Access Lighting 20368MG Installation instructions

(1) TOOLS AND MATERIALS REQUIRED
BLADE SCREW DRIVER
WIRE CUTTERS
WIRING SUPPLIES AS REQUIRED BY ELECTRICAL
CODE
Attention:
Before assembling your lighting fixture, please read the
following instructions. If you feel you do not have sufficient
electrical experience, refer to a do-it-yourself wiring handbook
or have your fixture installed by a qualified licensed electrician.
(2) GENERAL
1. To ensure the success of the installation, be sure to
read these instructions and review the diagrams
thoroughly before beginning.
2. All electrical connections must be in accordance with
local codes, ordinances, or the National Electrical
Code. If you are unfamiliar with methods of installing
electrical wiring, secure the services of a qualified
licensed electrician.
3. These fixtures are intended for mounting to a standard
4” x 2 ¼ ” deep metal octagon outlet box. The box must
be directly supported by the building structure and U.L
Recognized.
4. Before commencing with the installation, disconnect
the power by turning off the circuit breaker or
by removing the fuse at the fuse box. Turning the
power off using the light switch is not sufficient to
prevent electrical shock.
NOTE:
The important safeguards and instructions appearing in this
manual are not meant to cover all possible conditions and
situations that may occur. It must be understood that common
sense, caution and care, are factors that cannot be built into any
product. These factors must be supplied by the person(s) caring
for and operating the fixture.
(3) UNPACKING THE FIXTURE
On checking the contents of the box you will find;
Fixture Back Plate
Mounting Hardware
Fixture Canopy with socket attached
2 x Glass Shades
1 x Gasket
2 x 18W FT18D Lamp (2G11 Base)
(4) PREPARE THE FIXTURE
Refer to attached illustration of fixture parts and assembly.
1. If you are replacing an existing fixture disconnect and
remove the old fixture. Expose the supply wiring from the
outlet box.
2. Secure the Fixture Back Plate to the junction box with the
supplied Mounting Screws (1).
3. Ensure that the supplied Large Square Gasket is securely
fitted onto the Fixture Canopy with socket attached.
4. Pull the Supply wires through the Center Hole in the Back
Plate.
5. Connect the Black Supply Wire to the Black Wire of the
fixture with supplied Wire Nuts (2) ensuring a secure
connection.
6. Connect the White Supply Wire to the White Wire from
the fixture and secure with supplied Wire Nuts (2).
7. Attach the ground (GREEN) wire from the fixture to the
outlet box ground terminal (or to the box ground wire).
8. Secure all wire nuts connections with UL listed electrical
tape. Tuck wires carefully into Junction box.
9. Position the Fixture Canopy with Socket attached, such
that the 4 Screws protruding from the Fixture Back Plate
align with the four designated holes in the Fixture
Canopy. Place the supplied Mini Circular Gaskets onto
each screw and then secure with the supplied Knobs (3)
10. Insert the specified bulbs- 2 x 18w FT18DL (4). At the
top of the fixture and one below.
DO NOT EXCEED WATTAGE SPECIFIED ON WARNING
LABEL
11. Fit the Glass Diffusers (5) over the bulbs Secure by
screwing into the threaded metal portion of the fixture
housing the socket
12. NOTE: Outdoor wall fixtures must be caulked
with suitable PTV or silicone compound around
the top and sides of the cover plate to reduce
the chance of water entering into the splicing
area.
13. Restore electricity and check the operation of your new
lighting fixture.
CAUTION:
Ensure that the Fitting is Cool and Switched off,
Before Changing the Bulb.
Do Not use Bulbs Exceeding Maximum Wattage, As
Per Caution Label.
Do not operate your fixture on or near any
combustible material.
***READ & SAVE THESE INSTRUCTIONS ***
ACCESS LIGHTING
MODEL 20368MG
INSTALLATION & OPERATION INSTRUCTIONS

GND
Gasket
Glass shade
Bulb
Secure the fixture
plate with knobs
Wire nuts
Mounting screws
Gasket
MODEL 20368MG
