ABB DW Series User manual

DIGITAL WEEKLY TIME SWITCH User Manual
DW

English
- 1 -
User manual DW
Index
■Technical features page 3
■Safety warnings page 4
■Dimensions page 4
■Wiring diagrams page 5
■Display and keyboard description page 6
■Initial operation page 7
■Start page (or main) page 8
■Manual switching page 11
■Menu description page 12
Settings menu page 14
Language setting menu page 15
Date setting menu page 16
Time setting menu page 17
Daylight saving time (DST)/winter time (CET)
change setting menu page 18
Random switchings setting menu page 20
Cycle switchings setting menu page 21
Protection PIN setting menu page 22
■Program menu page 23
Program menu: new page 27
Program menu: new daily timed page 28
Program menu: new weekly timed page 29
Program menu: new holiday timed page 30
Program menu: check page 32
Program menu: modify page 34
Program menu: copy page 36
Program menu: delete page 37
■Bluetooth page 38
■Hour couter menu page 40
■Reset menu page 42
■Firmware menu page 44
■Error signals page 45
■Battery management page 46
■Reference standards page 46

English
- 2 -
User manual DW
USER MANUAL
The digital time switches of DW series are electronic devices for the management of the electrical utilities over time. They allow the time
programming (periodicity: daily or weekly).
DW1 is equipped with a relay (channel 1) while DW2 is equipped with two relays (2 independent channels).
DW time switches have a Bluetooth interface that allows it to be coupled with mobile devices (smartphone or tablet). Thanks to the free app
that can be downloaded from the AppStore and Google Play stores, it is possible to program and make settings directly on your smartphone,
and then transfer all the data to the time switch.
The reverse procedure is also possible, i.e. to copy the programming of a time switch on your mobile device.
The backup battery allows you to keep the settings even in case of black-out and can be replaced through the cover on the back of the time
switch.
DW time switches are devices of electronic type that perform actions of 1B type , intended to operate in environments with III overvoltage
category and pollution degree 2 in accordance with EN 60730-1 standard.
Code Model Description
2CSM222531R1000 DW1 Digital weekly time switch 1 channel with Bluetooth
2CSM222521R1000 DW2 Digital weekly time switch 2 channels with Bluetooth

English
- 3 -
User manual DW
TECHNICAL FEATURES
• Power supply: 230 Vac (-15% ÷ +10%) 50/60 Hz
• Power consumption:
- DW1: 2W (6 VA)
- DW2: 2W (6 VA)
• Lithium backup battery: 3V, CR2032 type (replaceable)
• Output:
- DW1: 1 monostable change-over relay with maximum
switchable load of 16A / 250V
- DW2: 2 monostable change-over relays with maximum
switchable load of 16A / 250V
• Terminal block for cables with maximum cables section
of 2.5 mm2
• Display LCD with backlighting (active with AC power supply)
• Bluetooth BLE 4.2 communication interface (active with mains
power supply)
• Storable programs:
- DW1: 120 events
- DW2: 120 events (divisible on 2 channels)
• Actions type: 1B
• Operating temperature: -20 ÷ +50 °C
• Operating humidity: 20 ÷ 90% non condensing
• Storage temperature: -25 ÷ +70 °C
• Operating frequency band: 2400-2483.5 MHz
• Maximum transmitted radiofrequency power: 4 dBm
• Container: 2 DIN modules
• Protection degree: IP20
• Insulation: reinforced between accessible parts (front) and all
the other terminals

English
- 4 -
User manual DW
SAFETY WARNINGS
nDuring product installation and operation it is necessary to
observe the following instructions:
1) The instrument must be installed by a qualified person,
strictly in observance of the connection diagrams shown in
this manual.
2) After installation inaccessibility to the terminals without
using dedicated tools must be guaranteed.
3) Before accessing the connection terminals, make sure that
the leads are not live.
4) Do not connect or feed the instrument if any part of it is
damaged.
5) The product must be installed and activated in compliance
with current electric systems standards.
6) Do not use the instrument for anything other than the
indicated purpose.
7) In the electrical system upstream of the device must be
installed a protection device against the overcurrents
8) The product can be used in environments with overvoltage
Category III and Pollution degree 2, according to the
Standard EN 60730-1
9) The access to the device must be limited and the default
device PIN and Bluetooth password must be changed in
order to avoid tempering of programs of relays.
DIMENSIONS (mm)
35
87
65

