ABB TZIDC-110 User manual

P R OF I
BU S
PROCESS FIELD BUS
®
Operating Instructions
41/1877 EN
Electro-Pneumatic Positioner
TZIDC-110
for PROFIBUS PA

2 Electro-pneumatic positioner TZIDC-110 41/18-77 EN
ElectroPneumatic Positioner TZIDC110
for PROFIBUS PA
Operating Instructions
Document No.: 41/18-77 EN
Issued: 04.05
Manufacturer
ABB Automation Products GmbH
Schillerstr. 72
32425 Minden
Germany
Tel: [phone]
Fax: [phone]
[email protected]b.com
Note
More information, e.g. regarding configuration, operation and ordering details, is available
on CD.
© Copyright 2005 by ABB Automation Products GmbH
Modifications reserved
This document is subject to copyright. It is intended to help the user operate the equipment safely
and efficiently. The content may not be copied or reproduced either in part or in full without the
prior consent of the copyright owner.

41/18-77 EN Electro-pneumatic positioner TZIDC-110 3
Table of contents
Important information....................................................................................................... 5
1 Safety summary............................................................................................................ 6
1.1 General safety instructions .....................................................................................6
1.2 Device-specific safety instructions.........................................................................7
1.2.1 General .......................................................................................................... 7
1.2.2 Pneumatic safety .......................................................................................... 7
1.2.3 Electrical safety .............................................................................................. 8
1.3 Explosion protection................................................................................................9
1.4 Correct use................................................................................................................9
1.5 Qualified personnel ..................................................................................................9
2 Manufacturer's information.................................................................................... 10
2.1 Delivery....................................................................................................................10
2.2 CE compliance information ...................................................................................10
3 Installing and commissioning............................................................................... 11
3.1 Mechanical mounting.............................................................................................11
3.1.1 General......................................................................................................... 11
3.1.2 Operating conditions at the installation site .................................................. 12
3.1.3 Mounting the positioner to linear actuators................................................... 12
3.1.4 Mounting the positioner to rotary actuators .................................................. 17
3.2 Pneumatic connection ...........................................................................................20
3.2.1 Safety instructions ...................................................................................... 20
3.2.2 Making the pneumatic connections .............................................................. 20
3.2.3 Mounting the splash guard cap .................................................................... 21

4 Electro-pneumatic positioner TZIDC-110 41/18-77 EN
3.3 Electrical connection..............................................................................................22
3.3.1 Safety instructions ........................................................................................ 22
3.3.2 General installation instructions ................................................................... 22
3.3.3 Overview....................................................................................................... 23
3.4 Commissioning.......................................................................................................25
3.4.1 Procedure ..................................................................................................... 25
3.4.2 Setting the bus address................................................................................ 27
3.4.3 Requesting information................................................................................. 28
3.4.4 Local operation (bus device)......................................................................... 28
3.4.5 Parameter setting example .......................................................................... 29
3.5 Functional test / maintenance ...............................................................................30
3.5.1 Functional test of the shutdown module ....................................................... 31
4 Technical data ............................................................................................................. 32
4.1 Basic model.............................................................................................................32
4.2 Options ....................................................................................................................36
5 Certificates.................................................................................................................... 38
Appendix A: Configuration overview........................................................................ 56

41/18-77 EN Electro-pneumatic positioner TZIDC-110 5
Important information
Symbols
In order that you can make the best use of this document and to ensure safety during commis-
sioning, operation and maintenance of the equipment, please note the following explanation of
the symbols used:
As well as the instructions in this document, you must also follow the generally applicable acci-
dent prevention and safety regulations.
If the information in this document is insufficient in any situation, please contact our service de-
partment, who will be happy to help you.
Please read this document carefully before installation and commissioning.
Symbol Signal Word Definitions
DANGER DANGER indicates an imminently hazardous situation
which, if not avoided, will result in death or serious injury.
(High level of risk.)
WARNING WARNING indicates a potentially hazardous situation
which, if not avoided, could result in death or serious
injury.
(Medium level of risk.)
CAUTION CAUTION indicates a potentially hazardous situation
which, if not avoided, could result in minor or moderate
injury.
(Low level of risk.)
NOTICE NOTICE indicates a potentially harmful situation which, if
not avoided, may result in damage of the product itself or
of adjacent objects.
(Damage to property)
IMPORTANT IMPORTANT indicates useful hints or other special
information which, if not observed, could lead to a decline
in operating convenience or affect the functionality.
(Does not indicate a dangerous or harmful situation.)
!
!
!
!

