ABB i-bus VC/S 4 1 Series User manual

—
PRODUCT MANUAL
ABB i-bus® KNX
VC/S 4.x.1
Valve drive controller

Table of contents
1 About this document........................................................................................................................................................... 7
1.1 Using the product manual ............................................................................................................................................................. 7
1.2 Legal disclaimer ............................................................................................................................................................................... 7
1.3 Explanation of symbols.................................................................................................................................................................. 7
2 Safety .................................................................................................................................................................................... 9
2.1 General safety instructions ........................................................................................................................................................... 9
2.2 Qualification of the specialist personnel.................................................................................................................................... 9
2.3 Proper use ......................................................................................................................................................................................... 9
3 Product overview................................................................................................................................................................. 10
3.1 Device description........................................................................................................................................................................... 10
3.1.1 Membrane keypad ........................................................................................................................................................ 10
3.2 Product name description ............................................................................................................................................................. 10
3.3 Ordering details............................................................................................................................................................................... 10
3.4 Connections...................................................................................................................................................................................... 10
3.4.1 Inputs .............................................................................................................................................................................. 11
3.4.2 Outputs........................................................................................................................................................................... 11
3.5 Valve Drive ControllerVC/S4.1.1,MDRC..................................................................................................................................... 12
3.5.1 Dimension drawing ...................................................................................................................................................... 13
3.5.2 Connection diagram..................................................................................................................................................... 14
3.5.3 Operating and display elements................................................................................................................................ 15
3.5.4 Technical data................................................................................................................................................................ 16
3.6 Valve Drive ControllerVC/S4.2.1,MDRC..................................................................................................................................... 18
3.6.1 Dimension drawing ...................................................................................................................................................... 19
3.6.2 Connection diagram..................................................................................................................................................... 20
3.6.3 Operating and display elements................................................................................................................................ 21
3.6.4 Technical data................................................................................................................................................................ 23
4 Function ................................................................................................................................................................................ 25
4.1 Device functions .............................................................................................................................................................................. 25
4.2 Software functions.......................................................................................................................................................................... 25
4.2.1 Functional overview...................................................................................................................................................... 25
4.2.2 Safety mode ................................................................................................................................................................... 25
4.3 Integration into i-bus® Tool........................................................................................................................................................... 27
4.4 Special operating states ................................................................................................................................................................ 27
4.4.1 Reaction on bus voltage failure (BSA)....................................................................................................................... 27
4.4.2 Reaction after bus voltage recovery (BSW) ............................................................................................................. 27
4.4.3 Reaction on ETS reset .................................................................................................................................................. 27
4.4.4 Reaction on download (DL)......................................................................................................................................... 27
5 Mounting and installation .................................................................................................................................................. 29
5.1 Information about mounting ........................................................................................................................................................ 29
5.2 Mounting on mounting rail............................................................................................................................................................ 29
5.3 Connecting analog room control unit ......................................................................................................................................... 30
6 Commissioning .................................................................................................................................................................... 31
6.1 Prerequisites for commissioning................................................................................................................................................. 31
6.2 Commissioning overview............................................................................................................................................................... 31
6.3 Putting device into operation ....................................................................................................................................................... 31
6.4 Assignment of the physical address ........................................................................................................................................... 31
6.5 Software/application ..................................................................................................................................................................... 32
6.5.1 Download reaction ....................................................................................................................................................... 32
6.5.2 Copying, exchanging and converting ....................................................................................................................... 32
ABB i-bus® KNX TABLE OF CONTENTS
Product manual | EN-US | VC/S 4.x.1 | 2CDC508220D0211 Rev. B 2

