Abaxis i-STAT Alinity v User manual

USER
MANUAL
GL
OBAL DIAGNOSTICS
FOR VETERINARY USE ONLY
v

Abbott Point of Care, Inc.
100 and 200 Abbott Park Road
Abbott Park, IL 60064
Manufactured for Abaxis, Inc.
Product of USA
i-STAT and Alinity are trademarks of the Abbott Group of Companies in various jurisdictions. Abaxis is a registered trademark of
Abaxis, Inc. ©Abaxis 2018
Contents
Abaxis, Inc.
3240 Whipple Road
Union City, CA 94587
USA
[phone]
[phone]
ABAXIS Europe GmbH
Bunsenstr. 9-11
64347 Griesheim
Germany
[phone]
The User Manual contains information that describes several functional pathways
of the i-STAT Alinity v Analyzer. The i-STAT Alinity v Analyzer is intended for
veterinary use only. Additional information regarding the use of the i-STAT Alinity
v Analyzer and i-STAT test cartridges can be found at www.abaxis.com. An Abaxis
Technical Support personnel can also be reached 24 hours a day, 7 days a week,
at 1-800-822-2947 (toll-free phone) for USA and Canada. International Technical
Support is available from 8:30 am to 5:00 pm CET at [phone].
Regulatory Compliance
Symbols
System Components
Component Anatomy
Screen Components and Their Meanings
Cartridge Information
Sample Collection and Handling
How to Perform Patient Testing
Maintenance
Software Updates
How to Perform Quality Testing
Troubleshooting
Connectivity
1
9
11
18
19
24
28
29
40
44
45
50
59
APOC Artwork #755229-01 Rev. B
Rev Date: 19-Jan-2018

i-STAT Alinity v — User Manual 650-7100 Rev. A1
Regulatory Compliance
The i-STAT Alinity system complies with applicable regulations.
Safety Regulations:
USA UL 61010-1: Safety Requirements for Electrical
Equipment for Measurement, Control and Laboratory
Use – Part 1: General Requirements
Canada CAN/CSA C22.2 No. 61010-1: Safety Requirements for
Electrical Equipment for Measurement, Control and
Laboratory Use – Part 1: General Requirements
European Union (EU) IEC 61010-1: Safety Requirements for Electrical
Equipment for Measurement, Control and Laboratory
Use – Part 1: General Requirements
European Union (EU) IEC 62133: Secondary cells and batteries containing
alkaline or other non-acid electrolytes – Safety
requirements for portable sealed secondary cells, and
for batteries made from them, for use in portable
applications
International UN Manual of Tests and Criteria “Recommendations on
the Transport of Dangerous Goods,” Section 38.3
“Lithium Batteries”
EMC Regulations:
USA FCC 47 CFR Part 15, Subpart B, Class A (Unintentional
Radiators)
Canada CAN ICES-001 Class A, Industrial, Scientific and
Medical Radio Frequency Radiators
European Union (EU) IEC 61326-1: Electrical Equipment for measurement,
control and laboratory use – EMC requirements – Part
1: General requirements.
Radio/Telecommunication Regulations:
Angola INACOM Instituto Angolano das Comuinicacoes
Equipment Type Model Number: 189
Antigua & Barbuda ABTD Antigua & Barbuda Telecommunications
Division
Type Approval Certificate Number 25-TAC2513000853