6 Electro-pneumatic positioner TZIDC-110 41/18-77 EN
1 Safety summary
1.1 General safety instructions
This chapter provides important instructions for your safety. Thoroughly read and follow
these instructions.
Proper and safe operation of the TZIDC-110 positioner requires:
• proper transportation and storage
• mounting, electrical and pneumatic installation and commissioning by qualified per-
sonnel (see chapter 1.5, page 9)
• correct operation according to the instructions in this manual
• correct use (see chapter 1.4, page 9)
• careful maintenance
The regulations, standards and directives referred to in this manual are applicable in Ger-
many. When using the TZIDC-110 positioner outside the German jurisdiction, the rele-
vant regulations, standards and directives applicable in the country where the device is
used must be observed.
The TZIDC-110 positioner has been designed and tested in accordance with
DIN VDE 0411 Part 1 / EN 61 010 Part 1
“Safety Requirements for Electronic Measuring Apparatus”
(based on IEC Publication 348) and has been delivered in a safe condition.
In order to retain the device in a safe condition and ensure safe operation, attentively
read and follow the instructions given in the sections marked with the respective sym-
bols. (See “Important information” on page 5.) Otherwise, persons can be endangered or
the device itself or other devices or equipment may be damaged or fail.
The device must be shut down and secured reliably against unintentional restart if it must
be assumed that safe operation is no longer ensured. Possible reasons for this assump-
tion can be:
• visible damage of the device
• failure of the electrical function
• exposure to a storage temperature of more than 85 °C for a longer time period
• exposure to considerable strain or wear during transport
Only the manufacturer is authorized to repair the device.

41/18-77 EN Electro-pneumatic positioner TZIDC-110 7
1.2 Device-specific safety instructions
1.2.1 General
1.2.2 Pneumatic safety
!
WARNING
• Any user-made changes or manipulations of the device are prohibited!
Only the manufacturer or an expert for explosion protection are authori-
zed to modify the device.
• Before re-using a TZIDC-110 positioner that has already been used in
another installation place always reset the device to the factory setting.
Never start the autoadjustment function before having restored the fac-
tory setting! Otherwise, hazardous situations may occur due to impro-
per settings.
• Do not use the internal communication interface (X5) on the mother-
board when the TZIDC-110 positioner is installed and used in the
hazardous area.
• The (optional) safety shutdown module must be subject to a functional
test every two years at the latest. Follow the instructions in chapter
3.5.1.
!
WARNING
• Observe the accident prevention rules of the Employers Liability Insu-
rance Association.
• Observe the safety instructions for the pneumatic actuator used. The
actuator's high actuating power may cause injuries !
!
NOTICE
• Take suitable precautions to ensure that even in case of malfunctions
the positioner’s max. admissible operating pressure of 6 bar (90 psi) is
not exceeded. Otherwise, the positioner and/or the actuator may be
damaged.
• The positioner must be supplied with instrument air exempt from oil,
water and dust according to DIN/ISO 8573-1, Class 3
- Purity: max. particle size 5 µm, max. particle density 5 mg/m3
- Oil content: max. concentration 1 mg/m3
- Pressure dew point: maximum value 10 K below operating temp. 3
Before connecting the air pipes blow them out to remove dust, splinters
and other particles.

