(1) TOOLS AND MATERIALS REQUIRED
BLADE & PHILIPS SCREW DRIVER
ADJUSTABLE WRENCH
STEP LADDER
WIRE CUTTERS
WIRING SUPPLIES AS REQUIRED BY ELECTRICAL
CODE
Attention:
Before assembling your lighting fixture, please read the
following instructions. If you feel you do not have sufficient
electrical experience, refer to a do-it-yourself wiring handbook
or have your fixture installed by a qualified licensed electrician.
(2) GENERAL
1. To ensure the success of the installation, be sure to
read these instructions and review the diagrams
thoroughly before beginning.
2. All electrical connections must be in accordance with
local codes, ordinances, or the National Electrical
Code. If you are unfamiliar with methods of installing
electrical wiring, secure the services of a qualified
licensed electrician.
3. These fixtures are intended for mounting to a standard
4” x 2 ¼ ” deep metal octagon outlet box. The box
must be directly supported by the building structure.
For mounting to a PVC or Plastic Box do not use
supplied crossbar or attach directly to the junction
box. The recessed holes located on the outer sides
of the fixture should be utilized for mounting the
fixture directly to the ceiling, utilizing the correct
screws and anchors (not supplied).
4. Before commencing with the installation, disconnect
the power by turning off the circuit breaker or
by removing the fuse at the fuse box. Turning the
power off using the light switch is not sufficient to
prevent electrical shock.
NOTE:
The important safeguards and instructions appearing in this
manual are not meant to cover all possible conditions and
situations that may occur. It must be understood that common
sense, caution and care, are factors that cannot be built into any
product. These factors must be supplied by the person(s) caring
for and operating the fixture.
(3) UNPACKING THE FIXTURE
On checking the contents of the box you will find;
Mounting Hardware
Fixture Assembly
Glass Diffuser
1 x 150W/HGN/120V/J78mm Bulb
(4) PREPARE THE FIXTURE
Refer to figure I for illustration of fixture parts and assembly.
1. If you are replacing an existing fixture, disconnect and
remove the old fixture. Expose the supply wiring from the
outlet box.
2 Attach the supplied crossbar (1) and fasten to the
junction box with supplied screws (2). Please note do
not attach this fixture directly to a PVC or Plastic
Junction box see point 3 of General section
3 Attach the ground wire from the fixture to the outlet box
ground terminal (or to the box ground wire). Connect the
fixture wires to the appropriate electrical supply wires
from the outlet box: Black fixture wire to black power wire,
and white fixture wire to white power wire. Use the
supplied wire connectors (3). Secure wire connectors
with UL listed electrical tape. Tuck wires carefully into
outlet box.
4 Mount the fixture plate to the crossbar (1), using the
supplied nut and washer set (4).
5 Insert the Halogen bulb into the socket (5). Do Not
Touch the Halogen Bulb with Bare Hands Use a Soft
Dry Cloth. DO NOT EXCEED RECOMMENDED
WATTAGE of 150W.
6 Fit the supplied tempered glass shade (6) onto the
socket rim and secure in place.
7 Position the body of fixture under the fixture plate such
that the screws in the body of the fixture can be inserted
into the designated holes in the fixture plate. Secure by
tightening the supplied brass nuts (7).
8 Restore electricity and check the operation of your new
lighting fixture.
CAUTION:
Ensure that the Fitting is Cool and Switched off,
Before Changing the Bulb.
Do Not use Bulbs Exceeding Maximum Wattage, As
Per Caution Label.
Do not Handle the Bulbs with Bare hands. Use a soft
Cloth.
Do not place fixture on or near combustible material.
***READ & SAVE THESE INSTRUCTIONS ***
ACCESS LIGHTING
MODEL 50480
INSTALLATION & OPERATION INSTRUCTIONS