7 Parameters ........................................................................................................................................................................... 33
7.1 General............................................................................................................................................................................................... 33
7.2 Parameter window .......................................................................................................................................................................... 34
7.2.1 Basic settings ................................................................................................................................................................ 34
7.2.2 Manual operation .......................................................................................................................................................... 35
7.2.3 Channel X ........................................................................................................................................................................ 36
7.3 Overview of parameters................................................................................................................................................................. 51
7.4 Parameter descriptions.................................................................................................................................................................. 54
7.4.1 Economy heating reduction........................................................................................................................................ 54
7.4.2 Standby heating reduction ......................................................................................................................................... 54
7.4.3 Send current setpoint .................................................................................................................................................. 55
7.4.4 Connect analog room control unit to physical device input a ............................................................................. 55
7.4.5 Economy cooling increase .......................................................................................................................................... 57
7.4.6 Standby cooling increase ............................................................................................................................................ 57
7.4.7 Activate basic-stage heating via................................................................................................................................ 57
7.4.8 Activate basic-stage cooling via ................................................................................................................................ 58
7.4.9 Activate additional-stage heating via....................................................................................................................... 59
7.4.10 Activate additional-stage cooling via ....................................................................................................................... 60
7.4.11 Number of group objects Actual temperature ....................................................................................................... 61
7.4.12 Limit number of telegrams ......................................................................................................................................... 61
7.4.13 Type of control value Basic-stage heating .............................................................................................................. 62
7.4.14 Type of control value Basic-stage cooling ............................................................................................................... 63
7.4.15 Type of control value Additional-stage heating ..................................................................................................... 64
7.4.16 Type of control value Additional-stage cooling...................................................................................................... 65
7.4.17 Type of heating/cooling system................................................................................................................................ 66
7.4.18 Ending temperature for summer compensation ................................................................................................... 66
7.4.19 Time for automatic reset to KNX operation............................................................................................................ 67
7.4.20 Automatic reset from manual operation to KNX operation ................................................................................ 67
7.4.21 Base setpoint is............................................................................................................................................................. 68
7.4.22 [Heating] limit temperature........................................................................................................................................ 69
7.4.23 Limit temperature [cooling] ....................................................................................................................................... 70
7.4.24 On group object value.................................................................................................................................................. 70
7.4.25 When opening the contact.......................................................................................................................................... 71
7.4.26 When closing the contact............................................................................................................................................ 71
7.4.27 Heating/cooling mode when monitoring time exceeded .................................................................................... 71
7.4.28 Operating mode after bus voltage recovery ........................................................................................................... 72
7.4.29 Operating mode after ETS download/reset ........................................................................................................... 72
7.4.30 Operating modes.......................................................................................................................................................... 72
7.4.31 Operating mode after exceeding monitoring time ............................................................................................... 73
7.4.32 Operating mode after bus voltage recovery or ETS download ........................................................................... 73
7.4.33 Data point type, manual setpoint adjustment ....................................................................................................... 74
7.4.34 Input................................................................................................................................................................................. 75
7.4.35 Scan input after download, ETS reset or bus voltage recovery........................................................................... 77
7.4.36 Input on operation........................................................................................................................................................ 77
7.4.37 Starting temperature for summer compensation ................................................................................................. 77
7.4.38 Input for temperature limit sensor ........................................................................................................................... 78
7.4.39 Window status receipt................................................................................................................................................. 79
7.4.40 Fill level status receipt ................................................................................................................................................. 79
7.4.41 Actual temperature receipt......................................................................................................................................... 80
7.4.42 Dew point status receipt............................................................................................................................................. 80
7.4.43 Extended settings......................................................................................................................................................... 81
7.4.44 Window open if [input x] ............................................................................................................................................. 81
7.4.45 Window open if [controller] ........................................................................................................................................ 82
7.4.46 Filter................................................................................................................................................................................. 82
7.4.47 Fill level reached if [input x]......................................................................................................................................... 82
7.4.48 Fill level reached if [controller] ................................................................................................................................... 83
7.4.49 Weighting of external measurement1 ..................................................................................................................... 83
7.4.50 Weighting of external measurement2 ..................................................................................................................... 84
ABB i-bus® KNX TABLE OF CONTENTS
Product manual | EN-US | VC/S 4.x.1 | 2CDC508220D0211 Rev. B 3