i-STAT Alinity v — User Manual 650-7100 Rev. A2
(Continued)
Armenia Conforms to: Technical Regulations of radio equipment
and telecommunication terminal equipment approved
by RA Government Regulations Decree of 15
December 2005 No 2228-N
Aruba Approved for use in accordance with article 4 of the
Telecommunication Regulation.
DTZ/910/2017/IZ, Pet nr. 3745
Australia Complies with Australian Communications and Media
Authority as required by the following Notices:
• Radiocommunications (Compliance Labelling-
Devices) Notice 2014 made under section 182 of the
Radiocommunications Act 1992;
• Radiocommunications Labelling (Electromagnetic
Compatibility) Notice 2008 made under section 182
of the Radiocommunications Act 1992;
• Radiocommunications (Compliance Labelling-
Electromagnetic Radiation) Notice 2014 made under
section 182 of the Radiocommunications Act 1992;
and
• Telecommunications (Labelling Notice for Customer
Equipment and Customer Cabling) Instrument 2015
made under section 407 of the Telecommunications
Act 1997.
Bahamas Utilities Regulation & Competition Authority (URCA)
Type Approval UCRA_TA/2017_023 FCC ID: 2AAEX-
SDABGN
Bahrain Telecommunications Regulatory Authority,
SPECT/0617/COM/150
Barbados Complies with GOVERNMENT OF BARBADOS,
TELECOMMUNICATIONS UNIT, Division of Energy &
Telecommunications. MED Approval Number: 1905
Belize Complies with Telecommunications Act, 2002
Type Approval per SI 152 OF 2002:
PUC/APC/0182017/BZE
Bonaire - Sint Eustatius – Agentschap Telecom, Minisceñe van Economische
Saba Zaken
Complies with articles 23 and 56 of the Besluit radio-
elektrische inrichtingen BES and article 2 of the
Regeling vrijstelling telecommunicatiemachtiging BES
2016 Type Approval 2017/008/AT and 2017/008a/AT
British Virgin Islands Telecommunications Regulatory Commission
Granted Equipment Type Approval for FCC Identifier
2AAEXSDABGN in accordance with section 42 of the
Telecommunications Act 2006.
Type Approval Number: VRGTA/011/2017
Brunei AITI Authority for Info-communications Technology
Industry of Brunei Darussalam
Equipment Registration Certificate
DRQ-D-BRUSIN-03-1998-7494-LPD-39421

i-STAT Alinity v — User Manual 650-7100 Rev. A3
Regulatory Compliance (Continued)
Burkina Faso ARCEP Type Approval 2017-000031
Autorite de Regulation des Communications
Electroniques et des Postes Authority of Regulations
of Communications Electronic and Posts
Canada Industry Canada RSS 210: Licence-Exempt Radio
Apparatus: Category I Equipment
Certification No.: 7228C-SDABGN
Cayman Islands Utility Regulation and Competition Oce
GRANT OF EQUIPMENT AUTHORISATION IN THE
CAYMAN ISLANDS
Certificate. No: KY1504003
Colombia Communications Regulatory Commission (CRC) -
Exempt
Curacao Director Bureau Telecommunicatie en Post
Type Approval Nos. 2017/054/TA and 2017/054a/TA
Dominica National Telecommunications Regulatory Commission
(NTRC)
Type Approval No. DMA-0217-0539p
Dominican Republic Istituto Dominicano de las Telecomunicaciones
(INDOTEL)
Type Approval 17003658
Egypt NTRA National Telecom Regulatory Authority
European Union (EU) DIRECTIVE 2014/53/EU OF THE EUROPEAN
PARLIAMENT AND OF THE COUNCIL of 16 April 2014
EN 300 328: Wideband transmission systems; Data
transmission equipment operating in the 2,4 GHz ISM
band and using wide band modulation techniques;
Harmonised Standard covering the essential
requirements of article 3.2 of Directive 2014/53/EU.
EN 301 893: 5 GHz RLAN; Harmonised Standard
covering the essential requirements of article 3.2 of
Directive 2014/53/EU.
Grenada National Telecommunications Regulatory Commission
EQUIPMENT TYPE APPROVAL NTRC REGISTRATION
NUMBER: CL 1090 | 17 – TA
Honduras CONATEL Comision Nacional De Telecomunicaciones
20161024HM32
Hong Kong CERTIFICATE OF TYPE APPROVAL per HKCA 1039
Issue 6, June 2015
India Ministry of Communcations & IT
Equipment Type Approval, ETA Certification No: ETA
– 3319/16-RLO(WR)
Japan Article 2 Section 1 No. 19, 19-3, 19-3-2
Radio Type Approval, Construction Designed
Certificate No: 208-160178

