ABB Relion 615 series User manual










 
—
Quick Start Guide
Relion® 615 series
Display Default view can be selected from single line diagram (SLD), measurements and main menu
Self-supervision and
protection indicator LEDs
Ready-LED steady: OK, Ready-LED flashing: Internal Relay Fault (IRF),
Start-LED steady: protection started, Start-LED flashing: protection function blocked,
Trip-LED: protection operated
Programmable LEDs Can be programmed for alarming and indication with latching and/or flashing features
Control Circuit Breaker (CB) Press open/close and confirm by pressing enter. If there is more than one controllable object
select the object first with navigation buttons. Note: control has to be in Local mode.
Escape / Cancel Used for canceling actions and leaving setting mode without saving the values.
Returns back to menu.
Navigation Left = go back, Right = go further, Up = scroll up, Down = scroll down.
Up/down can also be used when selecting controllable objects like breakers and
switches in single line diagram.
Enter / Select Entering to parameter setting mode and confirming new values
Authorization If authorization is used you can log in or log out using this button
Clear Clearing events and indications, see next page for further details
 Menu Switch views in between the main menu, single line diagram and measurements
 Local / Remote Changes the control between Local/Remote
 Help View help messages

2QUICK START GUIDE RELION® 615 SERIES
—
Using the local HMI
Accessing main menu and changing parameters
Press to navigate between main menu, measurements
and single-line diagram.
Press and select which setting value you want to change
and press to change it with or keys. If there is “#”
mark at the same line with parameter value, you have to first
select which setting group parameter you want to change.
If there is no “#” mark then you can change the value directly
by pressing and then with or or or keys.
You can change all parameters in the same way. The most
common function block names are described at the end of
this document.
Storing settings
After making changes to parameters they have to be stored
to get them into use. Store the settings by going back to main
menu by pressing or using the key. When IED asks
confirmation to commit changes, answer “Yes“. Some changes
require the IED to reboot before the changes can be taken into
use. Reboot the IED by going to 
 or switching the auxiliary power
off and back on.
Changing the overcurrent start value
 select setting group,
default 1 and press 
Start value
Changing function block naming from IEC 61850 names
to IEC 60617 or ANSI

Checking binary input value


Checking fault records and the currents and voltages
of the latest faults

Changing the display contrast
Hold and press or to change the display contrast.
If you want to store the contrast go first in the menu and then
go back to the default view, so that A (Administrator) appears
to the right upper corner. If authentication is enabled you need
to login and then change the contrast.
Clearing events and indications
There are two ways to do this:
• Go to clear menu by pressing or selecting Clear from
the main menu. Then select what you want to clear and
press → press (Clear text will appear and Cancel will
disappear) and then press .
• Press hold for three seconds to clear indications and
immediately after that three seconds again to clear LEDs.
Checking IED order code, serial number, HW revision


Display header area
The icon area at the upper right corner of the dislay shows
the current action or user level. These are described below:
S= Parameters are being stored, != Warning and/or indication
V= Viewer, = Operator, E= Engineer, A= Administrator


From here you can check the input and output data of
a function block. More information about function block
operation can be found under Monitored data. Physical input/
output statuses, communication monitoring etc are also
available.
Changing the language

Or you can push and anywhere in the menu and language
will be changed. English is always the default language and
there can be maximum of two additional languages in the IED.




Restoring factory settings
Warning! All parameter settings will be overwritten with the
default values. During normal use, a sudden change of the
settings can cause a protection function to trip.

Using the local HMI
Complete customer documentation is available in the product
pages that can be accessed through abb.com/relion.

QUICK START GUIDE RELION® 615 SERIES 3
—

  ANSI
ARCSARC1 ARC (1) 50L/50NL (1)
CBXCBR1 I < → O CB I < → O CB
CCBRBRF1 3I>/Io>BF 51BF/51NBF
CCRDIF MCS 3I MCS 3I
DARREC1 O → I 79
DCSXSWI1 I < → O DC (1) I < → O DC (1)
DEFHPDEF1 Io>> → 67N-2
DEFLPDEF1 Io> → (1) 67N-1 (1)
DPHHPDOC1 3I>> → 67-2
DPHLPDOC1 3I> → (1) 67-1 (1)
DPHLPDOC1 Io>> (1) 51N-2 (1)
EFIPTOC1 Io>>> 50N/51N
EFLPTOC1 Io> (1) 51N-1 (1)
ESMGAPC1 ESTART ESTART
ESSXSWI1 I < → O ES I < → O ES
FRPFRQ1 f>/f<,df/dt (1) 81 (1)
HREFPDIF1 dIoHi> 87NH
INRPHAR1 3I2f> 68
INTRPTEF1 Io> → IEF 67NIEF
JAMPTOC1 Ist> 51LR
LNPLDF1 3dI>L 87L
LOFLPTUC1 3I< 37
LREFPNDF1 dIoLo> 87NL
LSHDPFRQ1 UFLS/R 81LSH
MPTTR1 3Ith>M 49M
NSPTOC1 I2> (1) 46 (1)
NSPTOV1 U2> (1) 47O- (1)
OLATCC1 COLTC 90V
PDNSPTOC1 I2/I1> 46PD
PHHPTOC1 3I>> (1) 51P-2 (1)
PHIPTOC1 3I>>> (1) 50P/51P (1)
PHLPTOC1 3I> (1) 51P-1 (1)
PHPTOV1 3U> (1) 59 (1)
PHPTUV1 3U< (1) 27 (1)
PREVPTOC1 I2>> 46R
PSPTUV1 U1< (1) 47U+ (1)
ROVPTOV1 Uo> (1) 59G (1)
SECRSYN SYNC 25
SEQRFUF1 FUSEF 60
SSCBR1 CBCM CBCM
STTPMSU1 Is2t n< 49, 66, 48, 51LR
T1PTTR1 3Ith>F 49F
TCSSCBR1 TCS (1) TCM (1)
TPOSSLTC1 TPOSM 84M
TR2PTDF1 3d I>T 87T
TRPPTRC1 Master Trip (1) 94/86 (1)
The most common function blocks are listed below, see the full list from the operators manual.
Available function blocks varies depending on the selected IED and standard configuration.
The last digit indicates the instance number of the block, only the first instance is listed below.

1MRS757435 REV B EN 02-2019
—