English
- 5 -
User manual DW
WIRING DIAGRAMS
DW1 DW2

English
- 6 -
User manual DW
DISPLAY AND KEYBOARD DESCRIPTION
General indications
Time indication
Channel 1/channel 2 status indication
: active manual program
+ : blocked switchings
+ : active random switchings
+ (flashing) : active cycle switchings
: active holiday program
: active pulse program
Day of the week (DAY) indication
Turn on the display
Access the menu
ESC (one level back)
 “C1”: decrease datum/previous menu/ switching channel 1/
lock channel 1
“C2”: increase datum/next menu/ switching channel 2/
lock channel 2
 Confirm selection
 Hardware reset
“Ok” + “C1” (3 sec): active random switching on channel 1
“Ok” + “C2” (3 sec): active random switching on channel 2
“”+ “C1” (3 sec): active cycle switching on channel 1
“”+ “C2” (3 sec): active cycle switching on channel 2
C2
C1

English
- 7 -
User manual DW
INITIAL OPERATION
• Once out of the package, DW is off: press the key and wait
a moment before activating the display
• The set language is English. To change it, press the key for
at least 3 seconds. Choose among: German, English, Spanish,
French, Italian, Russian and confirm with .
• Make connections following the diagrams on page 5 of this
manual
• Power DW: the backlighting turns on permanently.
• The presence of the backup battery allows the DW to have
updated date and time.
To make the other settings follow the following steps:
Date - format: DD/MM/YY
- 1st day of the week: Monday
Daylight Saving time (DST)
change: active
- start of daylight saving time (DST):
last Sunday of March at 02:00
o’clock
- end of daylight saving time (DST):
last Sunday of October at 03:00
o’clock
Random switchings: - minimum: 1 minute
- maximum: 5 minutes
Cycle switchings: - ON duration: 1 minute
- OFF duration: 1 minute
PIN protection: disabled (---)
Bluetooth: disabled (Password: 000000)

English
- 8 -
User manual DW
START PAGE (or main)
Information messages
- day of the week
- product identification code and serial number
- battery status (only if discharged)
- *
* Only if DW is not powered by mains.
In this condition the backlighting is not active and the relay is in
off status.
NOTE: Bluetooth interface is active only when DW displays the
start page (main) and only if it’s mains power supplied. Therefore,
to transfer programs from and to the times witch it is necessary to
respect these conditions.
• Press the key:
to access the menu of DW
C1
and
C2
to change channel 1 and channel 2 status
(only for DW2)
to display the Bluetooth signal level
NOTE: The device is supplied with deactivated Bluetooth
interface. To activate it, access Bluetooth menu (see page 36).
information messages
date
relay 2 status (only for DW2)
hour
day of the week
relay 1 status

English
- 9 -
User manual DW
Access the store of your device, install and start the free app DBT TIMER

English
- 10 -
User manual DW
Activate Bluetooth on DW devices (see page 36)
At the start the app displays the list of the associated DW devices. To associate a new device, press the symbol “ ” in the upper
right corner.
All the Bluetooth devices detected nearby are displayed: select the device to be associated from the list.
Note: each device is identified by the product code (for example DW) and by the serial number (for example 00000020).
These informations can be viewed from the main page of the DW
Warning: make sure that the DW is mains powered, Bluetooth interface is activated and that the display shows the main page (initial).
Otherwise the Bluetooth interface is not active and the device is not visible
Enter the password to associate the DW with your device
After successfully completing the procedure, the DW is added in the list of the associated devices.
Select the DW on which you want to act from the list of the associated devices
Note: communication between the app and the DW is point-to-point. This means that,
even in the presence of multiple DW, the app can communicate with one only at a time.
The DW currently connected to the app displays the symbol * immediately after the serial number
The app displays the initial page of the selected DW. From this page you can:
a. Create new programs that will then be copied to the DW
b. Change the settings of the DW
c. View the parameters and associate an alias to the DW
d. Manually control the relay output/s and activate the random switching function or cycle function.