i-STAT Alinity v — User Manual 650-7100 Rev. A4
Regulatory Compliance (Continued)
Kuwait CITRA Communication and Information Technology
Regulatory Authority Type Approval Certificate
Lebanon Ministry of Telecommunications Approval 1031-16-041
Lesotho Lesotho Communications Authority
Lesotho Communications Authority Act 2012, Section 5
Libya General Authority for Communications
Type Approval Certificate No. 343-C1-2017
Madagascar Autorite de Regulation des Technologies de
Communication (ARTEC)
No 17/026/ARTEC/DG/DHCT/SSS/test
Mauritius Information & Communication Technologies Authority
(ICTA)
Type Approval Certificate Reference Number:
TA/2017/0214
Morocco Numéro d’agrément : MR 12797
Date d’agrément : ANRT 2016
Mozambique Instituto Nacional das Comunicacoes de Mocambique
(INCM)
Telecommunication and Radiocommunications
Agreements approved by Decree 37/2009 of 13
August
No. 1/R/IMS/2017
New Zealand Conforms to: Ministry of Business, Innovation &
Employment, Radio Spectrum Management as
required by notices under:
• Section 134 (1) (g) of the New Zealand
Radiocommunications Act 1989
Oman Telecommunication Regulatory Authority, Approval
Number: TRA/TA-R/4501/17
Pakistan Pakistan Telecommunication Authority (PTA), Type
Approval Certificate TAC NO: 9.197/2017
Peru Ministerio De Transportes Y Comunicaciones,
Certificado De Homologacion, Code: TRSS39479,
Report: 2158-2017-MTC/29.CGH.CH
Applied Technical Standard: PNAF-R.M. No. 187-2005-
MTC/03, pub.
04/03/2005 – R.M. No. 777-2005-MTC/03, pub.
11/05/2005
Philippines National Telecommunications Commission
Type Acceptance Certificate No. ESD-1714467C
Qatar Communications Regulatory Authority
Certificate of Type Approval CRA/SA/2016/R-5837

i-STAT Alinity v — User Manual 650-7100 Rev. A5
Regulatory Compliance (Continued)
Saudi Arabia Ministry of Communication and Information
Technology (MCIT)
Conformity Certificate TA 24012017-24012019-18944
Singapore Info-communications Media Development Authority
Regulation 20(6) of the Telecommunications (Dealers)
Regulations (Cap 323, Rg 6)
Registration Number: N0123-17 (5 GHz)
Registration Number: N0074-17 (2.4 GHz)
Sri Lanka Telecommunications Regulatory Commission of Sri
Lanka, TRC/SM/MISC/00041/17/WIFI-106
St. Lucia National Telecommunications Regulatory Commission
(Saint Lucia)
Telecommunications (Terminal Equipment and Public
Networks)
Regulations, No. 10 or 2002
Certification of Type Approval, Certificate No.:LCT/
AP17.118D
St. Maarten Bureau of Telecommunication and Post
Type Approval Certificate no 2017/018-b/TA
St. Vincent & the National Telecommunications Regulatory Commission
Grenadines Telecommunications (Terminal Equipment and Public
Networks)
Regulations, No. 13 of 2002
Certificate of Type Approval, Certificate No.:
SVG_050520171055
Turks and Caicos Turks and Caicos Islands Telecommunication
Commission
Approval Certification under TCITC Ordinance PART V
United Arab Emirates Telecommunications Regulatory Authority
Telecom Equipment Registration Certificate
ER53962/17 under Law No.3 of 2003
Uganda Uganda Communications Commission Type Approved
USA FCC 47 CFR Part 15, Subpart C - Intentional
Radiators
FCC 47 CFR Part 15, Subpart E - Unlicensed National
Information
Infrastructure Devices
FCC ID: 2AAEX-SDABGN

i-STAT Alinity v — User Manual 650-7100 Rev. A6
Regulatory Compliance (Continued)
Vietnam Ministry of Information and Communications
Type Approval Certificate No: C0031280217AE01A2
Yemen Ministry of Telecommunications and Information
Technology Type Approval
Zambia Zambia Information and Communications Technology
Authority (ZICTA)
Certificate of Type Approval ZMB/ZICTA/TA/2017/4/18
per ICT Act No. 15 of 2009
Zimbabwe Postal & Telecommunications Regulatory Authority of
Zimbabwe (POTRAZ)
Certificate of Type Approval No POZ521
SAR / RF Exposure Regulations:
USA FCC 47 CFR Part 2 Subpart J - Equipment
Authorization Procedures,
Section 2.1093, Radiofrequency Radiation Exposure
Evaluation: Portable Devices.
FCC OET-65C: Evaluating Compliance with FCC
Guidelines for Human Exposure to Radiofrequency
Electromagnetic Fields
Canada Industry Canada RSS 102 Radio Standards
Specification 102, Radio Frequency (RF) Exposure
Compliance of Radiocommunication Apparatus (All
Frequency Bands)
European Union (EU) EN 50360: Product standard to demonstrate the
compliance of mobile phones with the basic
restrictions related to human exposure to
electromagnetic fields (Frequency range of 300 MHz -
3 GHz)
EN 62209-1: Measurement procedure for the
assessment of specific absorption rate of human
exposure to radio frequency fields from handheld and
body-mounted wireless communication devices - Part
1: Devices used next to the ear (Frequency range of
300 MHz to 6 GHz)
EN 62209-2: Human exposure to radio frequency
fields from hand-held and body-mounted wireless
communication devices - Human models,
instrumentation, and procedures - Part 2: Procedure to
determine the specific absorption rate (SAR) for
wireless communication devices used in close
proximity to the human body (Frequency range of 30
MHz to 6 GHz)

