Ablerex 800LS User manual

1
REPLACING THE BATTERY
Note：Once the battery is disconnected, the loads are not
protected from power outages.
1. Use an insulated philip screwdriver to remove the four screws
located
at the base of the UPS.
2. Remove the front panel and top cover.
3. Disconnect the battery cable terminals before removing the
battery from the UPS.
Step1: Loosen the black cable from the negative (-) terminal.
Step2: Loosen the red cable from thepositive (+) terminal.
4.
Connect the battery cables to the terminals of thenew battery.
Step1: Insert the black cable to the negative (-) terminal.
Step2: Insert the red cable to thepositive (+) terminal.
Note: Small sparks at the battery connectors are normal during connection.
5. Slide the battery into the UPS.
6. Close the front panel and fasten the four screws located at the base of the UPS.
7. Dispose off the old battery properly at an appropriate recycling facility.
USER’S MANUAL
800LS /1000LS
This manual contains important safety instructions. Please follow all instructions during installation. Read this manual thoroughly before unpacking,
installing or operating.
Caution: Risk of Electric Shock
•The UPS contains batteries. The output outlets may be electrically live even when the UPS is disconnected from theAC mains.
•The UPS contains potentially hazardous voltages. Do not open the units as there are no user serviceable parts. All maintenance and servicing
should be performed by qualified service personnel.
•Risk of electric shock, Battery Circuit is not isolated from AC input, hazardous voltage may exist between battery terminals and ground. Test
before servicing and use insulated tools.
NOTE:The UPS is designed to be for use with computer loads only.
Caution：Do not connect a laser printer to the UPS.
A laser printer draws significantly more power than other types of equipment and may overload the UPS.
SETUP
1 Inspection
Inspect the UPS upon receipt.
Notify the carrier and dealer if there
is damage. The package is
recyclable; save it for reuse or
dispose of it properly.
Inspect accessories:
①Power cable 1PCS
USER MANUAL 1PCS
2 Choose an installation location
- Avoid locations that are excessively humid, near water,
near heat sources or in direct sunlight
- Allow 1inch (2.5cm) clearance on each side of the UPS.
3 Connecting Equipment and Power to the UPS
4 ConnectModem/ Phone / Network for Surge Protection (Optional)
5 ConnectInterface Device
6 Turn ON/OFF the UPS
Turn on theUPS:Press the UPS
On/OFF Switchfor approx. 3
seconds, then the Buzzer sounds
twice, the UPS will start-up.
Turn off theUPS:Press the UPS
On/OFF Switchfor approx. 3
seconds, then the Buzzer
soundstwice, the UPS will
shutdown.
7
Cold Start Function
When the UPS is OFF and no utility input
power is present, use the “Cold Start” feature
to apply power to the loads from UPS‘s battery.
Press the “ON/OFF” switch untilthe UPS
beeps.
8
Software Download and Installation
Please follow steps below to download and install monitoring software:
1. Go to the website http://www.ablerex.com.sg/downloads.html
2. Depending on the computer OS, select Emily software (for Win 7&8 OS, select Emily2) and click download.
3. Follow the on-screen instructions to install the software.
4. When the computer restarts, the monitoring software automatically search and connects to the UPS.
FRONT PANEL EXPLANATIONS
REAR PANEL EXPLANATIONS
800LS/1000LS–LED FRONT
PANEL (STANDARD) Symbol LED
Color Description/function 800LS/1000LS REAR PANEL Symbol Description
N/A Turn-on/Turn-off
Switch 1 AC Input Outlet
Green
Lit: Line mode
Dim: Abnormal input
voltage and
frequency
2 Fuse
3 Output Connector:
4x Thailand Outlets
Yellow Lit: Battery mode
Flashing: Battery
Low
4 USB (Standard)
Red Lit: System
malfunction
or abnormal
Step1: Connect the UPS to the
AC mains.
Step2: Connect the equipment to
the UPS output outlets.
Step3: Switch on the AC Mains,
follow by the UPS then the
equipment last.
*Plug the UPS into the AC Mains
to charge for 8 hours before
using the UPS.
- For modem/phone line protection,
connect equipment to the RJ11
port using RJ11 cable.
- For surge protection, connect
equipment to the RJ45 port using
Ethernet/RJ45 cable.
The UPS is equipped with
two interface ports: a USB
port (Standard) and a 9-pin
RS232 port (Optional)
allowing advanced
communication network
between the UPS and a
computer (network).
1
2
3
4

2
TROUBLESHOOTING
Refer to the steps below should the UPS
fail to function correctly
Step 1: Is the AC Mains switch in the
“ON”position?
Step 2:Is the UPS plugged into the AC
power supply?
Step 3: Is the power supply within specified
unit values?
Step 4: Has the fuse gone in the mains
plug?
Step 5: Is the UPS overload?
Step 6: Is the battery flat or defective?
Situation Problem / Possible Causes Solution
No LEDs displayon the
frontpanel.
Battery voltage is low.
Charge the UPS at least 6 hours.
Battery is defective.
Replace the battery withthe same capacity.
The UPS is not turned on.
Press the power switchagain to turn on the UPS.
Alarm beeps
continuouslywhen the
Utilityis normal.
The UPS is overloaded. Remove some loads/equipment first.
The connected equipment
exceeds the
UPS specified ‘capacity/load”.
UPS does not provide
expected backup time.
The UPS is overloaded.
Remove some loads/equipment first.The connected equipment
exceeds the
UPS specified ‘capacity/load”.
Battery voltage is too low.
Charge the UPS at least6 hours.
Battery is defective.
Replace the battery withthe same capacity.
The Utility is normalbut
LED is flashing. Power cord is loose. Reconnect the power cordproperly.
Description Ablerex 800LS/1000LS SPECIFICATIONS
Model 800LS 1000LS
Capacity 800VA/400W 1000VA/600W
Input
Voltage 220/230/240VAC
Voltage Range 160~290Vac
Output
Voltage Regulation 220Vac+/- 10%
Transfer Time 2ms ~ 6ms Typical
Waveform Simulated Sine Wave
Battery
Type & Number 12V/7Ah x 1 12V/9Ah x 1
Charging time 4-6 hours recover to 90% capacity
Physical
Dimension (WxHxD, mm) 100 x 140 x 292
Net Weight (kg) 4.5 5
Packaging Dimension
(WxHxD,mm)
137 x 226 x 321
Gross Weight (kg) 5 5.5
Environment
Humidity 95% RH Maximum,Non-condensing
Noise level Less than 40 dB
Standards and Certifications
Safety Standard EN62040-2
EMC/Surge Standard EN61000-3-2, EN61000-3-3
Mark CE, RoHS, TISI
STEP1
STEP2
GR600/GR800
GR1200/GR1800/GR2000
STEP1
STEP2
192321982010000