7.4.51 Weighting of internal measurement......................................................................................................................... 84
7.4.52 Basic load active when controller off........................................................................................................................ 84
7.4.53 Basic-stage heating [actuator] .................................................................................................................................. 85
7.4.54 Basic-stage heating [controller] ................................................................................................................................ 85
7.4.55 Basic-stage cooling [actuator] ................................................................................................................................... 86
7.4.56 Basic-stage cooling [controller]................................................................................................................................. 86
7.4.57 Hysteresis....................................................................................................................................................................... 86
7.4.58 Limit temperature hysteresis..................................................................................................................................... 88
7.4.59 Hysteresis for Heating/cooling changeover........................................................................................................... 89
7.4.60 I-proportion.................................................................................................................................................................... 90
7.4.61 I-proportion at temperature limitation.................................................................................................................... 91
7.4.62 In period (0 = deactivated).......................................................................................................................................... 92
7.4.63 Channel function ........................................................................................................................................................... 93
7.4.64 Enable group object "Block input"............................................................................................................................. 93
7.4.65 Enable group object "In operation"........................................................................................................................... 94
7.4.66 KTY type.......................................................................................................................................................................... 94
7.4.67 Long operation after .................................................................................................................................................... 94
7.4.68 Cable length, single distance...................................................................................................................................... 95
7.4.69 Cable error compensation .......................................................................................................................................... 95
7.4.70 Cable resistance (total of fwd and rtn conductor) ................................................................................................ 95
7.4.71 Manual operation .......................................................................................................................................................... 96
7.4.72 Enable manual valve override ..................................................................................................................................... 96
7.4.73 Max. manual reduction in heating mode via KNX................................................................................................... 97
7.4.74 Max. manual reduction in cooling mode via KNX ................................................................................................... 97
7.4.75 Max. manual increase in heating mode via KNX ..................................................................................................... 98
7.4.76 Max. manual increase in cooling mode via KNX...................................................................................................... 98
7.4.77 Maximum number of telegrams................................................................................................................................. 98
7.4.78 Maximum setpoint increase ....................................................................................................................................... 99
7.4.79 Maximum setpoint reduction..................................................................................................................................... 99
7.4.80 Maximum control value................................................................................................................................................ 100
7.4.81 Activate minimum signal duration............................................................................................................................ 101
7.4.82 Min. control value (basic load).................................................................................................................................... 102
7.4.83 Minimum control value for basic load > 0................................................................................................................ 103
7.4.84 NTC type ......................................................................................................................................................................... 103
7.4.85 Open if control value greater than or equal to........................................................................................................ 104
7.4.86 Valve drive opening/closing time.............................................................................................................................. 104
7.4.87 Setpoint temperature offset when summer compensation ends...................................................................... 104
7.4.88 Setpoint temperature offset when summer compensation starts.................................................................... 105
7.4.89 P-proportion .................................................................................................................................................................. 106
7.4.90 PWM cycle X.................................................................................................................................................................... 107
7.4.91 Cross-section of conductor, value* 0.01mm²......................................................................................................... 110
7.4.92 Reaction on event x ...................................................................................................................................................... 110
7.4.93 Sending and switching delay after bus voltage recovery ..................................................................................... 111
7.4.94 Sending cycle ................................................................................................................................................................. 111
7.4.95 Setpoint for frost protection (building protection, heating) .............................................................................. 111
7.4.96 Economy heating setpoint.......................................................................................................................................... 112
7.4.97 Comfort heating setpoint ........................................................................................................................................... 112
7.4.98 Standby heating setpoint ........................................................................................................................................... 113
7.4.99 Comfort heating and cooling setpoint..................................................................................................................... 113
7.4.100 Heat protection setpoint (building protection, cooling)...................................................................................... 114
7.4.101 Economy cooling setpoint .......................................................................................................................................... 114
7.4.102 Comfort cooling setpoint............................................................................................................................................ 115
7.4.103 Standby cooling setpoint............................................................................................................................................ 115
7.4.104 Comfort heating setpoint=Comfort cooling setpoint ........................................................................................ 116
7.4.105 Setpoint indication on slave display ......................................................................................................................... 116
7.4.106 Setpoint specification and adjustment ................................................................................................................... 117
7.4.107 Activate summer compensation................................................................................................................................ 118
7.4.108 Purge cycle in weeks..................................................................................................................................................... 118
ABB i-bus® KNX TABLE OF CONTENTS
Product manual | EN-US | VC/S 4.x.1 | 2CDC508220D0211 Rev. B 4