English
- 11 -
User manual DW
MANUAL SWITCHING
To manually take action on the channels of DW time switches (activated with the combination described on page 6), carry out the operations
described below:
SWITCHING CHANNEL: press the key
C1
for channel 1 or
C2
for channel 2. If on becomes off and vice versa.
temporary on : the selected channel is set on until the next programmed off event
temporary off : the selected channel is set off until the next programmed on event
LOCK CHANNEL: press for a long time (for 3 seconds at least) the key
C1
for channel 1 or
C2
for channel 2. The current state is locked
until the unlocking (press again for a long time the key
C1
or
C2
).
permanent on the selected channel is locked in on position until the manual unlocking
permanent off the selected channel is locked in off position until the manual unlocking
RANDOM SWITCHING: press contemporary and for a long time (for 3 seconds at least) the key and
C1
for channel 1 or
C2
for channel 2.
Press again simultaneously and for a long time the keys and
C1
or
C2
to disable the function.
random : the selected channel is set on and then will take place switching on/off at random intervals (the minimum and maximum
interval can be set from “Settings ➔ random” menu)
CYCLE SWITCHING: press contemporary and for a long time (for 3 seconds at least) the keys and
C1
for channel 1 or
C2
for channel 2
Press again simultaneously and for a long time the key and
C1
or
C2
to disable the function.
cycle (flashing) : the selected channel is set on and then will take place switching on/off (the on and off duration can be set from
“Settings ➔ cycle” menu).

English
- 12 -
User manual DW
MENU DESCRIPTION
C2
C2
C1
C2
C1
C2
C1
C2
C1
C1
Press the key to access the menu

English
- 13 -
User manual DW
“Settings” menu allows you to change: language, date, time, daylight saving time (DST), minimum and maximum
duration of the interval between two switchings with random program, ON and OFF duration of cycle switchings, PIN for
keyboard lock.
“Programming” menu allows you to set a new program or to check, to copy, to modify or to delete a set program.
“Bluetooth” menu allows you to configure the Bluetooth communication interface.
“Hour counter” menu allows you to check the operation hours (relay on) of the loads connected to the relays.
“Reset” menu allows you to reset settings, programmed settings, operating hour counter.
“Ver FW” menu allows you to check the firmware version installed on the device.

English
- 14 -
User manual DW
SETTINGS MENU
“Settings” menu allows you to view and eventually to modify the
the general operation settings of DW, such as:
language
date
time
automatic daylight saving time (DST) change
interval duration between two random switchings
ON and OFF time duration for cycle switchings
keys protection by PIN
C2
C1

English
- 15 -
User manual DW
Language setting menu
Available languages:
German, English, Spanish, French, Italian, Russian.
Quick access: from the main page it’s possible to access the
language setting by pressing the key for at least 3 seconds.
C2
C1

English
- 16 -
User manual DW
Date setting menu
Parameters modification
1Possible date formats: day-month-year ( ), year-month-day ( ),
month-day-year ( ).
2Choose, by convention, the first day of the week. In Italy, for example, the first day of the week
is Monday, in the UK it’s Sunday.
3Enter the date: day, month, year.
Parameters
modification
1
2
3
C2
C1
C2
C1

English
- 17 -
User manual DW
Time setting menu
1
Parameters modification
1Set the time: hours, minutes.
2Set the time zone. Range: -14:00 ÷ +14:00 at 15 minutes steps.
For Italy set +1:00.
Parameters
modification
C2
C1
C2
C1

English
- 18 -
User manual DW
Daylight saving time (DST)/winter time (CET) change setting menu
Daylight saving time (DST)/winter time(CET) change and vice versa can occur in an automatic way. In this case, DW:
- increases by an hour in the passage from winter time (CET) to daylight saving time (DST)
- decreases by an hour in the passage from daylight saving time (DST) to winter time (CET)
For every change it’s necessary to specify:
the week of the month during
which the time change occurs
(first, second, third, fourth, last)
the day of the week
(Monday: 1, Tuesday: 2, ...)
the month the hour and the minutes
In Italy,for example, daylight saving time (DST) begins occurs the last ( ) Sunday ( ) of March ( ) at o’clock, and ends the
last ( ) Sunday ( ) of October ( ) at o’clock.