8 Electro-pneumatic positioner TZIDC-110 41/18-77 EN
1.2.3 Electrical safety
!
WARNING
• Observe the common VDE safety regulations and the accident preven-
tion rules of the Employers Liability Insurance Association.
• Observe the common standards and safety regulations for the installa-
tion and operation of electrical systems.
• When connecting the device, observe all electrical specifications in
these operating instructions or in the data sheet.
• For the electrical installation of explosion-protected devices, observe all
standards, regulations and directives governing explosion protection
and applicable for the construction and use of explosion-protected sys-
tems, especially the DIN/VDE directives, the directives for explosion
protection (VDE 0165 or EN 60079), and the special requirements and
specifications for your devices (see the following chapter "Explosion
protection" and chapter "Certificates" starting on page 38).
• Excusively power devices with explosion protection via an electrically
isolated circuit with safe extra-low voltage (SELV) in accordance with
EN 60 950.
!
NOTICE
Power supply
• The basic device is bus-powered via the Fieldbus connected to the bus
terminals +(11) and -(12). The option modules have to be supplied
separately.
• When connecting a power source for test purposes without establishing
a bus communication (e.g. when executing the Autoadjust function), a
supply voltage between 9.0 V DC and a maximum of 32 V DC can be
applied.
!
NOTICE
Electromagnetic interference
• Do not run bus/signal lines close to power lines. Power lines produce
interference in their near vicinity which may affect the electrical capabi-
lities of the bus/signal lines.
• In order to ensure electromagnetic compatibility (EMC), always use
shielded cables conforming to the standards for the bus lines. When
running the device with the option modules (proximity switches, mic-
roswitches, shutdown module) use shielded cables for these modules
as well. All cable shields must be kept as short as possible and have to
be connected to protective ground on both sides (use the grounding
screw in the TZIDC-110 connection compartment on the device side).
• Keep the case closed. When the case is open, the positioning action
may be affected through electromagnetic interference. This may result
in a permanent positioning error, especially when the Autoadjust func-
tion is performed with the case open.

41/18-77 EN Electro-pneumatic positioner TZIDC-110 9
1.3 Explosion protection
One of the type plates seen below is attached to the positioner to the left of the main type
plate, depending on the positioner’s explosion protection. It indicates the degree of explo-
sion protection and the certificate valid for your positioner. For details please refer to
chapter "Certificates" starting on page 38.
1.4 Correct use
The TZIDC-110 positioner is an electro-pneumatic positioner for pneumatic final control
elements. It is designed for being attached to linear and rotary actuators following the
instructions in this manual. The positioner may be used only for the applications listed in
these operating instructions or in the data sheet 18-0.23 EN. Any other use is considered
as incorrect.
The signal current circuit and the input and output circuitry must meet the explosion pro-
tection requirements stipulated in the certificates (see chapter "Certificates" starting on
page 38).
The maximum permissible ambient temperature range of -40 °C to +85 °C (when using
proximity switches of type SJ2-S1N (NO): -25 °C to + 85 °C) must not be exceeded.
1.5 Qualified personnel
Only those persons familiar with the installation, commissioning, operation and mainte-
nance of the TZIDC-110 positioner or similar instruments who have the required qualifi-
cation and have read and understood the operating instructions are authorized to work
on the TZIDC-110 positioner. These persons must be sufficiently trained and experi-
enced and know the relevant standards and regulations to be able to judge their assig-
ned tasks and recognize potential hazards. Only persons who are qualified or have been
trained adequately and who have the required certificates are authorized to work on
explosion-protected devices.
!
WARNING
Always observe the specifications and special requirements for your
positioner stipulated in the applicable certificate.
Fig. 1 Type plates indicating the degree of explosion protection