7.4.109 Reset purge cycle from control value greater than or equal to........................................................................... 119
7.4.110 Send status values [analog room control unit]....................................................................................................... 119
7.4.111 Send status values [binary input] .............................................................................................................................. 119
7.4.112 Send status values [window contact]....................................................................................................................... 120
7.4.113 Send status values [fill level alarm] ........................................................................................................................... 120
7.4.114 Send status values [dew point alarm]....................................................................................................................... 121
7.4.115 Send status values [valve output].............................................................................................................................. 121
7.4.116 Control value.................................................................................................................................................................. 122
7.4.117 Control value on input fault ........................................................................................................................................ 122
7.4.118 Control value after exceeding monitoring time ..................................................................................................... 122
7.4.119 Control value on forced operation ............................................................................................................................ 123
7.4.120 Control value on forced operation active "OFF"..................................................................................................... 123
7.4.121 Control value on forced operation active "ON"....................................................................................................... 123
7.4.122 Control value after bus voltage recovery ................................................................................................................. 124
7.4.123 Control value after ETS download............................................................................................................................. 124
7.4.124 Control value difference for sending the control value......................................................................................... 125
7.4.125 Dew point reached if [input x] .................................................................................................................................... 126
7.4.126 Dew point reached if [controller]............................................................................................................................... 126
7.4.127 Temperature change for sending current room temperature............................................................................. 126
7.4.128 Activate temperature limitation ................................................................................................................................ 127
7.4.129 Temperature difference from basic-stage heating ............................................................................................... 127
7.4.130 Temperature difference from basic-stage cooling................................................................................................ 128
7.4.131 Temperature offset ...................................................................................................................................................... 129
7.4.132 Temperature sensor type............................................................................................................................................ 129
7.4.133 Send temperature value .............................................................................................................................................. 130
7.4.134 Monitor receipt of group object "Operating mode normal (master)" ............................................................... 131
7.4.135 Monitor receipt of group object "Window contact" .............................................................................................. 131
7.4.136 Monitor receipt of group object "Fill level alarm"................................................................................................... 132
7.4.137 Monitor receipt of group object "Dew point alarm" .............................................................................................. 132
7.4.138 Monitor receipt of group object "Heating/cooling changeover"........................................................................ 133
7.4.139 Monitor receipt of "Control value heating/cooling" group objects ................................................................... 133
7.4.140 Temperature input monitoring .................................................................................................................................. 134
7.4.141 Heating/cooling changeover...................................................................................................................................... 135
7.4.142 Distinction between long and short operation ...................................................................................................... 135
7.4.143 Valve output ................................................................................................................................................................... 137
7.4.144 Valve purge..................................................................................................................................................................... 138
7.4.145 Send value group object "In operation".................................................................................................................... 138
7.4.146 Send value of group object "Status valve purge" ................................................................................................... 138
7.4.147 Value after sending and switching delay has expired ........................................................................................... 139
7.4.148 Value is sent from a change of ................................................................................................................................... 139
7.4.149 Resistance in ohms at x°C .......................................................................................................................................... 140
7.4.150 Control value direction ................................................................................................................................................ 141
7.4.151 Valve drive operating principle, de-energized ........................................................................................................ 142
7.4.152 I-bus®Tool access......................................................................................................................................................... 142
7.4.153 Reset manual setpoint adjustment when base setpoint received ..................................................................... 142
7.4.154 Reset manual setpoint adjustment when operating mode changes................................................................. 143
7.4.155 Reset manual setpoint adjustment via group object............................................................................................ 144
7.4.156 Additional-stage heating ............................................................................................................................................ 144
7.4.157 Additional-stage cooling ............................................................................................................................................. 145
7.4.158 Forced operation .......................................................................................................................................................... 145
7.4.159 Send cyclically every ..................................................................................................................................................... 146
7.4.160 Cyclical monitoring....................................................................................................................................................... 146
7.4.161 Time interval for cyclical monitoring ........................................................................................................................ 146
7.4.162 Send inactive control values cyclically ...................................................................................................................... 147
7.4.163 Cycle for sending the room temperature (0 = deactivated) ................................................................................ 147
7.4.164 Cycle for sending the control value (0 = deactivated)........................................................................................... 148
7.4.165 Cycle for sending the setpoint................................................................................................................................... 149
7.4.166 PWM cycle time.............................................................................................................................................................. 149
ABB i-bus® KNX TABLE OF CONTENTS
Product manual | EN-US | VC/S 4.x.1 | 2CDC508220D0211 Rev. B 5