i-STAT Alinity v — User Manual 650-7100 Rev. A7
Regulatory Compliance (Continued)
Environmental Regulations:
European Union (EU) RoHS Directive 2011/65/EU
European Union (EU) WEEE Directive 2012/19/EU
European Union (EU) REACH Regulation 1907/2006/EC
European Union (EU) Packaging and Packaging Waste Directive 94/62/EC
Federal Communications Commission (FCC) Statement
(United States only)
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to Part 15 of the Federal Communications Commission
(FCC) Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the user manual, can cause harmful
interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case you will be required to
correct the interference, at your own expense.
Changes or modifications not expressly approved by the manufacturer could void
your authority to operate the equipment.
Canadian Department of Communications Industry Canada Notice
(Canada only)
This Class A digital apparatus complies with Canadian ICES-001.
FCC Part 15 / Industry Canada Information:
This device complies with Part 15 Subpart C and Subpart E of FCC Rules and
Industry Canada licenceexempt
RSS-210 standard(s). Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference, including interference that may
cause undesired operation of this device.
This product contains transmitter module:
FCC ID: 2AAEX-SDABGN
IC: 7228C-SDABGN
SAR / RF Exposure Notice:
This equipment complies with FCC/IC radiation exposure limits set forth for an
uncontrolled environment and meets the FCC radio frequency (RF) Exposure
Guidelines in Supplement C to OET-65 and RSS-102 of the IC (Industry Canada)
radio frequency (RF) Exposure rules.
Under Industry Canada regulations, this radio transmitter may only operate using
an antenna of a type and maximum (or lesser) gain approved for the transmitter
by Industry Canada. To reduce potential radio interference to other

i-STAT Alinity v — User Manual 650-7100 Rev. A8
Regulatory Compliance (Continued)
users, the antenna type and its gain should be so chosen that the equivalent
isotropically radiated power (e.i.r.p.) is not more than that necessary for successful
communication.
This radio transmitter (identify the device by certification number, or model
number if Category II) has been approved by Industry Canada to operate with
the antenna types listed below with the maximum permissible gain and required
antenna impedance for each antenna type indicated. Antenna types not included
in this list, having a gain greater than the maximum gain indicated for that type,
are strictly prohibited for use with this device.
For product available in the USA/Canada market, only channels 1-11 can be
operated. Selection of other channels is not possible.
If this device is to be operated in the 5.15~5.25 GHz frequency range, it is restricted
to indoor environments only.
Antenna: Laird Technologies, Mini-NanoBlade
Antenna gain information: Embedded Antenna: 2.5dBi (2.4 GHz), 4.8dBi (5 GHz)
Frequency Tolerance: +/-20ppm
Wireless Labeling
The i-STAT Alinity v Analyzer includes the FCC mark and FCC module identifier.
Table for Wireless Specification for the i-STAT Alinity v Analyzer
i-STAT Alinity v AnalyzerWireless Characteristic
Network Standard
Maximum RF Power
Typical Maximum SAR
Wireless QoS Requirements
Radio Band Center Frequencies
Modulation Types
IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
(1-stream)
200mW
765 mW/kg at 0cm
None. Best-eort delivery service is sucient.
802.11 b/g/n 2.412 – 2.472 GHz
802.11 a/n 5.180 – 5.825 GHz
OFDM (64QAM, 16QAM, QPSK, BPSK)
DSSS (CCK, DQPSK, DBPSK)
DSSS-OFDM (64QAM, 16QAM, QPSK, BPSK)

