Access Lighting SILO 20060LEDDMG User manual

WHAT YOU NEED
• Screwdriver
• Wire Cutters
• Wiring Supplies as Specified
by Electrical Code
INSTALLATION INSTRUCTIONS
WHAT WE PROVIDE
• Mounting Hardware
• Crossbar plate
• 1 X Glass shade
• LED
COLLECTION
1
CERTIFICATION: cETLus WET NO. 20060LEDDMG
SILO 20060LEDDMG
APPLICATION MODEL NO.
Wall Fixture
IMPORTANT SAFETY INSTRUCTIONS
MESURES DE SECURITE A RESPECTURE
Before assembling your ACCESS LIGHTING fixture, please make sure that
you carefully read through this instruction sheet. Save this instruction sheet
and refer to it when additions to or changes in the fixture
configuration are made.
Lisez attentivement ce manuel d’instructions. Enregistrer cette feuille
d'instructions et de s'y référer lorsque les ajouts ou changements dans
la configuration de montage sont faites.
CONSULT A QUALIFIED ELECTRICIAN TO ENSURE CORRECT BRANCH
CIRCUIT CONDUCTOR.
CONSULTER UN ELECTRICIEN QUALIFIE POUR VOUS ASSURER QUE LES
CONDUCTEURS DE LA DERIVATION SONT ADEQUATS
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE
INSTALLATION CODE BY A PERSON FAMILIAR WITH THE CONSTRUCTION
AND OPERATION OF THE PRODUCT AND THE HAZARDS INVOLVED.
CE PRODUIT DOIT ETRE INSTALLE SELON LE CODE D’INSTALLATION PERTINENT,
PAR UNE PERSONNE QUI CONNAIT BIEN LE PRODUIT ET SON FONCTIONNEMENT
AINSI QUE LES RISQUES INHERENTS
NOTE: The important safeguards and instructions that appear in this
manual are not meant to cover all possible conditions and situations
that may occur. It must be understood that common sense, caution and
care, are factors that can’t be built into any product. These factors must
be supplied by the person(s) caring for and operating the fixture.
Read all instructions
Do not install this fixture in hazardous locations.
N'installez pas cet appareil dans des emplacements dangereux.
Do not install any fixture assembly closer than 6 inches from any
curtain or similar combustible material.
Laisser une distance d’au moins 6 pouces entre ce luminaire et la toute
surface combustible.
"WARNING Risk of Fire and Electric Shock."
“CAUTION: Risque d’ Incendie et de Choc Electriques.”
GENERAL INFORMATION
All electrical connections must be in accordance with all ordinances,
Local and the U.S. National Electrical Codes (NEC). These fixtures are
intended for mounting to a standard 4” metal octagon outlet box.
The box must be directly supported by the building structure and U.L.
Recognized.
STEP BY STEP INSTRUCTIONS
Before starting your installation disconnect the Power by turning off the
Circuit Breaker or by removing the fuse at the fuse box. Just turning the
light off at the light switch is not sufficient to prevent electrical shock.
Recommended Dimmers
Lutron Maestro MACL-153MH
Lutron Maestro MAELV-600-WH
Leviton SureSlide NO.6672

MOUNT CROSSBAR AND WIRE CONNECTIONS
If there is an existing fixture remove it. Expose the supply wires
from the J-box.
Mount the crossbar to the J-box with the
supplied screws. Connect the black supply wire to the black
fixture wire. Secure with the supplied wire nuts. Connect the
white supply wire to the white fixture wire. Secure with the
supplied wire nuts. Attach the green J-Box wire around
green hexagonal head screw or connect it to the green
supply grounding wire of the fixture.
Secure all wire with electrical tape (not supplied).
Tuck all wires carefully into the J-Box.
1
WHAT YOU NEED
• Screwdriver
• Wire Cutters
• Wiring Supplies as Specified
by Electrical Code
2
4
2
CERTIFICATION: cETLus WET NO. 20060LEDDMG
3
MOUNT FIXTURE TO CROSSBAR
Position the fixture over the crossbar.
Align the holes in the center of the
fixture and secure with the supplied screws.
SECURE THE GLASS SHADE
Place the glass shade up to the fixture, rotate the
glass shade so that the glass is secure to the fixture.
**This fixture is wet location rated. In order to ensure
that moisture does not enter the outlet box and cause
a short circuit, clear caulking should be used to seal the
space between the fixture mounting bracket and the
wall. Ensure that a space is left at the bottom to allow
for the escape of moisture. It is recommended that
Outdoor Silicon Sealant is used for that purpose**
RESTORE THE ELECTRICITY AND
CHECK THE OPERATION OF YOUR
NEW ACCESS LIGHTING FIXTURE
If the fixture is to be removed or replaced,
please ensure that the electricity is
switched off and that the fitting is cool
before touching it.
CAUTION
VER: 18.12.1