8 Group objects....................................................................................................................................................................... 150
8.1 Overview of group objects ............................................................................................................................................................ 150
8.2 Group objects, general ................................................................................................................................................................... 151
8.3 Group objects, Channel x - General.............................................................................................................................................. 152
8.4 Group objects, Channel X - Valve X .............................................................................................................................................. 154
8.5 Group objects, Channel X - Input x............................................................................................................................................... 155
8.6 Group objects Channel X – Controller ......................................................................................................................................... 157
8.7 Group objects Channel X – Actuator............................................................................................................................................ 169
9 Operation.............................................................................................................................................................................. 170
9.1 Manual operation............................................................................................................................................................................. 170
9.1.1 Activating manual operation ...................................................................................................................................... 170
9.1.2 Blocking manual operation ......................................................................................................................................... 170
9.1.3 Ending manual operation............................................................................................................................................ 170
10 Maintenance and cleaning .................................................................................................................................................. 171
10.1 Maintenance ..................................................................................................................................................................................... 171
10.2 Cleaning............................................................................................................................................................................................. 171
11 Removal and disposal.......................................................................................................................................................... 172
11.1 Removal ............................................................................................................................................................................................. 172
11.2 Environment ..................................................................................................................................................................................... 172
12 Planning and application .................................................................................................................................................... 173
12.1 Priorities ............................................................................................................................................................................................ 173
12.1.1 Priorities for controller mode..................................................................................................................................... 173
12.1.2 Priorities for actuator mode....................................................................................................................................... 173
12.2 Basic knowledge .............................................................................................................................................................................. 173
12.2.1 2-pipe and 4-pipe systems.......................................................................................................................................... 173
12.2.2 Basic setpoint................................................................................................................................................................ 174
12.2.3 Explanation of the operating modes ........................................................................................................................ 174
12.2.4 Weighting of the temperature inputs....................................................................................................................... 177
12.2.5 Floating mean value ..................................................................................................................................................... 178
12.2.6 Basics of PI control ....................................................................................................................................................... 178
12.2.7 Basic load........................................................................................................................................................................ 178
12.2.8 Heating/cooling circuit ............................................................................................................................................... 179
12.2.9 Hysteresis....................................................................................................................................................................... 180
12.2.10 Manual valve override................................................................................................................................................... 180
12.2.11 Master/slave operation ............................................................................................................................................... 180
12.2.12 Refreshed KNX state .................................................................................................................................................... 180
12.2.13 Control types ................................................................................................................................................................. 181
12.2.14 Sending and switching delay...................................................................................................................................... 185
12.2.15 Temperature sensor types.......................................................................................................................................... 185
12.2.16 Summer compensation ............................................................................................................................................... 187
12.2.17 Valve drives..................................................................................................................................................................... 188
12.2.18 Telegram rate limit ....................................................................................................................................................... 189
12.2.19 Valve purge..................................................................................................................................................................... 190
12.2.20 Use of 6-way valve ........................................................................................................................................................ 190
12.2.21 Use of an analog room control unit........................................................................................................................... 191
12.2.22 Forced operation .......................................................................................................................................................... 192
12.2.23 Cyclical monitoring....................................................................................................................................................... 193
13 Appendix ............................................................................................................................................................................... 194
13.1 Scope of delivery.............................................................................................................................................................................. 194
13.2 Status byte channel......................................................................................................................................................................... 195
13.3 Status byte Valve ............................................................................................................................................................................. 197
ABB i-bus® KNX TABLE OF CONTENTS
Product manual | EN-US | VC/S 4.x.1 | 2CDC508220D0211 Rev. B 6

ABB i-bus® KNX ABOUT THIS DOCUMENT
1 About this document
1.1 Using the product manual
This manual provides detailed technical information on the function, installation and programming of
the ABB i-bus® KNX device.
1.2 Legal disclaimer
ABB AG reserves the right to make changes to the product or modify the contents of this document
without prior notice.
The agreed properties are definitive for any orders placed. ABB AG does not accept any responsibility
whatsoever for potential errors or possible lack of information in this document.
ABB AG reserves all rights in this document and in the subject matter and illustrations contained therein.
Reproduction, transfer to third parties or processing of the content – including sections thereof – is not
permitted without the prior written consent of ABB AG.
Copyright © 2021 ABB AG
All rights reserved
1.3 Explanation of symbols
1.
2.
ð
Instructions in specified sequence and result
▶Individual actions
a) Priorities
1) Processes run by the device in a specific sequence
• List level 1
– List level 2
Tab.1: Explanation of symbols
Product manual | EN-US | VC/S 4.x.1 | 2CDC508220D0211 Rev. B 7
Note about navigation in the PDF: Key combination 'Alt + left arrow'
jumps to the previous view/page