10 Electro-pneumatic positioner TZIDC-110 41/18-77 EN
2 Manufacturer's information
2.1 Delivery
When receiving the delivery please immediately check items and scope for intactness
and completeness. The scope of delivery is stated in the shipping documents. If ordered,
the accessories (e.g. mounting material, pressure gauge block, filter regulator) are added
to the delivery as individual items. Check items and scope of the delivery by means of
the catalog numbers to see if types and quantities are in accordance with your order. If
the positioner is delivered already mounted to the actuator, the positioner, accessories
and actuator or final control element are considered as a common delivery item. A list of
catalog numbers and details of the different versions and accessories can be found in
data sheet 18-0.23 EN.
2.2 CE compliance information
We declare that we are the manufacturer of the TZIDC-110 positioner and that the pro-
duct conforms with the EMC Directive 89/336/CEE as of May 1989 and meets the
requirements of the following standards:
• EN 55022:1998 “Information technology equipment, Radio disturbance
characteristics, Limits and methods of measurement”
• EN 61000-6-2:8/2002 ”Electromagnetic compatibility (EMC)
Part 6-2: Generic standards - Immunity for industrial environments
• EN 61000-6-3:3/2000 “Electromagnetic compatibility (EMC)
Part 6-3: Generic standards - Emission standard for residential,
commercial and light-industrial environments
The TZIDC-110 positioner complies with the EC directive for CE conformity certification.

41/18-77 EN Electro-pneumatic positioner TZIDC-110 11
3 Installing and commissioning
3.1 Mechanical mounting
3.1.1 General
The arrow (1) on the
feedback shaft (and
thus the lever) must
travel within the
area marked with
the small arrows (2).
When mounting the
positioner, ensure
that the transfer of
the stroke or rota-
tion angle for the
position feedback is
correct. The maxi-
mum rotation angle
is 60° for mounting
to linear actuators
and 120° for moun-
ting to rotary actua-
tors. The minimum
angle is always 25°.
Fig. 2 Operating range
12
Fig. 3 Positioner ranges
TZID-C
+60°
-60°
+30°
-30°
100%
0%
100%
0%
Sensor range for rotary actuators
Operating range for linear actuators
Operating range for rotary actuators
Sensor range for linear actuators

12 Electro-pneumatic positioner TZIDC-110 41/18-77 EN
3.1.2 Operating conditions at the installation site
Ambient temperature: -40 °C ... +85 °C (-25 °C ... + 85 °C when using
proximity switches of type SJ2-S1N (NO))
Relative humidity: 95 % (mean annual value), condensation permissible.
Observe the specifications for protection class IP65 /
NEMA 4X and the technical data in this manual.
Explosion protection: Observe the technical data, and the specifications in the
certificates (see the relevant sections of this manual).
Mounting orientation: any orientation allowed
3.1.3 Mounting the positioner to linear actuators
A special attachment kit is available for mounting the positioner to a linear actuator
according to DIN/IEC 534 (lateral mounting to NAMUR) comprising the following parts:
Tools required: Wrench 10 mm /13 mm
Allen key 4 mm
!
WARNING
Before installing check to ensure that the specifications in terms of safety
and control applicable to the TZIDC-110 positioner will not be exceeded at
the installation site of the actuator or final control element.
• Lever (1.0) with
follower pin,
for 10 ... 35 mm or
for 20 ...100 mm
actuator travel
• Follower guide (2.0)
with two screws (2.1),
spring washers (2.2),
and clamp plates (2.3)
• Angle bracket (3.0)
with two screws (3.1),
and 2 plain washers
(3.2)
• Screw (3.4) and plain
washer (3.5) for
mounting to cast iron
yoke
• Two U-bolts (3.7),
each with two plain
washers (3.8), and
two nuts (3.9) for
mounting to columnar
yoke
3.4
3.5
3.7
3.9
3.1 3.2
3.0
2.1
2.3
2.0
1.0
3.8
2.2
Fig. 4 Mounting kit for linear actuators