i-STAT Alinity v — User Manual 650-7100 Rev. A9
Symbols
Table 1: Analyzer/Power related
Symbol Denition/Use
Keep away from sunlight.
Model number. The model number will appear adjacent to
this symbol.
Printer
Humidity limitation
On/O
Direct current power supply
Alternating current power supply
Table 2: Regulatory and Safety Related; Miscellaneous
Symbol Denition/Use
Biological risks
Temperature limitations. The upper and lower limits for
storage are adjacent to upper and lower arms.
Serial number. The serial number will appear adjacent to
this symbol.
Catalog number, list number, or reference
USB
Do not reuse.

i-STAT Alinity v — User Manual 650-7100 Rev. A10
Symbol Denition/Use
Date of manufacture
Manufacturer
Consult instructions for use or see System Manual for
instructions.
Note the following information.
Denotes conformity to specified European directives.
ETL product safety listing mark for U.S. and Canada
Electrical hazard
ATTENTION: See instructions for use.
CAUTION: Indicates a hazardous situation, which if not
avoided, could result in minor or moderate injury or
damage to the equipment.
WARNING: Indicates a hazardous situation, which if not
avoided, could result in serious injury or death.
Separate waste collection for this electrical/electronic item
indicated; Equipment manufactured / put on the market
after 13 August 2005; Indicates compliance with Article
10(3) of Directive 2002/96/EC (WEEE) for the European
Union (EU).
Symbols (Continued)

i-STAT Alinity v — User Manual 650-7100 Rev. A11
1
3
5
2
4
6
1
2
3
4
5
6
i-STAT Alinity v Analyzer: Used to perform cartridge testing, reviewing test
results, and conducting quality control (QC) testing.
i-STAT Alinity Rechargeable Battery: Provides main power source to the
analyzer.
i-STAT Alinity Base Station: Used to recharge the battery installed in the
i-STAT Alinity v Analyzer.
i-STAT Alinity Test Cartridges: Contains sensors and reagents for all patient
and quality testing.
i-STAT Alinity Portable Printer: Used to print records stored in the analyzer.
i-STAT Alinity Electronic Simulator: Provides an independent check on the
analyzer’s thermal controls and success of software updates.
System Components (Continued)

i-STAT Alinity v — User Manual 650-7100 Rev. A12
Intended Use
The i-STAT Alinity v Analyzer is an analytical, point of care device designed for
veterinary use only.
The i-STAT Alinity v Analyzer with i-STAT test cartridges is intended for use in
point of care or clinical laboratory settings. The i-STAT Alinity system is intended
for the quantitative measurement of various analytes in arterial, venous and
capillary whole blood.
Principles of Operation
The design enables it to be taken to a convenient location near the point of care.
The analyzer requires i-STAT single-use cartridges containing sensors to perform
quantitative diagnostic testing on whole blood. After the insertion of a filled test
cartridge, the analyzer carefully monitors and controls the testing process. The
only user intervention is in the form of data entry. Data entry is performed via the
touchscreen or by barcode capture. Throughout the cycle, the analyzer performs
a series of quality checks. These checks are designed to monitor the status of the
analyzer and the quality of the cartridge. The analyzer and cartridge together
allow the user to perform clinical testing and administrative tasks related to the
quantification of various analytes in a whole blood sample.
The i-STAT Alinity v Analyzer includes the following subsystems:
• analytical measurement module: interfaces with the i-STAT single-use test
cartridges and controls execution of the measurement test cycle
• user module: a central computing unit with embedded firmware that controls
the user interaction with the device and supports communication with
outside peripherals
• user interface: allows data input, display of information, audio and visual
alerts
• rechargeable battery
Precautions and Limitations
For best results, observe the following precautions to prevent damage to the
i-STAT Alinity v Analyzer and its peripherals, to ensure the safety of the operator
and the integrity of the results.
DO:
• Only use Abaxis supplied accessories, power supplies, power cables, and
consumables specified for the i-STAT Alinity system (includes analyzer, printer
and base station).
• Always use the Base Station for charging the i-STAT Alinity v
Analyzer.
• Connect only the i-STAT Alinity printer to the Base Station
printer port.
• Always place the Analyzer, Base Station, and Printer on a level and stable
surface or in a location where they will not cause injury if dropped.
• Falling equipment may cause injury.
System Components (Continued)

