(1) TOOLS AND MATERIALS REQUIRED
BLADE SCREW DRIVER
WIRE CUTTERS
WIRING SUPPLIES AS REQUIRED BY ELECTRICAL
CODE
Attention:
Before assembling your lighting fixture, please read the
following instructions. If you feel you do not have sufficient
electrical experience, refer to a do-it-yourself wiring handbook
or have your fixture installed by a qualified licensed electrician.
(2) GENERAL
1. To ensure the success of the installation, be sure to
read these instructions and review the diagrams
thoroughly before beginning.
2. All electrical connections must be in accordance with
local codes, ordinances, or the National Electrical
Code. If you are unfamiliar with methods of installing
electrical wiring, secure the services of a qualified
licensed electrician.
3. These fixtures are intended for mounting to a standard
4” x 2 ¼ ” deep metal octagon outlet box. The box must
be directly supported by the building structure and U.L
Recognized.
4. Before commencing with the installation, disconnect
the power by turning off the circuit breaker or
by removing the fuse at the fuse box. Turning the
power off using the light switch is not sufficient to
prevent electrical shock.
NOTE:
The important safeguards and instructions appearing in this
manual are not meant to cover all possible conditions and
situations that may occur. It must be understood that common
sense, caution and care, are factors that cannot be built into any
product. These factors must be supplied by the person(s) caring
for and operating the fixture.
(3) UNPACKING THE FIXTURE
On checking the contents of the box you will find;
Mounting Hardware
Universal Crossbar
Fixture Back Plate with Socket Assembly
1 x Front Glass Diffuser
1 x Top Glass Diffuser
1 x Bottom Glass
2 x Glass Holders
1 x Bulb Cover
1 x 100W HGN J118 (T-3 Base)
(4) PREPARE THE FIXTURE
Refer to attached illustration of fixture parts and assembly.
1. If you are replacing an existing fixture disconnect and
remove the old fixture. Expose the supply wiring from the
outlet box.
2. Place the Supply wires through the center hole in the
Universal Crossbar. Secure the Universal Crossbar to
the junction box with the supplied Mounting Screws (1),
ensuring that the screws already inserted in the Universal
Crossbar face outward from your mounting surface.
3. Connect the BLACK supply wire to the Black wire of the
fixture with supplied Wire Nuts (2) ensuring a secure
connection.
4. Connect the WHITE supply wire to the White wire from
the fixture a secure with supplied Wire Nuts (2).
5. Attach the ground (GREEN) wire from the fixture to the
outlet box ground terminal (or to the box ground wire).
6. Secure all wire nuts connections with UL listed
electrical tape. Tuck wires carefully into Junction box.
7. Secure the Fixture Back Plate to the Universal
Crossbar by fitting the Two Screws protruding from the
Universal Crossbar fit into the designated holes in the
Fixture Back Plate. Secure with the supplied Nuts (3)
Insert the 1 x 100W/HGN/J118 bulb (5).
DO NOT EXCEED WATTAGE SPECIFIED ON WARNING LABEL.
8. Fit the supplied Bulb Cover (6) over the bulb (5).
9. Attach the Bottom End Glass to the fixture by
aligning the hole in the Bottom End Glass with the
hole in the Bottom Bracket. Secure with the supplied
Screw (4).
10. Fit the Front Glass Diffuser (7) into the groove of the
Bottom Glass Holder.
11. Slide the top of the Front Glass Diffuser (7) into the
groove of the Top Glass Holder, while
simultaneously sliding the Top Glass Holder onto the
top bracket screw. Secure with the supplied Brass
Nut (9).
12. Restore electricity and check the operation of your new
lighting fixture.
CAUTION:
Ensure that the Fitting is Cool and Switched off,
Before Changing the Bulb.
Do Not use Bulbs Exceeding Maximum Wattage, As
Per Caution Label.
Do not place fixture on or near combustible material.
***READ & SAVE THESE INSTRUCTIONS ***
