity Sensor without Digital Display
• ASM01836 - Combination Outdoor Air Temperature/
Humidity Sensor
• ASM01840 - Combination Return Air Temperature/
Humidity Sensor
• ASM01829 - Wall Mount CO2Sensor
• ASM01831 - Duct Mount CO2Sensor
The temperature value of a communicating sensor will be displayed
on the appropriate analog input (AI:2 through AI:9). If a combina-
tion temperature/humidity sensor is used, the humidity value of that
sensor will be displayed on the corresponding analog input (AI:10
through AI:17).
A communicating CO2 sensor value will be displayed on the ap-
propriate analog input (AI:2 through AI:9).
The Communicating Sensor Technical Guides can be downloaded
from www.aaon.com/controlsmanuals under Sensors.
NOTE: The communicating space sensor (temperature only
with display or combination temperature/humidity
with display) is the only communicating sensor that
can be used on multiple analog input addresses. If
multiple space sensors are used, they can be addressed
as address 1 through 8 via the display on the sensors.
Then, using points AV:29 through AV:36, those
sensors can be addressed accordingly on the BGC.
All other communicating sensors can only be used
once per BGC, and can be left at address 1 on the
appropriate point, AV:29 through AV:36.
Binary Inputs
The(8)wetcontact(24VAC)binaryinputscanbereadasOpen(O)
or Closed (On) using points BI:1 through BI:8. See the Appendix
A: BACnet®Parameters Table forthecongurationoptions.
Analog Outputs
The (4) analog outputs can be commanded to a voltage value be-
tween 0.0 VDC to 10.0 VDC using points AV:1 through AV:4. See
Appendix A: BACnet®Parameters Table for the selection options.
Relay Outputs
The(8)relayoutputscanbecommandedOnorOusingpointsBV:1
through BV:8. See Appendix A: BACnet®Parameters Table for
the selection options.
