Abocom ISM560 User manual

Doc. No.: 110701-01
Internal
Fax Modem 56K
User’s Manual

FCC REGULATORY STATEMENTS
FCC Part 68 Registration
This device complies with FCC Part 68 rules, and the use of this
device is subject to the following restrictions:
1. The FCC has established rules which permit this device to be
directly connected to the telephone network. Standardized jacks
are used for these connections. This equipment should not be
used on party lines or coin phones.
2. If this device is malfunctioning, it may also be causing harm to
the telephone network; this device should be disconnected until
the source of the problem can be determined and until repair has
been made. If this is not done, the telephone company may
temporarily disconnect service.
3. The telephone company may make changes in it's facilities,
equipment, operation and procedures; if such changes affect the
compatibility or use of this device, the telephone company is
required to give adequate notice of the situation with the FCC.
4. If the telephone company requests information on what
equipment is connected to their lines, inform them of:
a. The telephone number to which this unit is connected.
b. The Ringer Equivalence Number (REN).
c. The USOC jack required.
d. The FCC Registration number.
Items (b) and (d) are indicated on the label. The Ringer
Equivalence Number (REN) is used to determine how many
devices can be connected to your telephone line. In most areas, the
sum of the REN's of all the devices on any one line should not
exceed 5.0. If too many devices are attached, they may not ring
properly.
FCC Part 15 Registration
This device complies with Part 15 of FCC rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interface, and
2. This device must accept any interface received including
interface that may cause undesired operation.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy,
and if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
 Reorient or relocate the receiving antenna.
 Increase the distance between the equipment and receiver
 Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
 Consult an experienced radio/TV technician for help.
CTR 21 pan-European Certification
This equipment has been approved in accordance with Council
Decision 98/482/EC for pan-European single terminal connection
to the public switched telephone network (PSTN). However, due to
differences between the individual PSTNs provided in different
countries, the approval does not, of itself, give an unconditional
assurance of successful operation on every PSTN network
termination point. In the event of problems, you should contact
your equipment supplier in the first instance.
This device is designed to work with the notified networks in all
EC member states. Nevertheless, some of the network services in
invidual countries might not be supported, but they will not affect
the normal data and fax applications. For example, the metering
charge service in Germany. Besides you may encounter difficulty
of using PULSE dialing function in some of the countries, such as
Nordic countries. This kind of network compatibility is dependent
on the physical and software settings of this device. If the users
are desired to use this device on those networks, they should
contact the vendor or supplier first.

Table of Contents
INTRODUCTION ...................................................1
SPECIFICATIONS .....................................................1
SYSTEM SUPPORT AND REQUIREMENTS..................2
HARDWARE INSTALLATION ...........................3
SOFTWARE INSTALLATION.............................4
WINDOWS 9X INSTALLATION.................................4
WINDOWS ME INSTALLATION................................6
WINDOWS NT INSTALLATION ..............................11
WINDOWS 2000 INSTALLATION ...........................12
WINDOWS XP INSTALLATION ..............................15
CHECKING COUNTRY/REGION ....................18
WINDOWS 9X/ME/2000.......................................18
WINDOWS NT4.0 .................................................18
WINDOWS 2000....................................................19
WINDOWS XP.......................................................19
UNINSTALL..........................................................20
APPLICATIONS...................................................21
INTERNET ACCESS ................................................21
TROUBLE SHOOTING.......................................23
APPENDIX A: AT COMMAND .........................28
APPENDIX B: S-REGISTERS ............................35

INTRODUCTION
The Internal FaxModem 56K is Bell, ITU-T
(formerly CCITT) compliant and Hayes AT
command compatible, so that it can be used
worldwide with today’s popular communication
software programs. You will be able to send and
receive faxes to/from any Group 3 compatible fax
machine. Using standard phone lines, the data
communication functions of the modem will allow
you to successfully hook up to the Internet, transmit
E-mail, send and receive information as well as
communicate with other PCs, Bulletin Board
Services (BBS) or computer networks such as
Compuserve.
Specifications
Data:
K56flex, V.90, V.92, V.34bis, V.34, V.32bis,
V.32, V.22bis, V.22, and V.21, Bell 212A and
Bell 103
Fax:
V.17, V.29, V.27ter, and V.21 channel 2
Group 3 send and receive facsimile
Error Correction:
V.42 and MNP 2-4
Data Compression:
V.42bis and MNP 5
Communication software compatible commands:
Hayes compatible enhanced "AT" command
set
Fax Service Class 1 commands
Built-in DTE interface:
DTE speed up to 115,200 bps
16C550 UART interface
- 1 -

- 2 -
System Support and Requirements
 Pentium 200 MHz with 32 Mbytes of RAM
 AMD K6 200 MHz with 32 Mbytes of RAM
 A telephone line with RJ-11 jack.
 A CD-ROM drive.
 Windows 9X/ME/NT/2000/XP pre-installed.