ABB i-bus® KNX ABOUT THIS DOCUMENT
Notes and warnings are represented as follows in this manual:
DANGER
This symbol is a warning about electrical voltage and indicates high-risk hazards that will definitely
result in death or serious injury unless avoided.
DANGER
Indicates high-risk hazards that will definitely result in death or serious injury unless avoided.
WARNING
Indicates medium-risk hazards that could result in death or serious injury unless avoided.
CAUTION
Indicates low-risk hazards that could result in slight or moderate injury unless avoided.
CAUTION
Indicates a risk of malfunctions or damage to property and equipment, but with no risk to life and
limb.
Example
For use in application, installation and programming examples
Note
For use in tips on usage and operation
Product manual | EN-US | VC/S 4.x.1 | 2CDC508220D0211 Rev. B 8
Note about navigation in the PDF: Key combination 'Alt + left arrow'
jumps to the previous view/page

ABB i-bus® KNX SAFETY
2 Safety
2.1 General safety instructions
▶ Protect the device from moisture, dirt and damage during transport, storage and operation.
▶ Operate the device only in a closed housing (distribution board).
▶ Operate the device only within the specified technical data.
▶ Mounting, installation, commissioning and maintenance must be carried out only by qualified
electricians.
▶ Disconnect device from the supply of electrical power before mounting.
2.2 Qualification of the specialist personnel
Programming the device requires detailed specialist knowledge – particularly about the ETS commis-
sioning software – through KNX training courses.
2.3 Proper use
The Valve Drive Controllers VC/S are intended to be used to activate floor heaters, radiators or cooling
ceilings in a KNX environment.
Product manual | EN-US | VC/S 4.x.1 | 2CDC508220D0211 Rev. B 9
Note about navigation in the PDF: Key combination 'Alt + left arrow'
jumps to the previous view/page

ABB i-bus® KNX PRODUCT OVERVIEW
3 Product overview
3.1 Device description
The devices are modular installation devices (MDRC) in the pro M design. They are designed for installa-
tion in electrical distribution boards and small housings with a 35mm mounting rail (to EN60715).
The devices are KNX-certified and can be used as products in a KNX system → EU declaration of con-
formity.
The devices are powered via the bus (ABB i-bus® KNX) and require no additional auxiliary voltage supply.
The connection to the bus is made via a bus connection terminal on the front of the housing. The loads
are connected to the outputs using screw terminals → terminal designation on the housing.
The software application Engineering Tool Software (ETS) is used for physical address assignment and
parameterization.
3.1.1 Membrane keypad
Depending on the product variant, the devices can be operated manually using the membrane keypad.
Complete overview of operating and display elements → corresponding sub-chapter of the individual
product variant.
3.2 Product name description
Abbreviation Designation
V Valve drive
C Controller
/S MDRC
X. 4 = 4-fold
X. 1 = without manual operation
2 = with manual operation
X x = Version number (x = 1, 2, etc.)
Tab.2: Product name description
3.3 Ordering details
Description MW Type Order no. Packaging
[pcs.]
Weight (incl.
packaging)
[kg]
Valve Drive Controller 8VC/S 4.1.1 2CDG110216R0011 10.28
Valve Drive Controller 8VC/S 4.2.1 2CDG110217R0011 10.29
Tab.3: Ordering details
3.4 Connections
The devices possess the following connections:
• 12 inputs for sensors or analog room control units (SAF/A or SAR/A)
• 4 valve outputs for activating thermoelectric or magnetic valve drives.
• 1 bus connection
The tables below provide an overview of the maximum number of devices that can be connected to the
individual product variants.
Product manual | EN-US | VC/S 4.x.1 | 2CDC508220D0211 Rev. B 10
Note about navigation in the PDF: Key combination 'Alt + left arrow'
jumps to the previous view/page

