AccuBANKER LED440 User manual

LED440
IRSPY LED IR Detector
USER GUIDE www.AccuBANKER.com

Thank you for trusting AccuBANKER with your cash
handling needs. In order to optimize the performance
of your equipment, we encourage you to thoroughly
read this user guide prior to use.
®

3
Table of Contents
Table of Contents .............................................................................................3
Important Safety Instructions ...........................................................................4
1. Before Starting .............................................................................................5
Introduction ..................................................................................................5
2. Parts Description ..........................................................................................6
3. Operation Description ..................................................................................7
3.1 Ultraviolet Verification Operation..........................................................8
3.2 Infrared Verification ...............................................................................9
3.3 Watermark Verification Operation.......................................................11
3.4 Magnetic Verification Operation..........................................................11
3.5 Size Analysis ........................................................................................12
4. Specifications .............................................................................................13

4
Important Safety Instructions
•This device has been designed to operate with this specific Power
Supply (AC / DC Adapter which is included). Failing to do so may
cause malfunction and may void the warranty.
•Avoid looking directly at the super-bright Ultraviolet LEDs hidden
inside the unit.
•Avoid operating the unit close to a strong natural/artificial light
source. The effect of the UV light will be overpowered, and it will
affect the UV feature’s fluorescence.
•Unplug this product from the power outlet and refer servicing to
qualified service personnel under the following conditions:
1. When the power supply cord or power adapter is damaged.
2. If liquid has been spilled into the unit.
3. If the unit does not function properly by following the normal
operating procedures.
4. If the product has been dropped or the case has been damaged.
5. If the product shows a noticeable change in performance.

5
1. Before Starting
Introduction
Accurate and convenient to use, the LED440 detectors allow the user to
inspect either money, Credit Cards, IDs, or any security document and verify
and confirm its authenticity.
This User Guide will allow you to get familiar with all the details related to
the unit’s operation. We recommend reading this guide thoroughly before
operating the unit and keep it for future references.

6
2. Parts Description
1- Power On / Off indicator
2
-3.5” LCD display
3
-IR /UV / WM Selector Buttons
(Infrared / Ultraviolet / Watermark)
4
-Verification Window / Watermark Screen
5
-Magnetic Head
6- Function Activator
Sensor
7
-Security Thread
Identification Label
8
-Power Switch
9
-Power Adapter Jack
10
-Power Adapter
(12VDC)
8
9
10
1
2
3
4
5
6
7

7
3. Operation Description
To use the unit appropriately and efficiently, we recommend the user to
become familiar with the security features of the bills, or documents they
want to analyze. Additionally, the user should compare any dubious banknote
against a genuine one, to better determine its authenticity.
This is a DC-powered device and includes a power adapter for this purpose.
Proceed to connect the power adapter to the power outlet on the wall and the
DC plug into the device power adapter jack, then proceed to turn the device
ON using the power switch located at the back of the device.

8
3. Operation Description (continued)
3.1 Ultraviolet Verification Operation
Place the bill or document to be analyzed in the WM verification window.
The UV LED light should be activated with the bill or document while
placing it in the inspection area. In case the bill or document does not activate
the UV light, touch the UV control button to turn the UV LEDs ON
manually. The detector has an internal timer to keep the UV LEDs on for 50
seconds before turning them off. If more time is needed to finish the
verification, you can press the UV button.
The UV security features embedded in U.S. dollar bills, foreign currencies,
credit cards, IDs, and other special documents will fluoresce under the UV
light. This will allow the user to visualize them and confirm their
authenticity.
NOTE: The detector includes a “Security Thread Identification” label that
shows the operator the COLOR and POSITION of the security thread
embedded on the U.S. dollar bills for every specific denomination. Using it as
a reference will help the operator validate them since the COLOR and
POSITION must match.
The verification
window has printed
“AccuBANKER” that
glows under the UV
light to be used as a
comparison reference
during the analysis of
bills, credit cards, or
any other security
document.

9
3. Operation Description (continued)
3.2 Infrared Verification
The LED440 allows the user to verify the Infrared (IR) pattern hidden on
bills or documents which can be visualized only using an IR camera. The
screen will show the image of the bill seen with the “photosensitive ink”
effect, allowing the user to identify easily if the bill is genuine or fake.
The “Dual Band” technology is used to analyze the bill deeper using two
different IR wavelengths for its “photosensitive ink” analysis.
Press “IR” (1st time): Single-band (A) analysis (940nm wavelength).
Press “IR” (2nd time): Single-band (B) analysis (850nm wavelength).
Press “IR” (3rd time): Dual-band (A & B) analysis, the image switches
automatically.
Place the bill or document to analyze on the WM verification window then
press the “IR” button to activate the IR camera. The Infrared image will be
shown on the screen allowing the user to verify its IR pattern. The camera
will be turned OFF automatically after 30 sec.
NOTE: To make an accurate judgment of the bill, the user must be familiar
with the Infrared pattern of the bill that is being analyzed. The next page
shows some IR pattern image examples for the USD and CAD bills to be
used as a reference.

10
3. Operation Description (continued)
Infrared Images References (USD & CAD)

11
3. Operation Description (continued)
3.3 Watermark Verification Operation
Press the WM function button to turn the WM screen ON. The entire
inspection area will be illuminated to make the bill’s analysis procedure
easier and faster. Proceed to verify the watermark features embedded in the
bill or document and confirm their authenticity. The absence, displacement,
or low quality of this feature will indicate the bill is not genuine.
The internal timer will keep the WM ON for about 50 seconds. If more time
is needed to finish the verification, you can press the WM button.
3.4 Magnetic Verification Operation
Once the detector is turned ON, the magnetic circuitry is already active and
remains so while the unit is ON.
Proceed to rub the area of the bill that must contain magnetic ink against the
magnetic head. If the verification window flashes GREEN and BEEPS at the
same time, it confirms the Magnetic ink feature is present on the area just
verified. In case none of these signs are present, it means there is not MG ink
in the scanned area.

12
3. Operation Description (continued)
3.5 Size Analysis
The detector has a millimetric scale printed on the verification window. This
allows the user to verify any specific bill or document size and validate the
right position of any security feature inside the bill or document. Any
displacement encountered on any security feature could be a suspicious sign,
and other features must be verified to confirm the bill or document
authenticity.
NOTE: Avoid operating the unit close to a strong natural/artificial light
source. The effect of the UV and Watermark light will be overpowered, and it
will affect the good visualization and analysis of the security features
embedded on the bill or document.

13
4. Specifications
Power Source: External Power Adapter Vin: 100 - 240 VAC, 60/50Hz 0.6A
Vout: 12VDC / 1.0 A
Power Consumption: 5 W (Max.)
UV Light Source: Super-Bright UV LEDs
WM Light Source: Super-Bright White LEDs array
Dimensions: 8.55" x 5.67" x 5.98" (21.72 x 14.40 x 15.19 cms)
Net Weight: 1.35 lb (0.61 Kg)
Ambient Temperature: 32 - 104 °F (0 - 40 °C)

AccuBANKER USA
7104 NW 50th St
Miami, FL 33166
9AM- 5PM ET Monday through Friday
www.AccuBANKER.com
Please give us a call at 1-888-993-2228
®