41/18-77 EN Electro-pneumatic positioner TZIDC-110 13
Follow the procedure (steps 1 - 5) below to attach the positioner to a linear
actuator:
1. Mount the follower guide to the actuator
2. Assemble the lever (if not yet pre-assembled)
• Fasten the follower guide (1)
and the clamp plates (2) with
screws (4) and spring washers
(3) to the spindle of the actua-
tor; hand-tighten the screws.
• Slip the spring (2) onto the bolt
with the follower pin (1).
• Slip the plastic washer (3) onto
the bolt and compress the
spring with it.
• Insert the bolt with com-
pressed spring into the oblong
hole in the lever (4) and fasten it
in the desired position using the
plain washer (5) and nut (6) at
the lever; the scale on the lever
indicates the link point for the
stroke range.
• Slip the plain washer (8) onto
the screw (7), insert the screw
into the lever and counter with
the nut (9).
4
2
1
3
Fig. 5 Mounting follower guide to actuator
1
2
3
4
5
6
9
8
7
Fig. 6 Assembling the lever

14 Electro-pneumatic positioner TZIDC-110 41/18-77 EN
3. Mount the lever and the angle bracket to the positioner
• Attach the lever (1) to the positioner’s feedback shaft (2) (can only be mounted in one
position due to the flat on the side of the feedback shaft).
• Check whether the lever travels within the operating range (between the arrows) by
observing the arrow marks (3).
• Hand-tighten the screw (4) at the lever.
• Hold the preassembled TZIDC-110 with the angle bracket (5) still loose in such a way
against the actuator that the follower pin on the lever introduces into the follower
guide, in order to determine the bore holes of the TZIDC-110 to be used for the angle
bracket.
• Fasten the angle bracket (5) with screws (6), and plain washers (7) to the correspon-
ding bore holes in the TZIDC-110 case; if possible, tighten the screws evenly to
ensure linearity during operation. Align the angle bracket in the oblong hole to achieve
a symmetrical operating range (between the arrow marks (3)).
Fig. 7 Mounting lever and angle bracket to TZIDC-110
1
23
4
5
6
7

41/18-77 EN Electro-pneumatic positioner TZIDC-110 15
4.a Mount the positioner to a cast iron yoke
or
4.b Mount the positioner to a columnar yoke
• Fasten the angle bracket (1)
with screw (2), plain washer (3)
to the cast iron yoke (4).
• Hold the angle bracket (1) in the
appropriate position against the
columnar yoke (2).
• Insert the U-bolts (3) from the
inner side of the columnar yoke
through the holes in the angle
bracket.
• Slip on the plain washers (4),
and nuts (5). Hand-tighten the
nuts evenly.
IMPORTANT
Adjust the height of the TZIDC-110 positioner at the cast iron yoke or the
columnar yoke until the lever is horizontal (at visual check) at half valve
stroke.
Check the unit for proper mounting after having made the pneumatic and
electrical connection (see chapter "Commissioning" on page 25).
24
1
3
Positioner
Fig. 8 Mounting to cast iron yoke
5
1
2
3
4
Positioner
Fig. 9 Mounting to columnar yoke

16 Electro-pneumatic positioner TZIDC-110 41/18-77 EN
5. Adjust the stroke
The scale on the lever indicates the relevant points for the various valve stroke ranges.
You can adapt the valve stroke range to the operating range of the position sensor by
shifting the bolt with follower pin in the oblong bore hole of the lever. When the link point
is shifted to the inside, the position sensor’s rotation angle is increased; shifting to the
outside decreases the angle.
Set the stroke range in such a way that the used rotation angle of the position sensor is
as great and as symmetrical around the center position as possible.
Recommended range for linear actuators: between -28° and +28°
Minimum angle: 25°
IMPORTANT
After mounting, check whether the positioner operates within the sensor
range.
Check the unit for proper mounting after having made the pneumatic and
electrical connection (see chapter "Commissioning" on page 25).
Fig. 10 Positioner linkage
decreaseincrease