ABB i-bus® KNX PRODUCT OVERVIEW
Valve outputs
VC/S 4.1.1 VC/S 4.2.1
Thermoelectric Valve Drives (PWM) 4 4
Magnetic valve drives (open/closed) 4 4
Tab.4: Valve outputs
Physical inputs
VC/S 4.1.1 VC/S 4.2.1
Analog room control units 4 4
Binary sensors (floating) 12 12
Temperature sensors 8 8
Tab.5: Physical inputs
3.4.1 Inputs
Function a b c d e f g h i j k l
Temperature sensor
PT100 x x x x x x x x
PT1000 x x x x x x x x
KT/KTY x x x x x x x x
KT/KTY user-defined x x x x x x x x
NTC10k x x x x x x x x
NTC20k x x x x x x x x
NI‑1000 x x x x x x x x
Analog room control unit x x x x
Binary sensor (floating) x x x x x x x x x x x x
Dew point sensor (floating) x x x x x x x x x x x x
Fill level sensor (floating) x x x x x x x x x x x x
Window contact (floating) x x x x x x x x x x x x
Tab.6: Function of the inputs
3.4.2 Outputs
3.4.2.1 Valve outputs
Function A B C D
Thermoelectric Valve Drives (PWM) x x x x
Magnetic valve drives (open/closed) x x x x
Fault detection (overload/short circuit) x x x x
Tab.7: Function of the valve outputs
Product manual | EN-US | VC/S 4.x.1 | 2CDC508220D0211 Rev. B 11
Note about navigation in the PDF: Key combination 'Alt + left arrow'
jumps to the previous view/page

ABB i-bus® KNX PRODUCT OVERVIEW
3.5 Valve Drive ControllerVC/S4.1.1,MDRC
2CDC071016F0017
Fig.1: Valve Drive Controller VC/S 4.1.1
Product manual | EN-US | VC/S 4.x.1 | 2CDC508220D0211 Rev. B 12
Note about navigation in the PDF: Key combination 'Alt + left arrow'
jumps to the previous view/page

ABB i-bus® KNX PRODUCT OVERVIEW
3.5.1 Dimension drawing
2CDC072027F0017
Fig.2: Dimension drawing
Product manual | EN-US | VC/S 4.x.1 | 2CDC508220D0211 Rev. B 13
Note about navigation in the PDF: Key combination 'Alt + left arrow'
jumps to the previous view/page

ABB i-bus® KNX PRODUCT OVERVIEW
3.5.2 Connection diagram
2CDC072023F0017
Fig.3: Connection diagram VC/S 4.1.1
—
Legend
2 Programming LED
3 Programming button
4Bus connection terminal
5Cover cap
6Input
7Binary input
8Valve output
Product manual | EN-US | VC/S 4.x.1 | 2CDC508220D0211 Rev. B 14
Note about navigation in the PDF: Key combination 'Alt + left arrow'
jumps to the previous view/page

ABB i-bus® KNX PRODUCT OVERVIEW
3.5.3 Operating and display elements
Operating control/LED Description/function Display
Programming button/LED
Assignment of the physical address LED On: Device in programming mode
Tab.8: Operating and display elements
Product manual | EN-US | VC/S 4.x.1 | 2CDC508220D0211 Rev. B 15
Note about navigation in the PDF: Key combination 'Alt + left arrow'
jumps to the previous view/page