HARDWARE INSTALLATION
Precautions:
Please be sure you take adequate anti-static
precautions when handling this product. The
simplest way to achieve this is; touch a non-painted
surface of the computer’s chassis during the
hardware installation.
1. Make sure the computer is turned off before
installing the device.
2. Remove the expansion slot cover from the
computer.
3. Carefully slide the PCI modem card into an
available PCI slot, applying even pressure to the
card. Secure the card to the computer with the
screw. (PCI slots are 85mm long and positioned
40mm from the PC’s rear panel. Generally there
are several PCI slots side by side).
4. Plug one end of the telephone cable into the
Modem line jack and another end into the
telephone jack in wall.
5. Replace the cover.
6. You are now ready to continue the software
installation.
- 3 -

SOFTWARE INSTALLATION
Windows 9X Installation
1. Reboot the computer system after the modem is
well inserted into the PCI slot of your computer.
Windows 9X will automatically detect the device.
Click Next to continue.
2. Insert the device driver compact disc into your
CD-ROM drive when the following dialog box
appears. Click Next to continue.
- 4 -

- 5 -
3. Select Specify a location and press Browse to
choose the Dirver\Win98 folder in your CD-
ROM drive. Then click Next.
4. Click Next to continue.
5. When the following figure appears, click Finish
to complete software installation.

- 6 -
Windows ME Installation
1. Reboot the computer system after the modem is
well inserted into the PCI slot of your computer.
Windows ME will automatically detect the
hardware device and prompt the following
message. Select Specify the location of the
driver (Advanced) and click Next.

- 7 -
2. Insert the device driver compact disc you’re
your CD-ROM drive. Select Specify a
location and click browse to the location where
the driver is stored (Dirver\Winme). And then
click Next.
3. Click Next to continue.
4. Click Finish when the following screen
prompts. The installation program will
continue.

- 8 -
5. Repeat the step 1 as described above.
6. Follow the on-screen instruction to continue.

- 9 -
7. Click Next to continue.
8. Press Finish to complete the software
installation.

- 10 -
9. Go to StartSettingsControl Panel
SystemsDevice Manager. Click Modem
and WDM Modem Enumerator to expand. If
Agere System Soft Modem is listed as below,
the software installation will truly be completed.
If not, please consult your distributor for the
technical support.

- 11 -
Windows NT Installation
1. Reboot the computer system after the modem is
well inserted into your PCI slot of your computer.
2. Load the device driver compact disk in your CD-
ROM drive.
3. Start Windows NT.
4. Go to My Computer.
5. Click the CD-ROM drive. Click the
driver\Winnt4 folder. Or you may click the
Browse button to select the CD-ROM drive and
the driver\Winnt4 folder.
6. Double-click Setup.exe. The installation
program will proceed automatically.

- 12 -
Windows 2000 Installation
1. Reboot the computer system after the modem is
well inserted into the PCI slot of your computer.
Windows 2000 will automatically detect the
new hardware device and prompt the following
message. Click Next to continue
2. Select Search for a suitable driver for my
device (recommended) and click Next.
3. Select Specify a location and click Next.

- 13 -
4. Insert the device driver compact disc into your
CD-ROM drive. Click Browse to the location
where the driver is stored (\Driver\Win2000)
and click OK.
5. Click Next. Windows 2000 will start copying
necessary files onto your system.

- 14 -
6. Click Yes to continue.
7. Click Finish to complete the software
installation.

- 15 -
Windows XP Installation
1. Reboot the computer system after the modem is
well inserted into the PCI slot of your computer.
Windows XP will automatically detect the new
hardware device and prompt the following
message. Select Install from a list or specific
location and click Next.

- 16 -
2. Insert the device driver compact disc into your
CD-ROM drive. Select Include this location
in the search and click Browse to direct
Windows XP to the location where the driver
stored (\Driver\xp). Then click Next.
3. When the following window appears, click
Continue Anyway.