41/18-77 EN Electro-pneumatic positioner TZIDC-110 17
3.1.4 Mounting the positioner to rotary actuators
The following mounting kit is available for mounting to a rotary actuator according to VDI/
VDE 3845:
Tools required: Wrench 10 mm /13 mm
Allen key 3 mm
• Adapter (1.0) with
spring (1.4)
• Four screws, M6
(1.1), four spring
washers (1.2), and
four plain washers
(1.3) for fastening
the bracket (2.0) to
the positioner
• Mounting bracket
(2.0)
• Four screws, M5
(2.1), four spring
washers (2.2), and
four plain washers
(2.3) for fastening
the bracket to the
actuator
1.3
1.0
1.1
2.0
2.1
2.2
2.3
1.2
1.4
Fig. 11 Mounting kit for rotary actuators

18 Electro-pneumatic positioner TZIDC-110 41/18-77 EN
Follow the procedure (steps 1 - 3) below to attach the positioner to a rotary
actuator:
1. Mount the adapter to the positioner
2. Attach the mounting bracket (1) to the positioner
• Determine the mounting position (in paral-
lel to the actuator or shifted by 90°).
• Determine the direction of rotation of the
actuator (clockwise or counterclockwise).
• Move the rotary actuator to its home posi-
tion.
• On the basis of the mounting position, the
home position, and the direction of rotation
it must be determined in which position the
feedback shaft (1) of the positioner must be
pre-adjusted and in which position the
adapter (2) must be placed, to enable the
positioner to travel within the correct range
(the arrow on the rear of the device must
travel within the admissible range, for
details see Fig. 2 on page 11).
• Pre-adjust the feedback shaft.
• Place the adapter on the feedback shaft in
the appropriate position and fix it by
setscrews (3); ensure that one of the
setscrews is engaged on the side of the
feedback shaft with the flat.
Fig. 12 Mounting the adapter
1
2
3
1
M6 screws
Fig. 13 Attaching the mounting bracket to the positioner

41/18-77 EN Electro-pneumatic positioner TZIDC-110 19
3. Attach the positioner to the actuator
IMPORTANT
After mounting, check whether the actuator’s operating range is in
accordance with the positioner’s sensor range.
Check the unit for proper mounting after having made the pneumatic and
electrical connection (see chapter "Commissioning" on page 25).
M5 screws
Fig. 14 Attaching the positioner to the actuator

20 Electro-pneumatic positioner TZIDC-110 41/18-77 EN
3.2 Pneumatic connection
3.2.1 Safety instructions
3.2.2 Making the pneumatic connections
All pneumatic piping connections are located on the right-hand side of the positioner.
Threaded bores G 1/4 or 1/4-18 NPT, respectively, are provided. The positioner is
labeled according to the type of thread. The corresponding screwed pipe connections
have to be supplied by the customer. We recommend pipes with the dimension 6 x 1 mm
for the pneumatic piping.
The amount of supply pressure has to be matched to the working pressure necessary for
the actuation. The positioner's operating range is between 1.4 and 6 bar.
!
WARNING
• Observe the accident prevention rules of the Employers Liability Insu-
rance Association.
• Observe the safety instructions for the pneumatic actuator used. The
actuator's high actuating power may cause injuries !
!
NOTICE
• Take suitable precautions to ensure that even in case of malfunctions
the positioner’s max. admissible operating pressure of 6 bar (90 psi) is
not exceeded. Otherwise, the positioner and/or the actuator may be
damaged.
• The positioner must be supplied with instrument air exempt from oil,
water and dust according to DIN/ISO 8573-1, Class 3
- Purity: max. particle size 5 µm, max. particle density 5 mg/m3
- Oil content: max. concentration 1 mg/m3
- Pressure dew point: maximum value 10 K below operating temp.3
Before connecting the air pipes blow them out to remove dust, splin-
ters and other particles.
Fig. 15 Pneumatic connections
Filter
OUT 1
OUT 2
NPT ¼
G ¼
Pneumatic outputs
Air supply
Filter screw plug