System Components (Continued)
i-STAT Alinity v — User Manual 650-7100 Rev. A13
• Be sure to install all cables and power supplies so they do not pose a trip
hazard. Mount equipment so cables and accessories stay clear of walkways.
• Allow the analyzer temperature to stabilize to operating temperature and
humidity specifications prior to use.
• Check temperature strip for each new shipment of cartridges.
• Verify that the temperature in transit was maintained by reading the
temperature strip included in each shipping container.
• Keep the test cartridge and the analyzer at the temperature of the room
where they are to be used.
• Condensation on a cold cartridge can prevent proper contact with the
analyzer.
• If a printout appears inconsistent with a patient’s clinical assessment, verify that
the correct patient record was selected (patient ID, date and time of test, etc.). If
the record is not correct, select the correct record and print. If the printout still
does not match the data in the analyzer, the printer needs service and the
printed results must not be used. If another printer is available, retry.
• Clinical settings that demand fail-safe testing should have a backup analyzer
or test source available.
• Follow site specific guidelines for integration of wireless devices into the
facility/facility environment.
• Check with authorities for local, state, and/or national requirements for disposal.
DO NOT:
• Attempt to remove a test cartridge during the testing cycle. The force that
would be necessary to do so could damage the analyzer.
• Place metal objects on or near the exposed charging contacts on all peripherals.
• Store batteries in such a manner that they may short circuit each other,
or allow metal objects to touch the battery contacts.
• Expose the battery to heat or fire. Avoid storage in direct sunlight.
• Try to connect any non-electrically isolated equipment to the i-STAT Alinity Base
Station.
• Connect the i-STAT Alinity Base Station to unauthorized medical devices or
other equipment.
• Disturb the analyzer or the printer until printing is complete, since this will
interrupt the printout. If printing is interrupted, realign the analyzer and the
printer, or replace the analyzer in the Base Station to resume printing.

System Components (Continued)
i-STAT Alinity v — User Manual 650-7100 Rev. A14
• Use the analyzer in environmental conditions that exceed the operating
temperature and humidity specifications.
• Make any unauthorized repairs or modifications to this product as this may
cause personal injury or damage to the unit.
NOTE
• The analyzer and its peripherals are not listed by any authority with respect to
suitability for use in oxygen-enriched atmospheres.
• In the event of a battery leaking, do not allow any leakage to come into contact
with the skin or eyes. If contact has been made, wash the aected area with
copious amounts of water and seek medical advice.
• The analyzer can become contaminated with blood during use. Operators
should use standard precautions whenever handling the analyzer, cartridge,
and peripherals to protect themselves from blood-borne pathogens and
pathogens from other body substances. Standard precautions, such as
the wearing of gloves, are designed to protect personnel from blood-borne
pathogens and pathogens from other body substances.

Preparing for Use
For setup instructions on using the i-STAT Alinity v Analyzer and Rechargeable
Battery, Base Station, Printer, and External Simulator, please refer to the Getting
Started Guides enclosed with each item. Contact Abaxis Technical Support if
additional support is needed.
System Specications — i-STAT Alinity v Analyzer
i-STAT Alinity Rechargeable Battery*
Electrical rating:
Operational range-
Temperature and
humidity:
Storage range-
Temperature and
humidity:
Altitude:
3.65 VDC 19.3 Wh (nominal)
10 to 40ºC (50 to 104ºF)
10 to 90% non-condensing relative humidity, with maxi-
mum saturation temperature of 34ºC (93.2ºF)
-10 to 60ºC (14 to 140ºF)
10 to 90% non-condensing, with maximum saturation
temperature of 50ºC (122ºF)
Up to 3,048 meters (10,000 feet)
System Components (Continued)
i-STAT Alinity v — User Manual 650-7100 Rev. A15
*This Lithium-Ion rechargeable battery is designed for use only with the i-STAT Alinity v
Analyzer. Keep a spare, charged battery on hand at all times and store charged battery
in the original packaging.
Operational range -
Temperature and
humidity:
Testing Environment:
Altitude:
Storage range -
Temperature and
humidity:
Power source:
16 to 30ºC (61 to 86ºF) for clinical testing
10 to 40ºC (50 to 104ºF) other than clinical testing
10 to 90% non-condensing relative humidity, with
maximum saturation temperature of 34ºC (93.2ºF)
Indoors, on a dry, clean, horizontal, stable surface.
Avoid nearby vibration equipment such as centrifuges.
Avoid direct sunlight.
Up to 3,048 meters (10,000 feet)
-10 to 60ºC (14 to 140ºF)
10 to 90% non-condensing, with maximum saturation
temperature of 50ºC (122ºF)
Lithium Ion Rechargeable Battery, 3.65 (nominal) VDC,
19.3 Wh