ABB i-bus® KNX PRODUCT OVERVIEW
3.5.4 Technical data
3.5.4.1 General technical data
Device Dimensions 90 × 140 × 63.5 mm (HxWxD)
Mounting width in space units 8 modules, 17.5mm each
Weight 0.27 kg
Mounting position Any
Mounting variant 35 mm mounting rail
Design ProM
Degree of protection IP 20
Protection class II
Overvoltage category III
Pollution degree 2
Materials Housing Polycarbonate, Makrolon FR6002, halogen free
Material note Fire classification Flammability V-0
Electronics Rated voltage, bus 30 VDC
Voltage range, bus 21 … 32 V DC
Current consumption, bus < 12 mA
Power loss, device ≤ 3 W
Power loss, bus ≤ 0.25 W
KNX safety extra low voltage SELV
Connections Connection type, KNX bus Plug-in terminal
Cable diameter, KNX bus 0.6 … 0.8 mm, solid
Connection type, inputs/outputs Screw terminal with universal head (PZ 1)
Pitch 6.35 mm
Tightening torque, screw terminals 0.5 … 0.6 Nm
Conductor cross-section, flexible 1 × (0.2 … 4 mm²) / 2 × (0.2 … 2.5 mm²)
Conductor cross section, rigid 1 × (0.2 … 6 mm²) / 2 × (0.2 … 4 mm²)
Conductor cross section with wire end ferrule without
plastic sleeve
1 × (0.25 … 2.5 mm²)
Conductor cross section with wire end ferrule with
plastic sleeve
1 × (0.25 … 4 mm²)
Conductor cross section with TWIN wire end ferrule 1 × (0.5 … 2.5 mm²)
Length, wire end ferrule contact pin ≥ 10 mm
Certificates and declarations Declaration of conformity CE → 2CDK508250D2701
Ambient conditions Operation -5…+45 °C
Transport -25…+70 °C
Storage -25…+55 °C
Humidity ≤ 95 %
Condensation allowed No
Atmospheric pressure ≥ 80 kPa (corresponds to air pressure at 2,000 m above sea
level)
Tab.9: General technical data
3.5.4.2 Inputs
Rated values Number of inputs 12
Inputs for analog room control unit 4
Contact scanning Scanning current ≤ 1 mA
Scanning voltage ≤ 12 V DC
Resistance Selection User-defined
PT 1.000 2-conductor technology
PT100 2-conductor technology
KT 1k
KTY 2k
NI 1k
NTC 10k, 20k
Cable length Between sensor and device input, one-way ≤ 100 m
Tab.10: Inputs
Product manual | EN-US | VC/S 4.x.1 | 2CDC508220D0211 Rev. B 16
Note about navigation in the PDF: Key combination 'Alt + left arrow'
jumps to the previous view/page

ABB i-bus® KNX PRODUCT OVERVIEW
3.5.4.3 Valve outputs – thermoelectric, PWM
Rated values Number of outputs 4
Non-floating Yes
Rated voltage Un230 VAC
Voltage range 24 … 230 V AC
Rated frequency 50/60 Hz
Rated current In0.5 A
Continuous current at Tu Up to 20 °C 0.25 A resistive load per output
Continuous current at Tu Up to 45 °C 0.15 A resistive load per output
Inrush current at Tu Up to 45 °C ≤ 1.6 A (for 10 s)
Tu = Ambient temperature
Minimum load (per output) 1.2 W
Tab.11: Valve outputs – thermoelectric, PWM
3.5.4.4 Device type
Device type Valve Drive Controller VC/S 4.1. 1
Application Valve Drive Controller, 4f/ …
… = current version number of the application
Maximum number of group objects 298
Maximum number of group addresses 300
Maximum number of assignments 300
Tab.12: Device type
Note
Observe software information on the website →www.abb.com/knx.
Product manual | EN-US | VC/S 4.x.1 | 2CDC508220D0211 Rev. B 17
Note about navigation in the PDF: Key combination 'Alt + left arrow'
jumps to the previous view/page

ABB i-bus® KNX PRODUCT OVERVIEW
3.6 Valve Drive ControllerVC/S4.2.1,MDRC
2CDC071017F0017
Fig.4: Valve Drive Controller VC/S 4.2.1
Product manual | EN-US | VC/S 4.x.1 | 2CDC508220D0211 Rev. B 18
Note about navigation in the PDF: Key combination 'Alt + left arrow'
jumps to the previous view/page

ABB i-bus® KNX PRODUCT OVERVIEW
3.6.1 Dimension drawing
2CDC072027F0017
Fig.5: Dimension drawing
Product manual | EN-US | VC/S 4.x.1 | 2CDC508220D0211 Rev. B 19
Note about navigation in the PDF: Key combination 'Alt + left arrow'
jumps to the previous view/page

ABB i-bus® KNX PRODUCT OVERVIEW
3.6.2 Connection diagram
2CDC072024F0017
Fig.6: Connection diagram VC/S 4.2.2
—
Legend
1Label carriers
2 Programming LED
3 Programming button
4Bus connection terminal
5Cover cap
6Input
7Binary input
8Valve output
9Reset button / valve output error LED
10 Manual operation button/LED
11 Input LED
12 Valve output switching button/LED
Product manual | EN-US | VC/S 4.x.1 | 2CDC508220D0211 Rev. B 20
Note about navigation in the PDF: Key combination 'Alt + left arrow'
jumps to the previous view/page
