ABLE Ap1310 DP-BTi User manual
The Experts in Small Printer Solutions
Ap1310 DP-BTi
Thermal Printer
Quick Start Guide
Able Systems Limited Denton Drive, Northwich, Cheshire CW9 7TU England
Tel: +44 (0) 1606 48621 Fax: +44 (0) 1606 44903 Web: www.able-systems.com
Setting up
Connecting the Power Supply
Plug the AC Power Supply into a suitable Mains Outlet Socket and Insert the
Jack Plug into the Power Connector at the Rear of the Printer. The LED will
light solid green to show that the Printer is powered on and idle.
What’s in the box?
1
●Ap1310-DP-BTi Printer x1
●Roll of 55mm Diameter Thermal Paper x2
●RS-232 Data Cable (D9 <–> RJ12) x1
●Universal Power Supply Adaptor with 4 region click-ins x1
(UK/Euro/USA/Aus)
●Wall/Belt Mounting Kit x1
●Quick Start Guide x1
Loading Paper
Slide the Lid Release Button forwards until the Lid springs open.
Unwind a small amount of paper from the roll and Insert the Paper Roll into the Printer.
Close the Lid down, and the paper is loaded.
Pressing the paper feed button when the printer is idle advances paper at typically 50mm per second, depending on
the battery voltage. However, the feed button has several additional functions:
A single press and release of the button:
●In idle or spooling mode, advances paper.
“Double-clicking”the button:
●
character set.
●In spooling mode, exits spooling mode and prints any stored data.
●
1
2
3
1
2
3
Accessories
●55mm Diameter Thermal Paper Roll (Approx. 34m long).
Product Code: A05856TPR1
●RS-232 D9 to RJ12 Data Cable.
Product Code: AP1300-D9
●Removable linerless label kit for Ap1310 models. 8 rolls /box;
approx. 24.4 metres per roll
Product Code: A05855RLRKIT
Using your Bluetooth printer
LEDpatternsindicatethefollowingmodes:
●ConstantGREEN: operating normally.
●
●RED:lowpowersupply,orotherproblem.
●
TheLEDpatternswillchangewhenconnectedtoanotherdevice viaBluetooth.
AllGREENwillbereplacedbyBLUE.
Whentheconnectionisdropped,theLEDpatterns willreturn tostandard.
Connecting to Mobile devices
To connect to your iPod, iPhone or iPad device, follow these steps:
Ensure the printer is awake
On your mobile device’s settings app, enable Bluetooth and
connect to the printer marked“Able Ap13x0-BTi”
When prompted, enter the PIN“1234”
Your mobile device will now be connected to
your mini-printer and ready to print.
1
2
3
4
Tech Spec
Product Colour Code
Bluetooth PrinterTM, Direct Power (55mm diam. roll) White Ap1310-DP-BTi
Print Mode: Thermal Line Dot Print (8 dots/mm)
Fujitsu Printer Mechanism
Interface Options: RS-232 (6 Way RJ12) Rx, Tx, Busy, Ground
Selectable baud rates and formats (Default: 9600,N,8,1)
Bluetooth: Full Bluetooth Support Bluetooth V2.1 (up to 10m range)
Power Supply: Universal PSA with Mains Input (UK/Euro/USA/Aus) - PSA1310V2
Input: 100 - 240V ~ 50/60Hz
Print Speed: 60 mm/s Typical
Thermal Paper: Paper Width = 58+0/-1mm
55mm Max Outer Diameter - 34m approx. length - (for Ap1310) - A05856TPR1
Printer Life: 108print pulses or 50kms of Paper (more than 13 million print lines)
Printer Dimensions: Ap1310DP
Height (mm) 65
Width (mm) 95
Depth (mm) 128
Weight (g) (including Paper Roll) 320
For a Full User Guide please visit ourWebsite: www.able-systems.com
To learn more about Able’s Print App, please visit www.able-systems.com/able-print-app.asp
Document Reference:V1.0
Able Systems Limited
Denton Drive, Northwich, Cheshire, CW9 7TU England
T: +44 (0) 1606 48621 F: +44 (0) 1606 44903
www.able-systems.com
operationofthisdeviceoritscompliancewithsafetyandregulatorystandards.Pleasenote that theuseofthisaccessorywithiPod, iPhone,
T H E P O W E R T O P R I N T
Made for:
iPad (4th generation), iPad mini, iPad (3rd generation), iPad 2, iPhone 5, iPhone 4S,
iPhone 4, iPhone 3GS, iPod touch (4th generation)
iPad®, iPhone® and iPod touch® are trademarks of
Apple Inc. registered in the U.S. and other countries.
Cer JA98/1259
Download the
FREE app here!