i-STAT Alinity Base Station*
Communication
Interface:
Operational range-
Temperature and
humidity:
Testing Environment:
Altitude:
Storage range-
Temperature and
humidity:
External Power
Supply Unit:
Ethernet 10/100 base t, RS-232, USB 2.0
LED Indicators:
Color: Blue
Status: Power
10 to 40ºC (50 to 104ºF)
10 to 90% non-condensing, with maximum saturation
temperature of 34ºC (93.2F)
Indoors, on a dry, clean, horizontal, stable surface.
Avoid nearby vibration equipment such as centrifuges.
Avoid direct sunlight.
Up to 3,048 meters (10,000 feet)
-10 to 60ºC (14 to 140ºF)
10 to 90% non-condensing, with maximum saturation
temperature of 34ºC (93.2F)
Input: 110-240 VAC, 50-60 Hz, 1.5A
Output: 5.3V DC, 6.6A
*The Base Station is intended for use only with the i-STAT Alinity v Analyzer. Use only
the power supply shipped in the box with the Base Station. Attempting to use a differ-
ent type of manufacturer’s adapter could damage the unit and cause re or explosion
hazards.
System Components (Continued)
i-STAT Alinity v — User Manual 650-7100 Rev. A16

i-STAT Alinity Printer*
Power ratings
(AC adapter):
Power ratings
(battery pack):
Operational range-
Temperature and
humidity:
Storage range-
Temperature and
humidity:
Communication link:
Paper:
Input: 100-240 VAC, 50/60Hz, 1.1 A
Output: 12 VDC, 3.0 A
4.8 V
15 to 40ºC (59 to 104ºF)
20 to 90% Non-condensing relative humidity
-20 to 50ºC (-4 to 122ºF)
10 to 90% Non-condensing
Infrared or Serial/RJ12
Black print thermal paper
5.7 cm wide (Available from Abaxis)
*Attempting to print from an i-STAT Alinity v Analyzer to any printer other than an i-STAT
Alinity printer may be unsuccessful. Use only a rechargeable battery pack purchased from
Abaxis designed for the i-STAT Alinity printer.
System Components (Continued)
i-STAT Alinity Electronic Simulator*
Operational range-
Temperature and
humidity:
Storage range-
Temperature and
humidity:
Altitude :
16 to 30ºC (61 to 86ºF)
10 to 90% non-condensing, with maximum
saturation temperature of 34ºC (93.2ºF)
-10 to 60ºC (14 to 140ºF)
10 to 90% non-condensing, with maximum saturation
temperature of 34ºC (93.2ºF)
Up to 3,048 meters (10,000 feet)
*Electronic Simulator is designed for use only with the i-STAT Alinity v Analyzer.
i-STAT Alinity v — User Manual 650-7100 Rev. A17

i-STAT Alinity v — User Manual 650-7100 Rev. A18
Rechargeable battery is the sole
power source for the analyzer.
Component Anatomy
Display Screen
LED: Indicates
status of the
analyzer.
Green: Analyzer
is starting up or
test results are
complete.
White: Cartridge
is processing.
Red: Requires
immediate
attention.
Blue: Battery is
charging.
Power Button:
Press and hold
button for 2
seconds to power
up or power down
the analyzer.
Barcode Capture
Button:
Press and hold
button in order
to capture a
barcode. Audible
cues indicate
successful and
unsuccessful
barcode captures.
Cartridge Port:
Cartridge or Electronic Simulator is inserted
into the cartridge port to initiate testing.
Camera and IR Port: Camera is activated
by pressing and holding the barcode
capture button. The display screen
displays the object within the cameras
view. The IR port sends information from
the analyzer to the portable printer.
