abc FP4 User manual

FIREPLACE TV STAND
FP4

Part Identification
Hardware Identification
Assembly Steps
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Table of Contents Assembly Tools Required
3
4
5-24
FP4Page 2

Part Identification
◆While not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
Now you know
our ABCs.
A TOP (1)
B BOTTOM (1)
C LEFT END (1)
D RIGHT END (1)
E LEFT UPRIGHT (1)
F RIGHT UPRIGHT (1)
G BACK (2)
HSHELF (4)
J TOP MOLDING (1)
K LEFT MOLDING (1)
P BOTTOM MOLDING (2)
Q SHORT LEG (2)
R MIDDLE SHELF (1)
W FIREPLACE (1)
X TOP BRACKET (1)
Y END BRACKET (2)
L RIGHT MOLDING (1)
O END LEG (2)
R
Page 3
FP4

Hardware Identification
◆Screws are shown actual size. You may receive extra hardware with your unit.
CAM SCREW -8
1
APPLIQUE CARD- 2
4
HIDDEN CAM - 8
2
GLASS CLIP - 16
5
WOOD DOWEL- 10
3
1-3/16”HEX HEAD SCREW - 10
10 1/2" PAN HEAD SCREW - 8 1/2" FIAT HEAD SCREW - 16 11 12
5/8"FIAT HEAD SCREW - 8
13
CLIP - 8
6
LWRENCH - 1
71-5/8”HEX HEAD SCREW - 4
81-3/8” PAN HEAD
SCREW - 15
9
15
3/8" PAN HEAD SCREW-15
ZZ
FP4Page 4
METAL PIN - 4
14
522,68 22,68
22 kg 22 kg
(Refer to the last step for proper location and application)
WARNING LABEL - 1

HOW TO USE A HIDDEN CAM & CAM SCREW OR CAM DOWEL
NOTE: Various CAM SCREWS or a CAM DOWEL may be used.
Cam Screws Cam Dowel
Turn the CAM SCREW or
the surface of the part.
1.
Hidden Cam
Arrow
Push a HIDDEN CAM into
the part. The arrow in the
HIDDEN CAM must point
toward the hole in the
Hole
2.
3.
1
2
Insert the CAM SCREW or CAM DOWEL into the
Page 5
FP4

1
8 pcs
Step 1
◆Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
Turn eight CAM SCREWS (1) into the TOP (A).
◆
FP4Page 6

Arrow
◆Push eight HIDDEN CAMS (2) into the ENDS (C and D) and the UPRIGHTS (E and F).
Step 2
Page 7
FP4
Arrow
The arrow in the HIDDEN
CAM must point toward the
Hole
( 8 pcs )

9
Push the WOOD DOWELS (3) into the exact hole shown in
the UPRIGHTS (E and F).
Fasten the LEFT MOLDING (K) to the LEFT UPRIGHT (E).
Fasten the RIGHT MOLDING (L) to the RIGHT UPRIGHT (F).
Use four 1-3/8''mm Pan Head Screws.
NOTE: You should align each SCREW to the holes before completely
tightening any of them.
◆
◆
◆
◆
◆
Step 3
FP4Page 8
1-3/8" PAN HEAD SCREW
(4 used in this step)
WOOD DOWEL
(2 used in this step)

55
12 12
Step 4
◆Fasten sixteen GLASS CLIPS (5) to the ENDS (C and D) and
UPRIGHTS (E and F). Use sixteen 1/2'' FLAT HEAD SCREWS
Page 9
FP4
GLASS CLIPS
(16 used in this step)
1/2" FLAT HEAD SCREW
(16 used in this step)

Fasten the TOP MOLDING (J) to the TOP (A).
Use three 1-3/8''mm Pan Head Screws.
NOTE: You should align each SCREW to the holes before completely
tightening any of them.
Step 5
◆
◆
FP4Page 10
9
1-3/8" PAN HEAD SCREW
(3 used in this step)

Step 6
◆
◆
Push the WOOD DOWELS (3) into the exact hole shown in
the TOP (A).
Fasten the UPRIGHTS (E and F) and the ENDS (C and D) to the TOP (A).
Tighten eight HIDDEN CAMS.
Page 11
FP4
WOOD DOWEL
(4 used in this step)

Step 7
◆
◆
Slide the BACK (G) into the grooves of theLEFT UPRIGHT (E)
and LEFT END (C).
Slide the BACK (G) into the grooves of theRIGHT UPRIGHT (F)
and the RIGHT END (D).
FP4Page 12

Step 8
◆
◆
◆
Push the WOOD DOWELS (3) into the exact hole shown in
the UPRIGHTS (E and F) and the ENDS (C and D).
Fasten (B) to the ENDS (C and D), UPRIGHTS (E and F).
Use eight 1-3/8 " PAN HEAD SCREWS (9).
NOTE: You should align each SCREW to the holes before completely
tightening any of them.
Page 13
FP4
WOOD DOWEL
(4 used in this step)
9
1-3/8" PAN HEAD SCREW
(8 used in this step)

Step 9
◆Fasten the END LEGS (O) to the BOTTOM MOLDINGS (P). Use four 1-5/8''
HEX HEAD SCREWS (8) with the L-WRENCH.
FP4Page 14
87
1-5/8”HEX HEAD SCREW
(4 used in this step)
(LWRENCH - 1)

Step 10
◆Fasten the LEGS to the BOTTOM (B). Use ten HEX HEAD SCREWS (10)
with the L-WRENCH.
Page 15
FP4
87
1-3/16”HEX HEAD SCREW
(10 used in this step) (LWRENCH - 1)

Step 11
◆Fasten the SHORT LEGS (Q) to the BOTTOM (B). Use eight 1/2'' PAN HEAD SCREWS.
FP4Page 16
1/2" PAN HEAD SCREW
(8 used in this step)
11

Step 12
◆
◆
Push eight CLIPS (6) between the BACKS (G) and connecting BOTTOM(B),
ENDS (C and D), UPRIGHTS (E and F)and TOP(A).
Then, fasten the CLIPS (10) with eight 5/8" FLAT HEAD SCREWS (13).
Page 17
FP4
CLIP
(8 used in this step)
5/8"FIAT HEAD SCREW
(8 used in this step)
13

Step 13
◆
◆
Set the SHELVES (H) onto the GLASS CLIP (5).
Fasten the screw of Glass CLIP to fixed the SHELVES (H) in position.
FP4Page 18

Step 14
◆Please go to step 15 if you want to put the middle shelf (Z) as show in
diagram #1 or go to step 20 if you want to put the insert as show in diagram #2.
Page 19
FP4
Ｄiagram #1 Ｄiagram #2

Step 15
◆
◆
Insert the METAL PINS (14) into the hole locations of your
choice in the UPRIGHTS (E and F).
Set the ADJUSTABLE SHELF (R) onto the METAL PINS.
FP4Page 20
METAL PIN
(4 used in this step)
14 R
