Instruction Manual
Shay West Side Lumber #15

Instruction Manual Shay WSL #15 Instruction Manual Shay WSL #15
NOTES:
110
General information about your Accucraft Model:
This accurately detailed model is constructed of brass and stainless steel.
A large Pittman gearhead motor powers all drivers through a metal gear
box with steel gears. The museum quality finish and lettering represents
this locomotive as it would have looked in the 1950’s.
The Shay locomotives were developed by Ephraim Shay. His first
successful engine that we could recognize today as a Shay locomotive
was produced in 1880 by Lima Machine Work (later Lima Locomotive
Works), who would go on to produce approximately 2, 700 Shays up until
1945, when production ceased.
Shay locomotives are unusual in that they are powered by a steam engine
of either two or three cylinders mounted vertically near the cab on the right
side of the locomotive. The boiler was offset on the frame to counterbalance
the weight of the engine. The engine drove a drive shaft that, through
flexible couplings, turned bevel gears that engaged the wheels. This type
of engine is known as a geared engine; since the wheels turn at a different
rate from the engine, due to the gear ratio. This arrangement made the
engine very flexible and able to negotiate raggedy track without derailing.
Because of this characteristic, as well as its great power, it was an exceeding
popular engine with logging companies and other industries that relied on
tough engines in unforgiving environments.

Instruction Manual Shay WSL #15 Instruction Manual Shay WSL #15
9
NOTES:
The locomotive has carbon brush pickups for both rails, to insure reliable
operation when using track power.
Disassembly of this large and complex model is not recommended.
However, if absolutely necessary, the 1.6mm hex bolts and nuts can be
turned with a nut driver sized for US 00-90.
Please take care in lifting this large and heavy model. It is recommended
that the locomotive be picked up by grasping it under the frame on both
ends.
Technical Specifications
Scale 1:20.3
Gauge 45mm Gauge
Total Weight 9.25 lbs.
Length 16in.
Width 4.75 in.
Height 7in.
Minimum Radius 1.2 M, 48 in.
Power 0-24V, Pittman Gearhead Motor
Features Constant Lighting
* Be sure to leave at least a 3” clearance (measured from the inner rail) on
the 46 1/4” radius curve to allow for overhang.
The following parts are packaged separately
- M2 hex head screws
- 2mm hex head screw driver

Instruction Manual Shay WSL #15 Instruction Manual Shay WSL #15
3 8
Caution!
This model is an accurate replica of the original locomotive. It has
sharp and moving parts. The locomotive drive rods are stainless steel
with sharp edges.
OPERATORS MUST NOT COME IN CONTACT WITH A MODEL THAT
IS BEING POWERED AT ANY TIME. UNDER NO CIRCUMSTANCES
SHALL ACCUCRAFT TRAINS BE RESPONSIBLE FOR ANY
INCIDENTAL OR CONSEQUENTIAL DAMAGES ARSING IN
REGARD TO ANY ACCUCRAFT PRODUCT.
Model Features
This limited production model has been handcrafted for Accucraft Trains
by AMMC, one of the most respected makers of large scale brass models.
This museum quality model features:
- Full cab interior details.
- Detailed boiler with fittings, domes, pipes, and handrails
- Operating steel drive rods, valve gear and cross heads
- Prtotypical livery and lettering
- Steel helical gears in a die-cast transfer box
NOTES:

Instruction Manual Shay WSL #15 Instruction Manual Shay WSL #15
4
Maintenance
Tools you will need for maintenance
- 1.5 mm allen wrench
- 1.6 mm and 2 mm hex wrenches
- Flat head screw driver
Lubrication
Please lubricate your Accucraft Shay before attempting to operate.
With a bit of care, your Accucraft Shay should give you many years of
pleasure and reliable service. Lubrication is of prime importance on a model
of this type with so many moving parts. Always use quality lubricants. This
should not be a problem, as there are many modern lubricants available in
hobby and sport shops.
Light oil such as Labelle #108 or Hoppe’s Gun Oil will do a good job on
lubricating most of the moving parts.
For pistons and slides, a heavier lubricant such as Labelle #102
would suffice.
For gears use gear grease such as Permatex Super Lube or another
hobby gear lubricant.
To access the many moving parts of this model it is best to carefully place
it on its side on a soft towel or foam sheet. A drop of light oil on every
moving part is necessary, and there are many on this locomotive. Be sure
to lubricate all the crosshead
7
2. Lift the metal case from the cardboard box.
3. The locomotive is firmly taped to a ½” wood board which is then
fastened to the metal case with 4 M6 bolts. The bolts must be removed
before lifting the locomotive with wood board from the metal case.
4. Place taped locomotive on a level flat surface. Carefully cut the
tape along the wood board side surface. Be sure to cut both sides of the
wood board. Slowly lift the tape from the locomotive.
Be very careful with small parts. The tape cannot be re-used to re-pack the
model. Use new packing tape if necessary.

Instruction Manual Shay WSL #15 Instruction Manual Shay WSL #15
5
Unpacking Accucraft Locomotive
Accucraft locomotives are fine scale brass models with small parts. To
provide maximum protection from shipping damage, we carefully pack the
models in metal cases.
We ship via UPS with insurance coverage to its full value. Please contact
UPS if package is damaged.
Each locomotive is packed under UPS guidelines for shipping. We do not
warrant any damage resulted from re-packaging by any party other than
Accucraft Trains.
Please read the following directions before unpacking your locomotive.
1. Remove foam around the locomotive. Slide the inner box cover to
the side, and carefully open the inside cardboard box with a cutting knife.
slides, piston rods, etc. that are visible to you. Do not over lubricate, for
excess oil only picks up unwanted dirt. Be careful to keep the lubricant off
the painted surfaces as this will leave a shiny appearance on the area it
touches.
The main gear box is lubricated in the factory, and will not need any
attention when you first run your model. However, in time, you should
make sure that the gears are well lubricated with a technical gear grease.
The gear box cover is held on with screws, and removing it will allow you to
access all the gears and bushings that need lubrication. Take note of how
the cover came off and replace it exactly the way it was when you started.
Lubrication should be done every 25 hours of operation.
Operation
After following the recommended lubrication procedures your locomotive is
ready to provide many years of reliable operation.
We recommend that you use a D.C power supply with a capacity of 2.5
amps or larger.
Always pick your model up by grasping it under the frame on both ends. It
is a very heavy model so make sure that you grasp it firmly.
Electrical Pickup
Your Accucraft model is powered by the DC voltage off the track. All wheels
are insulated on both sides of the locomotive,
and the electricity is picked up with 8 pickup wheels. Be sure to clean
electrical pickup units before each operation.
Replacement electrical pickup units can be ordered from Accucraft Trains.
General maintenance
Clean the exterior surfaces of your locomotive with a clean, soft, lint free
